EJEAS Q7 User manual

Q7
Top Quality Hi-Fi Motorcycle Bluetooth Intercom
User manual
www.ejeas.com

Q7 is a cost-effective Bluetooth communication system for motorcy-
cle helmets. Qualcomm 5.0 chip is adopted to quickly pair in one
second. The maximum communication distance is 800 meters. It
can realize seven people switching and talking with each other.
Standard FM, it can automatically answer the phone, more conve-
nient and safe to use; Good waterproof performance, can be used
with confidence in rainy days; Optional controller makes it easier for
you to operate in cycling; Specially designed stereoscopic sound
effect allows you to enjoy the fun of riding anytime and anywhere.
01
English
FM radio
Type-C Volume - Earphone
interface
A/C/E Switch Key
Volume +AntennaIndicator
B/D/F
Switch Key
Power/
Phone key

Q7
TopQuality Hi-Fi Motorcycle Bluetooth Intercom
User manual
www.ejeas.com
Stick the Velcro &
earphone on
Install the host
Install the fixture
Unscrew the screws
Packing list
Product Installation
02
Host
Manual
Earphone
EUC Handle controller
Microphone Cable
Soft microphone
1 2
4
3
UNIVERSALCONTROLLER
Adapter:5V1A
SIN:EUC19070000
EJEASTechnologies.Inc
MabeinChina
Model
EUC
A/D
+
B/E
C/F
FM
Optional
Type-C charging cable
Mounting clip
English

03
Paring successful
Plug the earphone
into the intercom
Stick Velcro &
microphone on Connect with the microphone
57
6
Q7 operating instructions
Basic operation diagram
Single-click Double-click Triple-click
Long press
for 5s
Simultaneous
click
5s
English
ON OFF
Blue light flashes
“Ding~Ding~Ding~Ding~”
1s
Standby Blue light flashes slowly
ON/OFF Please charge before use

04
5s
The two machines enter pairing mode
A/C/E or B/D/F pairing
Red & blue lights flash fast alternately
“Intercom A/B pairing”
Auto searching & connecting
Pairing successful
“Intercom pairing successful”
“Intercom A/B connected”
Blue light flashes quickly
5s
or
The main device allows to pair with extra 6 intercoms. It's A-key could pair with
3 sub-machine, the 1st pairing is intercom A, the 2nd pairing is intercom C, & the
3rd pairing is intercom E. The A-key allows for many times pairing & only keep
the last three memory as its A/C/E sub-machine. The same goes for the B-key.
5s
Enter pairing mode
Compatible with all EJEAS models
“Intercom A/B pairing”
Red & blue lights
flash fast alternately
“Intercom A/B searching”
Red & blue lights
flash alternately
Click A/B to search & pair
or
Blue light flashes quickly
Pairing successful
“Intercom pairing successful”
“Intercom A/B connected”
When pairing with other Bluetooth intercom or headset, you can use intercom
search for pairing connection
or
Disconnected
“Intercom Disconnected”
Reset default setting
5s
“Restore default setting”
Disconect any intercom Clear existing pairing records
1s1s
or
English

05
While paring successful, click A key to connect A sub machine; Double-click the
A key to connect to the C sub machine; Triple-click A to connect E sub machine.
The same goes for the B key.
Switch the intercom connection
A
C
E
or or
Pairing
“Connecting intercom A/C/E”
“Connecting intercom B/D/F”
Blue light flash fast Pairing
successful
“Intercom A/C/E connected”
“Intercom B/D/F connected”
Blue light flash slow
F
B
D
or or
Long press to open the phone connection Disconnect
“Phone pairing”
Pairing the phone/Disconnect with phone
5s5s
Red and blue lights flash
Bluetooth
Q7
If there is no pairing connection, exit the pairing state after 2 minutes
Automatically
connect back
to the last
phone after
switching on
or
Bluetoothback connection Telephone answering
Automatic
answer when
there is no
operation within
8 seconds
or
English

06
Last Num Redial Cancel the redial
1s
Call rejection Hang up the call
Make sure your phone supports Bluetooth wake-upVoice assistant
Bluetooth
awaken
1s
or
“hi~siri”
Music play/paus
TEL priority
Call Interrupt music/FM/intercom Hang up Restore music /FM/intercom
When listening to Bluetooth music/FM/intercom, and receiving a phone call
Intercom/talk/music
Volume Regulating
When music is playedSwitch song
1s 1s
Power query In use
1s
“Battery level high”
“Battery level medium”
“Battery level low”
or
English

