EDELBROCK CAT-BACK EXHAUST SYSTEM (SIDE EXIT)
for 1987-1996 Ford Pick-Up Trucks with 2 & 4WD, 5.0L/5.8L V8
Catalog #5680
INSTALLATION INSTRUCTIONS
®
Application: Designed for 1987-1996 Ford F-150/F-250 pick-up trucks, up to 155” w.b., 2WD & 4WD with 5.0L, 5.8L V8 engine.
Suggested Tools for Installation:
❑3/8” rachet set with SAE and metric sockets ❑15mm deep sockets
❑Jackstands and jack ❑Long pry bars (for removing rubber-mounted hangers)
❑Hacksaw (to cut intermediate pipe to required length) ❑Tape measure
DISASSEMBLY
1. Raise vehicle and support with the proper jackstands,
leaving the suspension hanging.
2. Use caution around hot exhaust systems to avoid burns.
3. Use penetrating oil on all nuts and bolts, and rubber lube
on the rubber hangers.
4. Remove all nuts, bolts, and hangers from the rear of the
catalytic converter to the tailpipes.
5. Remove the old system.
INSTALLATION
1. Assemble the overaxle pipe to the muffler using two
gaskets and four of the 1-1/4" bolts, nuts, and
lockwashers.
2. Install the hanger supplied into the two rubber hangers
with the long side to the left so it will lean forward when
attached to the muffler flange.
3. Slip the overaxle muffler assembly over the axle from the
front and attach the hanger to the back side of the
muffler flange using the center hole with the 1-1/2" bolt,
nut and lockwasher supplied.
4. Slip the tailpipe assembly hanger into the rear rubber
hanger and bolt it to the rear of the overaxle pipe with the
remaining gaskets, bolts, nuts, and lockwashers.
Please study these instructions carefully before installing your new Cat-Back Exhaust System. If you have any questions, please
contact our Technical Hotline at: 1-800-416-8628, 7:00 am to 5:00 pm, Monday through Friday, Pacific Standard Time or e-mail
us at [email protected]. Please fill out and mail your warranty card.
WARNING: Exhaust gas contains carbon monoxide, a deadly invisible gas. Correct any leaks before driving!
5. Now the assembly is hanging in place and you can check
the length of the Intermediate pipe needed for your truck.
Using the following chart, cut the Intermediate pipe to the
following lengths, measuring from the front 2-1/4"
swage back to the 2-1/2" tube size.
Cut to
A. Standard Cab - Short Bed 117" Wheelbase 13-1/2"
B. Standard Cab - Long Bed 133" Wheelbase 29-1/2"
C. Supercab - Short Bed 138" Wheelbase 34-5/8"
D. Supercab - Long Bed 155" Wheelbase 50-3/4"
6. Deburr the cut and slip the 3" end of the tube into the
muffler. Install band clamps with the 2-1/4" clamp to the
front and slip the 2-1/4" end over the catalytic converter
outlet.
7. Level the muffler and adjust the system for clearance
from front to rear as you tighten everything up.
8. Install tailpipe tips using supplied band clamps.
9. Start your truck, check for leaks, and correct if any is
found.
NOTE: For those trucks that have Roll Pans installed, you can
modify the hangers to fit your situation on the rear exit
models. This will not be necessary on the side exit
models.
IMPORTANT NOTE:
Proper installation is the responsibility of the installer. Improper installation will void warranty and may result in
poor performance and engine or vehicle damage.

©2006 Edelbrock Corporation
Brochure #63-0499
Catalog #5680
Rev.3/06- DA/mc
Page 2of 2
WARNING: Support your vehicle with proper jack
stands or ramps rated for the total vehicle weight.
Place stands so that the rear axle is allowed to hang
free for easy system removal.
WARNING: These Cat-back Systems are engineered
to fit stock catalytic converters or equivalent
replacements. If your original system has been
modified, Edelbrock will not warranty fit or
performance.
TTwwoo--bboollttFFllaannggeeGGaasskkeettss
RReeaarrMMuufffflleerrHHaannggeerr
AAxxlleePPiippeeAAsssseemmbbllyy
IInntteerrmmeeddiiaatteePPiippee AAsssseemmbbllyy
TTaaiillppiippee AAsssseemmbblliieess
SSDDTTMMuufffflleerr
TTwwoo--bboollttFFllaannggeeGGaasskkeettss
22--11//44""BBaannddCCllaammpp
33""BBaannddCCllaammpp
®
Edelbrock Corporation, 2700 California St., Torrance,CA 90503
Tech Line: [phone]
Office: [phone]
E-Mail: [email protected]
Kit Contents
Cat-Back Exhaust System
Qty.Part # Description
123-4010 Rear muffler hanger
125-3071 Intermediate pipe
125-55764 Muffler
125-3065 Overaxle assembly
125-3066 Tailpipe assembly (side exit only) 225-5582 Tailpipe Tips (Not Shown) 233-5400 Two-bolt gaskets
146-6612 3” Band Clamp
146-6614 2-1/4" Band clamp
246-6610 Band clamps
8 - 3/8"-16 x 1-1/4" bolts
1 - 3/8"-16 x 1-1/2" bolt
9 - 3/8"-16 nuts
9 - 3/8" lockwashers
