1
Table of Contents
1. Introduction···················································································· 2
2. Features··························································································· 2
3. Operation notice··········································································· 3
4. Projector figure············································································· 4
4.1 Function list of control panel 4
5. Accessories···················································································· 7
5.1 Remote control 8
5.2 Function list of remote control panel 9
6. Operation guide·········································································· 11
6.1 Connecting component 11
6.2 How to connect the projector
toyourcomputer 12
6.3 How to connect the projector
to a DVD or VCR 12
6.4 Turning on the projector 13
6.5 Basic Image Adjustment 13
6.6 Turning off the projector 14
6.7 Adjusting the projected image height 14
6.8 Adjusting the image focus and zoom 15
7. OSD menu·····················································································16
7.1 Image (Computer mode) 16
7.2 Image (Video mode) 17
7.3 Display (Computer mode) 18
7.4 Display (Video mode) 20
7.5 Audio 21
7.6 Projection setting 22
7.7 Language 23
8. Maintenance and service························································24
8.1 Replacing the lamp module 24
8.2 Cleaning the projector lens 24
9. Appendix························································································26
9.1 Common problems and solutions 26
9.2 Distance ratio of screen and projector 28
9.3 Specifications 29
This Manual: http://www.manuallib.com/file/2687575

2
1.Introduction
Please read this manual carefully before using, to find out:
• How to use the projector safely
• How to use the remote control
• How to set up and connect the projector
• How to start and turn off the projector
• How to use the On-screen display (OSD) menus
• How to replace the lamp module
• How to solve troubleshoot common problems
2.Features
• Use the technology of chip TI 0.7”/ 0.6” DLPTM.
• Full-function remote including mouse controls.
• High quality manual zoom lens.
• Weight only 7.5 pounds with beautifully designed appearance.
• Expandable module design, compact and lightweight.
• High brightness/high contrast. Clear images.
• Provide the adjustment of 4：3 / 16：9 aspect ratio.
• Compatible with the VGA of P- Scan (480P) & HDTV (1080i / 720P).
• Compatible with the video of NTSC / PAL / HDTV.
• Multi languages function window.
This Manual: http://www.manuallib.com/file/2687575

3
3.Operation notice:
Please read and follow the following safety instructions and description carefully.
Inappropriate operation method may result in fire, electrical shock, and personal
injury or shorten the life span of projector.
Warning: Do not cover the lens while the lamp lights up.
Warning: To protect your eyes, do not look directly into the projector’s
light source.
Warning: Make sure that you provide adequate ventilation for the
projector. Do not block the ventilation holes in the case
Warning: To prevent electrical shock, never open the projector case.
Warning: Before using, please make sure that the power cord is connected
to an AC receptacle with a protective safety ground terminal. Do
not neglect the receptacle with protective safety ground terminal.
Warning: To replace the lamp, turn the projector off and unplug the power
cord. To avoid burns, wait 1 hr before opening the lamp door.
For relevant operation procedures, please refer to page 24 the
section of “changing lamp”.
Warning: Please use the power cord provided. And use the receptacle with
a protective safety ground terminal.
Warning: Do not block ventilation openings to avoid danger.
Warning: Do not place any drinks on top of your projector. Spilled liquids
may damage the projector.
Warning: Do not place the projector on a hot surface, moisture or in direct
sunlight.
Warning: Handle carefully during transportation.Avoid dropping it.
This Manual: http://www.manuallib.com/file/2687575

4
4.Projector figure
4.1 Function list of control panel:
Zoom ring
Infrared remote
sensor
Control panel
↑↓
←→
LAMP LED
TEMP LED
POWER LED
POWER
MENU
SOURCE
A
UTO/ENTER
Lens Ca
p
Focus ring
This Manual: http://www.manuallib.com/file/2687575

