ECS TIGD2-I User manual

TIGD2-I USER MANUAL
Preface
Copyright
This publication, including all photographs, illustrations and software, is protected
under international copyright laws, with all rights reserved. Neither this manual, nor
any of the material contained herein, may be reproduced without written consent of
the author.
Version 1.0
Disclaimer
The information in this document is subject to change without notice. The manufac-
turer makes no representations or warranties with respect to the contents hereof
and specifically disclaims any implied warranties of merchantability or fitness for
any particular purpose. The manufacturer reserves the right to revise this publica-
tion and to make changes from time to time in the content hereof without obligation
of the manufacturer to notify any person of such revision or changes.
Trademark Recognition
Microsoft, Windows and Windows 7/8 are registered trademarks of Microsoft Corp.
MMX, Pentium, Pentium-II, Pentium-III, Celeron are registered trademarks of Intel
Corporation.
Other product names used in this manual are the properties of their respective owners
and are acknowledged.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential instal-
lation. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment and the receiver
•Connect the equipment onto an outlet on a circuit different from that to
which the receiver is connected
•Consult the dealer or an experienced radio/TV technician for help
Shielded interconnect cables and a shielded AC power cable must be employed with
this equipment to ensure compliance with the pertinent RF emission limits govern-
ing this device. Changes or modifications not expressly approved by the system’s
manufacturer could void the user’s authority to operate the equipment.

ii
TIGD2-I USER MANUAL
Declaration of Conformity
This device complies with part 15 of the FCC rules. Operation is subject to the follow-
ing conditions:
•This device may not cause harmful interference.
•This device must accept any interference received, including interference
that may cause undesired operation.
Canadian Department of Communications
This class B digital apparatus meets all requirements of the Canadian Interference-
causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Réglement
sur le matériel brouilieur du Canada.
The manual consists of the following:
Describes features of the
motherboard.
Hpage 1
Describes installation of
motherboard components.
Hpage 7
Hpage 25
Hpage 47
Installing the Motherboard
Introducing the Motherboard
Provides information on us-
ing the BIOS Setup Utility.
Provides basic trouble
shooting tips.
Limits and methods of mesurement of radio disturbance char-
acteristics of information technology equipment
EN 55022
EN 61000-3-2 Disturbances in supply systems caused
EN 61000-3-3 Disturbances in supply systems caused by household appli-
ances and similar electrical equipment “ Voltage fluctuations”
EN 55024 Information technology equipment-Immunity characteristics-
Limits and methods of measurement
EN 60950 Safety for information technology equipment including electri-
cal business equipment
CE marking
About the Manual






This device is in conformity with the following EC/EMC directives:
Chapter 4
Chapter 1
Chapter 2
Chapter 3
Using BIOS
Trouble Shooting

iii
TIGD2-I USER MANUAL
Chapter 2 7
Installing the Motherboard 7
Safety Precautions..............................................................................7
Installing the Motherboard in a Chassis.......................................7
Checking Jumper Settings..................................................................8
Installing Hardware...........................................................................11
Installing Memory Modules.....................................................11
Installing Add-on Cards..........................................................12
Connecting Optional Devices.................................................14
Installing a SATA Hard Drive...................................................19
Connecting Case Components........................................................20
Front Panel Header................................................................22
TABLE OF CONTENTS
Preface i
Chapter 1 1
Introducing the Motherboard 1
Introduction...........................................................................................1
Specifications......................................................................................2
Motherboard Components................................................................3
I/O Ports...............................................................................................5
Chapter 3 25
Using BIOS 25
About the Setup Utility......................................................................25
The Standard Configuration........................ ...........................25
Entering the Setup Utility.......................................................25
Resetting the Default CMOS Values.....................................26
Using BIOS..........................................................................................26
BIOS Navigation Keys..............................................................27
Main Menu..........................................................................28
Advanced Menu........................................................................29
Chipset Menu..........................................................................40
Tweak Menu...........................................................................42
Boot Menu.............................................................................43
Security Menu......................................................................44
Exit Menu...............................................................................45
Updating the BIOS......................................................................46

iv
TIGD2-I USER MANUAL
Chapter 4 47
Trouble Shooting 47
Start up problems during assembly..............................................47
Start up problems after prolong use............................................48
Maintenance and care tips..............................................................48
Basic Troubleshooting Flowchart.....................................................49

