Edimax IC-3116W User manual

IC-3116W
User Manual
05-2015 / v2.0

2
Copyright ＠Edimax Technology Co., Ltd. all rights reserved. No part of this publication
may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated
into any language or computer language, in any form or by any means, electronic,
mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written
permission from Edimax Technology Co., Ltd.
Edimax Technology Co., Ltd. makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and specifically disclaims any
warranties, merchantability, or fitness for any particular purpose. Any software described
in this manual is sold or licensed as is. Should the programs prove defective following
their purchase, the buyer (and not this company, its distributor, or its dealer) assumes
the entire cost of all necessary servicing, repair, and any incidental or consequential
damages resulting from any defect in the software. Edimax Technology Co., Ltd. reserves
the right to revise this publication and to make changes from time to time in the contents
hereof without the obligation to notify any person of such revision or changes.
The product you have purchased and the setup screen may appear slightly different
from those shown in this QIG. For more information about this product, please refer to
the user manual on the CD-ROM. The software and specifications are subject to change
without notice. Please visit our website www.edimax.com for updates. All brand and
product names mentioned in this manual are trademarks and/or registered trademarks
of their respective holders.
Edimax Technology Co., Ltd.
Add: No. 3, Wu-Chuan 3rd Rd., Wu-Ku Industrial Park, New Taipei City, Taiwan
Tel: [phone]
Email: [e-mail]
Notice According to GNU General Public License Version 2
Certain Edimax products include software code developed by third parties, software code is subject to
the GNU General Public License ("GPL") or GNU Lesser General Public License ("LGPL"). Please see the
GNU (www.gnu.org) and LPGL (www.gnu.org) Websites to view the terms of each license.
The GPL Code and LGPL Code used in Edimax products are distributed without any warranty and are
subject to the copyrights of their authors. For details, see the GPL Code and LGPL Code licenses. You
can download the firmware-files at http://www.edimax.com under "Download" page.

3
I. Product Information.............................................................................. 6
I-1. Package Contents ................................................................................................................6
I-2. Front Panel .........................................................................................................................6
I-3. Back Panel ..........................................................................................................................7
I-4. LED Status ..........................................................................................................................7
I-5. Product Label .....................................................................................................................8
I-6. Reset ..................................................................................................................................8
II. Hardware Installation............................................................................ 9
II-1. Mounting Kit.......................................................................................................................9
II-2. Camera.............................................................................................................................10
III. Camera Setup.......................................................................................11
II-1. EdiView II App..................................................................................................................12
II-2. EdiView Finder..................................................................................................................15
II-2-1. Windows ..........................................................................................................................15
II-2-2. Mac ..................................................................................................................................21
II-2-3. Using EdiView Finder ........................................................................................................24
II-3. WPS (Wi-Fi Protected Setup) ............................................................................................26
IV. Web-Based Management Interface ......................................................27
IV-1. Basic .................................................................................................................................31
IV-1-1. Network ...........................................................................................................................32
IV-1-2. Wireless............................................................................................................................34
IV-1-2-1. Smartphone......................................................................................................................35
IV-1-2-2. Computer .........................................................................................................................38
IV-1-2-3. WPS..................................................................................................................................39
IV-1-3. Dynamic DNS....................................................................................................................40
IV-1-4. RTSP .................................................................................................................................41
IV-1-5. Date & Time .....................................................................................................................42
IV-1-6. Users ................................................................................................................................43
IV-1-7. UPnP ................................................................................................................................45
IV-1-8. Bonjour ............................................................................................................................46
IV-2. Video................................................................................................................................47
IV-2-1. Video Settings...................................................................................................................47
IV-2-2. Image Appearance............................................................................................................49
IV-2-3. Night Vision ......................................................................................................................50
IV-3. Events...............................................................................................................................51
IV-3-1. Motion Detection .............................................................................................................51
IV-3-1-1.Motion Detection ..............................................................................................................51

