1
Introducing the Motherboard
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the G33T-M2 motherboard. This motherboard is a high perfor-
mance, enhanced function motherboard designed to support the LGA775 socket for Intel®
Wolfdale/ CoreTM2 Duo processors for high-end business or personal desktop markets.
The motherboard incorporates the G33 Northbridge (NB) and ICH9 Base Southbridge (SB)
chipsets. The Northbridge supports a Front Side Bus (FSB) frequency of 1333/1066/800
MHz using a scalable FSB Vcc_CPU. The memory controller supports DDR2 memory
DIMM frequencies of 800/667. It supports four DDR2 Sockets with up to maximum
memory of 8 GB. DDR2 memory bandwidth of 12.8 GB/s in dual-channel symmetric mode
assuming DDRII 800. High resolution graphics via one PCI Express slot, intended for
Graphics Interface, is fully compliant to the PCI Express Base Specification revision 1.1.
The ICH9 Base Southbridge supports two PCI slots which are PCI 2.3 compliant. It imple-
ments an EHCI compliant interface that provides 480 Mb/s bandwidth for twelve USB 2.0
ports. The Southbridge integrates a Serial ATA host controller, supporting four SATA ports
with maximum transfer rate up to 3.0 Gb/s each.
The motherboard is equipped with advanced full set of I/O ports in the rear panel, including
PS/2 mouse and keyboard connectors, one serial port (optional), one parallel port (op-
tional), one VGA port, four USB ports, one LAN port (optional), one 1394A port (op-
tional) and audio jacks for microphone, line-in and 8-ch line out.

2
Introducing the Motherboard
Feature
• Accommodates Intel®Wolfdale/ CoreTM2 Duo processors
• Supports a system bus (FSB) of 1333/1066/800 MHz
• Supports “Hyper-Threading” technology CPU
The motherboard uses a LGA775 type of Intel®Wolfdale/CoreTM2 Duo that carries the
following features:
Processor
The G33 Northbridge (NB) and ICH9 Base Southbridge (SB) chipsets are based on an
innovative and scalable architecture with proven reliability and performance.
G33 (NB) • Supports 36-bit host bus addressing, allowing the CPU to
access the entire 64 GB of the memory address space.
• 2 GB/s point-to-point Direct Media Interface (DMI) to ICH9 (1
GB/s) each direction
• One, 16-lane PCI Express x16 for Graphics Attach, compli-
ant to the PCI Express Base Specification revision 1.1
• Supports 512 Mb and 1Gb DDR2 or DDR3 technologies for
x8 and x16 devices
“Hyper-Threading” technology enables the operating system into thinking it’s hooked
up to two processors, allowing two threads to be run in parallel, both on separate
“logical” processors within the same physical processor.
Chipset
ICH9 Base (SB) • Enhanced DMA Controller, interrupt controller, and timer func-
tions
• Compliant with PCI Express Base Specification, revision
1.1
• Compliant with PCI 2.3 specificaiton
• Compliant with SATA 3.0 Gb/s Host Controller
• Integrated USB 2.0 Host Controller supporting up to twelve
USB 2.0 ports
• Integrated Gigabit LAN Controller
• Supports DDR2 800/667 DDR SDRAM with Dual-channel architecture
• Accommodates four unbuffered DIMMs
• Up to 2 GB per DIMM with maximum memory size up to 8 GB
Memory
Audio
• 7.1 + 2 Channel High Definition Audio Codec
• All DACs support 44.1k/48k/96k/192kHz sample rate
• Software selectable 2.5V/3.75V VREFOUT
• Meets Microsoft WHQL/WLP 3.0 audio requirements
• Direct Sound 3DTM compatible

