i
i- -W WA AT TC CH HE ER R
Pan / Tilt Internet IP Camera
User Manual
Version 1.0 March. 2006
1

Table of Contents
1. System Features
1-1.Package Contents
1-2.System Requirements
1-3.Hardware Description and Features
1-4.i-WATCHER Hardware Specification
2. Installation
2-1. i-WATCHER Hardware Setup
2-2. i-WATCHER Hardware Setup (Wireless LAN Setup)
2-3. Connecting to an Access Point (AP)
3. Accessing the i-WATCHER
3-1.Change the i-WATCHER IP Status
3-2.On the LAN with DHCP Server
3-3.On the LAN without DHCP Server
3-4.On the LAN use with the ADSL Router
3-5.Access the i-WATCHER by ordinary user login.
4. i-WATCHER Network Camera on-line
5. Change Password
6. Camera Control
6-1. Quality Setting
6-2. Resolution Setting
6-3. Frequency Setting
6-4. Camera Advanced adjust
6-5. Operation Mode
7. View Log File
8. Configuration
8-1.System Setup
8-1-1. Camera Name
8-1-2. Camera’s Time
8-1-3. Web server Port number
8-2. User Setup
8-2-1. User Management
8-3. Motion Detect Setup
8-3-1. Motion Detection Enable / Disable
8-3-2. Motion detected mail function
2

8-3-3. Motion detected mail
8-3-4. Motion detected message on the main window.
8-3-5. FTP uploads when motion detected.
8-4.Alert IN Setup
8-4-1.Alert IN Setup
8-4-2.Alert IN with motion detected mail function(mail setting)
8-4-3.Motion detected mail (Alert IN Enabled)
8-4-4.Motion detected messenger on main window(Alert IN Enabled)
8-4-5.FTP uploads when motion detected(alert IN Enabled)
8-5. Network Setup
8-5-1. Manual Setup
8-5-2. Connect to ADSL by PPPOE mode
8-6. Audio Setup
8-6-1. Audio Configure
9. Snapshots
10. Image Recording
10-1. Save as JPEG
10-2. Save as AVI
10-3. Save Current Picture As…
11. GPIO Function
12. Hardware Reset Function
13. Accessing i-WATCHER over the Internet
13-1. WAN IPAddress
13-2. Network Address Translation (NAT)
13-3. Port Forwarding
13-4. Default Gateway
3

14. Network Utilities
14-1. Determining your IPAddress and Network Settings
14-2. Using PING
14-3. IPEdit search tool
15. POE(Power over Ethernet) Function
16. Pan and Tilt Control
16-1.Control the camera in the main window
16-2.Position Points Pre setting
16-3.Image Rotate Setting
16-4.Camera Moving Step Size
17. html code for you Website or Blog
18. i-WATCHER Installation Method
4

OVERVIEW
1. System Features
Remote Surveillance Becomes Handy
i-Watcher IP-Cam network camera let you monitor your surveillance system remotely
anywhere around the world. It's a mini PC that comes with a camera where you can say
"NO" to invest another PC specifically for surveillance purpose, uncomplicated installation
and training, and yet with unlimited expansion, all you need is just a power and network
cable and it's all DIY. Having achieved the professional level for security and surveillance
Supports Dynamic IP And Various Network Mode
Just switch on the power supply for the IP-Cam, and it's all ready for action regardless
whatever your network configuration may be, be it Static IP, DHCP auto acquire or PPPoE
auto dial-connect and UPNP etc. network setting, it's all in the IP-Cam, with the built-in
PPPoE dial-connect program and DDNS server, it eliminate the trouble of keying of
passwords every now and then. When the IP-Cam power is switched on, it will send the
current acquired IP address to you by e-mail or auto update to the IP-Cam server and it will
be ready for monitoring anytime anywhere.
Unique Dynamic IP DDNS Server
To cater to the dynamic IP and ADSL dial-up subscriber, we has setup DDNS server, Motion
DNS server and IP Cam server, user no longer need a static IP and the tedious DNS
application procedure, just key in the user name and the serial number, you camera IP
address will auto communicate with the server thus solving your dynamic IP problem.
Internet and Intranet, Hassle Free Expansion And Easy Installation
Having the UPnP auto detect setting IP function, setting up of the i-Watcher IP- Cam is
even easier. Regardless of LAN or ADSL, wired version, simply install wherever the wire
may run. There is no limit to the expansion, no more having to purchase another PC due to
the lack of PCI slot, and just simply connect the I-Watcher IP-Cam to the network with no
setting required and you are ready for user friendly remote surveillance.
Diversify Surveillance; Centralize Management "Zero" Training
i-Watcher IP-Cam is a mini PC, camera and surveillance system all-in-one; you no longer
need to spend lots of money to purchase DVR card for the PC. With the advantage of
diversifying surveillance and centralize management function, the i-Watcher IP-Cam will not
cause the whole security system breakdown due to malfunction of PC. No specific
hardware requirement and no extra installation software, doing away with complicated
operating system, the installation and setting of surveillance software and time for acquiring
the relevant knowledge and worry about the stability of the system. This will reduce the
maintenance cost substantially.
Up to VGA (640 X 480) Resolution
i-Watcher IP-Cam provide the resolution of 640 X 480 with video recording and still image
capture, synchronized camera audio and video recording, brightness, contrast and image
quality adjustment etc. where it's all the perfect function for a surveillance system.
5

