Catalog #s 67112, 67113, 67152, 67153
©2006 Edelbrock Corporation Page 1 of 2
Brochure #63-67112
Rev. 5/06 - DA/mc
®
TUBULAR EXHAUST SYSTEM
Vehicle Applications: See Below
Catalog #67112, #67113
#67152, #67153
INSTALLATION INSTRUCTIONS
Please study these instructions carefully before installing your new Tubular Exhaust System (TES). If you have any questions, please
contact our Technical Hotline at : 1-800-416-8628 from 7 am - 5pm, Monday-Friday, Pacific Standard Time or e-mail us at
[email protected]. Please fill out and mail your warranty card.
TUBULAR EXHAUST SYSTEM: These components are designed as a system to improve the exhaust efficiency of the GM C.P.I.
(Central Port Injection) 4.3L V6 engine. A performance gain can be expected by the installation of the system. This system requires
no welding for installation and retains all O.E.M. emissions equipment.
APPLICATIONS:
Catalog #s 67112 / 67113 - 1996-1997 Chevy/GMC S-10/S-15 Pick-up, 4.3L V6, 2 W.D., Standard Transmission
Catalog #s 67152 / 67153 - 1998 Chevy/GMC S-10/S-15 Pick-up, 4.3L V6, 2 W.D., Standard & Automatic Transmissions
Suggested Tools Needed for Installation: This vehicle has some metric fasteners.
❑ 3/8” ratchet socket set with extensions and sockets
❑Combination set of open-end wrenches
❑ Jackstands, screwdrivers, pliers, crescent wrench, etc.
❑ Liquid penetrant (GM #1052627), anti-seize compound (GM #5613695)
SPECIAL NOTICE: This Edelbrock Tubular Exhaust System has received an Executive Order number (E.O.#) from the California Air
Resources Board (C.A.R.B.) making it legal for street use in all 50 states. To assist you with emission equipment certification, we
have included a silver fan shroud decal to help testing personnel verify the this part is a legal replacement on the vehicle for which
it is cataloged. The adhesive-backed decal should be affixed next to the existing emission and engine specifications decal. Do not
cover any part of your original emission decal.
WARNING: The use of "Thermal Wrap" or any aftermarket coating process will void the warranty on your Edelbrock Tubular
Exhaust Systems. Those products can cause excessive heat and moisture buildup resulting in corrosion and failure of the system.
NOTE: High temperature spark plug wires and boots are recommended to withstand heat from T.E.S.
IMPORTANT NOTE:
Proper installation is the responsibility of the installer. Improper installation will void warranty and may result in
poor performance and engine or vehicle damage.
Qty. PN Description
❑125-9447 Header left side (#67112 & #67152)
❑125-9446 Header right side (#67112 & #67152)
❑125-9123 Header left side (#67113 & # 67153)
❑125-9078 Header right side (#67113 & # 67153)
❑125-9648 Y-Pipe assembly (#67152 & #67153)
❑125-9659 Y-Pipe assembly (#67112 & #67113)
❑ 125-9647 Extension pipe left side
❑ 2 - Manifold port gaskets
❑ 2 - Donut connector gaskets
Qty. PN Description
❑ 1 - Catalytic converter flange gasket
❑ 1 - 2-1/4” U-Muffler clamp
❑ 11 -3/8”-16 x 1” Hex header bolts
❑ 4 - 3/8”-16 x 2” Hex bolts
❑ 8 - 3/8” Flat washers
❑ 16 -3/8” Lock washers
❑ 1 - 3/8” Ferry bolt
❑ 1 - 5/8” Spacer, 1-1/2” long
❑ 252-8097 O2 Sensor plugs
KIT CONTENTS
Catalog #67112 (Ceramic-Coated), #67113 (Ti-Tech Coated)
Catalog #67152 (Ceramic-Coated), #67153 (Ti-Tech Coated)

Catalog #s 67112, 67113, 67152, 67153
©2006 Edelbrock Corporation Page 2 of 2
Brochure #63-67112
Rev. 5/06 - DA/mc
DISASSEMBLY OF EXHAUST PIPES
1. Disconnect battery.
2. Raise vehicle and support with jackstands.
3. Use penetrating oil on all nuts and bolts to be removed.
4. Remove O2 sensors and unbolt exhaust pipes from
manifolds.
5. Unbolt from catalytic converter and remove assembly from
vehicle.
DISASSEMBLY LEFT SIDE
1. Remove spark plugs and wires.
2. Disconnect E.G.R. tube from manifold under car.
3. Remove plastic cover on lower steering shaft. Remove
bolt and slide shaft up and off steering box and push shaft
aside.
4. Disconnect temperature wire from cylinder head.
5. Unbolt and remove stock manifold from top side.
DISASSEMBLY RIGHT SIDE
1. Remove spark plugs and wires.
2. Unbolt dipstick bracket from cylinder head, do not remove
dipstick.
3. Unbolt and remove right side manifold from top side.
ASSEMBLY RIGHT SIDE
1. Start rear manifold bolt with gasket; lock and flat washers
in place, then screw in leaving enough space to accept
T.E.S. manifold. Note: Be sure spark plug clips do not
interfere with manifold surface.
2. Place manifold into vehicle with dipstick between first and
second primary tubes, slide manifold into position and
start all bolts using lock washers provided. (Lock and flat
washers on all slotted ends).
3. Re-attach dipstick to cylinder head using 1/4" bolt and
1/2" long spacer tube provided in kit.
4. Tighten all bolts at this time.
INSTALLATION INSTRUCTIONS
Edelbrock Corporation, 2700 California St., Torrance, CA 90503
Tech Line: 1-800-416-8628
E-Mail: [email protected]
ASSEMBLY LEFT SIDE
1. Remove E.G.R. adapter in stock manifold and place it in
T.E.S.
2. Start rear manifold bolt with gasket, lock and flat washers
in place, and screw in leaving enough space to accept
T.E.S. manifold. Note: Be sure the spark plug clips do not
interfere with manifold surface.
3. Slide manifold into position and start all bolts using lock
and flat washers on all slotted ends. Do not tighten yet.
Use ferry bolt and spacer for radiator hose support
bracket, tighten header.
4. Re-attach E.G.R. hose to manifold.
5. Re-attach steering shaft to steering box and replace cover.
6. Re-connect temperature sensor wire.
7. Install spark plugs and wires.
8. Replace air cleaner assembly.
ASSEMBLY OF EXTENSION PIPES
1. Raise vehicle and install both sides of extension pipes
using both donut gaskets and catalytic converter gasket.
Left side extension pipe uses flange connector. All provided
in kit.
2. Once everything is lined up, tighten down all hardware on
collectors and catalytic converter.
3. Replace 02 sensors in the locations that give best
clearance to body, frame and transmission. Some wire
rerouting may be necessary.
4. Use 02 plug provided in kit to plug unused 02 sensor
position.
5. Re-connect battery and start car to bring up to normal
operating temperature and check for leaks.
6. Turn engine off and let cool. Tighten all bolts again.
®
