Eiki LC-X1000 Installation and operating instructions

SP Controls Application Note
Eiki LC-X1000
Revision B
I. Driver Features
1. Command Format
This device is controlled through RS-232.
2. RS-232 Commands
Power On
Power Off
Volume Up
Volume Down
Source 1 (VGA)
Source 1 (DVI)
Source 2 (BNC)
Source 2 Comp Video (BNC)
Source 2 YPbPr
Source 3 Comp Video (RCA)
Source 3 S-Video
Source 3 YPbPr
Menu
Menu Off
Adj Up
Adj Down
Adj Left
Adj Right
Enter
Auto Image
Zoom
Focus
Audio Mute On
Audio Mute Off
Video Mute On
Video Mute Off
Keystone Up
Keystone Down
3. Ot er Driver Features
Default Power Status Feedback
Pro ector Restart Lockout Timer (Default)
RS-232 Polling
95 Seconds
II. RS-232 Control Wiring
Wire the control cable to a male DB-9 cable as follows
Connect male DB9 to Eiki adapter cable (included with projector), then connect to the projector port
labeled Control Port.
Serial Adapters (for NRC only) A and B
Alternate Wiring If you do not have the optional Eiki serial adapter cable, terminate the SP Controls
control cable directly on a male 8-pin mini-DIN as follows
Connect the male mini-DIN to the projector port labeled Control Port.
© 2003-9 SP Controls Inc. SP Controls reserves the right to modify specifications without notice at any time.
RX to 2
GND to 5
TX to 3
SP Controls
Device
Control
Cable
3 4 5
8
76
21
GND to 8
RX to 6
TX to 1
Control
Cable
SP Controls
Device

SP Controls Application Note
Eiki LC-X1000
Revision B
III. Projector Configuration
To ensure the projector stays in sync with the control system, set the DISPLAY feature to OFF in the
projector's on screen menus. Scroll over to the menu to the SETTING menu whose first item is
LANGUAGE and toggle down to DISPLAY. De-select the DISPLAY option.
You may also wish to set POWER MANAGEMENT to OFF in the SETTING menu. By default, the
projector will shut itself off in 5 minutes in the absence of an input signal.
© 2003-9 SP Controls Inc. SP Controls reserves the right to modify specifications without notice at any time.