3
Introducing the Motherboard
Onboard LAN (Optional)
• Integrated Gigabit Ethernet Controller for PCI ExpressTM Applications
• Integrated 10/100/1000 transceiver
• Wake-on-LAN and remote wake-up support
The onboard LAN controller provides the following features:
• Integrated Fast Ethernet Controller for PCI ExpressTM Applications
• Integrated 10/100 transceiver
• Wake-on-LAN and remote wake-up support
1394a FireWire (Optional)
• Compliant with single chip hostcontroller for IEEE Std 1394-1995 and IEEE
1394a-2000
• Integrated 400 Mbit 2-Port PHY for the PCI BUS
• 3.3V Power Supply with 5V Tolerant Inputs
• One PCI Express slot for Graphic Interface
• One PCI Express x1 slot
• Two 32-bit PCI v2.3 compliant slots
• One floppy disk drive interface
• Four 7-pin SATA connectors
The motherboard comes with the following expansion options:
Expansion Options
The firmware can also be used to set parameters for different processor clock speeds.
Some hardware specifications and software items are subject to change
with out prior notice.
The motherboard has a full set of I/O ports and connectors:
• Two PS/2 ports for mouse and keyboard
• One serial port (optional)
• One parallel port (optional)
• One VGA port
• Four USB ports
• One 1394 port (optional)
• One LAN port (optional)
• Audio jacks for microphone in, line-in and 8-ch High Definition Audio output
Integrated I/O
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memroy timing
BIOS Firmware
This motherboard uses AMI BIOS that enables users to configure many system
features including the following

4
Introducing the Motherboard
Motherboard Components

5
Introducing the Motherboard
This concludes Chapter 1. The next chapter explains how to install the motherboard.
* Stands for optional components
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket LGA775 socket for Intel
®
Wolfdale /Core
T
M2 Duo
CPUs
2. CPU_FAN CPU cooling fan connector
3. DIMM1~4 240-pin DDR2 SDRAM slots
4. FDD Floppy disk drive connector
5. ATX_POWER1 Standard 24-pin ATX power connector
6. SATA1/2/5/6 Serial ATA connectors
7. PANEL1 Front panel switch/LED header
8. USB1~4 Front Panel USB headers
9. 1394A1* Onboard 1394a header
10. CLR_CMOS Clear CMOS jumper
11. SPI_ROM * SPI ROM header
12. COM2 * Onboard serial port header
13. SPDIF_OUT1 SPDIF out header
14. CD_IN Analog audio input connector
15. AUDIO1 Front panel audio header
16. PCI1~2 32-bit add-on card slots
17. PCIEX1 PCI Express x1 slot
18. PCIEX16 PCI Express x16 graphics card slot
19. ATX12V1 ATX12V power connector
20. SYS_FAN System fan connector

6
Introducing the Motherboard
Memo

7
Installing the Motherboard
Chapter 2
Installing the Motherboard
Safety Precautions
• Follow these safety precautions when installing the motherboard
• Wear a grounding strap attached to a grounded device to avoid damage from
static electricity
• Discharge static electricity by touching the metal case of a safely grounded
object before working on the motherboard
• Leave components in the static-proof bags they came in
• Hold all circuit boards by the edges. Do not bend circuit boards
Choosing a Computer Case
There are many types of computer cases on the market. The motherboard complies with
the specifications for the Micro ATX system case. First, some features on the motherboard
are implemented by cabling connectors on the motherboard to indicators and switches on
the system case. Make sure that your case supports all the features required. Secondly, this
motherboard supports one or two floppy diskette drives. Make sure that your case has
sufficient power and space for all drives that you intend to install.
Most cases have a choice of I/O templates in the rear panel. Make sure that the I/O
template in the case matches the I/O ports installed on the rear edge of the motherboard.
This motherboard carries an Micro ATX form factor of 244 x 244 mm. Choose a case that
accommodates this form factor.
Installing the Motherboard in a Case
Refer to the following illustration and instructions for installing the motherboard in a case.
Most system cases have mounting brackets installed in the case, which correspond the holes
in the motherboard. Place the motherboard over the mounting brackets and secure the
motherboard onto the mounting brackets with screws.
Ensure that your case has an I/O template that supports the I/O ports and expansion slots
on your motherboard.

