Eizo FlexScan EV2216W User manual

Important
Please read PRECAUTIONS, this User’s Manual, and the Setup Guide
(separate volume) carefully to familiarize yourself with safe and
effective usage.
• Please refer to the Setup Guide for basic information ranging from
connection of the monitor to a PC to using the monitor.
• The latest User’s Manual is available for download from our web site:
http://www.eizo.com
Cover

2
Location of Caution Statement
Ex.FlexStand2
This product has been adjusted specically for use in the region to which it was originally shipped. If operated
outside this region, the product may not perform as stated in the specications.
No part of this manual may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means,
electronic, mechanical, or otherwise, without the prior written permission of EIZO Corporation.
EIZO Corporation is under no obligation to hold any submitted material or information condential unless prior
arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been
made to ensure that this manual provides up-to-date information, please note that EIZO monitor specications are
subject to change without notice.

3
Noticeforthismonitor
Notice for this monitor
This product is suited to general purposes like creating documents, viewing multimedia content.
This product has been adjusted specically for use in the region to which it was originally shipped. If the product is
used outside the region, it may not operate as specied in the specications.
This product may not be covered by warranty for uses other than those described in this manual.
The specications noted in this manual are only applicable when the following are used:
· Power cords provided with the product
· Signal cables specied by us
Only use optional products manufactured or specied by us with this product.
It takes about 30 minutes for the performance of electrical parts to stabilize. Please wait 30 minutes or more after the
monitor power has been turned on, and then adjust the monitor.
Monitors should be set to a lower brightness to reduce changes in luminosity caused by long-term use and maintain a
stable display.
When the screen image is changed after displaying the same image for extended periods of time, an afterimage may
appear. Use the screen saver or power save function to avoid displaying the same image for extended periods of time.
Periodic cleaning is recommended to keep the monitor looking new and to prolong its operation lifetime (refer to
“Cleaning” (page 4)).
The LCD panel is manufactured using high-precision technology. Although, missing pixels or lit pixels may appear on
the LCD panel, this is not a malfunction. Percentage of effective dots: 99.9994% or higher.
The backlight of the LCD panel has a xed lifetime. When the screen becomes dark or begins to icker, please contact
your local EIZO representative.
Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference
patterns, etc. If pressure is continually applied to the panel, it may deteriorate or damage your panel. (If the pressure
marks remain on the panel, leave the monitor with a black or white screen. The symptom may disappear.)
Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. Do not attempt
to brush with tissues as this may scratch the panel.
When the monitor is cold and brought into a room or the room temperature goes up quickly, dew condensation may
occur on the interior and exterior surfaces of the monitor. In that case, do not turn the monitor on. Instead wait until
the dew condensation disappears, otherwise it may cause some damage to the monitor.

4Noticeforthismonitor
Cleaning
Attention
• Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel,
and also quality deterioration of the image.
• Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel.
Note
• The optional ScreenCleaner is recommended for cleaning the cabinet and panel surface.
The stains on the cabinet and panel surface can be removed by moistening part of a soft cloth with water.
To use the monitor comfortably
• An excessively dark or bright screen may affect your eyes. Adjust the brightness of the monitor according to
the environmental conditions.
• Staring at the monitor for a long time tires your eyes. Take a 10-minute rest every hour.

