Edimax EW-7303HPn V2 User manual

EW-7303HPn V2
Quick Installation Guide
09-2011 / v2.0

Introduction
EW-7303HPn v2 is a cost-effective IEEE 802.11b/g /n specifications of Outdoor WiFi construction
solution; setting SOHO and enterprise standard for high performance, secure, manageable and reliable
WLAN*. This document describes the steps required for the initial IP address assign and other
configuration of the outdoor router. The description includes the implementation of the above steps.
Package content
The package of the WLAN Broadband Router includes the following items,
Outdoor Router
DC 12V Power Adapter
Documentation CD
POE Injector
Tie
Product features
Compatible with IEEE 802.11n Specifications provides wireless speed up to 150Mbps data rate.
Compatible with IEEE 802.11g standard to provide wireless speeds of 54Mbps data rate.
Compatible with IEEE 802.11b standard to provide wireless speeds of 11Mbps data rate.
Maximizes the performance and ideal for media-centric applications like streaming video, gaming
and Voice over IP technology.
Support various operation (Bridge/Gateway/Ethernet Converter) modes between wireless and wired
Ethernet interfaces.
Supports WPS, 64-bit and 128-bit WEP, WPA, WPA2 encryption to protect the wireless data
transmission.
Support TKIP/AES/TKIPAES of WPA algorithms.
Support IEEE 802.3x full duplex flow control on 10/100M Ethernet interface.
Support DHCP server to provide clients auto IP addresses assignment.
Support DHCP client, static IP, PPPoE, L2TP and PPTP of WAN Interface.
Supports firewall security with port filtering, IP filtering, MAC filtering, port forwarding, DMZ
hosting and URL filtering functions.
Support WEB based management and configuration.
Support System Log.
Support Dynamic DNS
Support NTP
*Maximum performance, actual data rates and coverage may vary depending on network conditions and
environmental factors. Stated ranges are based on independent test results and are not guaranteed. Long
range coverage requires an additional high power access point to receive the wireless signal from the
EW-7303HPn V2 –coverage range from an EW-7303HPn directly to a computer/wireless device is
significantly less.

Front panel description
LED Indicator
State
Description
1. PWR LED
ON
The WLAN Broadband Router is powered ON.
Off
The WLAN Broadband Router is powered Off.
2. WLAN LED
ON
Wireless Radio ON.
Off
Wireless Radio Off.
Flashing
Data is transmitting or receiving on the wireless.
3. WAN LED ACT
ON
Port linked.
Off
No link.
Flashing
Data is transmitting or receiving on the WAN interface.
4. LAN LED ACT
ON
Port linked.
Off
No link.
Flashing
Data is transmitting or receiving on the LAN interface.

Rear panel description
Interfaces
Description
SMA connector
For external antenna. You can use the SMA connector to connect with
2.4GHz external antenna.
Secondary(Middle)
The RJ-45 sockets allow LAN connection through Category 5 cables.
Support auto-sensing on 10/100M speed and half/ full duplex; comply
with IEEE 802.3/ 802.3u respectively.
Main(Right)
The RJ-45 socket allows WAN connection through a Category 5 cable.
Support auto-sensing on 10/100M speed and half/ full duplex; comply
with IEEE 802.3/ 802.3u respectively.

Installation
Notes: The product shot is for reference only please refer to physical product.
1.LED Panel
2. Waterproof Sliding Door
3. Pass trough Ethernet cable from this cable
4. Push this button to remove upper housing

5. Wall Mount
6. Pole Mount
7. Secondary port with POE
8. Main port
9. SMA connector for external antenna

Hardware installation steps
Step2: Pass through Ethernet cable from the hole; insert the cable to Secondary port.
Note: RJ-45 8P8C Ethernet cable is required.
Step3: Install the upper housing and make sure the housing is well installed.

Software Installation
Step4:
Install POE Injector
DC: Insert adapter
POE: This hole is linked to Secondary port of the Outdoor Router with RJ-45.
LAN: This hole is linked to LAN side PC/Hub or Router/ADSL modem device with RJ-45

Step5: Complete the hardware installation as diagram at below
Notes: Use Reset button on POE injector. Push continually the reset button of POE injector about 5 ~
10 seconds to reset the configuration parameters to factory defaults.
There is no software driver or utility installation needed, but only the configuration
setting. Please refer to chapter 4 for software configuration.
Notice: It will take about 50 seconds to complete the boot up sequence after powered on the Outdoor
Router; Power LED will be active, and after that the WLAN Activity LED will be flashing to show the
WLAN interface is enabled and working now.

Software configuration
There are web based management and configuration functions allowing you to have the jobs done easily.
The Outdoor Router is delivered with the following factory default parameters on the Ethernet LAN
interfaces.
Default IP Address: 192.168.2.1
Default IP subnet mask: 255.255.255.0
WEB login User Name: admin
WEB login Password: 1234
Telnet login User Name: admin
Telnet login Password: 1234
