158CS
158CS Center Sport
OWNER ASSISTANCE MANUAL

158CS SPECIFICATIONS
LENGTH: 15’ 1” (4.6m)
BEAM: 6’ 7” (2.0m)
DRAFT (boat only): 10” (25.4cm)
BOAT WEIGHT: 900lbs (408.23kg)
WEIGHT CAPACITY: 1400lbs (636kg)
PERSON CAPACITY: 6
PERSON WEIGHT: 750lbs (341kg)
FUEL CAPACITY: 13 gal (49.21L)
TRANSOM HEIGHT: S-20
MAX POWER: 90hp (67kw)
MAX ENGINE WEIGHT: 325lbs (147.4kg)
COCKPIT DEPTH: 15.5” (39.3cm)
COCKPIT AREA: 39sq/ft (3.62m²)
APPROX LENGTH ON TRAILER: 21’ (6.4m)
BRIDGE CLEARANCE:
W/OUT TOP 4’ 6” (1.37m)
W/SUNTOP 6’ 6” (1.98m)
FLOTATION: UNSINKABLE LEVEL
HULL DEADRISE: 18°
U.S. Coast Guard CE
Maximum Capacities 6 PERSONS OR 341kg
6PERSONS OR 750 LBS 67kw MAX POWER
1400LBS PERSONS, MOTORS, GEAR CRATING
90 H.P. MOTOR

Owner’s Manual
158 CS
4-1-2014

2
Dear EdgeWater 158 CS owner:
Congratulations on purchasing one of the finest small boats ever built. It has been constructed with
care from the finest available materials. At EdgeWater we take great pride in the quality and
craftsmanship that goes into each boat, large or small. We believe you’ll have many years of
enjoyment from your new EdgeWater and thank you for entrusting your leisure time to one of our fine
products.
This manual has been assembled to help you learn more about your new boat and increase your
enjoyment of it. Your EdgeWater has been built for a “Lifetime on the Water”.
Boat safe and boat smart, we wish you many years of boating pleasure.
Sincerely,
Peter Truslow
President
EdgeWater Power Boats

3
Service Information
Please fill out the information below completely. It will help us in assisting you in the event your
EdgeWater needs service.
Customer Name ______________________________________________________________________
Address _____________________________________________________________________________
City __________________________________________ State Zip
Phone _________________________Cell _____________________Business _____________________
E-mail Address _______________________________________________________________________
Dealer Name _________________________________________________________________________
Address _____________________________________________________________________________
City ___________________________________________ State ______ Zip ______________
Phone _________________________________________ Fax __________________________________
Purchase Date __________________________________ Engine Make/Model ____________________
Delivery Date ___________________________________ Engine Serial # _________________________
Hull Number __DMA______________________________ Ignition Key # ___________________________
EdgeWater Power Boats, LLC. reserves the right to make alterations in the standard and
optional equipment without incurring obligation to those boats already having been built.
Every effort has been made to ensure that the information in this manual accurately
describes vessels being built at the date of printing.

4
Table of Contents
Chapter 1 General Information .................................................................6
1.1 General..............................................................................................................................6
1.2 Owner / Operator Responsibilities......................................................................................6
Chapter 2 Helm Control Systems.............................................................7
2.1 General..............................................................................................................................7
2.2 Steering System.................................................................................................................7
2.3 Engine Throttle and Shift Controls......................................................................................7
Chapter 3 Propulsion System...................................................................8
3.1 General..............................................................................................................................8
3.2 Engine Cooling System......................................................................................................9
3.3 Propellers ..........................................................................................................................9
3.4 Engine Power Tilt and Trim................................................................................................9
3.5 Engine Instrumentation ...................................................................................................10
Chapter 4 Electrical System ...................................................................11
4.1 General ............................................................................................................................11
4.2 Accessory Panel Switches ...............................................................................................11
4.3 Electrical System Maintenance ........................................................................................12
Chapter 5 Drainage System ................................................................... 12
5.1 General ............................................................................................................................12
5.2 Drain System Maintenance ..............................................................................................12
5.3 Cockpit Drains..................................................................................................................12
5.4 Transom Bilge..................................................................................................................12
5.5 Locker Drain........................................................................................................................12
Chapter 6 Safety Equipment...................................................................13
6.1 Required Safety Equipment ............................................................................................13
6.2 Suggested Safety Equipment - Inshore ............................................................................14
6.3 Suggested Safety Equipment – Offshore .........................................................................14
Chapter 7 Safe Operation .......................................................................15
7.1 Pre-Cruise Check List ......................................................................................................15
7.2 Basic Rules of the Road...................................................................................................16
7.3 Safe Operation.................................................................................................................17
7.4 Towing or Being Towed....................................................................................................18
7.5 Stopping the Boat.............................................................................................................18
7.6 Docking............................................................................................................................18
7.7 After Operation ...............................................................................................................19
7.8 Trailering Your Boat .........................................................................................................19
7.9 Launching Your Boat........................................................................................................20
7.10 Retrieving Your Boat ......................................................................................................20

5
Chapter 8 Routine Maintenance .............................................................21
8.1 Exterior Hull and Deck ....................................................................................................21
8.2 Engine..............................................................................................................................22
Chapter 9 Exterior Equipment ................................................................22
9.1 Swim Platform (optional) ..................................................................................................22
Chapter 10 Seasonal Maintenance.........................................................23
10.1 Engine............................................................................................................................23
10.2 Hull.................................................................................................................................23
10.3 Storage ..........................................................................................................................23
10.4 Trailer.............................................................................................................................23
Appendix....................................................................................................24

