EFG Ori User manual

www.efg.se
1
Ori
Assembly Instruction 039223
Always start with the plinth to the inner cor-
ner if this module is included. Screw the 90°-brack-
ets on the sides, aprox. 260mm from the back corner
on each side.
260mm
x4 x4
1. 2.
If adjustment feets are specied its time to mount them on all plinths.
Turn all the plinths upside down and place the plinth-clamp in positions
so you secure that the adjustmentfeet doesn’t collide with it later on
when you assemble the modules together. Adjustment feet comes in
package by 4 or 6 pcs with screws. 2 screws/foot. Use a hammer to hit
the foot on to the side. The sharp aps goes into the wood.
x4 x6
plinth-clamp

www.efg.se
2
See all pos. for adjustment feet below.
Outer corner
x6
Inner corner
x6
1-seater
x4
2-seater
x6
3-seater
x6
x2
frontside
frontside
frontside frontside
frontside

www.efg.se
3
3.
Next step is to assemble all the plinths with its seats.
Each seat is attached with 4 screws and washers.
Turn the seats upside down. If the seat will be placed
on a 2- or 3-seater plinth, you can use steering-dowels.
Place the dowels from the bag of screws, into the center
holes under the seat. They have corresponding holes in
the plinths and can help the assembling. This is an op-
tion, not necessary. Then place the plinth onto the seat/
seats and screw them together. Please screw each screw
clockwise in two rounds.
Holes for steering-dowels
A very useful tool to use on set-ups on 2-seater and 3-seater plinths is
the quick-grip. By using the tool you can push the modules tight. Very
useful on thicker fabrics to nd the correspondng attachment-holes.
x4
Quick-grip

www.efg.se
4
4.
If the module is specied with power or table, its time to
also equipe the plinths with this.
The power-units is placed in the large front holes. Lock-
ed by the connecting ring from behind
unit
ring
There is a small ”hole” on the
backside on all plinths with power,
to lead out the contact.

www.efg.se
5
5.
The table is attached in the small holes on the frontside.
Each table leg is attached with 2 screws and washers
from inside the plinth.
Then turn up the sofa on its plinth and screw on the
table top by using 6 screws.
x2
Screw from inside
x6
Table holes

www.efg.se
6
6.
Now all the modules are prepared to be assembeld. To
assemble a chosen set-up we use the plinth-clamp. It’s
open on one side to have some exibility. It’s not im-
portant where this side is located. The clamp is symme-
tric otherwise.
Always start with the inner corner module and build
from that one if the set-up contains one. Otherwise you
can start anywhere. The clamp pushed the plinth-sides
together when the sides are placed tight in the clamp.
Place the clamps on the sides on the inner corner or
other module. Take the connecting module and slide it
in by force from above.
Slide in with weight

www.efg.se
7
039223 Produced by: EFG Product development
The product contains one or more of following materials:
Metal, plastic, wood, fabric, foam.
To rearrange the modules they need to be slided out
from the clamp. Sit on one of the modules and push the
other one forward or backward. If you have an inner cor-
ner, sit on that one and slide the other ones attached.
Keep this still
Push on the back so the mo-
dule tilts backward and out of
the clamp
