EdgeStar CWR450DZ User manual

http://www.edgestar.com
This owner’s manual provides
instructions on safe installation,
use, and maintenance.
Please read it carefully and
save it for reference.
CWR450DZ
Built in Wine Cellar
Owner’s Manual

Table of Contents
First Time Operating Instructions
Before use, make sure all packaging labels and materials
are removed from the unit. Be sure to keep track of all
included parts and pieces before discarding packaging
materials. It is advised that you keep the original box and
packing materials in case you are ever to move or ship the
unit in the future.
Let the unit stand for at least 24 hours before use; this
allows the cooling components to settle from transit. The
instruction manual should be thoroughly read before use.
1
Important Safeguards……………………………………. 2
Specifications……………………………………………... 3
Parts and Features……………………………….………. 4
Installation…………………………………………………. 5
Operation………………………………………………...... 5
Temperature Control………………………………...…… 6
Rack Removal and Insertion………………………….. 7
Troubleshooting…………………………………………… 8
Limited Warranty………………………………………….. 10

IMPORTANT SAFEGUARDS
When using an electrical appliance, basic precautions should always be
followed, including the following:
BEFORE USE, PLEASE READ AND FOLLOW ALL INSTRUCTIONS FOR
THIS WINE COOLER
•Do not use if the power supply cord is damaged. If damaged, it must be
replaced by the manufacturer or a similarly qualified person.
•This wine cooler is not intended for use by young children without
supervision. Young children must be supervised to ensure they do not
play with the appliance.
•Ensure the cooler is unplugged before cleaning or if not in use.
•To clean the cooler use only mild detergents or glass cleaning
products. Never use harsh detergents or solvents.
•It is not recommended to use this wine cooler with an extension cord or
power strip. Please ensure that the appliance is plugged directly into
the electrical outlet.
•When positioning the wine cooler, ensure that there is at least a 2”
clearance at the sides and a 4” clearance at the back of the cooler.
This will allow for adequate ventilation of heat from the back of the
cooler.
•This cooler is designed to store wine bottles. If food is placed inside,
ensure that there is sufficient airflow between items. Also note that the
temperature range for this cooler is optimized for wine and beverage
storage. Perishable food items may require a different storage
environment.
•Do not place hot food or drinks into the wine cooler before they cool
down to room temperature.
•Close the cooler door immediately after putting in any items so the
inside temperature will not rise dramatically.
•Avoid subjecting the cooler to external heat sources or direct sunlight.
•For a stable installation, make sure the cooler is placed on a flat, level,
and solid surface.
•Make sure that the surface on which the wine cooler is placed is strong
enough to hold the wine cooler once it is fully loaded with wine bottles.
•Do not place any other appliances on top of the wine cooler.
•The wine cooler is an electrical appliance. To avoid injury or death from
electrical shock, do not operate the wine cooler with wet hands, while
standing on a wet surface, or while standing in water.
•Do not use outdoors or in wet or moist conditions.
•Do not turn the cooler upside down, on its side, or 45° or more off level.
•Never pull the power cord to disconnect it from the outlet. Grasp the
plug and pull it from the outlet.
•Never lift or carry the wine cooler by the power cord.
•Keep the power cord away from heated surfaces.
•This wine cooler is designed for household, non-commercial use only.
2
•Do not plug this cooler into the power socket before set up is completed.

•An empty cooler can be dangerous for children. If disposing of the
cooler remove gaskets, latches, lids and the entire door from your
unused appliance, or take other action to ensure that children cannot
become trapped inside.
•If your model of wine cooler is equipped with a lock, take care to keep
the keys away from children.
•Do not cut or remove the third prong (the grounding prong) from the
power cord.
•The cord should be secured behind the unit and should not be left
exposed or dangling.
•Do not move this cooler without emptying it of its contents and securing
the door in a closed position.
1. Specifications
3
Model Number CWR450DZ
Capacity 45 bottles
Input Power 140W
Rated Frequency 60Hz
Power Consumption 1.2kw.h/24h
Cooling System R134a
Ambient Temp 86.5°F
Temperature Range 45～65°F
Rated Voltage 115V
Weight 147 Lbs
Dimensions (HxWxD) 34 3/4”x 23 15/16" x 22"