8
Installing the Motherboard
Checking Jumper Settings
This section explains how to set jumpers for correct configuration of the motherboard.
Setting Jumpers
Use the motherboard jumpers to set system configuration options. Jumpers with more than
one pin are numbered. When setting the jumpers, ensure that the jumper caps are placed on
the correct pins.
The illustrations show a 2-pin jumper. When
the jumper cap is placed on both pins, the
jumper is SHORT. If you remove the jumper
cap, or place the jumper cap on just one pin,
the jumper is OPEN.
This illustration shows a 3-pin jumper. Pins
1 and 2 are SHORT
SHORT OPEN
Do not over-tighten the screws as this can stress the motherboard.

9
Installing the Motherboard
Checking Jumper Settings
The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled.
Jumper Settings
Jumper Type Description Setting (default)
CLR_CMOS 3-pin CLR_CMOS
1-2: NORMAL
2-3: CLEAR CMOS
Before clearing the
CMOS, make sure to
turn off the system.
1
CLR_CMOS

10
Installing the Motherboard
Connecting Case Components
After you have installed the motherboard into a case, you can begin con-
necting the motherboard components. Refer to the following:
1 Connect the CPU cooling fan cable to CPU_FAN
2 Connect the system cooling fan connector to SYS_FAN
3 Connect the case switches and indicator LEDs to the PANEL1.
4 Connect the standard power supply connector to ATX_POWER1.
5 Connect the auxiliary case power supply connector to ATX12V1.
Connecting 20/24-pin power cable
Users please note that the 20-pin and 24-pin power cables can both be connected
to the ATX_POWER1 connector. With the 20-pin power cable, just align the 20-
pin power cable with the pin 1 of the ATX_POWER1 connector. However, using
20-pin power cable may cause the system to become unbootable or unstable
because of insufficient electricity. A minimum power of 300W is recommended
for a fully-configured system.
20-pin power cable
24-pin power cable
With ATX v2.x power supply , users please
note that when installing 24-pin power cable,
the latches of power cable and the
ATX_POWER1 match perfectly.
With ATX v1.x power supply, users please
note that when installing 20-pin power cable,
the latche of power cable falls on the left
side of the ATX_POWER1 connector latch,
just as the picture shows.

11
Installing the Motherboard
Pin Signal Name Function
1GND System Ground
2+12V Power +12V
3 Sense Sensor
ATX_POWER1: ATX 24-pin Power Connector
Pin Signal Name Pin Signal Name
1+3.3V 13 +3.3V
2+3.3V 14 -12V
3Ground 15 Ground
4+5V 16 PS_ON
5Ground 17 Ground
6+5V 18 Ground
7Ground 19 Ground
8PWRGD 20 -5V
9+5VSB 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 +3.3V 24 Ground
ATX12V1: ATX 12V Power Connector
4+12V
3+12V
2Ground
1Ground
CPU_FAN: FAN Power Connector
1GND System Ground
2+12V Power +12V
3 Sense Sensor
4 PWM CPU FAN control
Pin Signal Name Function
Users please note that the fan connector supports the CPU cooling fan of
1.1A ~ 2.2A (26.4W max) at +12V.
Pin Signal Name
SYS_FAN: FAN Power Connector

