Model Ei 151TLR Ionisation
Remote control capability
Tamper proof rechargeable lithium battery back up
High performance ionisation chamber
Test/Hush button
Advanced suppression and calibration technology
Interconnectable to other Ei mains powered alarms
Low power cell warning
Kitemarked to BS EN 14604:2005
5 year guarantee
Product Description
The Ei151TLR is an Ionisation Smoke Alarm that runs on
230V AC mains power, and has built in tamper proof
rechargeable lithium cells that act as a battery back up in
the event of mains failure. These rechargeable lithium
cells are designed to have a ten year life and outlast the
life of the smoke alarm itself, whilst providing up to six
months of smoke alarm operation without mains power.
The Ei151TLR allows the detector to be controlled
remotely by either a “Test/Hush” Switch (Ei152), a
“Locate” Switch (Ei159) or a Manual Call Point
(MCP400). If the Ei151TLR is also interconnected to
other Ei mains powered alarms then the whole system
will be controllable remotely.
The Ei151TLR has the ability to interconnect up to twelve
alarms to allow all alarms to sound if just one of the
interconnected alarms should be triggered.
The Ei151TLR has built in circuitry to aid suppression of
voltage transients and RF interference to further reduce
the chances of false alarms under such conditions.
Operation
The green indicator will illuminate to show mains
power is present
The red indicator will flash rapidly to show an alarm
condition for the smoke detector
The “Test/Hush” button will either silence false
alarms or perform a unit self test. In “Test” mode the
alarm will perform a self test and sound the horn
In “Hush” mode the alarm enters a ten minute period
of reduced sensitivity to overcome false alarm
conditions, and will then automatically reset itself
When interconnected to other Ei mains powered
alarms, an alarm on one detector will trigger all other
interconnected alarms within one second (only the
triggered alarm will flash a red indicator)
The smoke detector will emit a beep and flash the
red light every 40 seconds to indicate that the
battery back up is depleted and needs recharging
The detector can be controlled remotely by either a
“Test/Hush” Switch (Ei152), a “Locate” Switch
(Ei159) or a Manual Call Point (MCP400).
MAINS POWERED 230V~
Rechargeable Battery Back-Up

Shannon Free Zone, Shannon, Co. Clare, Ireland.
Ph.+353 61 471277 Fx.+353 61 471053
Email. [email protected]
Web: www.eielectronics.com
E & OE As our policy is one of continuous product development, we reserve the right to alter product details without prior notice. Ei151TLR DataSht RevB
Model Ei151TLR Ionisation
Installation & Placement
Wiring for Interconnected Alarms
Be very careful about correctly wiring the alarms as mixing Live and Neutral
will blow/damage interconnected alarms.
Alarms should be placed in accordance with the general guidelines shown in
the diagram above. These recommendations are based on the problem of
areas of “dead air” close to corners of rooms and apexes of ceilings, which
could result in the prevention of smoke reaching the smoke detector
Please consult instruction booklet for specific installation details
Important Precaution:
Do not install the actual smoke/heat
alarm itself in new or renovated
buildings until all work is completed
(including floor coverings) and the
building has been fully cleaned. The
wiring can be installed when
appropriate. (Excessive dust and debris
from building work can contaminate the
smoke chamber and cause problems,
and it will also invalidate the guarantee).
If it must be installed, cover it
completely, particularly around the
edges, with a dust cover (eg. a plastic
bag), until all cleaning is finished..
Connect wires to the unit as in wiring
diagram. All wiring must comply with
local codes.
Technical Specification
Sensor Ionisation
Sensitivity: Complies with BS 5446 Part 1:
2000
Source: Americium 241
Button Test: Simulates the effect of smoke and
checks electronics and horn.
Supply Voltage: 230V AC
Battery back-up: Rechargeable lithium cells
Power-On Indicator: Continuous green LED
Alarm: Electronic Piezoelectric horn
in unit
Alarm Sound Output: 85dB (minimum) at 3m
Alarm Status: Red LED flashes every second on
unit sensing fire
Temperature Range: 0° to 40°C
Humidity Range: 15% to 95% Relative Humidity
Remote control: Ei152, Ei159 or MCP400
Interconnect: Up to 12 interconnected
Ei150/151TL/151TLR/154TL/155/1
56TLH/156TLR smoke or heat
alarms, along with an EI158 relay
base
Fixing: Screw fixings supplied
Plastic material: UL94VO flame retardant
Dimensions: 140mm x 120mm x 46mm
Weight: 227g
Warranty: 5 year (limited) warranty
Approvals: Kitemarked to BS EN 14604:2005,
CE Approved
Specifications are subject to change
