Freestanding Wine Refrigerator
Owner’s Manual
For more information on other great EdgeStar products on the web, go to http://www.edgestar.com
To use the EdgeStar self-diagnostic tool, go to https://support.edgestar.com
CWF440SZ

i
Important Safety Information
Improper handling can cause serious damage to the EdgeStar wine refrigerator and / or injury
to the user. This wine refrigerator is designed for domestic indoor use only. Do not use the
unit for industrial or commercial use. Any other use may invalidate the warranty. Please
review the ratings label located on the rear panel of the unit for electrical and other technical
data related to this unit. The unit must be used in a properly grounded wall outlet.
Please read and follow the safety information listed below to reduce the risk of fire,
electric shock, or injury.
Electrical Safety
Do not exceed the power outlet ratings.
It is recommended the wine refrigerator be connected on its own circuit.
The unit must be installed in accordance with state and local electrical codes.
A standard electrical supply (115 V, 60Hz), that is properly grounded in accordance with the
National Electrical Code and local codes and ordinances is required.
Use outlets that cannot be turned off by a switch or pull chain.
Always turn the unit off and unplug it from the outlet when cleaning.
Unplug the unit if it is not going to be used for an extended period of time.
Do not operate the unit with a power plug missing the ground plug, a damaged cord, or a loose
socket.
Be sure the wine refrigerator is properly grounded.
Never plug or unplug the unit with wet hands.
Do not bypass, cut, or remove the grounding plug.
Do not use extension cords or power strips with this unit. You may need to contact your electrician if
it is necessary to use a longer cord or if you do not have a grounded outlet. Do not modify the power
cord’s length or share the outlet with other appliances.
Do not start or stop the unit by switching the circuit’s power on and off.
If the power cord is damaged, it must be replaced by the manufacturer or a qualified technician.
Never repair the unit while it is plugged in.
Immediately unplug the unit if it makes strange sounds, emits smells, or smoke comes out of it, and
contact customer service.
Do not remove any part of the casing unless you are instructed to do so by an authorized
technician.
You should never attempt to repair the unit yourself.
Contact customer service for service options if the unit needs service.

ii
Note: This owner’s manual is provided for reference use only. Specifications may change
without prior notice. Refer to the product label on the back of your wine refrigerator for the
latest technical information.
General Safety
To prevent back and other types of injuries, use at least two people to move and install the wine
refrigerator.
This appliance is not intended for use by persons, including children, with reduced physical, sensory
or mental capabilities, unless they have been given supervision or instruction concerning the use of
the appliance by the person(s) responsible for their safety.
Install the wine refrigerator in a well-ventilated area where the ambient temperature is above 50° F
and below 95° F.
The temperature range for this refrigerator is optimized for wine and beverage storage. Perishable
food items may require a different storage environment.
Do not place hot or warm items into the refrigerator before they cool down to room temperature.
This unit is designed to be installed indoors, and protected from rain, sleet, snow, and / or moisture.
This unit is not intended to be used by children.
Children should be supervised to ensure that they do not play with this product.
Never allow children to crawl inside the wine refrigerator. If you are disposing of the unit, remove the
door.
Do not use this appliance near flammable gas or combustibles, such as gasoline, benzene, thinner,
etc.
Do not place the unit near heat sources such as ovens, grills, or direct sunlight.
Only use in an upright position on a flat, level surface and provide proper ventilation.
Do not pinch or kink the power supply line between the unit and cabinet.
Do not leave any cleaning solutions in the unit.
Do not use solvent-based cleaning agents or abrasive solutions to clean the unit as they may
damage the interior and exterior.
Do not place any other appliances on top of the unit.
Do not turn the unit upside down, on its side, or at an angle off level.
If your model of wine refrigerator is equipped with a lock, take care to keep the keys away from
children.
Do not move the unit without emptying the contents and securing the door in a closed position.
Note: Flammable Refrigerant Used! When handling, moving, and using the refrigerator, make
sure to avoid either damaging the refrigerant tubing, or increasing the risk of a leak.

