Eisco WBTH-6H User manual

UNSTIRRED DIGITAL
WATER BATH
CAT NO. WBTH-6H
Instruction Manual

SUMMARY
Water Bath is used for distillation, concentration, drying and thermostatic
heating in schools and colleges.
1. The enclosure of the product is formed and machined by using high-
quality steel plate. Static electric spraying process is adopted on the
surface, which is sturdy and durable. The inner container is finished
by the stainless steel stretching.
2. The liner and upper cover are made of high-quality stainless steel
plate, featuring strong corrosion resistance.
3. U-shapped heating pipe is used for direct heating in water. The
temperature rise is quick and the thermal loss is less.
4. Single-row digital display or intelligent temperature controller boasts
simple operation and favorable application effect.
MAIN TECHNICAL PARAMETERS
Model : WBTH-6H
Supply Voltage : 220-240V/50Hz
Power : 1500W
0
Temperature Motion : ±0.5 C
0
Temperature Range : 5 ~ 100 C
0
Display Error : ≤±2.5 C
Chamber Size : 500 x 300 x 150 mm
Product Size : 524 x 322 x 210 mm
WORKING CONDITIONS
0
1. Temperature ranges between 5 ~ 100 C.
2. Relative humidity less than 85% RH.
3 Power voltage 220-240V, frequency 50Hz.
4. No violent vibration and corrosive gas should surround the
equipment.
STRUCTURE FEATURES
-1-
© EISCO SCIENTIFIC ●www.eiscolabs.com
STRUCTURE FEATURES

ATTENTIONS
1. Before use, add water until the water reaches above the clapboard,
then connect to power supply and heat. DO NOT heat with
insufficient water.
2. During use DO NOT touch the heating pipe by your hands.
3. After use, timely discharge the water, dry it and keep it clean in order
to extend the service life.
TEMPERATURE CONTROLLER OPERATION
Meter Panel Instruction
Display and Key
1. PV : Measure Value
2. SV : Set Value
3. LED : (RUN : Work Light, OUT : Heat Light, ST : Set Time Light,
ALM : Alarm Light)
4. SET KEY : Set Value
5. MOV KEY : Set Value Change Bit
6. DOWN KEY : SUBTRACT 1
7. ADD KEY :ADD 1
-2-
© EISCO SCIENTIFIC ●www.eiscolabs.com
PV Display window
Power
Switch
Indicator Lights Keys
Outlet
Switch
SV Display window
PV
SV
RUN
OUT
AT
ST
ALM
SET
1
3
7654
2

OPERATION
1. Put the instrument horizontally.
2. Open the cover and add distilled water to the water tank. The water
level must be higher than the heating pipe and temperature sensor.
3. Connect the suitable power & switch ON the power switch.
4. The upper row of the instrument shows test temperature and setting
temperature is showed in the lower row.
5. Shot pressing the setting key can enter the setting state. Shift, plus
and minus keys can adjust the temperature.
6. Press the upper key to set time, when the upper row shows ST and
the lower row shows OFF, press the upper key again then the lower
row shows the time. The shift key is used to change the numerical
which unit is minute. There are two kinds of timing modes which are
timing after temperature constant and timing after setting finished.
When the time arrived, heating output stopped. To start the
operation again, the power switch must be shut OFF and ON again.
7. Automatic tuning function: if the test temperature fluctuates, the self-
tuning function can adjust. Press the plus & minus key till the
indicator light on.
FAULT ANALYSIS
Failure Cause Handling Method
No Power Supply
No Temperature Rise
The big difference
between Display
Temperature and
Actual Temperature.
1. Bad contact between plug and
socket.
2. The fuse is burnt.
1. The temperature controller is
broken.
2. The sensor is broken.
3. The set temperature is lower
than water temperature.
4. The heating pipe is burnt.
1. The temperature controller
broken.
2. The temperature sensor is
broken.
is
1. Replace the temperature controller.
2. Replace the temperature sensor.
1. Replace the instrument.
2. Replace the sensor.
3. Reset the temperature.
4. Replace the heating pipe.
1. Replace the plug or socket tube.
2. Replace the fuse with same
specification.