12
Installing the Motherboard
Front Panel Header
The front panel header (PANEL1) provides a standard set of switch and LED headers
commonly found on ATX or Micro ATX cases. Refer to the table below for information:
Pin Signal Function Pin Signal Function
1 HD_LED_P Hard disk LED(+)
3 HD_LED_N Hard disk LED (-)
5 RST_SW_N Reset Switch(-)
7 RST_SW_P Reset Switch(+)
9 RSVD Reserved
4 FP PWR/SLP *MSG LED (-)
6 PWR_SW_P Power Switch(+)
8 PWR_SW_N Power Switch(-)
10 Key No pin
* MSG LED (dual color or single color)
Hard Drive Activity LED
Connecting pins 1 and 3 to a front panel mounted LED provides visual indication that data
is being read from or written to the hard drive. For the LED to function properly, an IDE
drive should be connected to the onboard IDE interface. The LED will also show activity
for devices connected to the SCSI (hard drive activity LED) connector.
Power/Sleep/Message waiting LED
Connecting pins 2 and 4 to a single or dual-color, front panel mounted LED provides power
on/off, sleep, and message waiting indication.
Reset Switch
Supporting the reset function requires connecting pin 5 and 7 to a momentary-contact
switch that is normally open. When the switch is closed, the board resets and runs POST.
Power Switch
Supporting the power on/off function requires connecting pins 6 and 8 to a momentary-
contact switch that is normally open. The switch should maintain contact for at least 50 ms
to signal the power supply to switch on or off. The time requirement is due to internal de-
bounce circuitry. After receiving a power on/off signal, at least two seconds elapses before
the power supply recognizes another on/off signal.
2 FP PWR/SLP *MSG LED (+)

13
Installing the Motherboard
Installing Hardware
Installing the Processor
Caution: When installing a CPU heatsink and cooling fan make sure that
you DO NOT scratch the motherboard or any of the surface-mount
resistors with the clip of the cooling fan. If the clip of the cooling fan
scrapes across the motherboard, you may cause serious damage to the
motherboard or its components.
On most motherboards, there are small surface-mount resistors near the
processor socket, which may be damaged if the cooling fan is carelessly
installed.
Avoid using cooling fans with sharp edges on the fan casing and the clips.
Also, install the cooling fan in a well-lit work area so that you can clearly
see the motherboard and processor socket.
Before installing the Processor
This motherboard automatically determines the CPU clock frequency and system bus
frequency for the processor. You may be able to change these settings by making changes
to jumpers on the motherboard, or changing the settings in the system Setup Utility. We
strongly recommend that you do not over-clock processors or other components to run
faster than their rated speed.
This motherboard has a LGA775 socket. When choosing a processor, consider the perfor-
mance requirements of the system. Performance is based on the processor design, the clock
speed and system bus frequency of the processor, and the quantity of internal cache memory
and external cache memory.
Warning: Over-clocking components can adversely affect the reliability
of the system and introduce errors into your system. Over-clocking can
permanently damage the motherboard by generating excess heat in
components that are run beyond the rated limits.

14
Installing the Motherboard
A. Read and follow the instructions shown on the
sticker on the CPU cap.
B. Unload the cap
· Use thumb & forefinger to hold the
lifting tab of the cap.
· Lift the cap up and remove the cap
completely from the socket.
C. Open the load plate
· Use thumb & forefinger to hold the
hook of the lever, pushing down and pulling
aside unlock it.
· Lift up the lever.
· Use thumb to open the load plate. Be
careful not to touch the contacts.
D. Install the CPU on the socket
· Orientate CPU package to the socket.
Make sure you match triangle marker
to pin 1 location.
E. Close the load plate
· Slightly push down the load plate onto the
tongue side, and hook the lever.
· CPU is locked completely.
F. Apply thermal grease on top of the CPU.
G. Fasten the cooling fan supporting base onto
the CPU socket on the motherboard.
H. Make sure the CPU fan is plugged to the
CPU fan connector. Please refer to the CPU
cooling fan user’s manual for more detail
installation procedure.
CPU Installation Procedure
The following illustration shows CPU installation components.
1. To achieve better airflow rates and heat dissipation, we suggest that you
use a high quality fan with 3800 rpm at least. CPU fan and heatsink
installation procedures may vary with the type of CPU fan/heatsink sup
plied. The form and size of fan/heatsink may also vary.
2. DO NOT remove the CPU cap from the socket before installing a CPU.
3. Return Material Authorization (RMA) requests will be accepted only if the
motherboard comes with thecap on the LGA775 socket.
