Brake Hose Kit for Honda VTX1800
Models - 2005-2007 (R), 2006-2007 (N),
2006 (S), 2007 (T)
Catalog #R09259S
INSTALLATION INSTRUCTIONS
1. Begin by inspecting and noting the position and
routing of the factory brake lines.
2. Remove the factory brake line distribution blocks
from under the lower triple-tree, as well as the guide
brackets on each side of the fender.
3. Remove the original line from the master cylinder,
then the two hard lines from the small junction block
on the right side of the frame just forward of the fuel
tank ( “Left” and “Right” is defined while sitting on
the bike.)
4. Replace the small junction block with the one
supplied in the kit, noting the orientation of the bolt
hole, and reconnect the factory hard lines to the
corresponding locations.
5. Disconnect the four factory brake lines from the
calipers and remove the brake line assembly.
6. Bolt the new distribution block under the triple-tree.
Using the supplied banjo bolts and new crush
washers, install the new lines onto the proper ports
of the distribution block, with the angle of the banjo
fittings directing the lines outward
(Fig. 1) .
NOTE: The block and lines are labeled A,B,C, & D. Be
sure to match the labeled hose end to the
corresponding block port.
Please study these instructions carefully before installing your new Brake Hose Kit. If you have any questions, please call our
Technical Hotline at: 1-800-416-8628, 7:00 am - 5:00 pm, Pacific Standard Time, Monday through Friday or
e-mail us at [email protected].
INSTALLATION INSTRUCTIONS
IMPORTANT NOTE: Do not allow the master cylinder to completely drain of brake fluid at any time during this process. Doing so
may require removing the master cylinder from the vehicle for bench bleeding. Also, use care when handling brake fluid, as it can
quickly damage finished surfaces (paint, plating, etc.).
IMPORTANT NOTE:
Proper installation is the responsibility of the installer. Improper installation will void warranty and may result in
poor performance and engine or vehicle damage.
7. The double length banjo bolts will be used on the
right side of the distribution block where the
incoming lines from the master cylinder and from the
small junction block will be stacked on top of the
lines running to the right side caliper
(Fig. 2).
8. Connect the remaining two Russell lines to the small
junction block and master cylinder as labeled. port
“A” to small junction block, port “B” to front brake
master cylinder on handlebars.
Hose Descriptions
• Line #1 – Front, Distribution block port “A” to right
lower caliper
• Line #2 – Front, Distribution block port “B” to right
upper caliper
• Line #3 – Front, Distribution block port “C” to left
upper caliper
• Line #4 – Front, Distribution block port “D” to left
lower caliper
• Line #5 – Front, master cylinder to distribution block port
“B”
• Line #6 – Front, small junction block to distribution block
port “A”
• Line #7 – Front, down tubes to rear master cylinder
• Line #8 – Rear, rear hard line to rear caliper
Fig. 1

©2007 Edelbrock Corporation
Rev. 9/07 - JT/mc
Catalog #R09259S
Brochure #63-R09259S
Page 2 of 2
A Division of Edelbrock Corporation
2700 California Street, Torrance, CA 90503
Toll-Free Tech Line: 1-800-416-8628
Tech E-Mail: [email protected]
9. Using the rubber grommets supplied on the lines,
attach the lines using the stock guide brackets
located on the right and left side of the fender.
10. Disconnect stock brake line located on the front
down tubes of the frame leading to the rear master
cylinder. You may need to loosen the top of the
radiator bolt to make your disassembly and install
easier.
(Fig. 3 is the brake fitting bolted to the
frame, located behind the radiator).
11. Remove the battery, and loosen the lower and top
mount of the battery box. This is needed to access
the rear brake line junction block. Pull the battery
box up to gain more work area below the battery
box.
(Fig. 4 is the battery box with battery
removed)
12. Remove the hard line going to the rear caliper,
located under the seat. Disconnect the banjo bolt,
clamps and bolts located on the stock soft line and
hard line and remove the complete factory rear
brake line. You will need to assemble the new
stainless steel braided brake line to the stock hard
line before reinstalling the complete rear line on the
bike
(Fig. 5) due to space limitations.
13. Be sure to check hose for any interferences on rear
of bike (right side shock, swing arm, etc.)
(Fig. 6) .
14. Connect all brake lines using factory and supplied
banjo bolts and Russell crush washers. Bleed the
brake system. Close bleeders, apply pressure and
check for leaks around fittings.
Shop Time Approx. - 2.0 Hours Depending on skill level