4
IV-3-1-2. Detection Region ..............................................................................................................54
IV-3-1-3. Schedule Settings .............................................................................................................56
IV-3-2. Notification ......................................................................................................................58
IV-3-2-1. SMTP ................................................................................................................................58
IV-3-2-2. FTP ...................................................................................................................................60
IV-3-2-3. Push .................................................................................................................................61
IV-3-2-4. HTTP.................................................................................................................................62
IV-4. Storage Settings................................................................................................................63
IV-4-1. Storage Directory..............................................................................................................63
IV-4-2. Schedule Settings .............................................................................................................64
IV-4-3. NAS Settings .....................................................................................................................65
IV-5. System..............................................................................................................................67
IV-5-1. Basic .................................................................................................................................67
IV-5-2. Advanced .........................................................................................................................68
IV-5-3. Cloud Service....................................................................................................................70
IV-6. Status ...............................................................................................................................71
IV-6-1. System Information ..........................................................................................................71
IV-6-2. System Log .......................................................................................................................73
V. Myedimax.com ....................................................................................74
VI. 16 Channel Viewer for Windows...........................................................77
VI-1. Installation .......................................................................................................................77
VI-2. Using the 16 Channel Viewer ............................................................................................81
VI-3. Configuring the 16 Channel Viewer...................................................................................84
VI-3-1. Add Camera/Camera Configuration ..................................................................................84
VI-3-1-1. Camera.............................................................................................................................85
VI-3-1-2. Scheduled Recording ........................................................................................................87
VI-3-1-3. Audio................................................................................................................................90
VI-3-1-4. Motion Recording.............................................................................................................91
VI-3-2. General Options ...............................................................................................................93
VI-3-2-1. General.............................................................................................................................93
VI-3-2-2. Email Settings ...................................................................................................................95
VI-3-2-3. Security ............................................................................................................................97
VI-3-2-4. About ...............................................................................................................................99
VI-4. Changing the Display Layout ...........................................................................................100
VI-5. Full Screen Mode............................................................................................................103
VI-6. Scan................................................................................................................................104
VI-7. Zoom In/Out...................................................................................................................105
VI-8. Pan & Tilt........................................................................................................................106
VI-9. Snapshot ........................................................................................................................107

5
VI-10. Recording .......................................................................................................................108
VI-11. Video Playback ...............................................................................................................109

6
I. Product Information
I-1. Package Contents
IC-3116W QIG CD-ROM
Power Adapter Ethernet Cable Mounting Kit
I-2. Front Panel
Status LEDs
Infrared LEDs
Adjustable Lens
Light Sensor

7
I-3. Back Panel
I-4. LED Status
LED
LED Color
LED Status
Description
Power
Green
On
Network camera is on and
connected to cloud server.
Quick Flashing
Network camera is restarting.
Slow Flashing (1 x
per second)
Network camera is starting up OR
network camera is not connected
to cloud server.
LAN
Green
On
Network camera is connected to
the local network.
Quick Flashing
LAN activity (transferring data).
Slow Flashing (1 x
per second)
WPS is active.
Internet
Orange
On
Connected to Internet.
Slow Flashing ( 1 x
per second)
Not connected to Internet.
MAC/Cloud ID
& Setup SSID
LAN Port
12V DC Power Port
WPS/Reset Button

8
I-5. Product Label
The product label located on the back of the camera displays the MAC address,
cloud ID and setup SSID of your network camera.
The MAC address and cloud ID are the same for easy reference.
The cloud ID allows you to view a live stream from your network camera
remotely (from any Internet connection) as described later in III-4.
Myedimax.com.
I-6. Reset
If you experience problems with your network camera, you can reset the
camera back to its factory default settings. This resets all settings back to
default.
1. Press and hold the WPS/Reset button found
on the back panel for at least 10 seconds
2. Release the button when the green power
LED is flashing quickly.
3. Wait for the network camera to restart. The
camera is ready when the green power LED
is flashing slowly.
After setup, the green power LED will
display on to indicate a successful
connection to the cloud server.

9
II. Hardware Installation
II-1. Mounting Kit
A stand for your network camera is included in the package contents. The
stand requires some assembly.
1. Assemble the included camera stand as shown below. The camera stand
can stand by itself or be mounted to a wall:
2. Secure the network camera to the included camera stand using the
mounting hole on the rear of the camera.
You can also mount the network camera to a tripod using the
mounting hole.