07
When listening to FM alone Volume control
When listening to FMFM
1s 1s
Turn on/off the FM radio
Auto search & play radio, intercom & radio at the same time
76~108MHz
1s Turn on FM
Turn off FM
Blue light is on for 4 s
Red light flashes twice Cycle instructions
“FM radio”
“FM radio off ”
When listen to FM & intercom at the same time
Volume control
Intercom volume FM volume
Charging indicator
Low battery indication
Red light flashes twice Charging Constantly Red
“Low battery” Full The red light out
English

UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A/D
+
B/E
C/F
FM
F
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A/D
+
B/E
C/F
FM
A
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A/D
+
B/E
C/F
FM
D
Connect/disconnect intercom
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A/D
+
B/E
C/F
FM
B
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A/D
+
B/E
C/F
FM
E
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A/D
+
B/E
C/F
FM
C
When paired with EUC, A/B/C/D/E/F intercom is connected & disconnected
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A
+
B
C/D
E/F
1s
Reject call
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A
+
B
C/D
E/F
Hang up
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A
+
B
C/D
E/F
Telephone answering
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A
+
B
C/D
E/F
Connect to the last
connected phone
Last Number Redial
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A
+
B
C/D
E/F
08
EUC control handle operation instructions
Optional
Turn on/off the EUC pairing
5s
UNIVERSALCONTROLLER
Adapter:5V1A
SIN:EUC19070000
EJEASTechnologies.Inc
MabeinChina
Model
EUC
A/D
+
B/E
C/F
FM
English
or or
or or

09
Bluetooth Version: Bluetooth 5.0
Support: Qualcomm®aptX™, cVc noisecancellation technology 3D sound effects
Audio encoding format: SBC & AAC
Intercom mode: two-person intercom, can save 6 way switch intercom
Intercom communication distance: up to 800 meters
Bluetooth headset communication distance: more than 10 meters
Temperature: Use temperature -10~50°C
Battery Parameter: 3.7V/750mAh
Electric Parameter: DC 5V/1A
Charge Time: About 3 hours
Endurance: 22 hours
Standby time: 260 hours
Charging interface: Type-C
Waterproof rating: IP67
Product Characteristics
Switch song
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A
+
B
C/D
E/F
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A
+
B
C/D
E/F
1s 1s
Intercom/talk/music
UNIVERSAL CONTROLLER
A
+
B
C/D
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A
+
B
C/D
E/F
Volume
Music play/pause
UNIVERSAL CONTROLLER
A
+
B
C/D
Voice Assistant
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A
+
B
C/D
E/F
1s
UNIVERSAL CONTROLLER
Adapter:5V 1A
SIN:EUC19070000
EJEASTechnologies. Inc
Mabein China
Model
EUC
A/D
+
B/E
C/F
FM
Connect/
disconnect FM
English

10
Precautions for battery use
1.
2.
3.
4.
5.
6.
7.
8.
9.
Please do not put the discarded batteries together with the general
household garbage. In areas with relevant laws & regulations on recycling &
disposal of waste batteries, please follow the relevant regulations of the local
administrative department to make a contribution to environmental protection.
Don't short-circuit the battery. A short circuit occurs when metal objects
(keys, jewelry, wires, COINS, or other conductors) accidentally connect
the positive & negative electrodes of a battery. A short circuit can damage
batteries or connectors and may cause significant property damage or
personal injury. Please keep the charged batteries properly and do not
leave them in your pocket, wallet or other treasure bag with metal objects.
Do not put the battery on fire or place it in a hot place to avoid leakage,
overheating, bursting or fire.
Do not disassemble, weld or modify the battery. Do not place the battery
in a place with strong mechanical impact. Do not puncture the battery with
a hard object. Otherwise, the battery will leak, overheat, burst or catch fire.
Do not remove, squeeze, heat or burn the battery inside the product. It is
strictly prohibited to use sharp objects, screwdrivers or other devices to
puncture or pry the battery. The above operation may cause the battery
to catch fire or burn.
The battery's electrolyte enters the eye & can lead to blindness. If you
splash the battery electrolyte into your eyes, do not rub your eyes with
your hands. Rinse thoroughly with water immediately & contact the
hospital for treatment. If the battery's electrolyte sticks to the skin and
clothes, wash them immediately with soapy water & clean water, & seek
medical attention if necessary.
Do not transfer batteries from other uses. Do not use any damaged charger
or battery. If the temperature of the battery is too high during use, charging
or storage, or abnormal phenomena such as discoloration, deformation,
bulging & leakage occur in the battery, please stop using & replace the
battery, so as not to cause safety problems.
The battery is not waterproof, do not use or charge the battery in the kitchen,
bathroom & other high temperature and humidity places.
When charging, since the battery temperature will rise, please do not put
the battery & flammable objects (such as:bedside, clothes, books, etc.)
to avoidfire.
English