Audio and Video Recording Function
With the highly sensitive built-in microphone, i-Watcher IP-Cam provide you with the
recording of audio and video function, unlike those in the market where you can only record
video without the audio.
IP-Cam DVR Software
IP-Cam DVR is mainly Windows based DVR software for building multi- channel video and
audio surveillance DVR. IP-Cam DVR software ranges from entry level I-Watcher IP-cam to
the flagship, i-WATCHER IP-Cam full series products support. Up to 16 cameras can be
connected and view live on a local monitor screen or thru TCP/IP Internet. Video can be
recorded basing on specifiable schedules or motion detection. You can store video clips in
HDD.
Online Firmware Upgrade
i-Watcher IP-Cam is a human operated interface, all the functions can be controlled via the
internet in real time and we provide online firmware upgrade function. No worries for future
upgrading and continuity developing the i-Watcher IP-Cam, as you have the most
comprehensive security system
1-1. Package Contents
zi-WATCHER Pan/Tilt Network Camera x 1
zPower Adapter (5V 2A) x 1
zRed Color 10/100 Mbps Ethernet LAN Cable (MDI / X, Cross over LAN cable)
zBlue Color 10/100 Mbps Ethernet LAN Cable (MDI)
zi-WATCHER installation CD-ROM x 1
zi-WATCHER User’s Manual x 1
zClimber with screws X 2
1-2. System Requirements
To view the camera web page
zWeb Browser – Internet Explorer for Windows 6.0 or higher
zPC with Windows 98, Me, 2000, or XP connected to LAN
To run the included software (IPEDIT.exe) applications
zPC - Intel Pentium 4 or higher, 256MB RAM, 150 MB Hard Disk Space
zSupport 800x600 resolution with 32- bit color Display Card
zSupport Windows 98SE, Me, 2000, or Windows XP , XP –SP2
To access cameras from the Internet
zBroadband Internet Connection (DSL / Cable Modem) with min.128k upload speed
6

1-3. Hardware Description and Features
zStand-alone network camera for flexible installation.
zSimple installation and multiple mounting methods.
zEmbedded Web Server Supported.
zNo computer is needed at the monitored site.
zAccess live video via web browser at anytime and any place for remote surveillance and
management.
z2 default HTTP ports supported, they can be changed to fit different network
environments.
zBuilt-in Motion Detection for security at no extra cost.
zStandard JPEG Image Format.
zRecord AVI (Video) or Motion JPEG images onto hard disk for future viewing.
zCapture snapshots and video to your PC.
zPassword protection, Supervisor password system for you to decide who has authority to
access the cameras.
zReal-Time Motion Detection for E-mail and FTP alert.
zE-Mail the Detected Images to preset e-Mail address.
zFTP the Detected Images to preset FTP server.
zDirectly connect to ADSL by PPPoE, mail the IP setting to preset mail address.
z5 different resolutions, 5 different image quality.
z3 different Light Frequencies: Outdoor, Indoor 50Hz and Indoor 60Hz.
zUnlimited number of users concurrently browsing the same camera.
zE-Mail notification for sharing or notifying information actively to the connected party.
zCamera Name Support with Web console configuration interface.
zLAN / WAN interface supported with Fixed IP or Dynamic IP by DHCP.
zLog List report / Built-in Microphone
Network
zFixed IP.
zDynamic IP by DHCP.
zDirectly connect to ADSL by PPPoE, mail the IP setting to preset mail address.
User Management
zUser Management for Add User, Delete User, and Change Password.
zAdministrator, privileged user to change any settings.
zGeneral users, view images only.
Camera Control
zResolution: 160x120, 176x144, 320x240, 352x288, 640x480.
zQuality: Low, Medium, High
zImage Rotate / Flip Function
zVideo Adjustment: Saturation, Hue, Sharpness
zBuilt-in stepping motor for Camera PAN / TILT
zCamera Pan Degree ( Mechanic angle ): 300 degree (-165° ~ +165°)
zCamera Tilt Degree ( Mechanic angle ): 120 degree (Down 30° ~ up 90°)
zP/T Control: Up ,Down ,Right ,Left, Up-Right ,Up-Left, Down-Right ,Down-Left, Center
with Position presetting : 6 point
7

