Einstein E-Collar 800TS User manual

800TS / 1200TS
Owner's Manual

Thank you for purchasing the Einstein Remote Education Collar from E-Collar
Technologies, Inc. We have made every attempt to provide you with the
most technologically advanced product using the most stringent quality and
manufacturing standards.
We are confident you will be pleased with the results you will attain with the
800TS / 1200TS.
Please remember you will get better results with the use of lower stimulation
combined with consistent training techniques. The use of high levels of
stimulation should only be used as a last resort and in life-threatening
situations.
Good luck with your training and please feel free to contact us should you
have any questions.
1-855-326-5527 or 1-855-ecollar
800TS / 1200TS Owner's Manual
Welcome to the World of Einstein E-Collar™
Remote Education Collar
Einstein

02
Einstein Owner's Manual 800TS / 1200TS
CHARACTERISTICS
•
•
•
•
•
•
•
•
•
•
Range : 1 Mile
Three Stimulation Modes Supported (Momentary, Continuous,
and Combo Mode)
Tapping Sensation
Employs Ni-MH Rechargeable Batteries
Convenient Intensity Dial for Quick Adjustment
Stimulation Levels Adjustable from 0 to 100
Collar Receiver Light for Night Tracking
Lock and Set Stimulation Feature
Stimulation Boosting Mode Provides Instant Responses to
Emergency Situations
User Adjustable Boosting Levels

Einstein Owner's Manual 800TS / 1200TS
CONTENTS
• Collar Receiver with Strap
• Lanyard
• Test Light
• Contact Point Tool
• Contact Points 3/4"
• Battery Charger
• Transmitter
• Owner’s Manual
03
800TS / 1200TS
Owner's Manual
and 5/8” Contact Points

TABLE OF CONTENTS
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Safety and General Information
Transmitter Parts
Collar Receiver Parts
Charging the Batteries
Turning Your Einstein On/Off
The LCD Display Features
Button Functions
Changing the Intensity Level of Stimulation
Lock/Unlock the Stimulation Intensity Level
Indicator Light
Lost Transmitter Mode
Testing Your Einstein
Replacing the Contact Points
Correctly Fitting the Collar
Warranty
Accessories
05
06
07
08
10
11
12
17
20
21
22
23
24
25
26
27
Einstein Owner's Manual 800TS / 1200TS
04

SAFETY AND GENERAL INFORMATION
•
•
•
•
The Einstein Education Collar complies with all National and
International Standards and Guidelines for human exposure to radio
frequency electromagnetic energy.
Nearly all electronic devices are susceptible to electromagnetic
interference (EMI) if inadequately shielded or designed without
precautions to EMI.
Einstein E-Collar transmitters manufactured by E-Collar
Technologies, Inc. comply with Article 15 of the FCC rules and
operate under Part 95 of FCC regulations.
IMPORTANT NOTICE
1.
2.
To avoid Electromagnetic Interference and/or compatibility
conflicts, please turn off your transmitter and collar receiver in any
facility where posted notices instruct you to do so. Never use your
equipment in close proximity of a Hospital or Health Care Facility
or enter the facility without turning off both units.
An FCC license is not needed to operate Einstein E-Collar
transmitters. However, any change or modification made to the
transmitter, including the supplied antenna, without the expressed
written approval of E-Collar Technologies, Inc. could void your
authority to operate.
Einstein Owner's Manual 800TS / 1200TS
05

TRANSMITTER PARTS
Einstein Owner's Manual 800TS / 1200TS
06
Antenna
Stimulation Level Dial
/ Set and Lock Knob
Stimulation Button(Black) Indicator Light
(LED Window)
LCD Display
Tapping Sensation
Button
Light and On/Off Button
Battery Charging Receptacle
and Rubber Cover
Momentary / Continuous
Mode Button
Stimulation Boost Button
or Continuous Button(Red)
See figure on page 12 for button functions

COLLAR RECEIVER PARTS
Battery Charging
Receptacle and
Rubber Cover
Collar Strap
5/8” Contact Points
Indicator and Tracking Light
(LED Window)
On/Off Button
THIS D-CLIP IS
NOT TO BE USED
AS A TIE OUT
Einstein Owner's Manual 800TS / 1200TS
07

CHARGING THE BATTERIES
Indicator Light will blink “Green” under normal operation. It will
flicker “Red” when stimulation is applied and will blink “Red”
when recharging is required. We recommend you fully charge
your Einstein every six months when not in use to maintain
battery life.
Battery Charger
Transmitter Battery Charging
Receptacle and Rubber Cover
Collar Receiver Battery Charging
Receptacle and Rubber Cover
120 Volt Charger
Wall Outlet
Charging Cable
Einstein Owner's Manual 800TS / 1200TS
08

