Thank you for choosing the 848P-A7 motherboard. This motherboard is a high perfor-
mance, enhanced function motherboard designed to support the LGA775 Socket Intel
Pentium 4/Celeron D/Pentium D processors for high-end business or personal desktop
markets.
The motherboard incorporates the 848P Northbridge (NB) and ICH5 Southbridge (SB)
chipsets. The Northbridge supports a Front Side Bus (FSB) frequency of 800/533 MHz with
maximum theoretical BW of 6.4 GB/s. The momory controller supports DDR memory
DIMM frequencies of 400/333/266 MHz. It supports two DDR Sockets with up to maxi-
mum memory of 2 GB. DDR Maximum memory bandwidth of 3.2 GB/s in single-channel
mode is supported. One AGP interface supports AGP 3.0 including 8X/4X AGP Data Trans-
fers and 8X/4X Fast Write Protocol.
The ICH5 Southbridge supports five PCI slots which are PCI 2.3 compliant. It accomodates
eight USB 2.0 ports for Serial Transfers at maximum 480 Mb/s. This motherboard complies
with AC’97 2.3 codecs and supports up to six channels of PCM audio output (full AC3
decode). Two onboard IDE connectors support 4 IDE devices in Ultra ATA100/66/33 mode.
The Southbridge integrates two Serial ATA host controllers that is SATA v1.0 compliant,
supporting two SATA ports with maximum transfer rate up to 1.5 Gb/s each.
This motherboard is equipped with advanced full set of I/O ports in the rear panel, including
PS/2 mouse and keyboard connectors, one serial port, one parallel port, four USB ports, one
optional LAN port, and audio jacks for microphone, line-in and line-out.

2
Introducing the Motherboard
Feature
• Accommodates Intel Pentium 4/Celeron D/Pentium D processors
• Supports a system bus (FSB) of 800/533 MHz
• Supports “Hyper-Threading” technology CPU
The 848P Northbridge (NB) and ICH5 Southbridge (SB) chipset are based on an inno-
vative and scalable architecture with proven reliability and performance.
848P (NB) • Supports Hub Interface (HI) 1.5 with 266 MB/s point-to-
point connection to ICH5
• Supports AGP 3.0 with 8X/4X AGP data transfers and 8X/
4X fast writes respectively
• Supports Single-channel DDR memory interface
• Supports DDR400/333/266 DIMM modules
• Supports up to two unbuffered DIMMs with 2 GB maximum
memory size
“Hyper-Threading” technology enables the operating system into thinking it’s hooked
up to two processors, allowing two threads to be run in parallel, both on separate
“logical” processors within the same physical processor.
This motherboard uses an LGA775 type of Pentium 4/Celeron D/Pentium D that
carries the following features:
ICH5 (SB)
• Supports DDR400/333/266 DDR SDRAM memory module
• Accommodates two unbuffered DIMMs
• Up to 1 GB per DIMM with maximum memory size up to 2 GB
Memory
Processor
Chipset
• Compliant with AC’97 v2.3 CODEC
• Supports 6-channel audio CODEC designed for PC multimedia systems
Audio
• Provides three analog line-level stereo inputs with 5-bit volume control:
Line-in, CD, AUX
• Meets Microsoft WHQL/WLP 2.0 audio requirements
• Supports up to six PCI Masters fully compliant with PCI 2.3
specificaiton at 33 MHz
• Supports 2 channels Ultra ATA 100 bus master IDE control-
lers
• The SATA controller supports two SATA devices
• Compliant with AC’97 v2.3 supporting 6 Channels of audio
outputs
• Supports eight USB 2.0 ports for serial transfers at 480 Mb/
s maximum

3
Introducing the Motherboard
Some hardware specifications and software items are subject to change
without prior notice.
This motherboard supports UltraDMA bus mastering with transfer rates of 100/66 MB/
s.
The motherboard comes with the following expansion options:
Expansion Options
• One AGP 3.0 compliant slot with 8X/4X speed (supports 1.5V AGP interface
only)
• Five 32-bit PCI v2.3 compliant slots
• Two 40-pin IDE low profile headers that support four IDE devices
• One floppy disk drive interface
• Two 7-pin SATA connectors
• Two PS/2 ports for mouse and keyboard
• One serial port
• One parallel port
• Four USB ports
• One LAN port (optional)
• Audio jacks for microphone, line-in and line-out
Integrated I/O
The motherboard has a full set of I/O ports and connectors:
• Power management
• Wake-up alarms
• CPU parameters
• CPU and memory timing
BIOS Firmware
This motherboard uses Award BIOS that enables users to configure many system
features including the following:
The firmware can also be used to set parameters for different processor clock speeds.
Onboard LAN (Optional)
This motherboard may support either of the following LAN chipset:
• Supports 10/100 Mb/s N-Way Auto negotiation operation
• Half/Full duplex capability
• Supports Wake-On-LAN(WOL) function and remote wake-up
• Integrate 10/100/1000 transceiver
• Supports PCI v2.3, 32-bit, 33/66 MHz
• Supports fully with IEEE802.3, IEEE802.3u and IEEE802.3ab