Wireless LAN
zSupport USB Wireless Dongle for IEEE802.11 b and g
zZydas Chipset WiFi USB Dongle
zE-Mail the Detected Images to preset e-Mail address.
zFTP the Detected Images to preset FTP server.
Motion Detection
zSoftware Real-Time Motion Detection.
zSelected Region Provided.
zE-Mail the Detected Images to preset e-Mail address.
zFTP the Detected Images to preset FTP server.
Browser Supports
zIE only (ActiveX Control) saves the current image local PC.
zActiveX controls: ActiveX controls support full functions, including the Right Mouse
Button Menu control.
Utility
zIPEDIT.EXE to scan the Installed i-WATCHER and change the Camera Name and IP
Address
Power
zPower DC 5V 2A, switching type power supply
zPower consumption 6.5W (1300mA x 5 V) ,maximum
1-4. i-WATCHER Hardware Specification
zBuilt-in web server allows camera to be accessed by standard Internet browser
zNetwork, RJ-45: 10Base-T/100Base-TX Ethernet networks
zNetwork ready, IP address able (no PC required.)
zMotion-JPEG based compression
zSize: 160 mm x 70 mm x 57 mm, Weight: 500g
8

2. Installation
Before installing the i-WATCHER, you should have an available Ethernet LAN connection
(RJ-45 port). To view the camera’s image or make any manual configuration changes, you
will need a Windows PC with Internet Explorer 6.0 or higher and connection to the LAN.
2-1. i-WATCHER Hardware Setup (LAN Setup)
1. Plug the Ethernet cable into i-WATCHER
2. Plug the Ethernet cable into PC or Router
3. Connect the Power Supply to the i-WATCHER, Camera power LED ON
4. Wait 45 sec to 60 sec, the camera will auto Pan and Tilt, moving to camera center
5. Use the IPEdit.exe tools to find the i-WATCHER and setup camera IP address.
6. Use IE to view the i-WATCHER image.
Step 1.
Plug the Ethernet cable into i-WATCHER
Plug the included RED Color Ethernet cable
into the RJ- 45 connector at the back of the
camera as shown.
Step 2.
Plug the Ethernet cable into PC or Router
1.Temporarily disconnect the existing network
cable from the PC.
2.Plug the other end of the Ethernet cable into
any available LAN port. A typical home router
/gateway connection is shown on the left.
Step 3.
Connect the Power to the i-WATCHER
Connect the power supply to the back of the
i-WATCHER as shown, and then plug the
supply into an available power outlet.
The Camera Power LED ON (Blue)
9

Step 4.
Ensure the Camera power light is lighting
When the i-WATCHER is connected with power,
the LED light on top of the i-WATCHER will light
up. This indicates that the i-WATCHER is
powered on.
Wait 45 sec to 60 sec, camera will auto pan
tilt and moving camera center
Step 5.
Using IPEdit.exe to test the IP-Cam
1. Use IPEDIT.EXE to find the installed
i-WATCHER.
2. The i-WATCHER without IP allocated by DHCP
will have a default IPAddress of 169.254.xx.xx.
3. Select this i-WATCHER on Camera List Window.
4. The default configuration will be shown on
the right window.
5. Change i-WATCHER network settings.
zUpdate the Camera Name (Fixed IP).
zUpdate the Gateway Address
zUpdate the IP address
zUpdate the Network Mask
zHttp Port update the 80 port then ‘Submit’ it.
After the ‘Submit’ button is clicked, the IP
information of this i-WATCHER will be updated.
Step 6.
Using IE to view i-WATCHER image
1. Start the Internet Explorer, key in the IP
Address of i-WATCHER into the Address field,
such as 192.168.1.245.
2. Turn the lens to the left or right to adjust the
clarity of the focus.
Step 7.
Connect to the ADSL Modem or LAN Hub
1. Remove the blue LAN cable from the PC when
all the settings are completed.
2. Reconnect the existing network cable to PC.
3. Using the blue network cable provided,
connect one end to the IP-Cam, and the other,
to the ADSL model of LAN hub.
4. Return to Step 6
10