iii
Table of Contents
IMPORTANT SAFETY INFORMATION.....................................................................................................................I
TABLE OF CONTENTS ...........................................................................................................................................III
First Time Operating Instructions...............................................................................................................................1
INTRODUCTION........................................................................................................................................................1
PARTS IDENTIFICATION ......................................................................................................................................... 2
Front View..................................................................................................................................................................2
Back View...................................................................................................................................................................2
INSTALLING THE WINE REFRIGERATOR............................................................................................................. 3
Unpacking the Wine Refrigerator...........................................................................................................................3
Installation..................................................................................................................................................................3
Electrical Requirements.............................................................................................................................................4
Leveling the Wine Refrigerator ..................................................................................................................................5
Installing the Door Handle.......................................................................................................................................... 5
Removing and Installing Decorative Plugs ................................................................................................................6
Installing and Removing the Shelves.........................................................................................................................7
Reversing the Door Swing .........................................................................................................................................8
OPERATION............................................................................................................................................................10
Installation Check List Before Operation..................................................................................................................10
Using the Temperature Control Panel .....................................................................................................................10
Bottle Positioning .....................................................................................................................................................11
Normal Sounds ........................................................................................................................................................12
Defrosting.................................................................................................................................................................12
Preparing the Wine Refrigerator for Storage ...........................................................................................................12
CLEANING AND MAINTENANCE..........................................................................................................................13
Exterior Cleaning......................................................................................................................................................13
Interior Cleaning.......................................................................................................................................................13
TROUBLESHOOTING.............................................................................................................................................14
SPECIFICATIONS................................................................................................................................................... 16
EDGESTAR LIMITED WARRANTY........................................................................................................................17

1
First Time Operating Instructions
Before use, make sure all packaging labels and materials are removed from the unit. Be sure
to keep track of all included parts and pieces before discarding packaging materials. It is
advised that you keep the original box and packaging materials in case you ever need to move
or ship the appliance in the future.
Let the unit stand for at least 24 hours before you use it; this allows the cooling components
time to settle from transit. The instruction manual should be read before use.
Introduction
Thank you for purchasing this EdgeStar wine refrigerator. We hope that this purchase will be
the beginning of a lasting and rewarding relationship between you and EdgeStar. We will
provide the customer support and exemplary products necessary to nurture that relationship.
This manual contains important information regarding the proper installation, use, and
maintenance of your wine refrigerator. Following this manual will ensure that your product will
work at its peak performance and efficiency.
Please save the original product packaging in case you need to safely transport your wine
refrigerator.
For Your Records:
Please write down the model number and serial number below for future reference.
Both numbers are located on the ratings label on the back of your unit and are needed
to obtain warranty service. You may also want to staple your receipt to this manual as it
is the proof of your purchase, and is also needed for service under your warranty.
Model Number:
Serial Number:
Date of Purchase:
For a more efficient experience, please do the following before contacting customer service:
If you received a damaged product, immediately contact the retailer or dealer that sold you
the product.
Read and follow this instruction manual carefully to help you install, use, and maintain your
wine refrigerator.
Read the troubleshooting section of this manual as it will help you diagnose and solve
common issues.
Visit us on the web at http:/www.edgestar.com to register your product, download product
guides, and access additional troubleshooting resources and up-to-date information. You
can also find an interactive self-diagnostic tool at https://support.edgestar.com
If you need warranty service, our friendly customer service representatives are available
via email at serv[email protected].

2
Parts Identification
Front View
Back View
Note: The carbon filter
should be replaced
every 3-6 months
depending on the
unit’s exposure level
to odor. If the unit is
placed in the kitchen
regular replacement
every 3 months is
ideal.
Tip: Gather the model and serial number from the product label and write them down before
installing the wine refrigerator.
Note: The carbon filter (Part # PCWRFILTER) should be replaced every 3‐6 months
depending on the unit’s exposure level to odor. If the unit is placed in a kitchen, regular
replacement every three (3) months is ideal.

