Edelbrock 5700 Series User manual

Part #5700 Series Valve Springs
Rev. 2/10 - AJ/mc
©2010 Edelbrock Corporation
Brochure #63-5700Page 1
PLEASE study these instructions carefully before beginning this installation. Most installations can be accomplished with common tools and
procedures. However, you should be familiar with and comfortable working on your vehicle. If you do not feel comfortable performing this installation,
it is recommended to have the installation completed by a qualified mechanic. If you have any questions, please call our Technical Hotline at:
1-800-416-8628, 7:00 am - 5:00 pm, Pacific Standard Time, Monday through Friday.
IMPORTANT NOTE: Proper installation is the responsibility of the installer. Improper installation
will void your warranty and may result in poor performance and engine or vehicle damage.
DESCRIPTION: Edelbrock Sure-Seat valve springs are made of high quality wire and are wound to close specifications for use with our Performer
RPM and Torker-Plus camshafts. These quality controlled springs are part of Edelbrock’s concept of a dyno-tested parts combination. In most cases
Sure Seat valve springs have inner dampeners, although some are true dual springs (#5757, #5762, etc.). Edelbrock springs are carefully inspected
for potential flaws and can be depended on for performance and durability.
CAUTION: For successful installation, use only the springs and parts recommended by Edelbrock for each camshaft application. These springs
are designed to be used for high-performance applications and must be used with high performance valve train components (screw-in studs, high
performance rockers, retainers, etc.). If you have any questions, do not hesitate to call our Technical Hotline at: 1-800-416-8628.
VALVE SPRING REMOVAL & REPLACEMENT: Due to the many years and models involved, it would be impossible to cover all applications. For
ease of installation and correct installation, we suggest you refer to a service manual for your year and model vehicle or Motors, Chilton, or Mitchell
service manuals for tools and procedures to follow.
CAUTION: The following instructions must be read and dimensions checked. These dimensions are critical and can cause parts wear and
possible breakage if not correct. Check your instruction sheet for correct spring part number and recommended installed spring height.
VALVE SPRING INSTALLED HEIGHT: Installed height is the dimension between
the valve spring retainer and cylinder head valve spring pad. See Figure 1
Dimension “A”. In some cases, spring shims may be needed for correct spring
setting.
NOTE: Remember Dimension “A” is valve spring length only. Include shims if
used. Never shim springs to a lesser dimension than recommended. Shimming
to a lesser dimension will cause coil bind or parts damage.
VALVE SEAL INSTALLATION: Improper installation of incorrect or special
aftermarket valve guide seals, without sufficient clearance between spring retainer
and valve guide seal, can cause camshaft and lifter wear and even parts breakage.
See Figure 1, Dimension “B”. Check Edelbrock camshaft specifications for
maximum valve lift.
NOTE: Dimension “B” should be a minimum of valve lift plus .050".
CAUTION: Failure to install springs and seals correctly may void warranty.
Edelbrock Sure Seat valve springs are supplied to cover engines using the same
valve spring for both intake and exhaust as one set.
NOTE: Check your vehicle and application sheet for correct spring selection.
SURE SEAT VALVE SPRINGS
Performer RPM and Torker-Plus
Part #5700 Series
INSTALLATION INSTRUCTIONS
Figure 1
Edelbrock Corporation • 2700 California St. • Torrance, CA 90503
Tech-Line: 1-800-416-8628 • Sales/Office Line: 310-781-2222

Part #5700 Series Valve Springs
Rev. 2/10 - AJ/mc
©2010 Edelbrock Corporation
Brochure #63-5700Page 2
VALVE SPRING/RETAINER/LOCK KITS For the following applications, Edelbrock valve springs with matching retainers and locks are available as complete kits: Application Kit # Small-block Chevrolet (includes #5703, #9730, and #9611) 5794 Big-block Chevrolet (includes #5762, #9731, and #9612 5795 Small-block Ford (includes #5722, #9733, and #9611 5796
Use Edelbrock Valve Stem Locks #9611 for 11/32" stem valves Use Edelbrock Valve Stem Locks #9612 for 3/8" stem valves CAUTION: Edelbrock valve stem locks are for single groove valves only! Some Ford and Chrysler applications have multi-groove valves.Check your valves before proceeding with installation.