2-2. i-WATCHER Hardware Setup (Wireless LAN Setup)
The i-WATCHER provides a USB port for extra device.
Check the diagram for extra function
i-WATCHER IP-Cam support wireless LAN USB Dongle, the USB port in camera back
panel. The camera support dual mode, LAN and WLAN, when you want to use wireless
LAN with i-WATCHER, please follow setup step and notes.
1. After IP-Cam LAN setup process
2. Plug i-Watcher USB Wi-Fi Dongle into camera Wi-Fi USB port
3. Use IE browser, into Camera Configuration page -> Network page
4. Wireless LAN Enable. And Manually setup IP address, Subnet mask, Gateway or
Automatically by DHCP
5. Configuration page -> Wireless Interface page
Setup wireless all setting value, such as
Network Name (ESS ID), Channel, Operation
Mode and WEP settings, than click Set button
6. Select “Reboot Immediately” button for reboot.
(wait 60sec)
7. Confirm you PC connect wireless LAN and same
as Wireless LAN section with IP-Cam wireless,
Use IP-EDIT.EXE software to find out camera
(Now, camera in Wireless LAN status)
8. Use IP-EDIT.EXE, Camera List will show 2 cameras.
11

9. Use IE Browser to watch IP-cam image (wireless mode)
10. If you can find camera in IP-EDIT list and see camera video from IE, than mean is
your camera wireless setup complete, when camera in wireless mode, IP-Edit
software can’t change any setting, you must use IE into setup page to change
camera setting.
11. Configuration page -> Network -> Disable LAN
12. Remove LAN Cable from camera RJ-45 connector and select
“Reboot Immediately” button for reboot again (wait 60 sec)
13. Use IE Browser to watch IP-cam image (wireless mode)
NOTES: If you can’t find camera in IP-EDIT list , than mean is something wrong, you
need use reset button to reboot camera and setup again (from step 1).
Use Pin to press Reset button 10 sec, than camera will reboot
LAN Only WLAN Only LAN+WLAN
Use IP-EDIT change setting OK OK Can’t setting
Motion detect than send image via
E-Mail OK OK
Send Email by
LAN
Motion detect than send image via
FTP OK OK
Send FTP by
LAN
NTP Server Support OK OK By LAN
PPPoE OK X X
2-3. Connecting to an Access Point (AP)
Your 802.11g USB 2.0 USB dongle also enables a group of wireless stations to
communicate with each other. It acts as bridging functions between the wireless network
and the wired LAN network.
e.g. ASCII : [0~9] [A~Z] [_] , 64bit/5 charter,128bit/13 charter
12

3. Accessing the i-WATCHER
3-1. Change the i-WATCHER IP Status
Using the IPEdit.exe, you could select the
different network options.
The PC network options will display the
Gateway and Net mask network settings,
Which you can edit with IPEdit.exe .
Alternatively, you may contact your network
system administrator to provide you with the
details of your network Gateway and Net mask
settings.
Enter the Camera’s IP number.
If you allow outsiders to see the i-WATCHER, please enter another IP address.
If you only want the i-WATCHER to be viewed in the internal network, you could enter a
local IP number Example: 192.168.1.88.
Clicking “Submit” will update all of changes mode to the i-WATCHER settings.
Option Labels Translations Functions
Name: Name of the
Camera Options for the name of the camera
Gateway Gateway Reviews through your network options
IP Network Address
Net mask Network Reviews through your network options
HTTP Port 1 HTTP Port 1 80
HTTP Port 2 HTTP Port 2 IP address given by the administrator, refrain
from changing it
MAC MAC Address
Example:
Hinet (ISP) uses the IP address number:
Use IPEDIT.exe to enter Hinet assigned IP address.
Launch IE Browser.
Go to i-WATCHER ÆNetwork Setup ÆPPPoEÆSet ADSL User ID and Password
provided by HinetÆClick Submit and restart the PC.
13