5
CONTENTS
CONTENTS
Cover ...................................................................... 1
Notice for this monitor ......................................... 3
Cleaning .................................................................... 4
To use the monitor comfortably ............................. 4
CONTENTS ............................................................. 5
Chapter 1 Introduction ....................................... 7
1-1. Features ......................................................... 7
1-2. Controls and Functions ............................... 9
●Front................................................................ 9
●Rear................................................................10
1-3. EIZO LCD Utility Disk...................................11
●Diskcontentsandsoftwareoverview............11
●Touse“ScreenManagerProforLCD
(DDC/CI)/EIZOScreenSlicer”......................11
1-4. Basic Operations and Functions ...............12
●BasicoperationoftheSettingmenu..............12
●Functions........................................................13
Chapter 2 Adjusting Screens .......................... 14
2-1. Compatible Resolutions .............................14
●AnalogInput(D-Sub).....................................14
●DigitalInput(DVI-D).......................................14
●DigitalInput(DisplayPort)..............................14
2-2. Setting the Resolution ................................15
●Windows8/Windows7.................................15
●WindowsVista................................................15
●WindowsXP...................................................15
●MacOSX.......................................................15
2-3. Adjusting Color ............................................16
●Toselectthedisplaymode
(FineContrastMode)......................................16
●Toperformadvancedadjustments................17
●Adjustablesettingsineachmode..................17
●Toadjustbrightness.......................................17
●Toadjustcontrast...........................................18
●Toadjustcolortemperature...........................18
●Toadjustgamma...........................................19
●Toadjustthecolorsaturation.........................19
●Toadjusthue................................................. 20
●Toadjustgain................................................ 20
2-4. Screen Adjustment ......................................21
●DigitalSignalInput.........................................21
●AnalogSignalInput........................................21
2-5. Screen Size Changing ................................ 25
●ScreenSizeChanging.................................. 25
●Toadjustbrightnessofnon-displayarea...... 25
Chapter 3 Setting Monitor ............................... 26
3-1. Adjusting Volume........................................ 26
3-2. Selecting sound source while using the
DisplayPort signal input............................. 26
3-3. Compensating viewing angle deciency . 27
3-4. Enabling / Disabling DDC/CI
communication .......................................... 27
3-5. Locking Operation Buttons ....................... 28
3-6. Setting Orientation ..................................... 28
3-7. Showing and hiding the EIZO logo ........... 28
3-8. Changing Setting Menu Display Position 29
3-9. Setting Language ........................................ 29
3-10. Resetting the Monitor to the Default
Settings ........................................................ 30
●Toresetthecoloradjustments...................... 30
●Toreset“EcoViewSenseSettings”.............. 30
●Toresetalladjustmentstothedefault
settings.......................................................... 30
Chapter 4 Power Saving Functions ................ 31
4-1. Setting Power Saving ..................................31
●Monitor...........................................................31
●AudioOutput................................................. 32
4-2. Setting Power Indicator .............................. 32
4-3. Enabling / Disabling Automatic
Brightness Adjustment ............................. 32
●AutoEcoView................................................ 32
●EcoViewOptimizer2..................................... 33
4-4. Setting the power saving mode when a
person leaves the monitor ......................... 33
4-5. Checking the power saving level .............. 35
4-6. Enabling / Disabling Auto Power-OFF ...... 35
Chapter 5 Troubleshooting ..............................36
5-1. No picture .................................................... 36
5-2. Imaging problems (for both digital and
analog) ...........................................................37
5-3. Imaging problems (for digital only) .......... 38
5-4. Imaging problems (for analog only) ......... 38
5-5. Other problems ........................................... 39
Chapter 6 Reference ........................................40
6-1. Attaching the Optional Arm ....................... 40
6-2. Detaching / Attaching the TriStand2
Stand Base ....................................................41
6-3. Attaching / Detaching the TriStand2
Cable Holder ................................................ 43
6-4. Connecting Multiple PCs ........................... 45
●Toswitchamonginputsignals...................... 45
●Tosetinputsignalselection.......................... 46
6-5. Making Use of USB (Universal Serial
Bus) ............................................................... 46

6CONTENTS
●RequiredSystemEnvironment..................... 46
●ConnectionProcedure(SetupofUSB
Function).........................................................47
6-6. Displaying Monitor Information .................47
6-7. Specications ............................................. 48
●MainDefaultSettings.................................... 49
●OutsideDimensions...................................... 50
●Accessories................................................... 50
6-8. Preset Timing ...............................................51
Chapter 7 Glossary .......................................... 52
Appendix .............................................................. 54
Trademark ............................................................... 54
License / Copyright ................................................ 54
ENERGY STAR ........................................................ 55
TCO .......................................................................... 55
FCC Declaration of Conformity ............................ 56
Hinweise zur Auswahl des richtigen
Schwenkarms für Ihren Monitor ........................... 57
Hinweis zur Ergonomie : ....................................... 57
LIMITED WARRANTY ............................................. 58
Recycling Information ........................................... 67
China Measures for RoHS Compliance in
ChinaRoHS ...............................................................71