6
1/General Information
1.1 General
The EdgeWater 158 CS is a semi-custom fishing vessel designed to be powered by a single
outboard engine.
1.2 Owner / Operator Responsibilities
Registration
Registering your boat is important to you. Federal Law requires that all powered, undocumented
vessels be registered in their state of principal use. Contact the appropriate agency in your local
state to obtain specific registration information.
Reporting Boating Accidents
All boating accidents must be reported to the proper authorities in the state which the accident
occurred. If someone dies or disappears as a result of the recreational boating accident, it must
be reported immediately, with a formal report being made within 48 hours. If there is damage of
more than $500, or if the boat is completely lost, a formal report must be made within 10 days.
Questions regarding accidents may be directed to the Boating Safety Hotline, 800-368-5647.
Education
Whether or not you are an experienced boater, attending a Boating Education Course can be
beneficial. If you are inexperienced, it is the best, safest way to begin your life on the water. If you
are an experienced boater, it’s always good to sharpen your skills.
Required Equipment
The U.S. Coast Guard requires certain equipment on each boat. In addition, they also set
minimum equipment and safety standards. For more detailed requirement information, obtain
“Federal Requirements And Safety Tips For Recreational Boats”, by contacting the Boating Safety
Hotline,
800-368-5647.
Some states and local agencies require equipment that is not required by the U.S. Coast
Guard. Your local agency or dealer can provide specific information regarding these non-
standard requirements.

7
2/Helm Control Systems
2.1 General
The helm station is the control center for the boat. The main control systems are the engine
throttle/shift controls and the steering system. These provide the operator the ability to control
speed, direction, boat trim, and attitude. Each manufacturer provides manuals on the operation
and use of their systems.
2.2 Steering System
General
The manual which comes with your steering system provides specific information on your steering
system.
While running at slow speeds, most boats tend to wander slightly back and forth. Keeping the
wheel in the center without overcompensating for the slight wandering will prevent over steering
and reduce the tendency to wander.
Steering System Maintenance
Routine system inspection should occur regularly. Cables, linkage, and helm assemblies should
be inspected for wear, corrosion, cracking, or deterioration. Cleaning and light grease should be
applied to all exposed metal parts and other damaged or deteriorated parts should be replaced as
soon as possible.
2.3 Engine Throttle and Shift Controls
Refer to the engine manual supplied with your engine for specific information on your controls.
There are three major components of the engine throttle and shift controls: handles, throttle cable,
shift cable. Throttle and shift cables are push-pull and are connected to the fuel system
(carburetor or fuel injection) and the other to the shift rod linkage. By moving the handles forward
and back, the operator engages the cables thus controlling the amount of fuel being used and the
gear selector for forward, neutral and reverse. Careful use of the controls provides smooth,
responsive and safe operation.
Do not bring the throttle back abruptly to stop the boat unless it is an emergency. Allow
time for the engine RPM to come down to idle before shifting to reverse or severe gearbox
damage could occur. PLEASE REFER TO YOUR ENGINE OWNER’S MANUAL FOR
FURTHER OPERATIONAL PROCUDURES FOR YOUR OUTBOARD.

8
Engine Stop Switch
This device is designed to prevent the operator falling overboard while the engine remains
running. The engine stop switch lanyard should always be worn by the operator, while the boat is
in motion. Pulling the lanyard from the control will stop the engine. If the engine will not crank
properly, the lanyard may not be properly attached to the engine stop switch.
Do not use the engine stop switch to stop the boat unless it is an emergency as it may
impair your ability to quickly re-start the engine.
**NOTE** Each ignition key has a 3 digit number stamped on it. Please record this number
for future reference on the service information page in the front of this manual.
3/Propulsion System
3.1 General
Your new EdgeWater 158CS is designed to be powered by a single outboard motor. Most 2-cycle
outboards currently use an automatic system to mix the oil with the gasoline before the engine
uses it. On a 158CS equipped with a 2-cycle engine, the oil tank is maintained in the crankcase.
Make sure this tank always has a sufficient amount of the recommended 2-cycle oil for your
cruise, plus some reserve. 4-cycle engines require oil be maintained in the crankcase also.
Always check the crankcase oil level before each day’s run.
Always follow the manufacturer’s recommendations and use only the recommended oil
types.
Don’t attempt to service your outboard or any of its components unless you are
thoroughly familiar with its operation and dangers. Many of the moving part components
are exposed and can pose an extreme danger to anyone unfamiliar with their operation.
Always leave the servicing to a qualified technician.
Each manufacturer provides manuals designed to assist you in the proper operation and
maintenance of your new engine. Follow their guidance and schedules for proper operation of
your new engine. With a modern outboard there is little to do as long as proper maintenance is
performed, in accordance with the manufacturer’s recommendations. If the boat is to be kept in
saltwater for an extended period, electrolysis and marine growth can become a problem. When
leaving your boat in salt water overnight or for an extended period, tilt the engine as high out of
the water as possible. This will decrease the possibility of marine growth on the outside of the
engine, as well as reduce the potential of marine growth compromising the cooling water inlets in
the lower unit, which can cause overheating.
Do not paint your outboard’s lower unit with paints designed for boat hulls. Some can
cause severe damage to your engine. Check with your engine manufacturer to get their
recommendation.
Do not attempt control adjustments unless you are very familiar with their function, operation and
adjustment. Failure to properly adjust the system components can adversely affect your boat’s