3-2. On the LAN with DHCP Server
1. Use IPEDIT.EXE to find the installed
i-WATCHER.
2. Select this i-WATCHER in the Camera
Lists Window.
3. The default configurations will be shown in
the right window.
4. Update the Camera’s IP status.
3-3. On the LAN without DHCP Server
1. Use IPEDIT.exe to find the installed
i-WATCHER.
2. The i-WATCHER without IP allocated
by DHCP will have a default IPAddress
of 169.254.xx.xx.
3. Select this i-WATCHER in the Camera
Lists Window.
4. The default configurations will be shown in
the right window.
1. Update the Camera Name (Fixed IP)
2. Update the Gateway Address (192.168.1.254).
3. Update the IP address of this IP-Cam (192.168.1.xx).
4. Update the Network Mask (255.255.255.0).
5. Http Port1 type in 80 and press ‘Submit’ it.
After the button ‘Submit’ is clicked, the IP information of this i-WATCHER will be updated.
Access this i-WATCHER by this IP address; on the Configuration -> Network, the Fixed IP
address was assigned.
3-4. On the LAN use with the ADSL Router
If the i-WATCHER was installed on the ADSL router, the i-WATCHER will dynamically be
allocated an IP address from the DHCP server. However, if the i-WATCHER ants to be
accessed from the WAN, the i-WATCHER IP address needs to be setup as fixed IP. Same
goes for the Virtual Server function of ADSL router, which needs to be setup as well.
1. Setup the i-WATCHER as Fixed IP, such as 192.168.0.49.
2. Enter the administrator page of +ADSL router. (Use sonnet ASDL router as an
example).
3. Enter the Virtual Server Page.
14

A. Setup the mapping of HTTP Port (80) to 192.168.0.49.
B. Restart the ADSL router.
Then the i-WATCHER can be accessed from WAN, by the ADSL WAN IP Address.
3-5. Access the i-WATCHER by ordinary user login.
If the user accesses the i-WATCHER by an ordinary user account, the i-WATCHER would
not allow the user to access the privileged functions. From the following screen, the
Camera Control, Resolution, Quality, and Configuration are disabled.
4. i-WATCHER Network Camera on-line
After setting up the IP based on the above step, connect to the intended network or LAN.
Execute IE directly on PC. The left side of the above diagram is the control panel and the
right side is image display.
5. Change Password
Before you select “Change Password” check button, make sure “User authorization
required” enable the user check function
1. When you want to Change Password, set a new
password to replace the old password.
2. If you get this message from windows screen, that
mean “User authorization required” mode is not set yet.
Please Click “ConfigurationÆUser Setup ÆUser
Management ÆUser authorization required
15

3. Select “Yes“ then press “Set” button , check box will
enable the user check when the users want to access
the i-WATCHER. The login window will prompt for the
User name and Password.
6. Camera Control
On the IE Browser, right mouse click on the video to activate a pop-up menu. You can then
change the camera settings accordingly.
6-1. Quality Setting
The i-WATCHER provides 3 image quality settings. The
user can select the setting from the Quality list box.
zLow
zMedium
zHigh
Note: The value in the list box displays the current setting of the current image.
When you make a new selection, the value on the list box will be changed to the new
image quality settings.
6-2. Resolution Setting
i-WATCHER provides 5 resolutions
z640 X 480
z320 X 240
z352 X 288
z176 X 144
z160 X 120
User can select the desired new setting from the “Resolution” list box.
Note: The value in the list box displays the current setting of the current image. When you
make a new selection, the value on the list box will be changed to the new image quality
settings.
6-3. Frequency Setting
i-WATCHER provide the Frequency setting for
zOutdoor
zIndoor & 50 (For PAL system)
zIndoor & 60 (For NTSC system)
6-4. Camera Advanced Adjust
i-WATCHER provide the advanced setting for
zSaturation
zHue
zSharpness
16

To control the camera, use the “+” to increase, “-“ to decrease it, or “STD” to return
to default value.
6-5.Operation Mode
Continuous Mode:
The i-WATCHER will always try to capture the
image as fast as possible. This is the default
setting.
Periodic Mode:
MS (mill-second) or s (second) can be set. The value set must be greater than 0.
Setting the periodic mode to 5 seconds will update the image every 5 seconds. The time
interval can be checked by the time displayed on the image.
7. View Log File
The user can check the log information of the i-WATCHER, including the Main Info,
Appended Info, Operator IP, Operator MAC, and Time.
Select the ”Camera Window” button to return to Camera mode.
17