7
Chapter1Introduction
Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
• 22.0″ wide format LCD
• Supports a resolution of 1680 × 1050
• Applicable to DisplayPort (applicable to 8 bit)*1
The DisplayPort input receives both an image signal and an audio signal via a single DisplayPort cable.
*1 When transmitting an audio signal using the DisplayPort cable, the graphics board must be compatible with audio
output (see “6-7. Specications” (page 48)).
• The FineContrast function allows the user to select the display mode optimum to the displayed image.
- The Paper mode reproduces a printed paper effect on the monitor.
See “To select the display mode (FineContrast Mode)” (page 16).
• The software “ScreenManager Pro for LCD (DDC/CI)” to adjust the screen using the mouse and keyboard is
included.
See “1-3. EIZO LCD Utility Disk” (page 11).
- EyeCare Filter
Texture of the paper is reproduced by displaying a translucent image in the foreground of the desktop.
By using this function with the Paper mode, the screen looks more like paper.
See “To select the display mode (FineContrast Mode)” (page 16).
• Supports the power management software “EIZO EcoView NET”
For more information, refer to our web site (http://www.eizo.com).
• Power saving function
Suppressing the power consumption*2 reduces the carbon dioxide emissions. This product is equipped with power saving
function.
- 0 W power consumption when the main power is off
Equipped with main power switch.
When the monitor is not required, the power supply can be shut off using the main power switch.
- Auto EcoView
The ambient light sensor on the front side of the monitor detects the environmental brightness to adjust the screen
brightness automatically and comfortably. Excessively high brightness may increase power consumption and cause
unwanted environmental effects. It may also lead to fatigue of your eyes. Use the Auto EcoView to reduce the
brightness.
See “Auto EcoView” (page 32).
- EcoView Optimizer 2
The monitor automatically adjusts the screen brightness according to the white level of the input signal. This
function can reduce the power consumption while maintaining the brightness specied by the input signal.
See “EcoView Optimizer 2” (page 33).
- EcoView Sense
The sensor on the front side of the monitor detects the movement of a person. When a person moves away from the
monitor, the monitor shifts to the power saving mode automatically and does not display the images on the screen.
Therefore, the function reduces the power consumption. The sensitivity and time until the power saving mode is
activated can be set according to the monitor usage environment and movement of the user.
See “4-4. Setting the power saving mode when a person leaves the monitor” (page 33).
*2 Reference values:
Maximum power consumption: 39 W (Brightness Max., when a USB device is connected, speaker working, at
default settings)
Standard power consumption: 12 W (Brightness 120 cd/m2, when no USB device is connected, speaker not working,
at default settings)
• Up View
The viewing angle is adjusted so that the screen looks like a front view when the screen is looked up.
See “3-3. Compensating viewing angle deciency” (page 27).

8Chapter1Introduction
• Supports portrait and landscape formats (FlexStand2 only)
• Displays HDCP (High-bandwidth Digital Protection) protected contents.
Note
• This monitor supports the portrait display. This function allows you to change the orientation of the Setting menu when
using the monitor screen in vertical display position (see “3-6. Setting Orientation” (page 28)).
• When using the monitor screen in a portrait position, the graphics board supporting portrait display is required. When
placing the monitor in a portrait position, the settings of your graphics board need to be changed. Refer to the User’s
Manual of the graphics board for details.

