NPC ReverseTap RD BF1 User manual

ReverseTap In-counter Models
Installation Guide
( KEGERATOR SYSTEM )
Incounter Models
RD BF1
RD SF1
RD SF2
RD SF3
RD SF4
1
V2.0

ReverseTap In-counter Models Installation Guide ( Kegerator )
1. Decide a desired install position and cut out by the size shown below.
- Please refer to ReverseTap website for hole dimension for each dispenser model.
* Required tools : Drill, Jig-saw, Driver, Hose cutter, Knife, Hose clamps, etc.
V2.0
*Hand-drill
*Jig-saw
*Screw driver
*Hose-cutter
*Wrench
*Clamps
*Tape
*Scissors
*Tapeline
Model RD-BF1 RD-SF1 RD-SF2 RD-SF3 RD-SF4
Vertical 175mm 285mm
Horizontal 175mm 164mm 300mm 436mm 572mm
- To be installed on flat and smooth surface. ( Insulating cold air is a critical issue in kegerator system )
- Be careful not to get hurt by the flying debris during the cut out process.
( Wearing safety goggles is recommended )
- Clear the debris after the cut out process.
2. Connect the Flow meter to the Solenoid valve set.
①Remove a lid from the solenoid valve set and insert the flow sensor.
( Please aware that the flow sensor is to be inserted as the indicated direction only )
②Insert the flow sensor connector to the Board assembled with solenoid valve set.
( The flow sensor connector and the Board socket are 3-pin )
③Organize the cables.
( The flow sensor cable can be neatly wrapped around the solenoid valve set before inserted to the socket. )
* Please be careful not to have substances into the flow sensor.
①①
②③

3. Put ReverseTap on the desired surface.
- Silicone is wrapped around the bottom borders of the dispenser for sealing purpose.
Please be careful not to have it escape.
*Silicone for sealing
ReverseTap In-counter Models Installation Guide ( Kegerator )
4. Connect DC 24 V CONNECTOR CABLE with the main power cable of ReverseTap.
①The end part of DC 24 V CONNECTOR CABLE is a waterproof connector.
②DC plug of DC 24 V CONNECTOR CABLE is not waterproof, therefore keep it away from water and tape
around the joint part.
*DC 24 V CONNECTOR CABLE
* Organize the cables after connecting DC 24 V CONNECTOR CABLE with ReverseTap.
②
V2.0

6. Connect the power and run a function test.
-①ReverseTap power turns ON as soon as power is connected.
-②To individually turn ON/OFF each unit, press START/STOP button in its keypad for a few seconds.
-③Check if a cup is easily inserted and properly sensed.
-④Check if LED is lit properly.
-⑤Check if solenoid valves are opened with clicking sound.
-⑥Check if all buttons in each key pad work properly. ( the sensitivity of each button may slightly differ )
* Press START/STOP button in its keypad for a few
seconds to turn ON/OFF units individually.
* Assemble PROTECT COVER and NOZZLE COVER.
* Insert a cup to check LED, Solenoid valve functions correctly, and check all buttons work fine.
①
②②
③~⑥
ReverseTap In-counter Models Installation Guide ( Kegerator )
7. Tightly fasten main body of ReverseTap with the included Bracket set to the desired surface.
①Assemble bolts(M4 X 100mm) with wing nuts.
②Locate fastening clamps beneath the kegerator and fasten the bottom part of the dispenser with bolt-wing nut
assemblies. ( Total of 4 ea of fastening clamps are included in the product )
③Fasten wing nuts to tightly fix ReverseTap to the kegerator with fastening clamps.
( Loosened wing nuts may cause cold air escape and foreign substances flow in )
* Check the number of bracket sets and assemble bolts with wing
nuts.
①
②
③
* Bracket set and bolts fastening spots
V2.0

8. Connect beverage tubing to the flow sensor and the other end of beer line with a coupler.
①Flow sensor has fitting assembled already for 1/4 inch beer line.
( The inlet of flow sensor is 5/16 inch )
②For draft beer line : Approximately 3m long 1/4 inch(O.D) beer line must be used.
( Wind up a beer line several times and finish with taping for organizing )
ReverseTap In-counter Models Installation Guide ( Kegerator )
9. Connect the Drain hose set.
- Be careful not to bend drain hose too much, and organize for the easy drain.
- Connect the end of the drain hose to the sewers or a drain bucket.
5/16 inch
V2.0

ReverseTap In-counter Models Installation Guide ( Kegerator )
10. Install a coupler to a keg and set the CO2 gas pressure.
①Install a coupler to a keg and open the mid-valve, then set the gas pressure.
* Recommended pressure for draft beer : 13 psi ~ 16 psi
②Lock the gas pressure setting by fastening the lock nut.
③Gas pressure tend to adjust itself after some drinks are dispensed, so some calibrations are required initially.
①
②
11. Settings (Preset Mode, Dispensing Amount, FOB Mode)
- Now all steps for installing the ReverseTap dispenser is complete.
-Kegs must be cooled down to 2℃~4℃ for proper use of ReverseTap.
- For initial use, initial settings must be done in steps as the following.
- When a cup is inserted for the first time, the following screen will show due to the FOB Mode (Function for blocking
foam popping )
-Press the ‘STOP’ button to deactivate FOB Mode, and proceed in order of Cleaning →PRESET →Dispensing Amount →
FOB Mode Activation ( For detailed information, please refer to the S/W Manual or Quick User’s Manual)
Cleaning PRESET Dispensing
Amount FOB
* FOB Mode is activated in
the first cup insertion.
* Press the ‘STOP’ button to
deactivate the FOB Mode.
* Remove foam from the tubing
by operating Cleaning Mode.
* Measure the flow rate by
operating PRESET Mode.
* Enter the desired volume of
dispensing.
* Activate FOB Mode. * Confirm the FOB Mode turned
ON in the Standby screen.
V2.0
