Edimax EW-7325Ig User manual

Wireless LAN PCI Card
Wireless LAN PCI Card
EW-7325Ig
802.11g Wireless LAN PCI Card
802.11g Wireless LAN PCI Card
IEEE 802.11g/b, 32bit PCI BUS, WPA Compliant
Taiwan / Headquarters
Edimax Technology Co., LTD.
TEL:[phone]
FAX:[phone]
[e-mail]
China
Beijing Edimax Science &
Technology Co., LTD.
TEL:[phone]
FAX:[phone]
[e-mail]
U.S.A.
Edimax Computer Company
TEL:[phone]
FAX:[phone]
[e-mail]
Latin America
TEL:[phone]
FAX:[phone]
sales_latinameri[email protected]
Europe
Edimax Technology Europe B.V.
TEL:[phone]
FAX:[phone]
[e-mail]
U.K.
Edimax Technology (UK) Ltd.
TEL:[phone]
FAX:[phone]
[e-mail]
Super-G
108Mbps
Features：
•Works with both IEEE 802.11b and IEEE 802.11g products.
•High-speed transfer data rate - up to 108Mbps (turbo mode enabled).
•High throughput supports multi-media data bandwidth requirement.
•64/128/152-bit WEP,WPA, WPA-PSK (WPA2 / 802.11i for Win 2K/XP).
•Detachable antenna with cable, convenience to locate the antenna.
•Automatic fallback increases data security and reliability.
•Extended Range technology eliminates indoor “dead spots” and
increases outdoor range by 2X-3X
•Supports the most popular OS : Windows 98SE/Me/2000/XP.
Standard IEEE 802.11g/b
Bus Type 32-bit PCI
Security WEP, WPA, WPA-PSK, (WPA2 / 802.11i for 2K/XP)
Receive Sensitivity 54Mbps OFDM, 10% PER, -70dBm
11Mbps CCK, 8% PER, -86dBm
1Mbps BPSK, 8% PER, -92dBm
Frequency Band 2.4000~2.4835GHz (Industrial Scientific Medical Band)
Modulation OFDM with BPSK, QPSK, 16QAM, 64QAM (11g)
BPSK, QPSK, CCK (11b)
Data Rate 54/48/36/24/18/12/11/9/6/5.5/2/1Mbps auto fallback
108Mbps (Turbo mode enabled)
Antenna External detachable dipole antenna
(Connector: RP-SMA connector, Cable Length: 94 cm)
LEDs TX/RX, Link
Chipset Atheros AR2414
Drivers Windows 98SE/Me/2000/XP
Dimension 19(H) x 127(W) x 121(D) mm
Temperature 32~131°F (0 ~55°C)
Humidity Max. 95% (NonCondensing)
Certification FCC , CE