5
Power LED (Indicator light)
• When the projector is on, Power LED will blink. Press “Power” button to
enter screen, Power LED remains lit continually.
Temp LED (Indicator light)
• When fan malfunctions, the screen will shows the message stating “fan
error, system is forced to turn off!”. Temp LED remains lit continually.
• When the temperature is unusual, screen will shows the message stating
“temperature error, system is forced to turn off!”. Temp LED blinks once
every half of second.
Lamp LED (Indicator light)
• Lamp LED will turn on automatically when lamp is on. Lamp LED
will turn off automatically when the lamp is off..
Power (On/Standby)
• Press to turn power off and on.
• Please refer to the “Starting and turning off the projector” section in Page
13.
Menu (OSD menu)
• Press this button to display the menu, press once again to close the menu.
• If no other action is taken after the menu is opened, it will disappear
automatically after 20 sec.
Source (Signal source)
• Select the signal of Analog RGB, Analog Y Pb Pr, Digital RGB, Composite
Video, S-Video and Component Video in proper order, and automatically
adjust the phase and frequency.
Auto/Enter (confirm/Sync)
• When using menu, this button is the Enter function.
• Under general condition, this button is the Sync function.
This Manual: http://www.manuallib.com/file/2687575

6
ÇÈ (Up and down button)
• OSD active: Press to move between menu options.
• OSD inactive: Press to select the video input source.
ÅÆ(Left and right button)
• When using these buttons, press ”Auto/Enter” button then press right key to
add setting value; on the contrary, left button to reduce the setting value.
This Manual: http://www.manuallib.com/file/2687575

7
5.Accessories
You should check to make sure the accessories below are complete with nothing
missing. For any missing accessory, please contact the local distributor.
Projector lens cap power cord Component Video cable
CompositeVideocable PCAudioin/outcable S-Videocable
VGAcable USBcable Carrybag
VGA－RCAcable DVIcable remotecontrol&2AAAbatteries
This Manual: http://www.manuallib.com/file/2687575

8
5.1 Remote Control
The infrared sensor is located on the top of the projector. The distance between the
sensor and remote control should not exceed 10 meters for the remote control to
function correctly.
How to insert batteries in the remote control:
1) Remove the battery compartment cover.
2) Insert two AAA batteries into the battery compartment. Ensure the batteries
polarity is aligned correctly.
3) Replace the battery compartment cover.
• Using remote control
This Manual: http://www.manuallib.com/file/2687575

9
5.2Function list of remote control panel:
Function key Function description
Freeze/Esc/L • OSD inactive: press this button to freeze the display image.
Press again to resume motion.
• OSD active: press this button to exit.
• Mouse active: Use as the left mouse button.
Enter/R • During common status or using OSD options, please refer to
“Auto/Enter” of “Projector panel” in page 5.
• Mouse active: Use as the right mouse button.
Power • Please refer to “Turning on and turning off the projector”
section in page 13.
Mode • Press ”Mode” button to make LED light become green. At
this time, the remote control presents mouse status and
capable of simulating mouse.
• If no action is input within 15 sec, remote control will return
to common status automatically. Please press “Mode” button
again to return to mouse mode.
• You must have USB cable connected between your computer
and the projector to use this option.
Menu • Please refer to “Menu” of “Projector panel” in page 5.
Source • Select the signal of Analog RGB, Analog Y Pb Pr, Digital
RGB, Composite Video, S-Video and Component Video in
proper order.
Blank • Press to set the current image into a plain blue screen. Press
again to restore the display image.
Auto • This button can automatically adjust the picture position and
frequency.
Pg.Up • Use as display image magnifying (*).
• Mouse active: Use as Page up cursor.
Pg.Dn • Use as display image minifying (*).
• Mouse active: Use as Page down cursor.
This Manual: http://www.manuallib.com/file/2687575

10
• Press this button, then press right and left button to execute
keystone correction.
• Press button to correct a display image that is wider at the
bottom.
• Press button to correct a display image that is wider at the
top.(*)
• Do not activate when displaying text or spreadsheets to
eliminate text distortion.
 • OSD inactive: The same as the Up, Down, Left, Right
control button on the panel. (*)
• Mouse active: Use as the Up, Down, Left, Right button of
mouse.
Press “Auto” button to return to previous setting value.
This Manual: http://www.manuallib.com/file/2687575