4
Introducing the Motherboard
Motherboard Components

5
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
1 CPU Socket
2 CPU_FAN CPU cooling fan connector
20 AGP Accelerated Graphics Port slot
10 SATA1~2 Serial ATA connectors
5 ATX1 Standard 20-pin ATX power connector
11 F_PANEL Front Panel switch/LED header
4 FDD Floppy diskette drive connector
18 PCI1~5 32-bit add-on card slots
15 IR Serial Infrared header
LABEL COMPONENT
6 IDE1 Primary IDE connector
7 IDE2 Secondary IDE connector
3 DIMM1~2 184-pin DDR SDRAM slots
8 PWR_FAN* Power fan connector
9 CLR_CMOS Clear CMOS jumper
12 BIOS_WP BIOS protect jumper
19 SPDIF1 SPDIF out header
22 CD_IN Analog audio input header
24 SYS_FAN Case cooling fan connector
16 CHS1* Chassis detect header
17 JP1 LAN function enable/disable jumper
21 AUXIN1 Auxiliary In header
23 F_AUDIO Front panel audio header
*Stands for optional components
13 SPK1 Speaker header
14 F_USB3~4 Front panel USB headers
25 ATX12V 4-pin +12V power connector
26 PAT1~2 PAT jumpers
LGA775 socket for latest Intel Pentium 4/Celeron
D/Pentium D CPUs

6
Introducing the Motherboard
Memo

7
Installing the Motherboard
Chapter 2
Installing the Motherboard
Installing the Motherboard in a Case
Refer to the following illustration and instructions for installing the motherboard in a case.
Safety Precautions
• Follow these safety precautions when installing the motherboard
• Wear a grounding strap attached to a grounded device to avoid damage from
static electricity
• Discharge static electricity by touching the metal case of a safely grounded
object before working on the motherboard
• Leave components in the static-proof bags they came in
• Hold all circuit boards by the edges. Do not bend circuit boards
Choosing a Computer Case
There are many types of computer cases on the market. The motherboard complies with
the specifications for the ATX system case. First, some features on the motherboard are
implemented by cabling connectors on the motherboard to indicators and switches on the
system case. Make sure that your case supports all the features required. Secondly, this
motherboard supports one or two floppy diskette drives and four enhanced IDE drives.
Make sure that your case has sufficient power and space for all drives that you intend to
install.
Most cases have a choice of I/O templates in the rear panel. Make sure that the I/O
template in the case matches the I/O ports installed on the rear edge of the motherboard.
This motherboard carries an ATX form factor of 305 x 244 mm. Choose a case that
accommodates this form factor.
Most system cases have mounting brackets installed in the case, which correspond the holes
in the motherboard. Place the motherboard over the mounting brackets and secure the
motherboard onto the mounting brackets with screws.
Ensure that your case has an I/O template that supports the I/O ports and expansion slots
on your motherboard.

8
Installing the Motherboard
Checking Jumper Settings
This section explains how to set jumpers for correct configuration of the motherboard.
Setting Jumpers
Use the motherboard jumpers to set system configuration options. Jumpers with more than
one pin are numbered. When setting the jumpers, ensure that the jumper caps are placed on
the correct pins.
The illustrations show a 2-pin jumper. When
the jumper cap is placed on both pins, the
jumper is SHORT. If you remove the jumper
cap, or place the jumper cap on just one pin,
the jumper is OPEN.
This illustration shows a 3-pin jumper. Pins
1 and 2 are SHORT
SHORT OPEN
Do not over-tighten the screws as this can stress the motherboard.

9
Installing the Motherboard
Checking Jumper Settings
The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled.
Jumper Settings
Jumper Type Description Setting (default)
JP1 3-pin LAN FUNCTION
1-2: ENABLE
2-3: DISABLE
OPEN: UNPROTECT
SHORT: PROTECT
BIOS FLASH PROTECT
3-pin
BIOS_WP
CLR_CMOS 3-pin CLEAR CMOS
1-2: CLEAR
2-3: NORMAL
Before clearing the
CMOS, make sure to
turn off the system.
PAT1
PAT2
3-pin Turbo Mode 1-2: DISABLE
2-3: ENABLE

10
Installing the Motherboard
Connecting Case Components
After you have installed the motherboard into a case, you can begin con-
necting the motherboard components. Refer to the following:
1 Connect the CPU cooling fan cable to CPU_FAN.
2 Connect the case cooling fan connector to SYS_FAN.
3 Connect the power fan connector to PWR_FAN (optional).
4 Connect the case speaker cable to SPK1.
5 Connect the case switches and indicator LEDs to the F_PANEL.
6 Connect the standard power supply connector to ATX1.
7 Connect the auxiliary case power supply connector to ATX12V.
CPU_FAN: FAN Power Connector
Pin Signal Name Function
1GND System Ground
2+12V Power +12V
3 Sense Sensor
4 PWM CPU FAN control
SYS_FAN/PWR_FAN (optional): FAN Power Connectors
Pin Signal Name Function
1GND System Ground
2+12V Power +12V
3 Sense Sensor