10
II-2. Camera
Follow the instructions below to ensure your camera is properly connected
and ready for setup.
1. Connect the power adapter to the network camera’s
power port and to a power supply, as shown to the right.
2. Wait a moment for the camera to power on. The camera
green power LED will flash slowly when it’s ready. Please
refer to III. Camera Setup to setup your network camera
using the free EdiView II smartphone app.

11
III. Camera Setup
Your network camera’s unique SSID is displayed on the product label on
the product’s indoor main unit and consits of “EdiView.Setup**” where **
are the last two characters of your camera’s unique MAC address.
Now you need to connect your network camera to your network. There are
three easy ways:
A. With the free EdiView II app on Android or iPhone: II-1. EdiView II App.
B. Using a computer and EdiView Finder: II-2. EdiView Finder.
C. Using WPS (Wi-Fi Protected Setup), a simple method to connect your
camera to your wireless network. Refer to II-4. WPS.
After connecting your camera to your network using one of the methods
above, you can view your camera’s live image or configure its settings:
Local network:
A. Using the web based management interface (see IV. Web Based
Management Interface.).
B. Using the 16 channel viewer software (see VI. 16 Channel Viewer
Software).
Remotely (from any Internet connection):
A. Using the camera’s cloud ID (see V. Myedimax.com).
B. Using the EdiView II app.

12
II-1. EdiView II App
1.Use a smartphone or tablet to search, download and install the EdiView II
app from Google Play or the Apple App Store.
2.For iOS users, go to your iPhone’s Wi-Fi settings and connect to your
network camera’s SSID (EdiView.Setup**), before opening the EdiView II
app. Continue to Step 4.
3.Android users ensure your Android device’s Wi-Fi is switched on, and open
the EdiView II app. Select your network camera and click “OK” to continue.

13
4. Android & iOS users select your Wi-Fi network from the list and then enter
your Wi-Fi password, before clicking “OK”.
If prompted to allow push notifications, please select “Yes”. Click the
refresh icon to refresh the Wi-Fi list.
5. Please wait a moment while your camera connects to your Wi-Fi. When
you see the “Setup complete” screen, click the “Live” icon to continue or
wait for a few seconds to continue automatically.

14
6.Setup is complete. The camera’s LED should display on and green. You
should see a live stream from your network camera which you can view
anytime you are connected to the Internet.
It is recommended that you change your camera’s password. Go to
“More” in the bottom right corner and select “Settings”.
You can configure your camera’s settings and functions using the icons
below the live image.

15
II-2. EdiView Finder
Ensure your computer is connected to the same router as the
network camera using an Ethernet cable.
II-2-1. Windows
1. Insert the included CD into your CD-ROM drive and if the setup utility does
not automatically open, please locate and open the “Autorun.exe” file in
the “Autorun” folder.
2. Click “Setup Utility” to install the EdiView Finder software utility.
3. Click “Next” and follow the on-screen instructions to install the EdiView
Finder software utility.

16
4. When installation is complete, select “Launch EdiView Finder Utility”
before clicking “Finish”. Or double click the ”EdiView Finder Utility” icon on
your desktop to launch EdiView Finder.

17
5. EdiView Finder will list all cameras on your local network, along with each
camera’s name, model, IP address and MAC address.
Click the search icon to refresh the list if your camera is not
displayed.
The network camera’s IP address is displayed on this screen. After
setup, you can enter this IP address into the URL bar of a web
browser on the same local network to access your network
camera’s web-based configuration interface.
6. Double click your camera and then choose “Yes” or “No” if you wish to set
up a wireless connection. If you choose “No” please go to step 10.
The IC-3116W is a wireless camera, you can choose “Yes” to set
up your wireless connection.

18
7. Select your wireless network from the list and enter the correct password
in the “Password” field, before clicking “OK”. This is the wireless network
which your camera will connect to.
8.Unplug the Ethernet cable from your network camera and click “Next”.
Please wait a moment for the camera to detect the connection.

19
9.When the connection is detected as shown below, please click “Next”.
10. Enter a name and password for your camera. The password will be
used later to log in to your camera remotely via its cloud ID, web interface
or via the EdiView II smartphone app. Click “OK” to continue.

20
11. The next screen will indicate that setup is complete. The camera is
operational and ready for use. Click “OK”or click the URL and a preview
window showing a live stream from your camera may open.