Einstein Owner's Manual 800TS / 1200TS
CHARGING THE BATTERIES
09
The indicator light will turn solid red during the 10 to 12 hour charge
cycle and stay red even though the unit is fully charged.
•
Battery Care:
It is important to fully charge the batteries and fully discharge
them for the first three uses. After that it is not necessary to fully
discharge the batteries with each use, because NiMH do not
exhibit “memory effect” like other rechargeable battery types. It is
recommended that every six months you recondition the batteries
by fully discharging them and then fully charging them, this will
ensure you get the rated 500 charges per battery.
•

TURNING YOUR Einstein ON/OFF
•
To turn the Collar Receiver On or Off :
Press the power button to turn collar receiver on/off.
TRANSMITTER ON/OFF BUTTON
COLLAR RECEIVER ON/OFF BUTTON
•
To turn the Transmitter On or Off :
Press the “L” light button for more than 2 seconds.
If “L” light button is pressed less than 0.5 seconds, it will turn On/Off
Tracking lights of Collar Receiver.
Einstein Owner's Manual 800TS / 1200TS
10

THE LCD DISPLAY FEATURES
•
Press down on the Stimulation Level Knob or press any button
to wake up the LCD display. Please note that if the collar
receiver is on, pressing the stimulation buttons and/or the
tapping sensation button will trigger the collar receiver.
Flashing “1D” indicates the stimulation is
ready for adjustment. Solid “1D” indicates
stimulation is “Locked”, tap the knob down to
unlock and adjust stimulation.
Displays the Stimulation Level :
“0”means no stimulation
and “HI” means the highest level(100
)
Indicates current stimulation mode: “M” indicates Momentary/
Momentary Boost, “C” indicates Continuous/Continuous Boost,
Both “M” and “C” illuminated indicates Momentary/Continuous/
Both Button Boost. “M” and “C” mode is recommended for first time
e-collar users.
Einstein Owner's Manual 800TS / 1200TS
11

BUTTON FUNCTIONS
Tapping Sensation
Button Light and On/Off Button
Momentary/Continuous
Mode Button
The 800TS / 1200TS transmitter is equipped with five control buttons,
LCD display, and an adjustable dial. For long range use hold the
transmitter up like the Statue of Liberty and never allow the antenna to
touch anything as it will decrease the range. Power lines and foliage
will also reduce the range.
Einstein Owner's Manual 800TS / 1200TS
12
Stimulation Button(Black)
Stimulation Boost Button
or Continuous Button
Determined by the Mode
Setting(Red)
TRANSMITTER

Einstein Owner's Manual 800TS / 1200TS
BUTTON FUNCTIONS
13
Three Programmable Modes are provided based on the status of M/C
button. Two Stimulation buttons will be working differently.
/%$WVVQP %QODQ/QFG /QOGPVCT[
/QFG
%QPVKPWQWU
/QFG
6%ODFN 0RPHQWDU\ 0RPHQWDU\ &RQWLQXRXV
65HG &RQWLQXRXV 0RPHQWDU\
%RRVWHU
&RQWLQXRXV
%RRVWHU
6%ODFN65HG 0RPHQWDU\
%RRVWHU 1$ 1$
65HG6%ODFN &RQWLQXRXV
%RRVWHU 1$ 1$
77DSSLQJ
6HQVDWLRQ
7DSSLQJ
6HQVDWLRQ
7DSSLQJ
6HQVDWLRQ
DQG'LVSOD\
Momentary/Continuous Button "M/C"
- M/C Button on the backside of the transmitter allows the user to easily
switch between the three stimulation modes.
- Combo Mode : In this mode, both “M” and “C” icon will be displayed
simultaneously. Stimulation (Black) Button “S” will send momentary
stimulation and Stimulation Booster (Red) Button “S” will send continuous
stimulation.
- Momentary Mode : Stimulation (Black) Button “S” and Stimulation Booster
(Red) Button “S” will send Momentary Stimulation. In this mode, “M” icon will
be displayed in the LCD window.
- Continuous Mode : Stimulation (Black) Button “S” and Stimulation Booster
(Red) Button “S” will send Continuous Stimulation. In this mode, “C” icon will
be displayed in the LCD window.
--> Combo Mode --> Momentary Mode --> Continuous Mode --

Stimulation Button “S(Black)”
- Sends momentary or continuous stimulation to the collar receiver
based on the state of Momentary/Continuous Button.
- Pressing stimulation button in continuous mode will send stimulation
to the collar receiver for the duration of the button being pressed. After
10 seconds the Over-Stimulation feature will stop the stimulation until
the button is released and pressed again.
Stimulation Booster Button “S(Red)”
- Send momentary or continuous boosted stimulation.
- The default value of the boosted level is 20, it can be adjusted to any
value between 1 and 60. Smaller and more sensitive breeds should
use levels 1 through 20, larger more stubborn breeds can use 20
through 60.
- If current level is higher than “100-boosting level”, output intensity
level will be 100 (HI).
- Useful function in emergency situations.
Einstein Owner's Manual 800TS / 1200TS
BUTTON FUNCTIONS
14
- Boosting Stimulation in Combo Mode
Momentary boosting is accomplished by first sending a momentary
stimulation pulse “S(Black)” to the dog and keeping the button pressed
and then applying the Continuous “S (Red)” Button
Continuous boosting is accomplished by first pressing the Continuous
“S (Red)” Button keeping the button pressed and then applying the
Momentary “S (Black)”. The over-stimulation feature will only allow 10
seconds of continuous stimulation.