11
6.Operation guide
6.1 Connecting components
You can connect the projector to your computer, DVD player or VCR. To connect
the projector to a DVD player or VCR, go to “Connecting to a DVD player or
VCR” on page 12.
1. VGA In/Out port
2. USB In port
3. S-Video In port
4. Composite Video port
5. PC Audio In/Out In port
6. DVI-D In port
This Manual: http://www.manuallib.com/file/2687575

12
6.2 How to connect the projector to your computer
1) Plug the VGA cable into the VGA port at the left side of projector, then plug
the other end of VGA cable into the computer.
Note: If you are connecting to a notebook, you may need to make adjustments to
the notebook’s display settings first. Please refer to the user’s guide that
came with your notebook.
2) If you want to use the remote control as a mouse, plug the USB cable into the
USB port at the left side of projector, and then plug the other end into the
computer.
3) If your presentation contains an audio track, plug the PC Audio in/out cable into
the Audio In port at the left side of projector then plug the other end into the
computer.
4) Turn on the projector first, then the computer.
6.3 How to connect the projector to a DVD player or VCR
If you are using composite video cable, please refer to the following
description to complete the connection action.
1) Plug the yellow, red, and white composite cable connectors separately into the
same color port at the left side of projector.
2) Then plug the yellow, red, and white connectors on the other end into the
corresponding ports on the back of the DVD player or VCR.
If you are using S-video cable, please refer to the following description to
complete the connection action.
1) Plug the S-Video cable connector into the S-Video port at the left side of
projector, then plugs the other end into the DVD player or VCR.
2) Plug the red and white connectors from a composite video cable into the
corresponding ports at the left side of projector, then plug the other end of red
and white connectors into the corresponding ports on the back of DVD player or
VCR.
Note: When you are using the S-Video cable along with the A/V cable, make sure you
do not plug in the A/V cable’s yellow connector.
This Manual: http://www.manuallib.com/file/2687575

13
After you have connected all components to the projector, you are
ready to begin using the projector.
6.4 Turning on the projector:
1) Remove the lens cap.
2) Ensure the cable connectors have connected properly.
3) Plug the power cord, press the main switch on the top of power cord socket of
the projector, Power LED blinks steadily and slowly.
4) Press down the “Power” button on the remote control or panel to turn on the
projector, the Power LED displays steady green.
5) The projection screen displays “Warming up! Please wait! ”. Please wait for
30sec; the projector will automatically detect the input source.
6) If the screen displays “No signal”, ensure the source is turned on and the cables
are properly connected.
7) To have the best image performance, press “AUTO/ENTER” each time when
you turn on the projector.
Note:After the projector is turned on, it will detect the interior temperature
automatically. If it is overheated, Lamp LED will blink rapidly and the fan
will carry out cooling action automatically after rotating 8 sec. At this time,
“Power” will have no function.
6.5 Basic image adjustment
1) Power up your equipment in right order and aim the projector at the screen.
2) Please rotate the zoom ring to adjust the image size.
3) Please rotate the focus ring to adjust the image focus.
4) Please use the tilt foot to adjust the image height.
5) Please use the panel or remote control to adjust the horizontal and vertical
position of image or execute keystone correction.
6) Please use the OSD menu to adjust the brightness, contrast and color of the
screen.
This Manual: http://www.manuallib.com/file/2687575

14
6.6 Turning off the projector
1) Press “Power” button to turn off the projector lamp.
2) When you press the “Power ” button, you will see the message stating “Press
Power again to turn off the lamp!”. At this time, you only have to press
“Power” button again to turn off the projector. Or else the message will
disappear automatically after 5 sec.
3) After the lamp is turned off, LED indicator will blink rapidly. At this time,
“Power” will have no function. To restart the projector, please wait 60 sec,
when LED indicator blinks slowly and steadily, you can restart the projector.
4) After turning off the main switch on the top of power cord socket of the
projector, then disconnect the power cable.
Note: To extend the lamp life-span, please do not unplug the power cord
immediately after the lamp is turned off. Please allow at least 120 sec for
the fan to stop, and then you can unplug the power cord.
6.7 Adjusting the projected image height.
To adjust the tilt angle of the projector
To raise the projector
1. Press and hold the Adjustor-foot release button.
2. Raise the projector to the height you want, then release the button to lock the
foot into position.
A
d
j
ustor-foot release button
A
d
j
ustor-foo
t
This Manual: http://www.manuallib.com/file/2687575