1
TIGD2-I USER MANUAL
Chapter 1
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the TIGD2-I motherboard of high performance, enhanced
function. This motherboard has Onboard D2550 CPU with a Thin Mini-ITX form factor
of 170 x 170 mm.
This motherboard is based on Intel®®
®®
®NM10 Express Chipset. It supports up to 4 GB of
system memory with single channel DDR3 SO-DIMM 1066/800 MHz. One optional
PCI slot is supported.
It implements an EHCI compliant interface that provides eight USB 2.0 ports (four
USB 2.0 ports at the rear panel and two USB 2.0 headers support additional four USB
2.0 ports).
The motherboard is equipped with a full set of I/O ports in the rear panel, including
PS/2 mouse and keyboard connectors, one DC-IN port, one VGA port, one DVI port,
two RJ45 LAN connectors, four USB 2.0 ports, and audio jacks for microphone and
line-out.
In addition, this motherboard supports two SATA 3.0Gb/s connectors for expansion.
Your motherboard package ships with the following items:
Package Contents
TIGD2-I Motherboard
User Manual
I/O Shield
2 SATA 3.0Gb/s Cables




The package contents above are for reference only, please take the actual
package items as standard.

Chapter 1
2
TIGD2-I USER MANUAL
CPU
Specifications
• Intel®NM10 ChipsetChipset
• Single channel DDR3 SO-DIMM memory architecture
• 1 x 204-pin DDR3 SO-DIMM sockets support up to 4 GB
• Supports DDR3 1066/800 MHz DDR3 SDRAM
Memory
• 1 x PCI slot
• Supported by Intel®NM10 Express Chipset
- 2 x Serial ATA 3.0Gb/s devices
Expansion
Slots
Storage
• 1 x DC-IN port
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x D-Sub port (VGA)
• 1 x DVI port
• 4 x USB 2.0 ports
• 2 x RJ45 LAN connectors
• 1 x Audio port (1x Line out, 1x Mic_in Rear)
Rear Panel I/O
LAN • Dual LAN 8111E(VL) Gigabit Lan
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• Intel®Onboard D2550 CPU
• Intel TDP 10W
• 1 x 20-pin ATX Power Supply connector
• 1 x 4-pin SYS_FAN connector
• 2 x USB 2.0 header supports additional four USB 2.0 ports
• 2 x Serial SATA 3.0Gb/s connectors
• 6 x COM headers
• 6 x COM setting jumpers
• 1 x LVDS S/D channel & output data format setting jumper
• 1 x LVDS connector
• 1 x Printer header
• 1 x HDD_PWR connector
• 1 x ODD_PWR connector
• 1 x DIO header
• 1 x LVDS Power header
• 1 x LVDS Power select jumper
• 1 x LVDS_12V header
• 1 x LVDS_19V header
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x CLR_CMOS header
Internal I/O
Connectors &
Headers
• Realtek ALC662 VD
- 2.1 Channel High Definition Audio Codec
- Compliant with HD audio specification
Audio

3
TIGD2-I USER MANUAL
Chapter 1
• AMI BIOS with 16Mb SPI Flash ROM
- Supports Plug and Play, STR(S3)/STD(S4), Multi-Language
- Supports Hardware Monitor
- Supports ACPI 3.0 version & DMI
- Supports Audio, LAN, can be disabled in BIOS
- Supports Dual-Monitor function
- F7 hot key for boot up devices option
System BIOS
Form Factor • Thin Mini-ITX Size, 170mm x 170mm

Chapter 1
4
TIGD2-I USER MANUAL
Motherboard Components
This picture may be different due to Optional Features on speccifications.

