F E A T U R E S
The FlexScan S2100 comes with a wide range of sophisticated image and color
control functions for handling both still and
moving images, making it well-suited
to CAD/CAM and DTP work. Also
welcome in call centers and offices, the
21.3-inch screen can display two A4
pages at full size and the ergonomic
stand ensures perfect positioning
of the screen with height, tilt, and
swivel adjustment.
• 1600 × 1200 native resolution
• 300 cd/m² brightness
• 1000:1 contrast ratio
• 5-year warranty
Smooth, Clean Motion
An overdrive circuit is included to enhance the play-
back of moving images by adjusting the voltage input
for each frame based on image data from the previ-
ous three frames. Commonly used in LCD TVs, this
circuit improves midtone response time — the time
required to transit between gray levels — to 8 ms. Fast
video sequences and 3D-CAD animation are displayed
without delays.
BrightRegulator
This function keeps the screen at the ideal bright-
ness level under all lightning conditions. A sensor on
the front panel takes readings of the ambient bright-
ness and signals the backlight to adjust the screen
brightness accordingly.
Fine Contrast Mode Selection
The Fine Contrast function provides ideal viewing
conditions for office applications (Text mode), video
clips (Movie mode), graphics (Picture mode), and
web browsing (sRGB mode). A Custom mode is also
available for individual user settings. The bundled
ScreenManager Pro for LCD software supports au-
tomatic mode switching, such as changing to Picture
mode when a graphics application is selected.
Precise Color Control
An internal 10-bit look-up table offers a palette of
more than 1 billion colors from which the most ap-
propriate 16.7 million (8-bits) are displayed, ensur-
ing accurate reproduction of subtle color variations.
Gamma values can be adjusted manually from 1.4
to 3.0 in steps of 0.2 and color temperature in 500 K
increments from 4,000 to 10,000 K. In addition, hue,
gain, and saturation can be controlled separately.
2 1. 3 " C o l o r L C D M o n i t o r

Panel Panel Size and Type 54 cm (21.3") TFT color LCD panel
Viewing Angles (H, V) 178°, 178° (at contrast ratio of 10:1)
Brightness / Contrast 300 cd/m2 / 1000:1
Response Time 16 ms (typical)
Midtone Response Time 8 ms1
Native Resolution 1600 × 1200
Active Display Size (H × V) 432 × 324 mm
Viewable Image Size Diagonal: 540 mm
Pixel Pitch 0.270 × 0.270 mm
Display Colors 16.77 million from a palette of 1.06 billion
Cabinet Colors Gray, Black
Dot Clock Analog: 162 MHz, Digital: 162 MHz
Scanning Frequency (H, V) Analog 24 – 80 kHz, 49 – 76 Hz
Digital 31 – 76 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz)
Input Signals Analog: RGB Analog, Digital: DVI Standard 1.0
Input Terminals D-Sub mini 15 pin, DVI-I 29 pin (switchable)
USB Port / Standard 1 upstream, 2 downstream /
USB Standard Rev. 2.0
Plug & Play VESA DDC 2B
Power Power Requirements AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz
Power Consumption 70 W (maximum)
Power Save Mode Less than 2 W
Physical
Specifi-
cations
Height Adjustment Range 82 mm
Tilt / Swivel / Pivot 40° Up, 0° Down / 35° Right, 35° Left / 90°
Dimensions (W × H × D) With Stand: 465 × 453 – 535 × 208.5 mm
Without Stand: 465 × 361 × 64 mm
Net Weight With Stand: 9.7 kg, Without Stand: 6.7 kg
Auto Brightness Functions Auto Brightness Stabilization, BrightRegulator
Auto Adjustment Functions Auto Adjustment, Range Adjustment
Display Mode Options Fine Contrast (Text, Picture, Movie, sRGB,
Custom, WindowMovie2), Auto Fine Contrast3
Screen-
Manager OSD
Adjustment
Functions
Screen Adjustment Clock, Phase, Position, Resolution, Bright-
ness, Signal Filter, Screen Size (full screen,
enlarge, normal), Smoothing (5 stages), Border
Intensity
Color Adjustment Range Adjustment (RGB), Gamma, Temperature
(14 stages in 500 K increments from 4,000 K
– 10,000 K including 9,300 K), Saturation, Hue,
Gain, Reset
Power Save
Settings
Analog PowerManager (VESA DPMS), Off Timer
Digital PowerManager (DVI DMPM), Off Timer
Other Settings Signal Settings, Input Priority, Product
Information (product name, serial number,
resolution, operating time), OSD Menu Set-
tings, Adjustment Lock, Languages (English,
French, German, Italian, Japanese, Spanish,
Swedish), Reset
Certifications and Standards TCO’03, TÜV/Ergonomics (including ISO
13406-2), TÜV/GS, c-Tick, CE, CB, UL (cTÜVus),
CSA (cTÜVus), FCC-B, Canadian ICES-003-B,
TÜV/S, VCCI-B, EPA ENERGY STAR®, EIZO Eco
Products 2004
Supplied Accessories AC power cord, signal cables (DVI-D - DVI-D,
D-Sub mini 15 pin - D-Sub mini 15 pin), USB
cable, EIZO LCD Utility Disk (HTML user’s
manual, ScreenManager Pro for LCD , ICC
Profile), warranty registration card
Warranty Five Years4
1 Average response time measured between each grayscale level of 31, 63, 95, 127, 159, 191, and 223.
2 WindowMovie mode is selectable only when Auto Fine Contrast is active. 3 Bundled ScreenManager Pro for
LCD is necessary to activate Auto Fine Contrast. Support for this function varies with the graphics board used.
ScreenManager Pro for LCD is compatible with the Microsoft® Windows® 98SE/Me/2000/XP operating systems
only. 4 The usage time is limited to 30,000 hours or less, and the warranty period of the LCD panel and backlight is
limited to three years from the date of purchase.
With current LCD technology, a panel may contain a limited number of missing or flickering pixels.
21.3" Color LCD Monitor
SpecificationsPlacement Flexibility
The FlexScan S2100 offers exceptional flexibility to
accommodate both your work style and your work
space. The stand is height adjustable through an 82 mm
range and provides 40° tilt and 70° swivel so every
user can easily set the ideal position. It also pivots 90°
for portrait mode viewing. Compatibility with VESA
mounting standards allows the monitor to be removed
from the stand for mounting on a movable arm or
wall bracket.
Digital and Analog Inputs
With both DVI-I and D-Sub inputs, you can use a
computer that has either a digital or an analog graph-
ics board (or both if connected to two computers),
and quickly switch between the inputs via a front
panel button.
Customer Assurance
Complies with leading industry standards, including
TCO’03 (gray and black cabinets) and TÜV Ergo-
nomics. It also conforms to EIZO’s own strict Eco
Products 2004 environmental criteria for design,
manufacture, packaging, and usage, including the
introduction of lead-free solder and chrome-free
steel plates.
Accessories
A variety of accessories are available to enhance
convenience and flexibility, including height adjustable
stands, arms, a panel protector, and client manage-
ment software. For detailed information, please see
www.eizo.com/products/accessories/
Dimensions
153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan
Phone [phone] Fax: [phone]
www.eizo.com
All product names and logos are trademarks or registered trademarks of their respective companies.
ScreenManager, SlimEdge, FlexScan, and EIZO are registered trademarks of Eizo Nanao Corporation.
Specifications are subject to change without notice.
© 2005 Eizo Nanao Corporation.
325.5 208.5
64
465
163
535 — 354