9
Chapter1Introduction
1-2. Controls and Functions
●Front
766 7 88 99552211 33 44 766 7 88 99552211 33 44
Settingmenu*1 Settingmenu*1
FlexStand2 TriStand2
1. EcoView Sense sensor Detectsthemovementofapersoninfrontofthemonitor(EcoViewSensefunction(page
33)).
2. Ambient light sensor Detectsambientbrightness(AutoEcoViewfunction(page32)).
3. button Displaysthesettingmenuofthepowersavingfunction(AutoEcoView(page32)and
EcoViewOptimizer2(page33))andEcoViewSense(page33).
4. button Switchesinputsignalsfordisplay(page45).
5. button ChangestheFineContrastmode(page16).
6. button DisplaystheSettingmenu,determinesanitemonthemenuscreen,andsavesvalues
adjusted(page12).
7. , button*2
• Providesthemenuselectionaswellastheadjustmentandsettingofafunction.
• button:Displaysthevolumeadjustmentmenu(page26).
button:DisplaystheBrightnessadjustmentmenu(page17).
8. button Turnsthepoweronoroff.
9. Power indicator
Indicatesthemonitor’soperationstatus.
Blue: Operating
Orange: Powersavingmode
OFF: Mainpower/Poweroff
*1 See “1-4. Basic Operations and Functions” (page 12) for how to use.
*2 In this User’s Manual, the button may be hereafter simply displayed as , and the button as .

10 Chapter1Introduction
●Rear
13 16
15
14
13 16
15
14
21
21
1011 12
20
19
18
17
20
19
18
17
1011 12
FlexStand2 TriStand2
*3
10. Main power switch Turnsthemainpoweronoroff.
11. Power connector Connectsthepowercord.
12. Input signal connector Left:DisplayPortconnector/Center:DVI-Dconnector/Right:D-Submini15-pin
connector
13. Security lock slot ComplieswithKensington’sMicroSaversecuritysystem.
14. Speaker Outputsaudiosource.
15. Handle
Handleusedfortransportation
Attention
• Firmly grasp and hold the monitor by the bottom while grabbing the handle, and carefully
convey the monitor so as not to drop it.
16. Stand*4 Adjuststheheightandangle(tiltandswivel)ofthemonitor.
17. USB port (DOWN) ConnectsaperipheralUSBdevice.
18. USB port (UP) ConnectstheUSBcableforusingtheUSBHubfunction(page46).
19. Headphone jack Connectstheheadphones.
20. Stereo mini jack Connectsthestereominijackcable(commerciallyavailableproduct).
21. Cable holder Coversthemonitorcables.
*3 See “6-3. Attaching / Detaching the TriStand2 Cable Holder” (page 43) for how to attach the cable holder.
*4 An optional arm (or an optional stand) can be attached by removing the stand (see “6-1. Attaching the Optional Arm” (page 40)).

11
Chapter1Introduction
1-3. EIZO LCD Utility Disk
An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents
and the overview of the software programs.
●Disk contents and software overview
The disk includes software programs for adjustment, and User’s Manual. Refer to Readme.txt le on the disk
for software startup procedures or le access procedures.
Item Overview Windows Macintosh
Screenadjustmentpatternles Usedwhenadjustingtheimageofanalog
signalinputmanually. √ √
ScreenManagerProforLCD
(DDC/CI)
Softwareforadjustingthescreenusingthe
mouseandkeyboard. √ -
EIZOScreenSlicer Softwarethatdividesascreenandlaysout
multiplewindowsefciently. √ -
User’sManualofthismonitor(PDFle) √ √
Readme.txtle √ √
●To use “ScreenManager Pro for LCD (DDC/CI) / EIZO ScreenSlicer”
For the installation and use of “ScreenManager Pro for LCD (DDC/CI) / EIZO SceenSlicer”, refer to the
respective User’s Manual on the disk.

12 Chapter1Introduction
1-4. Basic Operations and Functions
●Basic operation of the Setting menu
1. Displaying the Setting menu
1. Press . The Setting menu appears.
2.
Adjusting / Setting
1. Choose a menu to adjust / set with , , and then press . The Sub menu appears.
2. Choose an item to adjust / set with , , and then press . The adjustment / setting menu appears.
3. Adjust / set the selected item with , , and then press .
3.
Exiting
1. Choose “Return” from the Sub menu and press . The Setting menu appears.
2. Choose “Exit” from the Main menu and press . The Setting menu quits.
Note
• The Setting menu can also be exited by pressing twice quickly.