5
TIGD2-I USER MANUAL
Chapter 1
Table of Motherboard Components
LABEL
COMPONENTS
1. CPU
Onboard D2550 CPU
2. SYS_FAN
4-pin system cooling fan connector
3. DIMM1
204-pin DDR3 SDRAM SO-DIMM
4. PRINTER
Printer header
5. COM3/4/2/1/6
Onboard serial port headers
6. ATX_POWER
20-pin ATX power connector
7. JP1/2/4/3/5/6
COM setting jumpers
8. F_PANEL
Front panel switch/LED header
9. DIO
DIO header
10. SATA1~2
Serial ATA 3.0 Gb/s connectors
11. COM5
Onboard serial port header
12. PCI
32-bit add-on card slot
13. ODD_PWR
ODD power connector
14. HDD_PWR
HDD power connector
15. CLR_CMOS
Clear CMOS jumper
16. F_AUDIO
Front panel audio header
17. F_USB1~2
Front panel USB 2.0 headers
18. LVDS_PWR1
LVDS power select jumper
19. LVDS
LVDS header
20. JP7
LVDS S/D channel & output data format setting jumper
21. LVDS_19V
19V LVDS power header
22. LVDSPW_CONN LVDS power connector
23. LVDS_12V
12V LVDS power header

Chapter 1
6
TIGD2-I USER MANUAL
I/O Ports
1. DC_IN Port
Connect the DC_IN port to the power adapter.
2. PS/2 Mouse(green)
Use the upper PS/2 port to connect a PS/2 mouse.
3. PS/2 Keyboard(purple)
Use the lower PS/2 port to connect a PS/2 keyboard.
4. VGA Port
Connect your monitor to the VGA port.
5. DVI Port
You can connect the display device to the DVI port.
6. LAN Ports
Connect an RJ-45 jack to the LAN port to connect your computer to the Network.
7. USB 2.0 Ports
Use the USB 2.0 ports to connect USB 2.0 devices.
8. Line-out(lime)
It is used to connect to speakers or headphones.
9. Microphone(pink)
It is used to connect to a microphone.
LAN LED Status Description
OFF No da ta
Yellow blinking Active
OFF No link
Green/Orange Link
Activity LED
Link LED
Link LED
LAN Port

Chapter 2
7
TIGD2-I USER MANUAL
Chapter 2
Installing the Motherboard
2-1. Safety Precautions
2-2. Installing the motherboard in a Chassis
This motherboard carries a Thin Mini-ITX form factor of 170 x 170 mm. Choose a
chassis that accommodates this form factor. Make sure that the I/O template in the
chassis matches the I/O ports installed on the rear edge of the motherboard. Most
system chassis have mounting brackets installed in the chassis, which corresponds
to the holes in the motherboard. Place the motherboard over the mounting brack-
ets and secure the motherboard onto the mounting brackets with screws.
Follow these safety precautions when installing the motherboard:
• Wear a grounding strap attached to a grounded device to avoid damage
from static electricity.
• Discharge static electricity by touching the metal case of a safely grounded
object before working on the motherboard.
• Leave components in the static-proof bags.
• Always remove the AC power by unplugging the power cord from the power
outlet before installing or removing the motherboard or other hardware
components.
Do not over-tighten the screws as this can stress the motherboard.

Chapter 2
8
TIGD2-I USER MANUAL
The following illustration shows the location of the motherboard jumpers. Pin 1 is
labeled.
2-3. Checking Jumper Settings
No. Components No. Components
1 JP1/2/4/3/5/6 4 JP7
2 CLR_CMOS 5 LVDS_19V
3LVDS_PWR16 LVDS_12V
1 & 4. JP1/2/4/3/5/6 & JP7: COM Setting Jumpers & LVDS S/D channel and LVDS
output data format setting jumper

Chapter 2
9
TIGD2-I USER MANUAL
Default
5V 12V RI 5V 12V DCD
COM1 JP6 (1-3) (3-5) (7-9) (2-4) (4-6) （
8-10
）
COM2 JP5 (1-3) (3-5) (7-9) (2-4) (4-6) （
8-10
）
COM3 JP3 NA NA NA (1-3) (3-5) (7-9)
COM5 JP3 NA NA NA (2-4) (4-6) （
8-10
）
PIN1，9
OUTPUT
PIN9 PIN1
（8-10）
*
(7-9)
(1-3)(2-4) RS232
(3-5)(4-6) TTL
(1-3)(2-4) RS232
(3-5)(4-6) TTL
(1-3)(2-4) RS232
(3-5)(4-6) RS485
COM3 JP1
COM5 JP4
COM4 JP2
(1-3) Dual channel
(3-5) Single channel
(2-4) 18bit
(4-6) 24bit
JP7
JP7
LVDS S/D channel & output data format setting
2. CLR_CMOS: Clear CMOS Jumper
To avoid the system instability after clearing CMOS, we recommend users to
enter the main BIOS setting page to “Load Default Settings” and then “Save
and Exit Setup”.
COM setting

