EdgeStar BR1500BL User manual

Undercounter Kegerator
Owner’s Manual
V2.5-06092021www.edgestar.com
BR1500BL / BR1500SS
BR1500SSOD

2
Important Safety Information
Electrical Safety
Improper handling can cause serious damage to the EdgeStar kegerator and / or injury to the user. This
kegerator is designed for domestic use only. Do not use the unit for industrial or commercial use.
Any other use may invalidate the warranty. Please review the ratings label located on the rear panel of
the unit for electrical and other technical data related to this unit. The unit must be used in a properly
grounded wall outlet.
Please read and follow the safety information listed below to reduce the risk of re, electric
shock, or injury.
• Do not exceed the power outlet ratings.
• It is recommended the kegerator be connected on its own circuit.
• The unit must be installed in accordance with state and local electrical codes.
• A standard electrical supply (115 V, 60Hz), that is properly grounded in accordance with the National
Electrical Code and local codes and ordinances is required.
• Use outlets that cannot be turned o󰀨 by a switch or pull chain.
• Always turn the unit o󰀨 and unplug it from the outlet when cleaning.
• Unplug the unit if it is not going to be used for an extended period of time.
• Do not operate the unit with a power plug missing the ground plug, a damaged cord, or a loose
socket.
• Be sure the kegerator is properly grounded.
• Avoid installation in high humidity environments such as bathrooms and non-acclimatized
basements. Excess moisture may create condensation on the door and impact the performance of
the kegerator.
• Never plug or unplug the unit with wet hands.
• Do not bypass, cut, or remove the grounding plug.
• Do not use extension cords or power strips with this unit. You may need to contact your electrician
if it is necessary to use a longer cord or if you do not have a grounded outlet. Do not modify the
power cord’s length or share the outlet with other appliances.
• Do not start or stop the unit by switching the circuit’s power on and o󰀨.
• If the power cord is damaged, it must be replaced by the manufacturer or a qualied technician.
• Never repair the unit while it is plugged in.
• Immediately unplug the unit if it makes strange sounds, emits smells, or smoke comes out of it, and
contact customer service.
• Do not remove any part of the casing unless instructed to do so by an authorized technician.
• You should never attempt to repair the unit yourself. Contact customer service for service options if
the unit needs service.
DANGER: Flammable Refrigerant Used! When handling, moving, and using the kegerator,
make sure to avoid either damaging the refrigerant tubing or increasing the risk of a leak.
!

3
Important Safety Information
General Safety
• To prevent injuries, use at least two people to move and install the kegerator.
• Install the kegerator in a well-ventilated area where the ambient temperature is above 50° F and
below 95° F.
• The temperature range for this kegerator is optimized for storage. Perishable food items may
require a di󰀨erent storage environment.
• Do not place hot or warm items into the kegerator before they cool down to room temperature.
• This unit is designed to be installed indoors, and protected from rain, sleet, snow, and / or moisture.
• This unit is not intended to be used by children.
• Children should be supervised to ensure that they do not play with this product.
• Never allow children to crawl inside the kegerator. If you are disposing of the unit, remove the door.
• Do not use this appliance near ammable gas or combustibles such as gasoline, benzene, or
thinner.
• Do not store explosive substances such as aerosol cans with ammable propellant in this
appliance.
• Do not place the unit near heat sources such as ovens, grills, or direct sunlight.
• Only use in an upright position on a at, level surface and provide proper ventilation.
• Do not pinch or kink the power supply line between the unit and cabinet.
• Do not leave any cleaning solutions in the unit.
• Do not use solvent-based cleaning agents or abrasive solutions to clean the unit as they may
damage the interior and exterior.
• Do not place any other appliances on top of the unit.
• Do not turn the unit upside down, on its side, or at an angle o󰀨 level.
• If your model of kegerator is equipped with a lock, keep the keys away from children.
• Do not move the unit without emptying the contents and securing the door in a closed position.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory, or mental capabilities unless they are given supervision or instruction by a person
responsible for their safety.
• This appliance is meant for use in the household or similar settings.
• Keep all ventilation openings clear of obstruction.
• Do not use mechanical devices or other means to accelerate the defrosting process.
• Do not damage the refrigerant circuit.
• Do not use other appliances inside the kegerator unless recommended by the manufacturer.
• If the power cord is damaged, it must be replaced by the manufacturer, its service agent, or a
similarly
!
DISPOSAL: This appliance may not be treated as regular household waste, it should be
taken to the appropriate waste collection
!