Einstein Owner's Manual 800TS / 1200TS
15
* 1st pressing will make the collar receiver light flashing.
* 2nd pressing will make the collar receiver light turn solid.
* 3rd pressing will make the collar receiver light turn off.
* When the button is pressed, “L” will be displayed.
BUTTON FUNCTIONS
Change the mode to Momentary Mode (Press M/C button until “M” is displayed)
Change the intensity level to “0”
Press S(Black) button for more than 5 seconds to enter the Booster Level
Change Mode.
The intensity level display will start to blink. Rotate the dial to change the
boosted level from 1 up to 60.
1.
2.
3.
4.
- When pressed for more than 2 seconds, it will turn On or Off the transmitter.
Momentary/Continuous Mode Button "M/C"
- M/C Button on the backside of the transmitter allows the user to easily
switch between the three stimulation modes.
How to Change Boosting Level
- Default boosting level is 20. Please follow the procedure below to
change the boosted level.
- If the state of Momentary/Continuous Button is in Combo mode, this
button will be used as Continuous Stimulation Button.
Tapping Sensation Button “T”
- Sends education tapping sensation to the collar receiver.
Light Button(On Back) “L”
- When pressed less than 0.5 seconds, it will turn On or Off the high
intensity night tracking light which is good for finding your dog after dark.

Einstein Owner's Manual 800TS / 1200TS
16
Back to Factory Default Setting
Your e-collar transmitter is a small computer, if you feel it is behaving badly,
it probably needs to be reset. Please turn the stimulation to “0” and press
both stimulation buttons and the tapping sensation button at the same time
for 2 seconds. The mode and boost level will revert back to the default
settings.
BUTTON FUNCTIONS
Press S(Black) button again to save new level and exit from Booster Level
Change Mode.
If any other button is pressed or 20 sec passes, Booster Level Change Mode
will be cancelled.
5.
6.

Einstein Owner's Manual 800TS / 1200TS
17
CHANGING THE INTENSITY LEVEL
OF STIMULATION
Rotating clockwise increases the
stimulation level and conversely,
rotating counter-clockwise lowers
the stimulation level.
It is highly recommended that the user practices changing levels
and modes before putting the collar receiver on the dog.
Setting the correct stimulation level for your dog is very important.
To set your “conditioning” stimulation level, put the collar receiver
(see page 25 for proper fitting technique) on your dog. Let him/
her get used to the collar receiver for a couple of hours.
While watching your dog, turn the level to “0” and press the
continuous stimulation button. Slowly turn the stimulation up at
a rate of approximately 2-3 levels per second. When your dog
first perceives the stimulation, usually between 5 and 30, release
the button. This is your “conditioning” stimulation level. You may
need to increase the “conditioning” level a few levels to get your
dog to respond, some dogs are more stubborn and need more
stimulation. The ‘corrective” level is typically 10 to 30 levels
higher than the “conditioning level.

Einstein Owner's Manual 800TS / 1200TS
18
USING THE E-COLLAR IN CONTINUOUS AND MOMENTARY
MODES
For example, if you want your dog to come to you and heel, you
can hold the button down until your dog comes and heels or if
jumping is an issue, you can hold the button down anytime their
front paws are off the ground. Your dog will learn that he/she
controls the stimulation.
Setting the “Corrective” stimulation level is a little more difficult
due to the wide differences in temperaments and stimulation
tolerance among the many breeds of dogs. On average, it is
normally 20 to 40 levels higher than the “Conditioning” level.
This higher level will only be used in “Momentary” mode as not to
over-stimulate your dog.
CHANGING THE INTENSITY LEVEL
OF STIMULATION

Einstein Owner's Manual 800TS / 1200TS
19
IMPORTANT TRAINING TIPS
E-Collars should be used to reinforce commands your dog already
knows. It is not a replacement for basic leash obedience training, but
a tool to allow you to better communicate to your dog.
For best results, use the least amount of stimulation required to
get compliance from your dog. A calm and consistent approach to
training will always produce better long term results. It is highly
recommended that aggressive dogs be taken to a professional trainer
for evaluation before e-collar use.
There are many different e-collar training techniques
recommended by a variety of professional trainers. We believe
you, the owner of the dog, can best determine the most
successful technique for your dog. YouTube has many videos
demonstrating these varying techniques by simply searching
“e-collar training” or “remote dog training techniques”.
Good Luck with your training!
CHANGING THE INTENSITY LEVEL
OF STIMULATION
* CAUTION : Do not put the Einstein E-Collar receiver on a human being.
* WARNING : E-Collar Technologies, Inc. is not responsible for any misuse of
the Einstein E-Collar and loss and damages as a result of a dog
bite. Aggressive dogs should be evaluated by a professional
trainer before e-collar use.
