EFG Hybe 039220 User manual

039220 EFG Product development
The product contains one or more
of following materials: Metal, plastic,
wood, fabric, foam.
Hybe
For more information, please visit efg.se.
ASSEMBLY INSTRUCTION 039220
Position the armrest(s) by sliding
them into the tubes underneath
the seat(s).
Assemble the armrests/side tables
Secure them by screwing the M6x20
mm screws through the tubes into
the armrest(s), 4 screws/armrest.
Assemble the armrest top(s)
by screwing the M6x20 mm screws in the
T-nuts from underneath. NOTE! If you are
adding screens, don´t tighten the screws
until the screens are added.
1(2)

Continue assemble the
side
screens. Assemble the
zipper in the corner and
fasten the screen brackets
with the M6x20 mm screws
into two T-nuts underneath
the armrest top and two
tapered holes in the metal
part. There are clearence
holes in the armrest tops
for these screws.
Finish the assembling by tightening the screws for the armrest tops.
Hybe assembly
Assemble the screens
Fasten the brackets onto the
screens with the countersunk
M6x20 mm screws. Two brackets
for the side screens and two or
three for the back screen.
Start to assemble the back
screen. Use the M6x20 mm
screws into the T-nuts under-
neath the armrest tops.
Zipper
2(2)
