EFG Aura User manual

EFG Aura
General Assembly instruction 039133
For more information,
please visit www.efg.info 150504 / Produced by: EFG Marketing Support
The product contains one or more of following materials:
Wood, metal, plastic.

2 3
1. Adjust the adjustable feet so the Bookcase / Cabinet stand straight
and steady.
2. On Cabinets with doors: Adjust the doors, if necessary, so they are
straight and have even gaps.
Adjust, using the Set Screw, from -1,5 mm to +4,5 mm. The Door is
displaced in relation to the cabinet side.
Loosen the two screws and it is possible to adjust +/-2 mm. After adjust-
ment tighten the two screw again.
The Door can be adjusted depthwise from -0,5 mm to +2,8 mm, using
the eccentric screw. No other screws need to be loosen.
DEPTHWISE
HEIGHT
SIDEWISE
EFG AURA - GENERAL INSTALLATION INSTRUCTIONS
3. The Drawer Fronts can only be adjusted by loosen the screws the
metal box is attached to the Front. There are no adjustment possibi-
lities in the expansion.
4. If the Push-to-open needs to be adjusted it can be done by turning
the pin. Inwards by turning clockwise. Outwards by turning counter
clockwise.