4
Table of Contents
Important Safety Information ..........................................................................................2
First-Time Operating Instructions ...................................................................................5
Introduction.....................................................................................................................5
Parts Identication.......................................................................................................... 6
Installation ......................................................................................................................8
Unpacking the Kegerator.........................................................................................8
Types of Installation.................................................................................................8
Countertop Opening for Dispense Kit......................................................................9
Clearance Requirements.........................................................................................10
Seal Space Between Cabinet and Countertop........................................................ 11
Electrical Requirements ..........................................................................................12
Recommended Grounding Method ......................................................................... 12
Leveling the Kegerator ............................................................................................12
Installing the Door Handle....................................................................................... 13
Installing the Guard Rail.......................................................................................... 13
Installing the Drip Tray.............................................................................................13
Installing the Casters...............................................................................................14
Reversing the Door Swing.......................................................................................14
Keg Loading ............................................................................................................16
Operation........................................................................................................................17
Installation Checklist before Operation....................................................................17
Using the Temperature Control Panel ..................................................................... 17
Normal Sounds........................................................................................................18
Temperature Alarm .................................................................................................. 18
Door Ajar Alarm ....................................................................................................... 18
Defrosting................................................................................................................ 19
Preparing the Kegerator for Storage ....................................................................... 19
Cleaning and Maintenance.............................................................................................19
Troubleshooting.............................................................................................................. 20
Specications .................................................................................................................22
EdgeStar Limited Warranty ............................................................................................23

5
First-Time Operating Instructions
Before use, make sure all packaging labels and materials are removed from the unit. Be sure to keep
track of all included parts and pieces before discarding the packaging materials. It is advised that you
keep the original box and packaging materials in case you ever need to move or ship the appliance in
the future.
Let the unit stand for at least 24 hours before you use it; this allows the cooling components time to
settle from transit. The instruction manual should be read before use.
Introduction
Thank you for purchasing this EdgeStar kegerator. We hope that this purchase will be the beginning of
a lasting and rewarding relationship between you and EdgeStar. We will provide the customer support
and exemplary products necessary to nurture that relationship.
This manual contains important information regarding the proper installation, use, and maintenance of
your kegerator. Following this manual will ensure that your product will work at its peak performance
and e󰀩ciency.
Please save the original product packaging in case you need to safely transport your kegerator.
For Your Records:
Please write down the model number and serial number below for future reference. Both numbers are
located on the ratings label on the back of your unit and are needed to obtain warranty service. You may
also want to staple your receipt to this manual as it is the proof of your purchase, and is also needed
for service under your warranty.
Model Number: ________________________________
Serial Number: ________________________________
Date of Purchase: ______________________________
For a more e󰀩cient experience, please do the following before contacting customer service:
• If you received a damaged product, immediately contact the retailer or dealer who sold the product.
• Read and follow this instruction manual carefully to help you install, use, and maintain your kegerator.
• Read the troubleshooting section of this manual. It will help you diagnose and solve common issues.
• Visit us on the web at www.edgestar.com to register your product, download product guides, and
access additional troubleshooting resources and up-to-date information.
• For warranty service, customer service representatives are available at [e-mail].