13
Chapter1Introduction
●Functions
The following table shows the Setting menu and setting items of each menu.
Main menu Setting Reference
Color*1 Brightness “2-3.AdjustingColor”(page16)
Contrast
Temperature
Gamma
AdvancedSettings Saturation
Hue
Gain
ColorReset “Toresetthecoloradjustments”(page30)
Screen ScreenSize “ScreenSizeChanging”(page25)
Smoothing “2-4.ScreenAdjustment”(page21)
AnalogAdjustment*2 AutoScreenAdjust
AutoRangeAdjust
Clock
Phase
Hor.Position
Ver.Position
Sound Source “3-2.Selectingsoundsourcewhileusing
theDisplayPortsignalinput”(page26)
PowerSave “AudioOutput”(page32)
PowerManager PowerSave “4-1.SettingPowerSaving”(page31)
EcoTimer “4-6.Enabling/DisablingAutoPower-
OFF”(page35)
MonitorSettings UpView “3-3.Compensatingviewingangle
deciency”(page27)
InputSignal “Tosetinputsignalselection”(page46)
PowerIndicator “4-2.SettingPowerIndicator”(page32)
Language “3-9.SettingLanguage”(page29)
DDC/CI “3-4.Enabling/DisablingDDC/CI
communication”(page27)
BorderIntensity “Toadjustbrightnessofnon-displayarea”
(page25)
MenuSettings Orientation “3-6.SettingOrientation”(page28)
Logo “3-7.ShowingandhidingtheEIZOlogo”
(page28)
MenuPosition “3-8.ChangingSettingMenuDisplay
Position”(page29)
Reset “Toresetalladjustmentstothedefault
settings”(page30)
Information “6-6.DisplayingMonitorInformation”
(page47)
*1 The adjustment / settings available on the “Color” menu depend on the selected Color mode. The above table shows
the sub menus when the User1 or User2 mode is selected.
*2 These functions can be adjusted with analog input.

14 Chapter2AdjustingScreens
Chapter 2 Adjusting Screens
2-1. Compatible Resolutions
The monitor supports the following resolutions.
●Analog Input (D-Sub)
Resolution Applicable Signals Vertical Scan
Frequency Dot Clock
640×480 VGA 60Hz
146.25MHz
(Max.)
800×600 VESA 60Hz
1024×768 VESA 60Hz
1280×720 CEA-861 60Hz
1280×960 VESA 60Hz
1280×1024 VESA 60Hz
1680×1050*1 VESACVT,VESACVTRB 60Hz
●Digital Input (DVI-D)
Resolution Applicable Signals Vertical Scan
Frequency Dot Clock
640×480 VGA 60Hz
119MHz
(Max.)
800×600 VESA 60Hz
1024×768 VESA 60Hz
1280×720 CEA-861 60Hz
1280×960 VESA 60Hz
1280×1024 VESA 60Hz
1680×1050*1 VESACVTRB 60Hz
●Digital Input (DisplayPort)
Resolution Applicable Signals Vertical Scan
Frequency Dot Clock
640×480 VGA,CEA-861 60Hz
119MHz
(Max.)
720×480(4:3) CEA-861 60Hz
720×480(16:9) CEA-861 60Hz
800×600 VESA 60Hz
1024×768 VESA 60Hz
1280×720 CEA-861 60Hz
1280×960 VESA 60Hz
1280×1024 VESA 60Hz
1680×1050*1 VESACVTRB 60Hz
ThegraphicsboardshouldcomplywiththeVESAstandardandCEA-861standard.
*1 Recommended resolution