15
To lower the projector
1. Press and hold the Adjustor-foot release button.
2. Lower the projector to the height you want, then release the button to lock the
foot into position.
6.8 Adjusting the image focus and zoom
You can adjust the zoom ring to magnify or minify the image. Rotate
counterclockwise to magnify the image. Rotate clockwise to minify the image. To
adjust the focus, please rotate the focus ring to obtain the best focus. The focus
distance of this projector is 1.4~12 meter.
Zoom Wheel
Focus rin
g
This Manual: http://www.manuallib.com/file/2687575

16
7.OSD Menu
Press “Menu” button to open the menu. Press up and down button to choose the
OSD options or press Esc to exit. To enter the submenu, please press “Auto/Enter”
button or right button. Under the submenu, press “Menu” or the Esc button on the
remote control to return to Menu main screen or double click to exit the OSD
menu.
7.1 Image (Computer mode)
Submenu
options Description Operation method
Brightness
(**) Adjusts the brightness of the
display image
• Pressbutton can reduce the brightness of
display image.
• Pressbutton can increase the brightness of
display image.(*)
Contrast Adjusts the contrast of the
display image. • Pressbutton can reduce the contrast of
display image.
• Pressbutton to increase the contrast of
display image.(*)
Keystone Corrects a display image that is
wider at the top or at the bottom. • Pressbutton to correct the display image
that is wider at the bottom.
• Pressbutton to correct the display image
that is wider at the top.(*)
Zoom Enlarges or reduces the display
image. • Pressbutton to reduce the display image.
• Pressbutton to enlarge the display
image.(*)
• Please press Auto/Enter button to enter zoom
operation.
 Under this mode, pressbuttons to
shift the image, press the Pg Up and
Pg Dn button on the remote control to
adjust the image size.
* Press “Auto” button to return to previous setting value.
**If the source is switched to HDTV/DVD 480P, the “Brightness” turns to “Tint” the
adjust the balance between red and blue colors in the image.
This Manual: http://www.manuallib.com/file/2687575

17
7.2 Image (Video mode)
Submenu
options Description Operation method
Brightness Adjusts the brightness of the
display image. • Pressbutton can reduce the brightness
of display image.
• Pressbutton can increase the brightness
of display image.(*)
Contrast Adjusts the contrast of the
display image. • Pressbutton can reduce the contrast of
display image.
• Pressbutton to increase the contrast of
display image.(*)
Hue Adjusts the balance between
red and green color levels. • Pressbutton to increase the color level
of green.
• Pressbutton to increase the color level
of red.(*)
Saturation Changes the display image
from black and white to color. • Pressbutton to reduce the color
saturation.
• Pressbutton to increase the color
saturation level.(*)
Sharpness Adjusts the sharpness of the
display image.. • Pressbutton to reduce the sharpness.
• Pressbutton to increase the
sharpness.(*)
* Press “Auto” button to return to previous setting value.
This Manual: http://www.manuallib.com/file/2687575

18
7.3 Display (Computer mode)
Submenu options Description Operation method
Frequency Minimizes any vertical bars
or stripes visible on the
screen background.
• PressÅÆbutton to adjust
(*).
Phase Removes any horizontal
distortion and clears or
sharpens the displayed
characters.
• Press ÅÆbutton to
adjust(*).
V position Adjusts the display image
up and down. • PressÅbutton to move down
the display image.
• PressÆbutton to move up the
display image.(*)
H position Adjusts the display image
left and right. • PressÅbutton to move the
display image to the left.
• PressÆbutton to move the
display image to the right.(*)
This Manual: http://www.manuallib.com/file/2687575