6
Parts Identication
Front View:
Rear View:
Note: Gather the model and serial number from the product label and write them down
before installing the kegerator.
Cabinet
Product Label
Power Cord
Control Panel
Dispense Tower Opening
Leveling Leg
Internal Fan with Fan Pipe
Door Lock
Front Vent

7
Internal Fan:
This is an air-cooled unit equipped with an internal fan that maintains a consistent internal
temperature.
Accessories:
(1) Drip Tray (1) Guard Rail (4) Guard Rail
Installation Pegs
(1) Door Handle
(Not included with BR1500BL)
(4) Casters
(Includes 16 screws for
installation)
(4) Dispense Tower
Screws

8
Installation
The kegerator should be installed in accordance with local electrical code requirements. The kegerator
should also be placed in a location that is strong enough to support its total weight, keeping in mind that
it will weigh substantially more when fully loaded than when empty. Before you plug the kegerator
into a power supply, be sure to let it stand upright for at least 24 hours to allow the compressor’s
oils to settle.
Unpacking the Kegerator
Warning: Use two or more people to move and install the kegerator. Failure to do so
can result in back or other injury. Carefully remove the packaging materials. Remove any
shipping tape and glue from your kegerator before use. Do not use sharp instruments,
rubbing alcohol, ammable uids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your kegerator.
!
Warning: Do not remove any safety, warning, or product information labels from your
kegerator.
!
Warning: DO NOT install the kegerator behind a closed cabinet door.
This kegerator has been designed for freestanding or built-in installation. In each case, there must be
adequate ventilation and access for service.
Freestanding Installation:
A freestanding installation will allow you to install the kegerator in almost any place you desire. You
must follow the stated instructions for electrical requirements and leveling the kegerator.
Built-in Installation:
A built-in installation will allow you to install the kegerator under a counter as long as the required
clearance space around the kegerator is provided. It is necessary to allow adequate ventilation space
around the unit, including at the back of the unit.
This installation requires several more steps and considerations than a free standing installation.
Types of Installation
!
Note: Please refer to the dispense kit installation guide to complete the full assembly of the
kegerator.

9
Countertop Opening for Dispense Kit
Notes:
• Choose a location that has ambient temperatures above 50° F and below 95° F. Operation
outside these temperatures may result in lowered e󰀩ciency or cause other adverse e󰀨ects.
• This unit MUST be installed in an area protected from the elements, e.g. wind, rain, water
spray or drips.
• The kegerator should not be located next to ovens, grills, or other heat sources.
• Do not kink or pinch the power supply cord between the kegerator and the wall or cabinet.
Once the location of the kegerator installation is determined the rst step is to create an opening in the
counter for the dispense kit lines to pass through.
1. Mark o󰀨 a spot on the countertop where the opening will be created.
2. Align that spot so it will be directly above the opening of the kegerator that will be placed under the
counter.
3. Drill or cut (depending on the material of your countertop) an opening into your counter the same
size as the opening of the top of the kegerator.
4. Conrm that the opening is not larger than the size of the dispense tower for optimal performance.

10
Note: The kegerator should be installed on a rm and level surface that will be able to
support the entire weight of a fully loaded unit. It is important for the kegerator to be level
in order to work properly. If needed, you can adjust the height of the kegerator by rotating
the feet. See the “Leveling the Kegerator” section.
Note: A standard electrical supply (115V AC only, 60 Hz), properly grounded in accordance
with National Electrical Code and local codes and ordinances, is required.
Clearance Requirements
Make sure the top cover, guard rail, drip tray, and installation pegs are NOT installed on the top of the
cabinet. These items will create an obstacle for the cabinet to be installed under counter. Move the
kegerator so the opening on the top of the cabinet is aligned with the opening in the counter.
When installing the kegerator under a counter, follow the recommended spacing dimensions shown
below:
To ensure proper service access and ventilation, allow at least 1-2” of clearance at the back, 1/2” at
the top, and 1/4” at the sides. If the door side is against a wall, allow at least 2 3/8” of clearance. The
installation should allow the unit to be pulled forward for servicing, if necessary.
90
Door Swing
2“
16 3/16 "
2 /”
1-2”
1/4
” 1/4”
1/4”
1 - 2”
Top View: Side View:

