Edimax EN-9235TX-32 User manual

1
EN-9235TX-32
User Manual
09-2012 / v2.0

2
COPYRIGHT
Copyright Edimax Technology Co., Ltd. all rights reserved. No part of this
publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language, in any form or
by any means, electronic, mechanical, magnetic, optical, chemical, manual or
otherwise, without the prior written permission from Edimax Technology Co.,
Ltd.
Edimax Technology Co., Ltd. makes no representations or warranties, either
expressed or implied, with respect to the contents hereof and specifically
disclaims any warranties, merchantability, or fitness for any particular purpose.
Any software described in this manual is sold or licensed as is. Should the
programs prove defective following their purchase, the buyer (and not this
company, its distributor, or its dealer) assumes the entire cost of all necessary
servicing, repair, and any incidental or consequential damages resulting from
any defect in the software. Edimax Technology Co., Ltd. reserves the right to
revise this publication and to make changes from time to time in the contents
hereof without the obligation to notify any person of such revision or changes.
The product you have purchased and the setup screen may appear slightly
different from those shown in this QIG. For more information about this
product, please refer to the user manual on the CD-ROM. The software and
specifications are subject to change without notice. Please visit our website
www.edimax.com for updates. All brand and product names mentioned in this
manual are trademarks and/or registered trademarks of their respective
holders.
Edimax Technology Co., Ltd.
Add: No. 3, Wu-Chuan 3rd Rd., Wu-Ku Industrial Park, New Taipei City, Taiwan
Tel: [phone]
Email: [email protected]

3
Contents
Chapter 1: Introduction .....................................................................................................4
1.1 Model no. .................................................................................................................4
1.2 Package Contents .....................................................................................................4
1.3 LED Status.................................................................................................................4
1.4 Product Features ......................................................................................................5
1.5 System Requirements...............................................................................................5
Chapter 2: Installation Guide .............................................................................................6
2.1 Hardware Installation ...............................................................................................6
2.2 Driver Installation .....................................................................................................7
2.2.1 Windows : Setup Wizard...........................................................................................7
2.2.2 Windows : CD Drivers ...............................................................................................9
2.2.3 Novell and Linux: CD Drivers...................................................................................13
Chapter 3: Troubleshooting .............................................................................................14

4
Chapter 1: Introduction
1.1 Model no.
EN-9235TX-32: Gigabit Ethernet PCI Adapter
1.2 Package Contents
Before you start using this product, please check if there is anything missing in
the package, and contact your dealer to claim the missing item(s):
Gigabit Ethernet 32-bit PCI Adapter x 1
Low-profile bracket x 1
Quick installation guide x 1
CD containing setup wizard, user manual & multi-language QIG x 1
1.3 LED Status
There are two LED indicators on the adapter:
• LINK Indicator
This indicator lights green when the Gigabit Adapter is connected to a
Gigabit Ethernet Network device.
• Activity Indicator (ACT)
This indicator blinks green when transmitting or receiving data on the
network.

5
1.4 Product Features
Supports 32-bit 33/66MHz PCI Local Bus Master high-speed operation
(Rev.2.1/2.2/2.3)
Complies with IEEE 802.3, 802.3u, 802.3ab and 802.3x standards
Supports 10/100Mbps full and half duplex, 1000Mbps full duplex
Supports 10/100/1000Mbps Auto Negotiation and jumbo frame
Supports IEEE 802.3x Full Duplex flow control
Supports IEEE 802.1Q VLAN Tagging
Supports PCI 2.2 Wake On LAN function
Supports PCI Message Signalled Interrupt (MSI)
Built-in FIFO buffers reduce overhead of memory transfers
Includes a Setup Wizard program
Includes a low-profile bracket
Plug-and-Play
Supports drivers for Novell 5.X/6.X, Windows
98/ME/NT4.0/2000/XP/Vista/7,Linux 2.4.x
1.5 System Requirements
32-bit PIC slot
CD-ROM Drive
CPU: Pentium III 1G above or similar
Memory size: 256MB RAM or above
Hard Disk: Minimum 100MB disk space
OS: Novell 5.X/6.X, Windows 98/ME/NT4.0/2000/XP/Vista/7,Linux 2.4.x
RJ-45 Ethernet cable

