Eiki XGA User manual

XGA "Powerhouse" Projector
r6,500 ANSI Lumens bright at 90% uniformity
and a 1300:1 contrast ratio.
rNative XGA. Compatible with UXGA through
VGA. Video scaling.
rWorks on 120V AC power (15 amp circuit).
No special wiring required!
rProjects images up to 33.3' wide (500" diagonal).
Wide choice of lenses.
rSome lenses feature memory. Improved Lens
Installation System.
rCompatible with most video signal input,
including DVI, RGB, Y/C, DVD, HDTV.
rDisplays video 4:3 & 16:9 in NTSC/PAL/
SECAM/NTSC 4.43/PAL-M/PAL-N.
rImproved progressive scan with HDTV at 1080i
and 2-3 pulldown support.
r3fixed inputs, two modular bays. Wide range
of available modules.
rSupplied softwarepermits the preconfiguring
of color adjustments.
rOptional Network Control module permits
network monitoring and control.
rStackable Cabinet Design.
r3Year / 6000 Hr.* Warranty.
Shown with optional
lens installed, connection
cover removed.
Outstanding Features
1. Compatibility up to UXGA (1600x1200) & HDCP.
2. Touch-pad menu navigation on remote control.
3. Accepts computer USB Mouse for projector control.
4. 3 fixed inputs, 2 module bays.
5. Operable through 360° pitch rotation.
6. RF Wireless/Wired remote control.
7. Built-in mechanical shutter. Custom warm-up screen image option.
8. PIN code security for Remote and Local control.
9. Key Lock, PJ Lock and USB Lock Security.
10. Utilizes existing Powerhouse lenses (but different Throw:Width).
Note: compared-to the LC-X6, the LC-X6A lacks the following:
Warp and Blending Module • Audio Input and Output • Local Control Touch Pad • Some Accessories
XGA "Powerhouse" Projector
Get the rich color imaging of 3-panel LCD technology
ina54.5 lb. highly configurable large venue projector.
Projectors... and more!
2345
LC-X6A 6500 ANSI lumens
LC-X6A 6500 ANSI lumens

Specifications subject to change without notice.
©2007 EIKI International, Inc. Printed in the USA. 03/01/07
Brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6500 ANSI Lumens (5200 in Eco mode)
Uniformity....................................................... 90%
SizeofColorPalette.......................................... 16.7Million
ContrastRatio....................................... 1300:1(FullON/OFF)
HorizontalResolution.................................... 800TVLines(HDTV)
ProjectionLamp........................................... 300WUHPx2
EstimatedLampLife...................................... upto3,000Hours
Imaging System . . . . . . . . . . . . . . . . . . . . . . . 1.4” PolySilicon active matrix TFT Panels x 3
Screen Pixels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1024 x 768 in stripe configuration
TotalPixels.................................... 2,359,296((1024x768)x3)
Lens . . . . . . . . . . . . . . . . . . . . . . . . . . Not included. See specifications of optional lenses
ImageDiagonal............................. 30~500 in. (76.2~1270 cm.)
Image Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.5~33.3 ft. (0.762~10.16 m.)
Throw Distance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . See specifications of selected lens
Front Elevation / Maximum Pitch . . . . . . . . . . . . . . . . . up to 3.65° up/360° (max. 20° tilt)
Vertical Anti Keystone . . . . . . . . . . . . . . . . . . . . . . Power Lens Shift, Ratio (T:B) 10:0~0:10
Horizontal Anti Keystone . . . . . . . . . . . . . . . . . . . . . . Power Lens Shift, Ratio (L:R) 3:2~2:3
Vertical Keystone Correction . . . . . . . . . . . . . . . . . Digital: Variable Up to 40° up or down
Horizontal Keystone Correction . . . . . . . . . . . . . . . Digital: Variable Up to 30° left or right
Scanning Frequency . . . . . . . . . . . . . . . . . . . Auto: H Sync. 15-120kHz; V Sync. 48-120Hz
DotClock................................................... 230MHz
Image Orientation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Normal, Reversed, Inverted
Local Control / Power Management . . . . . . . . . . . . . . . . Full Function/Auto Lamp Shut-Off
Remote Projector & Mouse Ctrl . . . . . . . . . . . . . . . . . . . . . . . . . . . RF Wireless/Wired x 1
MouseControlPorts.................................... USB-Ax1,USB-Bx1