11
Seal Space Between Cabinet and Countertop
Once the cabinet is installed and the two openings of the cabinet and countertop are aligned, you must
seal o󰀨 the open space that will be created above the kegerator cabinet and under the countertop. If this
open space is not properly sealed, the cabinet will lose its cold air and allow warm air to enter. Similarly
to leaving the kegerator door open, an improper seal can result in kegerator performance issues such
as temperature inconsistency, foam problems, and excessive frost build up in certain cases.
To close the opening you will need to run a short connecting tube from the cabinet to the countertop.
There is not an accessory included for this connection with the unit. Common materials for this
connection include PVC pipe, insulated pipe tubing, or rubber lining material. It is important to form a
seal between the kegerator cabinet opening and the bottom surface of the countertop. If you use PVC
or foam tubing, your sealing apparatus may extend from the interior of the kegerator cabinet up through
the countertop and into the base of the faucet tower.
Note: This installation tip applies to front vented, built-in capable kegerator models only.
Improper installation of a kegerator that is not intended for a built in application will result in
damage to your appliance.

12
ELECTRIC SHOCK HAZARD!
• Plug into a grounded 3-prong outlet.
• Never remove the grounding prong from the plug.
• Never use an adapter to bypass the grounding prong.
• DO NOT use an extension cord.
• Failure to follow these instructions can result in re, electrical shock, or death.
!
Electrical Requirements
Recommended Grounding Method
Before you move your Kegerator into its nal location, it is important to make sure you have the proper
electrical connection:
A standard electrical supply (115 V, 60Hz), properly grounded in accordance with the National Electrical
Code and local codes and ordinances is required.
It is recommended that a separate circuit, serving only your kegerator, be provided. Use receptacles
that cannot be turned o󰀨 by a switch or pull chain.
The fuse (or circuit breaker) size should be 15 Amps.
For your personal safety, this appliance must be grounded. It is equipped with a power supply cord that
has a 3-pronged grounding plug. To minimize possible shock hazard, the cord must be plugged into a
mating 3-pronged wall socket and grounded in accordance with the National Electrical Code and local
codes and ordinances. If a mating wall socket is not available, it is the personal responsibility of the
customer to have a properly grounded, 3-prong wall receptacle installed by a qualied electrician.
Leveling the Kegerator
It is important for the kegerator to be level in order to work properly. It can
be raised or lowered by rotating the plastic sheaths around each of the
feet on the bottom of the machine. If you nd that the surface is not level,
rotate the feet until the kegerator becomes level. You may need to make
several adjustments to level it. We recommend using a carpenter’s level
to check the machine.
1. Place a carpenter’s level on top of the product to see if the kegerator
is level from front to back and side to side.
2. Adjust the height of the feet as follows:
Turn the leveling feet to the right to lower that side of the kegerator.
Turn the leveling feet to the left to raise that side of the kegerator.
Note: Once you are ready to install the unit in a cabinet or directly on the oor, you must
adjust the feet to level the kegerator.

13
Installing the Door Handle
To install the door handle:
1. Remove the four screws from the side of the door. This should be the side opposite of the door
hinge.
2. Place and align the openings of the handle hinges over the screw holes in the side of the door.
3. Insert and tighten the screws to hold the handle in place.
Warning: Do not over-tighten the screws as this may cause damage to the handle or the
stainless steel door.
!
Installing the Guard Rail
Installing the Drip Tray
The guard rail helps to hold glasses on top of the cabinet in order to prevent spills and broken glass.
To install the guard rail:
1. Insert the four installation pegs on the outer edges of the top of the cabinet.
2. Place the guard rail onto the four installation pegs. You may need to push down on the guard rail
to ensure the rail has clicked into place on the pegs.
3. Screw the four small guard rail screws into the guard rail. This will lock the rail into position.
The surface mount drip tray is a reservoir designed to collect any runo󰀨 liquid from overlled glasses,
leaking faucets, or spills. There are two pieces included for this tray. Place it on top of the cabinet (or
countertop) and position under the faucet(s).