6
Chapter 2: Installation
2.1 Hardware Installation
To install the adapter, please follow the steps listed below:
A. Turn off your computer and unplug/disconnect all cables, including the
power supply.
B. Remove your computer’s case cover.
C. Locate an available PCI Express slot.
D. Remove the screw that secures the back plate (the small piece of metal
that covers the opening for a PCI Express card on the back panel of your
computer), then remove the back plate.
E. Carefully insert the adapter into the PCI Express slot. Do not touch the
metal connector on the adapter.
F. Secure the adapter to the case using the screw you removed from the
back plate.
G. Reattach your computer’s case cover.
H. Reconnect the power cord and all other cables to your computer, and
then turn on your computer.
When the hardware has been successfully installed in your computer, you will
be prompted on-screen to follow the “Found New Hardware Wizard”; please
click “Cancel”and follow 2.2 Driver Installation to install the driver for your
adapter.

7
2.2 Driver Installation
The included CD contains a setup wizard which will guide Windows users
through the installation process, as explained in the next section. You can also
install the drivers manually. Please follow the instructions appropriate for your
operating system.
2.2.1 Windows: Setup Wizard
A. Please insert the Driver CD-ROM into your computer’s CD-ROM drive.
B. Select the product model “EN-9235TX-32”.
For Windows XP
Windows 7/Vista/98SE/ME/2000/XP

8
C. Click “Setup Driver”.
D. The wizard will help you install the driver for Windows 7/Vista/98SE/ME
/2000/XP.

9
E. Restart Windows to complete the installation.
2.2.2 Windows : CD Drivers
Windows 7/Vista/98SE/ME/2000/XP users can alternatively install the drivers
manually. The following instructions will guide you through the CD Drivers
installation procedure.
A. Insert the Edimax Resource CD into the CD-ROM drive.
B. Right-click the icon “My Computer”on the desktop, and then click
“Manage”.
Windows 7/Vista/98SE/ME/2000/XP

10
C. The “Computer Management”screen will appear as shown. Click “Device
Manager”, and you will see various options on the right. Click “Other
devices”, and then from the drop-down list please find “Ethernet
Controller”you have installed. Right-click it, and then select “Update
Driver”.
D. The “Hardware Update Wizard”window will show up. Select “Install from a
list or specific location [Advanced]”, and then click “Next”.

11
E. Select “Search for the best driver in these locations”, and then click
“Browse”and choose the system driver location of the disk, and then click
“Next”.
F. Wait a few seconds for the installation.

12
G. Click “Finish”to complete the installation.
H. Restart Windows to complete the installation.

13
2.2.3 Novell and Linux: CD Drivers
Novell and Linux users need to install the drivers manually. The drivers for
Novell and Linux operating systems can be found in the CD at the following
location:
-/Drivers/Linux/
-/Drivers/Novell/
Please follow the usual driver installation procedure for your operating system.
Contact our technical support team, or the vendor of your operating system for
further help.
Novell and Linux

14
Chapter 3: Troubleshooting
1. What should I do if my PC cannot find the new hardware?
Check to see if the network adapter is inserted in the PCI slot properly.
Otherwise, please reinsert the adapter.
2. What should I do if my PC cannot identify the new hardware?
Check if you can find the network adapter you’ve installed in the following
location:
/My Computer/Manager/Device Manager/Network Adapter/..
If not, please follow the instructions in 2.2 Driver Installation to update the
driver.
3. Why am I only getting a network connection speed of 100Mbps instead of
1000Mbps?
Check your Ethernet cable, and make sure you are using CAT-5e or CAT-6
Ethernet cables. Some CAT-5 cables are not capable of running at
1000Mbps.
Ensure that you are connected to a 1000Mbps switch.
Contact your dealer if problems persist.

15
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
This device and its antenna must not be co-located or operating in conjunction
with any other antenna or transmitter.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible
for compliance could void the authority to operate equipment.
CE Mark Warning
This is a class B product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.
