FlexScan Widescreen Monitors
Need a little extra space?

FEATURES
Widescreen Format
Both monitors employ a 16:10 aspect ratio as opposed to the 4:3
ratio of conventional screens. The increased horizontal space this
affords means you can keep tool palettes open without covering the
window you’re working on. You can also view two windows or two
applications with no overlap. And because the 16:10 aspect ratio is
almost the same as the 16:9 used by DVDs, you can enjoy movies with
minimal black borders at the top and bottom of the screen.
Fast Response Time
To ensure that movies and other moving images look clean and
sharp, with an absolute minimum of blurring and ghosting, both
monitors feature fast response time. An overdrive circuit smooths im-
age flow by adjusting the voltage input for each frame based on image
data from the three previous frames (more accurate than using only
one or two frames). Commonly used in LCD TVs, overdrive improves
midtone response time — the time required to transmit gray levels
— to 8 ms for both monitors.
With overdrive circuitWithout overdrive circuit
Conventional monitor: working
space and tool palettes overlap.
Widescreen monitor: full working space
and tool palettes are displayed
simultaneously with no overlap.
Stretch out, with EIZO
widescreen monitors.
Whether you use your current monitor for work or
entertainment or both, you probably wish at times
that you had a little extra horizontal space. The FlexScan
S2410W and S2110W have 24.1" and 21.1" screens respec-
tively and a 16:10 aspect ratio, providing the widescreen view
you want for movies and games, as well as for 3-D CAD and
graphic design applications. With their fast response time, high
contrast ratio and outstanding brightness, they are truly high
performance monitors, delivering smooth, accurate and
natural reproduction of moving as well as still images.
Both models are designed to make operation easy and
efficient, with electrostatic touch switches on the front
panel and EIZO’s latest ArcSwing 2 stand for
easy, flexible positioning.

1000:1 Contrast Ratio
This outstanding contrast performance makes images on dark
backgrounds appear more vivid, brings out the subtle differences in
similar shades of color, and ensures that colors retain their richness
even in brightly lit rooms.
450 cd/m2 Brightness
With high brightness of 450 cd/m2, the same as high quality LCD
TVs, these monitors present a clear view even in bright environments.
This performance is made possible by a direct backlighting system,
which also provides higher power efficiency and better uniformity.
14-Bit Processing for Accurate Color Reproduction
These widescreen monitors incorporate a powerful new EIZO-
developed ASIC (Application Specific Integrated Circuit) with 14-bit
color processing capability (16 times more accurate than 10-bit). This
allows a larger number of grayscale increments, for smooth grayscale
rendering. The result is a much greater degree of color detail, espe-
cially in dark areas and shadows.
10-bit v. 14-bit processing
Error Rate (%)
0
2
1
0
-1
-2
-3
2
1
0
-1
-2
-3
32 64 96 160 192 224 255128
0 32 64 96 160 192 224 255128
Error Rate (%)
Internal 14-Bit Processing
Internal 10-Bit Processing
Tones (0 – 255)
Tones (0 – 255)
With 10-bit processing, the error rate is high in low tonal areas during calcula-
tion. With 14-bit processing, accuracy is significantly improved resulting in
fewer conversion errors.
Fine Contrast Mode Selection
For optimum viewing of all types of content, the Fine Contrast
function allows the selection of five imaging modes: Text, Picture,
Movie, Custom, and sRGB. Each mode has its own settings for im-
age parameters such as color temperature, gamma and brightness.
You can navigate between the modes simply by pressing a button on
the front panel. For further convenience, a Fine Contrast mode can
be assigned to any application with the bundled ScreenManager® Pro
for LCD utility software. When the application is opened, the screen
automatically changes to its assigned mode.
Detailed Color Control
Gamma, saturation, hue, gain, and color temper-
ature from 4,000 K to 10,000 K can all be adjusted
in the OSD menu for accurate, natural display of
color. For fine-tuning of even a single color, the hue
and saturation settings for red, green, blue, cyan,
magenta, and yellow can be adjusted independently.
ArcSwing 2 Stand
The ArcSwing 2 stand is a significant
improvement over conventional monitor
stands, adjusting through a large arc-
shaped range of movement. You can
position it at eye level or at a low
angle akin to reading a book, for
best viewing no matter how and
where you are using the monitor. In
addition, this stand features a sturdy
base and a compartment for cable management.
Touch Sensitive Switches
You have quick ac-
cess to a variety of
functions via highly
sensitive electrostatic
“touch” switches on the front panel.
Presenting a sophisticated appearance, they are also easier to engage
than the small buttons of most LCD monitors.
500:1 1000:1