14
Warning: Before you begin, unplug the Kegerator.
!
Reversing the Door Swing
1. Open the door and using a Phillips screwdriver, remove the bottom screws from the lower hinge.
2. Carefully slide the bottom of the door forward and down, and place it on a padded surface to
prevent damage.
2
1
Installing the Casters
This unit comes with four (4) casters. These are an optional accessary to assemble if you would like
to make the unit more mobile. To install the casters:
1. Remove the four leveling legs from the bottom of the unit.
2. Separate the front casters and back casters. The front casters have a lever for a brake lock.
3. Place the top plate of the caster over the area of the removed leveling leg and align the opening
to the screw hole openings.
4. Insert the screws to attach the caster to the cabinet.
5. Make sure the screws are tight so the caster is installed rmly.

15
3. Remove the screws from the upper right hinge. Place the upper right hinge in a safe place in case
you need to reverse the door in the future. Remove the plastic caps from the upper left hinge
corner. Install the upper left hinge by fastening the screws through the left hinge to the cabinet.
Insert the plastic caps into the upper right corner.
4. Remove the lower hinge and washer from the lower right support bracket and install in the lower
left support bracket.
5. Remove the plastic screw cap from the lower right support bracket and install in the lower left
support bracket..
6. Carefully insert the door into the upper left corner hinge and then slide lide the door on top of the
lower hinge and secure the door by installing the lower screws.
34
6
5

16
Keg Loading
• Sixth Barrel Keg
• 5 lb. CO2tank
• CO2Regulator
• Slim Quarter Keg
• 5 lb. CO2tank
• CO2Regulator

17
Operation
Installation Checklist before Operation
Using the Temperature Control Panel
1. Have all packing materials and tape been removed from the interior and exterior of the kegerator?
2. Have the installation instructions been followed, including connecting the machine to electricity?
And has proper grounding been installed for the kegerator?
3. Has the machine been leveled?
4. Is the kegerator in a site where the ambient temperature is between 50° F and 90° F all year
round?
5. Is there a clearance of at least 1- 2” at the rear, 1/2” at the top, and 1/4” at the sides for proper air
circulation?
The kegerator has a temperature range from 32°F to 60°F and will display the set temperature.
Power Button: Press and hold for approximately 3 seconds to turn the unit on or o󰀨.
Up Button: Press to increase the temperature by 1 degree increments.
Down Button: Press to decrease the tempreature by 1 degree increments.
ºC/ºF
Run Light: When lit, the unit is in cooling mode.
i
Celsius/Fahrenheit Button: Press and hold for approximately 3 seconds to switch
between C and F. A beep will occur and the indicator light will illuminate next to desired
temperature setting.
Note: The internal LED light will illuminate when the door is open.

18
Note: The kegerator is equipped with a temperature memory function. If power is suddenly
lost, the previously set temperature will be saved and the Kegerator will return to this
setting once power is restored. Allow at least 24 hours before storing your items to allow
the setting temperature to be reached.
Caution: If you turned the unit o󰀨, please wait at least 5 minutes before turning it back on.
!
Normal Sounds
Your new kegerator may make noise during normal operation. Most of these sounds are normal. Hard
surfaces like the oor and walls can make sounds seem louder than they actually are.
The following describes several sounds you may hear and what may be making them:
• Rattling noises may come from the ow of the refrigerant or the water line. Items stored on top of the
kegerator can also make noises.
• The high e󰀩ciency compressor may make a pulsating or high-pitched sound.
• Water running from the evaporator to the water bin may make a splashing sound.
• As each cycle ends, you may hear a gurgling sound due to the refrigerant owing in your kegerator.
• You may hear air being forced over the condenser by the condenser fan.
Warning:
• Do not touch the power plug when your hands are wet.
• Never unplug the unit by pulling on the cord.
!
Temperature Alarm
If the interior temperature is higher than 73°F (23°C), “HI” is shown on the temperature
control panel and the temperature alarm will sound continuously after one hour.
This indicates that the inner temperature is too high. If the inner temperature is lower
than 23°F (-5°C), “LO” is shown on the temperature display panel and the temperature
alarm will sound continuously after one hour. If one of these situations occurs please
reference the troubleshooting section found in this manual or contact EdgeStar for support.
Door Ajar Alarm
This kegerator includes a door ajar alarm, which will sound if one of the doors is
open for more than three (3) minutes. Leaving the door open for extended periods of time
will cause poor cooling performance and may shorten the life of the kegerator. Keep
the doors closed as frequently as possible.