15
Chapter2AdjustingScreens
2-2. Setting the Resolution
When you connect the monitor to the PC and nd that the resolution is improper, or when you want to change the
resolution, follow the procedure below.
●Windows 8 / Windows 7
1. For Windows 8, click the “Desktop” tile on the Start Screen to display the desktop.
2. Right-click the mouse anywhere on the desktop except for icons.
3. From the displayed menu, click “Screen resolution”.
4. On the “Screen Resolution” dialog box, select the monitor.
5. Click “Resolution” to select the desired resolution.
6. Click the “OK” button.
7. When a conrmation dialog box is displayed, click “Keep changes”.
●Windows Vista
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Personalize”.
3. On the “Personalization” window, click “Display Settings”.
4. On the “Display Settings” dialog box, select the “Monitor” tab and select desired resolution in the
“Resolution” eld.
5. Click the “OK” button.
6. When a conrmation dialog box is displayed, click “Yes”.
●Windows XP
1. Right-click the mouse anywhere on the desktop except for icons.
2. From the displayed menu, click “Properties”.
3. When the “Display Properties” dialog box is displayed, click the “Settings” tab and select desired resolution
for “Screen resolution” under “Display”.
4. Click the “OK” button to close the dialog box.
●Mac OS X
1. Select “System Preferences” from the Apple menu.
2. When the “System Preferences” dialog box is displayed, click “Displays” for “Hardware”.
3. On the displayed dialog box, select the “Display” tab and select desired resolution in the “Resolutions” eld.
4. Your selection will be reected immediately. When you are satised with the selected resolution, close the
window.

16 Chapter2AdjustingScreens
2-3. Adjusting Color
●To select the display mode (FineContrast Mode)
This function allows easy selection of a desired mode according to monitor application.
Display Modes
Mode Purpose
User1 Selectthistodeneadesiredsetofparametersettings.
User2
sRGB SuitableforcolormatchingwithsRGBcompatibleperipherals.
Paper Producesaprintedpapereffect.Suitablefordisplayingimagesfrommediasuchasbooks
anddocuments.
Movie Suitableforplayingbackanimatedimages.
Themodemenu
appears.
Procedure
1. Press .
The mode menu appears at the bottom left of the screen.
2. The mode among the list is highlighted in turn each time is pressed.
You can switch the mode with or while the mode menu is displayed.
→User1←→User2←→sRGB←→Paper←→Movie←
Note
• The Setting menu and the Mode menu cannot be displayed at the same time.
• “ScreenManager Pro for LCD (DDC/CI)” allows you to select the FineContrast mode automatically according to the
application used (see “Chapter 3 Auto FineContrast” in the “ScreenManager Pro for LCD (DDC/CI)” User’s Manual).

17
Chapter2AdjustingScreens
●To perform advanced adjustments
The “Color” menu of the Setting menu allows you to set and save the independent color adjustment for each
mode.
Attention
• It takes about 30 minutes for the performance of electrical parts to stabilize. Please wait 30 minutes or more after the
monitor power has been turned on, and then adjust the monitor.
• Perform the range adjustment rst when adjusting color for analog signals (see “To adjust color gradation automatically”
(page 24)).
• The same image may be seen in different colors on multiple monitors due to their monitor-specic characteristics. Make
ne color adjustment visually when matching colors on multiple monitors.
Note
• Using the “ScreenManager Pro for LCD (DDC/CI)” allows you to perform the color adjustment by using the mouse and
keyboard of your PC. (Refer to “Chapter 4 Color Adjustment” in the User’s Manual for “ScreenManager Pro for LCD
(DDC/CI)”.)
●Adjustable settings in each mode
The adjustable settings depend on the mode. (Non-adjustable or non-settable function cannot be selected.)
√: Adjustable -: Not adjustable
Function FineContrast Mode
User1 User2 sRGB Paper Movie
Brightness √ √ √ √ √
Contrast √ √ - - √
Temperature √ √ - √ √
Gamma √ √ - - -
AdvancedSettings Saturation √ √ - - √
Hue √ √ - - √
Gain √ √ - - -
ColorReset √ √ √ √ √
●To adjust brightness
The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back
panel).
Adjustable range
0 to 100
Procedure
1. Press .
2. Use or for adjustment.
3. Press to exit.
Note
• If you feel that the image is too dark even if the brightness is set to 100, adjust the contrast.
• Alternatively, you can use “Brightness” under “Color” in the Adjustment menu to adjust it.
• To adjust the screen brightness automatically and comfortably, see “4-3. Enabling / Disabling Automatic Brightness
Adjustment” (page 32).