11
Installing the Motherboard
ATX12V: ATX 12V Power Connector
Pin Signal Name
4+12V
3+12V
2Ground
1Ground
SPK1: Internal speaker
Pin Signal Name
1VCC
2Key
3GND
4Signal
ATX1: ATX 20-pin Power Connector
Pin Signal Name Pin Signal Name
1+3.3V 11 +3.3V
2+3.3V 12 -12V
3Ground 13 Ground
4+5V 14 PS ON#
5Ground 15 Ground
6+5V 16 Ground
7Ground 17 Ground
8PWRGD 18 -5V
9+5VSB 19 +5V
10 +12V 20 +5V

12
Installing the Motherboard
Hard Drive Activity LED
Connecting pins 1 and 3 to a front panel mounted LED provides visual indication that data
is being read from or written to the hard drive. For the LED to function properly, an IDE
drive should be connected to the onboard IDE interface. The LED will also show activity
for devices connected to the SCSI (hard drive activity LED) connector.
Power/Sleep/Message waiting LED
Connecting pins 2 and 4 to a single or dual-color, front panel mounted LED provides power
on/off, sleep, and message waiting indication.
Reset Switch
Supporting the reset function requires connecting pin 5 and 7 to a momentary-contact
switch that is normally open. When the switch is closed, the board resets and runs POST.
Power Switch
Supporting the power on/off function requires connecting pins 6 and 8 to a momentary-
contact switch that is normally open. The switch should maintain contact for at least 50 ms
to signal the power supply to switch on or off. The time requirement is due to internal de-
bounce circuitry. After receiving a power on/off signal, at least two seconds elapses before
the power supply recognizes another on/off signal.
Front Panel Connector
The front panel connector (F_PANEL) provides a standard set of switch and LED connec-
tors commonly found on ATX or micro-ATX cases. Refer to the table below for informa-
tion:
Pin Signal Function Pin Signal Function
1 HD_LED_P Hard disk LED(+) 2 FP PWR/SLP *MSG LED(+)
3 HD_LED_N Hard disk LED(-)
5 RST_SW_N Reset Switch(-)
7 RST_SW_P Reset Switch(+)
9 RSVD Reserved
4 FP PWR/SLP *MSG LED(-)
6 PWR_SW_P Power Switch(+)
8 PWR_SW_N Power Switch(-)
10 Key No pin
* MSG LED (dual color or single color)

13
Installing the Motherboard
Installing Hardware
Installing the Processor
Caution: When installing a CPU heatsink and cooling fan make sure that
you DO NOT scratch the motherboard or any of the surface-mount
resistors with the clip of the cooling fan. If the clip of the cooling fan
scrapes across the motherboard, you may cause serious damage to the
motherboard or its components.
On most motherboards, there are small surface-mount resistors near the
processor socket, which may be damaged if the cooling fan is carelessly
installed.
Avoid using cooling fans with sharp edges on the fan casing and the clips.
Also, install the cooling fan in a well-lit work area so that you can clearly
see the motherboard and processor socket.
Before installing the Processor
This motherboard automatically determines the CPU clock frequency and system bus
frequency for the processor. You may be able to change these settings by making changes
to jumpers on the motherboard, or changing the settings in the system Setup Utility. We
strongly recommend that you do not over-clock processors or other components to run
faster than their rated speed.
This motherboard has an LGA775 processor socket. When choosing a processor, consider
the performance requirements of the system. Performance is based on the processor design,
the clock speed and system bus frequency of the processor, and the quantity of internal
cache memory and external cache memory.
Warning: Over-clocking components can adversely affect the reliability
of the system and introduce errors into your system. Over-clocking can
permanently damage the motherboard by generating excess heat in
components that are run beyond the rated limits.

14
Installing the Motherboard
CPU Installation Procedure
The following illustration shows CPU installation components.
B. Unload the cap
· Use thumb & forefinger to hold the
lifting tab of the cap.
· Lift the cap up and remove the cap
completely from the socket.
C. Open the load plate
· Use thumb & forefinger to hold the
hook of the lever, pushing down and pulling
aside unlock it.
· Lift up the lever.
· Use thumb to open the load plate. Be
careful not to touch the contacts.
D. Install the CPU on the socket
· Orientate CPU package to the socket.
Make sure you match triangle marker
to pin 1 location.
E. Close the load plate
· Slightly push down the load plate onto the
tongue side, and hook the lever.
· CPU is locked completely.
F. Apply thermal grease on top of the CPU.
G. Fasten the cooling fan supporting base onto
the CPU socket on the motherboard.
H. Make sure the CPU fan is plugged to the
CPU fan connector. Please refer to the CPU
cooling fan user’s manual for more detail
installation procedure.
To achieve better airflow rates and heat dissipation, we suggest that you
use a high quality fan with 3800 rpm at least. CPU fan and heatsink
installation procedures may vary with the type of CPU fan/heatsink sup-
plied. The form and size of fan/heatsink may also vary.
A. Read and follow the instructions shown on the
sticker on the CPU cap.
Return Material Authorization (RMA) requests will be accepted only if the
motherboard comes with the cap on the LGA775 socket.
1.
3.
DO NOT remove the CPU cap from the socket before installing a CPU.
2.