19
Warning: Never attempt to remove frost with a sharp object!
!
Defrosting
Preparing the Kegerator for Storage
Note that under most refrigerating settings, the unit will automatically defrost in most ambient conditions.
However, on colder settings, some frost may build up. Additionally, the more humid the ambient
conditions, the more frost may build up. Keep the door closed as much as possible and avoid opening
the door unnecessarily to minimize frost build-up. If frost is preventing the door from closing properly,
you may need to power the unit o󰀨 until the frost melts. Use a soft absorbent towel to dry the unit.
If the kegerator will not be used for a long time, or is to be moved to another place, it will be necessary
to defrost the unit and dry the interior.
1. Disconnect the Kegerator from the power supply by removing the power plug from the wall socket.
2. Leave the door open to allow for air circulation and to prevent mold, mildew, and unpleasant smells.
Caution: Store the unit out of reach from children. If you have children, you may want to
take precautions such as removing the door to prevent a child from being trapped inside.
!
Cleaning and Maintenance
Periodic cleaning and proper maintenance will ensure e󰀩ciency, top performance, and long life.
The door and cabinet may be cleaned with a mild detergent or hand soap mixed with warm water.
Do not use solvent based or abrasive cleaners. Use a soft sponge and rinse with clean water. Wipe
with a soft clean towel to prevent water spotting. If the door panel is stainless steel, it can discolor
when exposed to chlorine gas and moisture. Clean stainless steel using a cloth dampened with a mild
detergent and warm water solution. Never use an abrasive or caustic cleaning agent.
The kegerator’s interior should be cleaned occasionally.
1. Disconnect power to the unit.
2. Open the door and remove the contents and shelves.
3. Wait until the unit defrosts.
4. With a clean cloth, wipe down the interior of the unit.
5. Reinsert the shelves and items.
6. Reconnect power to the unit.
Exterior Cleaning
Interior Cleaning

20
Troubleshooting
If the unit appears to be malfunctioning, read through the “Operation” section of this manual rst. If
the problem persists, check the Troubleshooting Guide below and on the following page. The problem
may be something that can easily be solved or explained.
Before Calling for Help:
Symptoms Possible Causes Solutions
The kegerator turns on and
o󰀨 frequently.
The room temperature
is higher than the
recommended ambient
environment.
Run the kegerator at the appropriate
ambient temperature.
The door is being opened
too often.
Minimize the number of times the door
is opened.
The door is not completely
closed.
Make sure the door is completely
closed.
The door gasket is not
sealing properly.
Make sure the door gasket is sealing
properly.
The kegerator does not have
the suggested ventilation.
Read and follow the “Installation
Clearance Requirements” section.
The kegerator does not turn
on.
There is a power failure. Ensure that the kegerator is plugged
in and the power outlet has power.
The kegerator is not plugged
in.
Plug the unit in to a power outlet that
has su󰀩cient amperage.
A house fuse has blown or
the circuit breaker is tripped.
Replace the broken fuse in your fuse
box or reset the breaker.
The kegerator will not reach
the desired temperature.
The kegerator is placed too
close to a heat source.
Keep the kegerator away from direct
sunlight or other heat sources.
The kegerator does not have
su󰀩cient ventilation.
Read and follow the “Installation
Clearance Requirements” section.
The door is opened too
frequently or for a long
period of time.
Close the door tightly and do not open
the door too frequently or for a long
period of time.
The kegerator is making
strange noises.
Certain sounds are normal. Read the “Normal Sounds” section.
The unit is not level or is
touching another appliance.
Check to make sure that the kegerator
is level, and that it is not in contact
with another appliance or furniture.
The body of the kegerator is
electried.
The unit is not grounded
properly.
Contact your local electrician to test
your electrical grounding system.