FEATURES & SPECIFICATIONS
153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan
Phone: [phone] Fax: [phone]
www.eizo.com
All Product names and logos are trademarks or registered trademarks of their respective companies. SlimEdge, FlexScan,
ScreenManager, and EIZO are registered trademarks of Eizo Nanao Corporation.
Specifications are subject to change without notice.
Published on chlorine-free paper. © 2005 Eizo Nanao Corporation. All rights reserved.
(050905) Printed in Japan, 9, 2005, 3K
Panel Size and Type 61 cm (24.1") TFT color LCD panel 53 cm (21.1") TFT color LCD panel
Viewing Angles (H, V) 178°, 178° (at contrast ratio of 10:1) 178°, 178° (at contrast ratio of 10:1)
Brightness / Contrast 450 cd/m2 / 1000:1 450 cd/m2 / 1000:1
Response Time 16 ms (typical) 16 ms (typical)
Midtone Response Time 8 ms18 ms1
Native Resolution 1920 × 1200 1680 × 1050
Active Display Size (H × V) 518.4 × 324.0 mm 453.6 × 283.5 mm
Viewable Image Size Diagonal: 611 mm Diagonal: 534mm
Pixel Pitch 0.270 × 0.270 mm 0.270 × 0.270 mm
Display Colors 16.77 million from a palette of 1.06 billion 16.77 million from a palette of 1.06 billion
Available Cabinet Colors White, Black White, Black
Dot Clock Analog: 202.5 MHz, Digital: 162 MHz Analog: 150 MHz, Digital: 120 MHz
Scanning Frequency (H, V) Analog: 24 – 94 kHz, 49 – 86 Hz
Digital: 31 – 76 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz)
Analog: 24 – 82 kHz, 49 – 86 Hz
Digital: 31 – 65 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz)
Input Signals Analog: RGB Analog, Digital: DVI Standard 1.0 Analog: RGB Analog, Digital: DVI Standard 1.0
Input Terminals DVI-I 29 pin × 2 (switchable) DVI-I 29 pin × 2 (switchable)
USB Ports / Standard 1 upstream, 2 downstream / USB Standard Rev. 2.0 1 upstream, 2 downstream / USB Standard Rev. 2.0
Plug & Play VESA DDC 2B VESA DDC 2B
Power Power Requirements AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz AC 100 – 120 V, 200 – 240 V: 50 / 60 Hz
Power Consumption 110 W (maximum) 80 W (maximum)
Power Save Mode Less than 2 W Less than 2 W
Physical
Specifica-
tions
Height Adjustment Range 95 mm 95 mm
Tilt / Swivel / Pivot 60° Up, 5° Down / 172° Right, 172° Left / – 60° Up, 5° Down / 172° Right, 172° Left / –
Dimensions (W × H × D) With Stand: 566 × 358.7 – 480 × 230 mm
Without Stand: 566 × 396 × 85 mm
With Stand: 501 × 341.1 – 459.5 × 230 mm
Without Stand: 501 × 355 × 85 mm
Net Weight With Stand: 10.2 kg, Without Stand: 7.8 kg With Stand: 8.2 kg, Without Stand: 5.8 kg
Display Mode Options Fine Contrast (Text, Picture, Movie, sRGB, Custom, WindowMovie2), Auto Fine Contrast3
ScreenMan-
ager OSD
Adjustment
Functions
Screen Adjustment Clock, Phase, Position, Resolution, Brightness, Signal Filter, Screen Size (full screen, enlarge, normal), Smoothing (5
stages), Border Intensity
Color Adjustment Range Adjustment (RGB), Independent 6-Color Control3, Gamma, Temperature (14 stages: in 500 K increments from
4,000 K – 10,000 K including 9,300 K), Saturation, Hue, Gain, Reset
Power Save Settings Analog: PowerManager (VESA DPMS), Off Timer, Digital: PowerManager (DVI DMPM), Off Timer
Other Settings Signal Settings, Input Priority, Product Information (product name, serial number, resolution, operating time), OSD Menu
Settings, Adjustment Lock, Languages (English, French, German, Italian, Japanese, Spanish, Swedish), Reset
Certifications and Standards TCO’03 (white), TCO’99 (black) TÜV/Ergonomics (including ISO 13406-2), TÜV/GS, c-Tick, CE, CB, UL (cTÜVus), CSA
(cTÜVus), FCC-B, Canadian ICES-003-B, TÜV/S, VCCI-B, EPA ENERGY STAR®, EIZO Eco Products 2004
Warranty Five Years4Five Years4
1 Average response time measured between each grayscale level of 31, 63, 95, 127, 159, 191, and 223. 2 WindowMovie mode is selectable only when Auto Fine Contrast is active. 3 Bundled ScreenManager Pro for
LCD is necessary to activate Auto Fine Contrast and Independent 6-Color Control. Support for this function varies with the graphics board used. ScreenManager Pro for LCD is compatible with the Microsoft® Windows®
98SE/Me/2000/XP operating systems only. 4 The usage time is limited to 30,000 hours or less, and the warranty period of the LCD panel and backlight is limited to three years from the date of purchase.
With current LCD technology, a panel may contain a limited number of missing or flickering pixels.
Dual DVI-I Inputs
The two DVI-I input terminals can accept both digital and analog
inputs for greater freedom in connecting other equipment. If both types
are connected, you can switch between them via a front panel button.
USB 2.0 Hub
Both monitors provide a high speed (480 Mb/s)
USB 2.0 hub with two downstream ports which are
conveniently located on the side of the monitor for
quick connection of peripherals.
Choice of Colors
Both models are available in black
and also with a white/silver cabinet
that complements the Mac G5 and
Mac Mini.
Accessories
A variety of accessories are available including a height adjust-
able stand and mounting arms for the FlexScan S2110W, and client
management software and panel protectors for both monitors. For
detailed information, please see www.eizo.com/products/accessories/
Customer Assurance
A five-year warranty offers a long service life, and compliance
with leading industry standards such as TCO’03 (white cabinet only)
and TÜV Ergonomics ensures a better working environment. The
EIZO Eco Products 2004 label indicates these products meet strict
internal requirements for design, manufacturing, packaging, and
usage, including the introduction of lead-free solder and chrome-free
steel plates.