2. Parts and Features
Important Note: Even if your refrigerator looks slightly different; the operation
will essentially be the same. Picture is provided for reference.
1 Dual-pane window
2 Front grill
3 Adjustable legs
4 Main shelving
5 Cabinet
6 PCB Cover
7 Temp. adjustment (upper shelves)
8 LED display (upper shelves)
9 Light button
10 Temp. adjustment (lower shelves)
11 LED display (lower shelves)
4

3. Installation
•Remove all exterior and interior packaging materials before use.
•Check that you have all parts and copy of instruction manual.
•Place your wine cooler on a flat, dry surface, strong enough to support
the unit when fully loaded.
•The unit is designed to be built-in (recessed) or free standing.
•Do not place heavy objects on top of the unit.
•The unit is not designed for installation in a garage or basement.
•Do not place in direct sunlight or near sources of heat. Extreme hot and
cold temperatures may cause the unit to perform improperly, increase
electrical consumption, or cause damage.
•Do not place next to a major appliance that emits large amounts of
heat. (Such as ovens, microwaves, dishwashers, etc.)
•Do not share unit with the same outlet as a refrigerator or microwave.
•Before connecting to the power source, let the unit stand upright for
approximately 24 hours. This will reduce the possibility of a malfunction
in the cooling system from handling during shipping and transportation.
•Gently clean the unit’s interior surface with warm water, using a soft
cloth before first use.
4. Operation
1. Carefully slide the racks in the wine cellar.
2. Determine the best temperature setting to use for your wine.
3. Place bottles gently inside cooler.
4. Plug the power cord into a standard grounded electrical outlet.
5. Keep door closed to conserve energy and maintain proper storage
temperature.
6. You can turn the interior light on and off by pressing the ‘Light’ button
on the front control panel of the unit.
7. If unit is equipped with a lock, insert provided key and turn to operate.
Important Note: When using the unit for the first time, allow at least 24 hours
for the internal temperature to become adjusted properly. Also make sure
there are at least three to five bottles in the unit.
5

5. Temperature Control
Preset temperature control:
This unit is factory programmed at ‘storing’ temperature.
The manufacturer presets the temperature for the upper
three shelves (white wines) at 48°F (9°C). The red wines
are stored on the lower three shelves, where the
temperature is preset at 56°F (13°C).
Manual temperature control:
To manually adjust temperature, press the ( - ) button on
the control panel to decrease, and the ( + ) button to
increase by 1degree inside the unit. The upper three
shelves (white wines) have a range from 45°F (7°C) to
54°F (12°C), and the lower (red wines) have a range of
54°F (12°C) to 65°F (18°C).
When the temperature of the unit becomes too low, the
LED will display “LL”, likewise, when the temperature is
too high, it will display “HH”. The unit will display “ER” in
the event of an error or power disruption.
Important Note: This unit will operate best in a room with
a temperature of less than 90°F (32°C).
6

6. Wine Rack Removal and Installation
Important Note: Make sure the door is completely open before removing
racks to avoid damage.
1. Remove any stored bottles.
2. Pull the racks out horizontally and press the button in on each side. (Fig. 1)
3. Push the racks into sliders. (Fig. 2)
Important Note: The bottom rack cannot be removed.
7

7. Troubleshooting
Symptoms Possible causes
8
Solutions
The wine
cooler does
not turn on.
There is a power
failure.
The cooler is not
plugged in.
A house fuse has
blown or the circuit
breaker is tripped.
Ensure the cooler is
plugged in and the
power outlet has power.
Replace the broken fuse
in your fuse box or reset
the breaker.
The wine
cooler will
not reach the
desired
temperature
The cooler is placed
too close to a heat
source.
The cooler does not
have sufficient
ventilation.
The door is opened
too frequently or for a
long period of time.
Keep the cooler away
from sunshine or other
heat sources.
Make sure the wine
cooler has several
inches of ventilation on
the sides and back.
Close the door tightly
and do not open the door
too frequently or for a
long period of time.
Frost is
forming in
the wine
cooler
The environment is
humid.
The ambient
temperature is too
low.
The door is being
opened too
frequently.
Though the unit uses an
“auto-defrost” system,
under certain conditions,
manual defrosting may
be required. If frost
builds up, you can try
running the cooler on a
warmer temperature
setting, minimizing the
number of times you
open the door, or
unplugging the unit to
allow the frost to melt.

