83-SA2-003 Installation Guide
SwitchAir Active Network Switch Cooling
Effective cool air delivery for front of rack mounted
multi RU switches with single side air intake.
Installation Precaution:
●Install SwitchAir such that the required airow for safe operation of equipment is not compromised.
●Take precaution to avoid interference with the switch input power cords when installing on a live unit.
SwitchAir Installed in Rack
Installs in minutes while network switch is live.
Specications
Rail Depth Range 26.625” to 29.625”
(676mm to 752mm)
Input Connector C14
Chassis Depth 9” (229mm) Airow 47 CFM
Channel Depth 26” (660mm) Switch
Intake / Exhaust
Side/Side
Input
Power / Indicator
90-264 VAC 50/60Hz
15 watts
LED Power Indicator
Safety / Approvals UL, cUL 60950, CE,
FCC Class A
www.edpeurope.com
Installing the SwitchAir
1. Install air channel to rack front using customer provided cage nuts and screws. Use the outside holes
on the channel to attach the channel to the rack. The inner holes will be used by the chassis attaching
to the rack. The rear of the channel doesn’t attach to the rack or switch.
2. Attach the wiper to the chassis using the two ea. 6-32 1/4 “pan head screws. The wiper helps
channelise the cool air from the chassis to the switch intake fans.
3. Slide chassis into channel and attach to the front of the rack using customer provided cage nuts and
screws. Install customer provided power cable to power distribution unit.
Ver: EDPSA2003IG1118.1