WiredRemoteJack......................................... MiniStereox1
RS-232Port.......................................... (In&Out)Dsub9x2
Computer Native Resolution ................................ 1024x768(XGA)
Computer Compatibility . . . . . . . . UXGA, SXGA+,SXGA, W-XGA, XGA, SVGA, VGA, MAC
Computer Resolutions . . . . . . . . . . . . . . . . . . . . . . . . . . . 1600 x 1200 through 640 x 480
Computer: Image Sizing .................. Normal or Smart compressed or expanded
Video: Standards . . . . . . . . . . . . . . . . . . . . NTSC/PAL/SECAM/NTSC 4.43/PAL-M/PAL-N
Video: Formats Supported . . . . . . . . . . . . . . . . . . . . . . Normal 4:3 and Wide Screen 16:9
Video: Image Sizing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Progressive Video Scaling
Video: Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Composite, S-Video, Component
Inputs:
1a. either Computer: HD15 x 1 Analog RGB
1b. or DVI-D x 1 Digital RGB Computer or HDCP Video
2a. either Computer: BNC x 5 (RGBHV)
2b. or Video: BNC x 3 (Composite/Component: Y,Pb/Cb,Pr/Cr)
3. Video: RCA x 3 (Composite/Component: Y,Pb/Cb,Pr/Cr)
and S-Video x 1
4. (Empty) (bay is modular, Digital/Analog module compatible)
5. (Empty) (bay is modular, Digital module compatible only)
Output: Computer Analog RGB.................... HD15x1 (monitors Input 1 Analog)
Fan Noise .........................................42 dBA, 39 in Eco mode
Size (H x W x D) ................. 9.92 x 20.39 x 23.86 in. (252 x 518 x 606 mm.)
Weight................................................ 52.9lbs.(24kg.)
Packaged Size (H x W x D) . . . . . . . . . . . 21.4 x 29.4 x 32.6 in. (542 x 746 x 826 mm.)
PackagedWeight.......................................... 75lb.(34kg.)
Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . 100~120/200~240V AC, 50/60Hz
Power Consumption . . . . . . . . . . . . . . . . . . . . . 900 Watts, 720 in Eco mode (13 standby)
Heat . . . . . . . . . . . . . . . . . . . . . . . . 3071 BTU/hr (774 Kcal/hr), 2457 (619) in Eco mode
PowerCord.................................... 10’(3.m)Type3,Detachable
SafetyCompliance.............................................. ULListed
OperatingTemperature................................... 41~95°F(5~35°C)
User Maintenance ............................... Clean Air Filter,Replace Lamp
Warranty: (to the original end-use customer)
Projector ........................ 3Yr./6000 Hr.*(Parts/Labor to Correct Defects)
Warranty: Lamp . . . . . . . . . . . . . . . . . . . . . . . 90 Days. (Failed Lamp Replaced Pro-Rata)
*whichever occurs first
SPECIFICATIONS: LC-X6A
Eiki International, Inc.
30251 Esperanza, Rancho Santa Margarita, CA 92688-2130
Tel: [phone]; Fax: [phone], E-mail: [email protected]
In Canada, 310 First St.- Unit 2, P.O. Box 156, Midland, ON L4R 4K8
Phone: [phone], Fax: [phone] E-mail: [email protected]
http://www.eiki.com
Talk to your EIKI Dealer... the"pro" in projectors.
Projectors... and more!
2345
LC-X6A 6500 ANSI lumens
Lamp Contains
Mercury. Do not
put in trash.
Dispose-of-as Hazardous
Waste, according to the
laws in your jurisdiction.
LC-X6A 6500 ANSI lumens
Afull array of standard connections,
plus spare bays for additional
modules.
RF wireless remote control
with touch pad input.
Optional smoke resistant external
air filter box.
Arange of wide angle
and telephoto lenses is
available to satisfy a
variety of projection
requirements.
INCLUDED ACCESSORIES:
Owner's Manual CD. Quick Start Manual. AC Power Cord
10' (3.m). VGA-type Input Cable 6’ (1.8m) HD15~HD15.
Wireless/wired Remote with Mouse Control & 2 x AA batteries.
Lens Adapter Ring x 2. Lens light shield x 2. Real Color
Management Software CD.
OPTIONAL ACCESSORIES:
Telephoto, Midrange & Wideangle Lenses. Replacement Lamps.
DVI-D Module. 5 BNC Module and Y/C Input Modules. PC
(HD15) Input Module. Dual (SD & HD) SDI Module. Network
Module. Warp & Blending Module. Projector USB Key. Smoke
Resist Box. Hard Shipping Case with wheels and telescoping
handle. Ceiling Mount and Post & Plate. Long Life Lamp & Ballast
Kit. Extra Long Life Lamp & Ballast Kit. Ez-250 Local Control.
NPC-1 Network Control.