11
Safety Precaution
1. Keep out of reach of children and pets:
Please keep the products and all spare parts out of reach of children and
pets.Children or pets may swallow small parts that can cause suffocation
or other dangerous conditions.
2. Safe startup:
When it is forbidden to use electronic products or the use of electronic
products may cause interference or danger, please do not turn on this product.
3. Pay attention to traffic safety:
Please comply with all relevant laws and regulations of the place of use.
Traffic safety should be taken into consideration when using this product.
Never use this product after drinking alcohol or using drugs, or when you
are extremely tired.
4. Interference:
All wireless product equipment may be interfered, which affects its
performance.
5. Shut down near medical devices:
Hospitals & health care facilities may see the use of radio-frequency
sensitive equipment.Please effectively follow therules & regulations of
any medical institution & turn off the product when necessary.
6. Power off on an airplane:
Please comply with any restrictions related to aviation. The use of
wireless devices on the aircraft will interfere with the aircraft, so please
shut down the aircraft during flight.
7. Gas stations should shut down:
Do not use this product near a gas station (service station) or where fuel
or chemical agents are stored.
8. Power off near the blasting site:
Please observe any blasting regulations & don't use this product in the
place where blasting is performed.
9. Accessories andbatteries:
Please use accessories and batteries approved by the company. Using
other accessories & batteries may damage the product & cause danger.
10. Connect to other devices:
When connecting to other devices, please read the device's instructions
carefully for detailed safety instructions & correct product operation. Do
not connect incompatible products.
English

Attention
4.
7.
1.
2.
3.
5.
6.
8.
In order to ensure the communication distance when riding,
please try to use it in an open place.
If the electronic function fails, please power off and try again.
Installing equipment on the helmet is a modification of the helmet,
which may cause the helmet's warranty to fail or hinder the
helmet's function. This may cause danger in the event of accidents,
so please fully understand the facts when using the helmet. If not,
please return the product
Before driving, please makesure that the product is firmly &
correctly mounted on the helmet. If the product falls off during
driving, it will cause injury oraccident.
To ensure riding safety, please use this product carefully while on
the road to avoid serious body injury, death or injury.
In the case of rain, please put the device jack down, USB rubber
plug tight; During use, ensure that the headphone jack is fully
plugged into the device to prevent water from entering the device.
The product contains 3.7V/750mAh battery. The battery capacity
will change with the temperature. When the battery is used at low
temperature or below 0°C, the battery life of the product may
attenuate to different degrees.
When using this product when operating vehicles or vehicles, the
safety precautions of the vehicle manufacturer must be observed.
12
Warning
1.
2.
3.
The use of this device on public transportation may not be
authorized by law. Please check your local laws and use this
product only in private Spaces or on closed roads.
If local law prohibits the use of both headphones while riding a
motorcycle, use only one headset while riding. If you do not comply
with this warning, the company does not accept any responsibility.
Use this product at a high volume for a long time will cause damage
to your ears & hearing.Please keep the volume at an appropriate level.
English

Environmental friendliness
Toxic and harmful substances or elements and content table
Toxic or harmful
substances or elements
Part name
Host Battery Accessories
XX
O O O
O O O
O O O
O O O
O O O
Plumbum（Pb）
Mercury（Hg）
Cadmium（Cd）
Chromium VI（Cr6+）
Polybrominated
Biphenyls（PBB）
Polybrominated
diphenyl ethers（PBDE）
X
13
English