Chapter 2
10
TIGD2-I USER MANUAL
5&6. LVDS_19V & LVDS_12V: LVDS Power Jumper
3. LVDS_PWR1: LVDS Power Select Jumper

Chapter 2
11
TIGD2-I USER MANUAL
2-4. Installing Hardware
2-4-1. Installing Memory Modules
• This motherboard accommodates one memory module. It can support
one 204-pin DDR3 SO-DIMM 1066/800.
• Do not remove any memory module from its antistatic packaging until
you are ready to install it on the motherboard. Handle the modules only
by their edges. Do not touch the components or metal parts. Always wear
a grounding strap when you handle the modules.
• You must install one module in SO_DIMM1 slot. Total memory capacity is
4 GB.
• Refer to the following to install the memory modules.
Install the DIMM module into the slot and press it firmly down until it fits
in place. Check that the cutouts on the DIMM module edge connector
match the notches in the DIMM slot.
* For reference only

Chapter 2
12
TIGD2-I USER MANUAL
2-4-2. Installing Add-on Cards
The slots on this motherboard are designed to hold expansion cards and connect
them to the system bus. Expansion slots are a means of adding or enhancing the
motherboard’s features and capabilities. With these efficient facilities, you can
increase the motherboard’s capabilities by adding hardware that performs tasks
that are not part of the basic system.
Before installing an add-on card, check the documentation for
the card carefully. If the card is not Plug and Play, you may have
to manually configure the card before installation.
This motherboard is equipped with one standard PCI slot. PCI
stands for Peripheral Component Interconnect and is a bus
standard for expansion cards, which for the most part, is a
supplement of the older ISA bus standard. The PCI slot on this
board is PCI v2.3 compliant.
PCI Slot

Chapter 2
13
TIGD2-I USER MANUAL
1 Remove a blanking plate from the system case corresponding to the slot
you are going to use.
2 Install the edge connector of the add-on card into the expansion slot.
Ensure that the edge connector is correctly seated in the slot.
3 Secure the metal bracket of the card to the system case with a screw.
1. For some add-on cards, for example graphics adapters and network adapt-
ers, you have to install drivers and software before you can begin using the
add-on card.
2. The onboard PCI interface does not support 64-bit SCSI cards.
Follow these instructions to install an add-on card:
Please refer to the following illustrations to install the add-on card:
* For reference only
Install the VGA Card in the PCI slot

Chapter 2
14
TIGD2-I USER MANUAL
No. Components No. Components
1PRINTER5 COM5
2 COM3/4/2/1/6 6 F_AUDIO
3SATA1~27F_USB1~2
4DIO8LVDS
1 PRINTER: Printer Header
2-4-3. Connecting Optional Devices
Refer to the following for information on connecting the motherboard’s optional
devices:

Chapter 2
15
TIGD2-I USER MANUAL
SATA1~2 connectors are used to support the Serial ATA 3.0Gb/s devices, simpler disk
drive cabling and easier PC assembly. It eliminates limitations of the current Paral-
lel ATA interface. But maintains register compatibility and software compatibility
with Parallel ATA.
3. SATA1~2: Serial ATA connectors
2 & 5. COM2/1/4/3/6 & COM5: Onboard Serial Port Headers
Connect a serial port extension bracket to this header to add a serial port to your
system.

Chapter 2
16
TIGD2-I USER MANUAL
The front panel audio header allows the user to install auxiliary front-oriented mi-
crophone and line-out ports for easier access. This header supports HD audio by
default. If you want connect an AC’97 front panel audio to HD onboard headers,
please set as below picture.
6. F_AUDIO: Front Panel Audio Header
4. DIO: DIO Header