18 Chapter2AdjustingScreens
●To adjust contrast
The brightness of the screen is adjusted by varying the video signal level.
Adjustable range
0 to 100
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Contrast” in the “Color” menu, and press .
The “Contrast” menu appears.
3. Use or for adjustment.
4. Press to exit.
Note
• In the contrast of 50, every color gradation is displayed.
• When adjusting the monitor, it is recommended to perform the brightness adjustment which may not lose the gradation
characteristics, prior to the contrast adjustment.
• Perform the contrast adjustment in the following cases.
- When you feel the image is too dark even if the brightness is set to 100 (Set the contrast to higher than 50.)
●To adjust color temperature
Color temperature can be adjusted.
The color temperature is normally used to express the hue of “White” and / or “Black” by a numerical value.
The value is expressed in degrees “K” (Kelvin).
The screen becomes reddish at a low color temperature, and bluish at a high color temperature, like the ame
temperature. A gain preset value is set for each color temperature setting value.
Adjustable range
Off, 4000 K-10000 K (specied by every 500 K unit, including 9300 K)
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Temperature” in the “Color” menu, and press .
The “Temperature” menu appears.
3. Use or for adjustment.
4. Press to exit.
Note
• The value shown in “K” is available only as reference.
• “Gain” allows you to perform more advanced adjustment (see “To adjust gain” (page 20)).
• If you set to “Off”, the image is displayed in the preset color of the monitor (Gain: 100 for each RGB).
• When gain is changed, the color temperature is changed to “Off”.

19
Chapter2AdjustingScreens
●To adjust gamma
Gamma can be adjusted. The brightness of the monitor varies depending on the input signal, however, the
variation rate is not proportional to the input signal. To keep the balance between the input signal and the
brightness of the monitor is called as “Gamma correction”.
Adjustable range
1.8, 2.0, 2.2
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Gamma” in the “Color” menu, and press .
The “Gamma” menu appears.
3. Use or for adjustment.
4. Press to exit.
Note
• If “Paper” is selected in the FineContrast mode, the gamma value is displayed for “Paper”. The setting “Paper” is
specially meant to get the displayed image look like it is printed on paper.
●To adjust the color saturation
This function allows you to adjust color saturation.
Adjustable range
-50 to 50
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Advanced Settings” in the “Color” menu, and press .
3. Choose “Saturation” in the “Advanced Settings” menu, and press .
The “Saturation” menu appears.
4. Use or for adjustment.
5. Press to exit.
Attention
• Using this function may make some color gradations unavailable for display.
Note
• The minimum value (-50) changes the screen to monochrome.

20 Chapter2AdjustingScreens
●To adjust hue
This function allows you to adjust hue.
Adjustable range
-50 to 50
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Advanced Settings” in the “Color” menu, and press .
3. Choose “Hue” in the “Advanced Settings” menu, and press .
The “Hue” menu appears.
4. Use or for adjustment.
5. Press to exit.
Attention
• Using this function may make some color gradations unavailable for display.
●To adjust gain
The brightness of each color component red, green, and blue is called “Gain”. You can change the hue of
“white” by adjusting gain.
Adjustable range
0 to 100
Procedure
1. Choose “Color” in the Setting menu, and press .
2. Choose “Advanced Settings” in the “Color” menu, and press .
3. Choose “Gain” in the “Advanced Settings” menu, and press .
The “Gain” menu appears.
4. Adjust gain with or for each of red, green, and blue.
5. Press to exit.
Attention
• Using this function may make some color gradations unavailable for display.
Note
• The value of gain changes with that of color temperature.
• When gain is changed, the color temperature is changed to “Off”.