3
Warning: Use two or more people to move and install the wine refrigerator. Failure to do so
can result in back or other injury. Carefully remove the packaging materials. Remove any
shipping tape and glue from your wine refrigerator before use. Do not use sharp instruments,
rubbing alcohol, flammable fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your wine refrigerator.
Important: Do not remove any safety, warning, or product information labels from your wine
refrigerator.
Installing the Wine Refrigerator
The wine refrigerator should be installed in accordance with local electrical code requirements.
The wine refrigerator should also be placed in a location that is strong enough to support its
total weight, keeping in mind that it will weigh substantially more when fully loaded than when
empty. Before you plug the wine refrigerator into a power supply, be sure to let it stand
upright for at least 24 hours to allow the compressor’s oils to settle.
Unpacking the Wine Refrigerator
Installation
This wine refrigerator has been designed for free-standing installation. There must be
adequate ventilation and access for service.
Free-standing Installation:
A free-standing installation will allow you to install the wine refrigerator in almost any place
you desire as long as there is proper ventilation. This product is not designed to be built
into a cabinet or recessed setting. You must follow the stated instructions for electrical
requirements, and leveling the wine refrigerator.
Choose a location that has ambient temperatures above 50° F and below 95° F.
Operation outside these temperatures may lead to lowered efficiency or other adverse
effects.
This unit MUST be installed in an area protected from the elements, e.g., wind, rain,
water spray or drips.
The wine refrigerator should not be located next to ovens, grills, or other high heat
sources.
Do not kink or pinch the power supply cord between the wine refrigerator and the wall
or cabinet.
The wine refrigerator should be installed on a firm and level surface that will be able
to support the entire weight of a fully loaded unit. It is important for the wine
refrigerator to be level in order to work properly. If needed, you can adjust the height
of the wine refrigerator by rotating the feet. See the “Leveling the Wine Refrigerator”
section.
A standard electrical supply (115 VAC only, 60 Hz), properly grounded in accordance
with National Electrical Code and local codes and ordinances, is required.
Tip: Gather the model
and serial number
from the product label
and write them down
before installing the
wine refrigerator.
Warning: DO NOT install the wine refrigerator behind a closed cabinet door.

4
Electrical Shock Hazard!
Plug into a grounded 3-prong outlet.
Never remove the grounding prong from the plug.
Never use an adapter to bypass the grounding prong.
DO NOT use an extension cord.
Failure to follow these instructions can result in fire, electrical shock, or death.
Installation Clearance Requirements
To ensure proper ventilation and service access, allow at least 3” of clearance at the sides
and top of the wine refrigerator, and at least 5” of clearance at the back. Do not install this
unit in a built-in undercounter setting.
Electrical Requirements
Before you move your wine refrigerator into its final location, it is important to make sure you
have the proper electrical connection:
A standard electrical supply (115 V, 60Hz), properly grounded in accordance with the National
Electrical Code and local codes and ordinances, is required.
It is recommended that a separate circuit, serving only your wine refrigerator, be provided. Use
receptacles that cannot be turned off by a switch or pull chain.
The fuse (or circuit breaker) size should be 10-15 Amps..

5
Important: Once you are ready to install the unit in a cabinet or directly on the floor, you must
adjust the feet to level the wine refrigerator.
Note: Some wine refrigerators do not have decorative plugs installed.
Caution: Do not over-tighten the screws as this may cause damage to the handle or to the
stainless steel door.
Recommended Grounding Method
For your personal safety, this appliance must be grounded. It is equipped with a power
supply cord that has a 3-pronged grounding plug. To minimize possible shock hazard, the
cord must be plugged into a mating 3-pronged wall socket, and grounded in accordance
with the National Electrical Code and local codes and ordinances. If a mating wall socket is
not available, it is the personal responsibility of the customer to have a properly grounded,
3-prong wall receptacle installed by a qualified electrician.
Leveling the Wine Refrigerator
It is important for the wine refrigerator to be level in order to work properly. It can be raised or
lowered by rotating the plastic sheaths around each of the feet on the bottom of the machine. If
you find that the surface is not level, rotate the feet until the wine refrigerator becomes level .You
may need to make several adjustments to level it. We recommend using a carpenter’s level to
check the machine.
1. Place a carpenter’s level on top of the product to see if the wine refrigerator is level from front
to back and side to side.
2. Adjust the height of the feet as follows:
Turn the leveling feet to the right to lower that side of the refrigerator.
Turn the leveling feet to the left to raise that side of the refrigerator.
Installing the Door Handle
To install a door handle:
1. Open the door and carefully pull the door gasket around the area where the handle will be
installed.
2. Carefully remove the two pre-installed decorative plugs from the front of the door.
3. Insert each Philips head screw through the gasket side of the door until the screw passes
through the door.
4. Align the handle with the screws and tighten them using a Philips head screwdriver until
the handle is flush against the door frame.
5. Carefully press the door gasket into its original position.

6
Removing and Installing Decorative Plugs
Follow the instructions below to remove the decorative plugs from the door.
1. Open the door and carefully pull the door gasket from the top left corner until you have
exposed the two holes which correspond with the decorative plugs.
Note: A small Flathead screwdriver is required.
2. Insert the Flathead screwdriver through the gasket side of the door into the decorative
plug slot. You may need to use a flashlight to help guide you through this process.
3. Carefully turn the screwdriver clockwise to remove the two pre-installed decorative plugs
from the front of the door. Reinsert the decorative plugs into the right side of the door
using this same procedure.
Important: Before you begin, unplug the refrigerator.