I.D.O.D.Coil BindOpen Pressure
Press. @
Inst. Ht.
Max Vlv. Lift +
.050" (Dim. “B”)
Inst. Ht.
(Dim. “A”)Spring Type
Used with
Cam #
Install.
NotesPart #Engine
EDELBROCK #5700 SERIES SURE SEAT VALVE SPRING PART NUMBERS & SETTINGS
INSTALLATION NOTES: 1— Use #5767 for Edelbrock Performer RPM Aluminum Cylinder Heads for S/B V8s;
installed height = 1.800"
2— Inner spring will not clear stock valve seal; head must be machined for Perfect
Circle type seals
3— May be used on 318 c.i.d. if 340/360 heads are installed 4— 1967 & earlier must use early style lifters 5— Not for 1985 & later OEM roller lifter engines 6— Not for 429 “Shotgun”; not for 1988-’92 engines 7— Will fit 455 cylinder heads when used on 350 and 403 engines 8— Not for 1964 & earlier; not recommended for 350 c.i.d. a— Use retainers #9724 for 429/460; use retainers #9720 for 390-428 b— Use retainers #9730 c— Use retainers #9731 d— Use retainers #9732 e— Use retainers #9733 or #9724 for additional .100" installed height f— Use retainers #9734 g—Use retainers #9735 h— Use retainers #9736 i— Use retainers #9715 with keepers #9615
Chevrolet 262-400 V8 Chevrolet Gen III V8 (LS1) Chevrolet 396-454 V8 Chevrolet 396-454 V8 (Edelbrock Heads 60459) Chrysler 340-360 V8 Chrysler 383-440 V8 Ford 289-351W V8 Ford 390-428, 429-460 V8 Oldsmobile 350-403 V8 Pontiac 326-455 V8
5703 5768 5762 5745 5777 5792 5722 5767 5712 5757
1, b 2, c 2, i 3, d 4, f 5, e 1, 6, a 7, h 8, g
5002, 7102 2218 5062, 7162 5062, 7162 5077, 7177 5092 5022, 5082, 7122, 7182 5067, 7167, 7106 7112 5057
Single w/ Dampener Single
(Beehive)
Dual Dual Single w/ Dampener Single w/ Dampener Single w/ Dampener Single w/ Dampener Dual w/ Dampener Dual
1.700” 1.800” 1.880” 1.975” 1.650” 1.885” 1.770” 1.820” 1.750” 1.700”
.510”+.050”=.560” .600”+.050”=.650” .571”+.050”=.621” .571”+.050”=.621” .510”+.050”=.560” .480”+.050”=.530” .520”+.050”=.570” .581”+.050”=.631” .520”+.050”=.570” .488”+.050”=.538”
120 lbs. 138 lbs. 100 lbs. 120 lbs. 110 lbs. 130 lbs. 120 lbs. 105 lbs. 130 lbs. 112 lbs.
330 lbs @ 1.180” 326 lbs @ 1.200” 285 lbs @ 1.315” 330 lbs @ 1.425” 310 lbs @ 1.140” 310 lbs @ 1.385” 338 lbs @ 1.200 330 lbs @ 1.250” 300 lbs @ 1.220” 320 lbs @ 1.210”
1.130” 1.140” 1.150” 1.150” 1.070” 1.125” 1.140” 1.130” 1.050” .950”
1.130” 1.301”/ 1.066” 1.450” 1.080” 1.540”/ 1.130” 1.500” 1.550” 1.440” 1.460” 1.440”/ 1.000” 1.485”/ 1.110”
.880” .885”/ .650” 1.080”/ .800” 1.130”/ .805” 1.075” 1.120” 1.030” 1.060” 1.075”/ .755” 1.120” .830”