Symptoms Possible causes
9
Solutions
The cooler
turns on and
off
frequently.
The room
temperature is higher
than the
recommended
ambient temperature
(77°F).
The door is being
opened often.
The door is not
completely closed.
The door gasket is
not sealing properly.
The cooler does not
have the suggested
ventilation.
Run the cooler in the
appropriate ambient
temperature.
Minimize the number of
times the door is
opened.
Make sure the door is
completely closed.
Make sure the door
gasket is properly
sealing.
Make sure the cooler
has at least 2” on the
sides and 4” in the back
for clearance.
The cooler
makes too
much noise.
If the noise is from
the fan, it may be
normal operating
noise.
The unit is not level.
Popping or crackling
noises are coming
from the unit.
The fan will make some
noise when operating-
this is normal.
Make sure the cooler is
on a level surface.
Some popping or
crackling noises are
normal. They are caused
by expansion and
contraction of the inside
walls due to temperature
changes.
The door will
not shut
properly.
Your cooler is not
level.
The door gasket is
dirty.
The door gasket is
malformed.
The shelves are
incorrectly installed.
Make sure the cooler is
on a level surface.
Clean the door gasket.
Make sure the door
gasket is properly
sealing.
Correctly install the
shelves.

8. Limited Warranty
This EdgeStar product is warranted to be free from defective workmanship
and materials for the first year following the date of original purchase.
Replacement parts will be supplied free of charge for the first year following
the date of original purchase. Labor will be performed free of charge for the
first 90 days following the date of original purchase.
WHAT IS COVERED:
This warranty applies to the original purchaser only, and only covers defects
in workmanship experienced during operation of the product under normal
service, maintenance, and usage conditions. This warranty applies to the
purchase and use of this product in residential settings within the United
States of America.
WHAT IS NOT COVERED:
The following limitations apply to the coverage of this warranty:
- Optional accessories, attachments, and appearance items are
excluded from warranty coverage, as is shipping damage, and any
damage caused by improper voltage or any other misuse, including
abnormal service, handling, or usage.
- This warranty does not cover normal wear and tear on parts or
replacement of parts designed to be replaced, e.g. filters, etc.
- This warranty does not cover service trips to deliver, pick-up, repair, or
install the product, or to instruct in proper usage of the product.
- Damages or operating problems resulting from abuse, operation
outside environmental specifications, uses contrary to instructions
provided in the owner’s manual, accidents, vermin, fire, flood, improper
installation, unauthorized service, acts of God, unauthorized installation
or modification, or commercial use are excluded from warranty
coverage.
- This warranty does not cover labor incurred 91 days or more after the
date of original purchase.
- This warranty does not cover use of EdgeStar products in commercial
settings.
DESCRIPTION OF WARRANTY SERVICE:
All defective product components covered by this warranty will be repaired or
replaced, at EdgeStar’s option, free of charge on a mail-in basis to EdgeStar’s
authorized repair facility during the first 90 days from the date of original
purchase.
10
All defective product components covered by this warranty will be repaired or
replaced, at EdgeStar’s option, on a mail-in basis to EdgeStar’s authorized
repair facility during the time period beginning on the 91st day from the date of

11
original purchase and ending one year from the date of original purchase.
During this time period, parts will be supplied free of charge, but labor charges
will apply. All replacement parts and units will be new, remanufacturered, or
refurbished. All products and components replaced by EdgeStar under
warranty service become the property of EdgeStar.
OBTAINING WARRANTY SERVICE:
Contact EdgeStar for troubleshooting assistance and warranty service
authorization at 1-866-319-5473. Please have your order receipt available to
confirm the date of purchase. Once an EdgeStar authorized representative
has confirmed that your product is eligible for warranty service, the product
must be returned to an EdgeStar authorized repair facility. The purchaser is
solely responsible for prepaying all shipping related costs to and from the
repair facility. EdgeStar is not responsible for damage resulting from shipper
mishandling or improper packaging.
Do not return defective product to the place of purchase.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR
IMPLIED, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO
THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS
LIMITED IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE.
NEITHER THE MANUFACTURER NOR ITS DISTRIBUTORS SHALL BE
LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL,
OR PUNITIVE DAMAGES OF ANY NATURE, INCLUDING WITHOUT
LIMITATION, LOST REVENUES OR PROFITS, OR ANY OTHER DAMAGE
WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. SOME
STATES DO NOT ALLOW THE EXCLUSION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO
STATE.

For information on EdgeStar and to view our
full line of products, please visit our website:
http://www.edgestar.com
EdgeStar Products
Box 81336
Austin, Texas 78708-1336
Toll Free: 1-866-319-5473