8. Configuration
Only the administrator can select the “Configuration”;
the ordinary user account does not have this privilege
to access this function.
The screen is the main menu for configuration setting,
when the administrator selects the “Configuration” in the main window.
i-WATCHER provides 6 types of configurations:
System Setup
User Setup
To add/delete user, change password;
Enable/Disable user check.
Add / Delete User Account.
Change Password.
Motion Detection
Enable/Disable motion detection.
Motion detected mail setting.
Motion detected FTP setting.
Alert OUT setting
Alert IN Setup
Alert IN Setting
Motion detected mail setting.
Motion detected FTP setting.
Network setting.
DHCP – setting the IP dynamically.
Fixed IP – setting the IP manually.
Connect to ADSL by PPPoE.
Wireless Interface
WLAN ESS ID, Channel, WEP…. settings
Audio
Server / Client Configure Setting
DDNS
DynDns / IPCamServer / IPCamDDNS
Pan/Tilt
Preset Point – Set /Move/Clear
Rotate 0 / Rotate 180 / Flip Horizontal/Flip Vertical
Step Size – Small/Medium/Large
Camera Window
Turn Back to Live Video Window
18

8-1. System Setup
8-1-1. Camera Name
The camera name can be set on the “Camera
Name” field, and select “change “ to summit it .
8-1-2. Camera’s time
Select “ NTP ” button
XKey in the Sever IP address like:
http://www.org.ntp.org Press ”adjust” to activate
YAfter i-WATCHER get the time from NTP sever,
it will update the Camera’s time field.
Select “Input new time” button and click on
“Synchronize with PC’s time“
XKey in “mm/dd/yyyy” format into “Date“ field,
and “ hh:mm:ss ” by 24 hours format into
“Time“ filed!
YSelect the “Adjust” button to adjust the time!
8-1-3. Web Server Port Number
The implementation supports 2 HTTP port settings. The HTTP “Port 1” is set to 80; the
HTTP “Port 2” is set to 8080. The user can access the i-WATCHER by
http://xx.xx.xx.xx/ or
http://xx.xx.xx.xx:8080/
to access the i-WATCHER.
It is recommended to keep the HTTP “Port 1” as 80 to make sure the i-WATCHER can be
accessed by the default HTTP port setting access on the LAN. http://xx.xx.xx.xx/
If multiple i-WATCHERs are installed on the LAN, also required to be accessed from the
WAN, the HTTP “Port 2” can be changed as the virtual server port mapping to support
multiple i-WATCHERs. The following table lists example configurations.
Example:
IP-Cam IP HTTP
port.1 HTTP port.2 Virtual Server Port Setting Access IP-Cam on LAN Access IP-Cam on
WAN
IP: 68.68.68.68
192.168.1.1 80 8080 8080 Î192.168.1.1 http://192.168.1.1
http://192.168.1.1:8080 http://68.68.68.68 :8080
192.168.1.2 80 8081 8080 Î192.168.1.1 http://192.168.1.2
http://192.168.1.1:8081 http://68.68.68.68 :8081
192.168.1.3 80 8082 8080 Î192.168.1.1 http://192.168.1.3
http://192.168.1.1:8082 http://68.68.68.68 :8082
19

8-2. User Setup
8-2-1. User Management
User authorization required:
Checking the Enable use check function will
enable the user check when the users want to
Access the i-WATCHER. The Login window will
prompt for the User name and Password.
If the check box is not checked, then the user check will not be enabled. All users can
access the i-WATCHER directly, with the administrator’s permission.ALogin window is not
required.
Note: Before you select Enable user check ”Yes” button, please remember to change
the administrator password.
Add a user or change password:
Enter a new user name and password information
to create a new user account, or enter an existing
user account, then set a new password to replace
the old password.
Confirm by clicking on the [Set/Change] button to
create the account or change password.
After submitting, the “Current User List:” would
display the newly created user account. In this example: “newuser”.
8-2-2. Delete User
Select the user account from the “Username” list box.
Click the [Delete] button to delete the selected user account. A confirmation window will
prompt the user to select “OK” or “Cancel”.
After selecting the “OK” button, the selected user account will be deleted from the “Current
User List”. In this example, the “newuser” account will be removed.
8-3. Motion Detect Setup
8-3-1. Motion Detect Enable / Disable
Check the “Enable motion detection” check box
to activate the motion detection.
If the check box is not checked, the motion
detection send mail function will not be enabled.
Enter the “ Sensitivity “ button for select “High” or “Middle “ and “Low “ mode .
20
