EK-Quantum Reflection PC-O11D Mini D5 PWM D-RGB User manual

USER GUIDE
DISTRIBUTION PLATE
EKQuantum
Reflection PC-O11D Mini D5 PWM D-RGB

Before you start using this product please follow these basic guidelines:
Please carefully read the manual before beginning with the
installation process!
The EK Fittings require only a small amount of force to screw
them firmly in place since the liquid seal is ensured by the
rubber O-ring gaskets.
The use of quality market-proven corrosion-inhibiting coolants
is always strongly recommended for any liquid cooling system.
Do not use pure distilled water as a cooling liquid! For best
results, EK recommends the use of EK-CryoFuel Coolants.

- 3 -
TABLE OF CONTENTS
BOX CONTENTS 4
DISTRIBUTION PLATE DIMENSIONS 5
DISTRIBUTION PLATE SPECIFICATIONS AND MAIN PARTS 6
PREPARING THE O11D Mini CHASSIS 7
INSTALLING THE DISTRIBUTION PLATE IN THE O11D Mini 8
RECOMMENDED DISTRIBUTION PLATE CONFIGURATIONS 9
7SLOT CONFIGURATION 9
5SLOT CONFIGURATION 11
CONNECTING THE D-RGB LED STRIP 13
CONNECTING THE PUMP 13
TESTING THE LOOP 14
SUPPORT AND SERVICE 15
SOCIAL MEDIA 15

- 4 -
BOX CONTENTS
8
EK-Quantum Reflection PC-O11D Mini D5 PWM D-RGB
M4 x 8 7991DIN (8 pcs)
Allen Key 2.5 mm (1 pc)
EK-Loop Multi Allen Key

- 5 -
DISTRIBUTION PLATE DIMENSIONS
206 mm
29.2 mm
16.4 mm
54.2 mm
332 mm
132 mm
296.4 mm
235.4 mm
134.6 mm
31.5 mm
8 mm
77.3 mm

- 6 -
DISTRIBUTION PLATE SPECIFICATIONS AND MAIN PARTS
Technical Specification:
• Technical Specification: - Dimensions (LxHxW): 206 x 332 x 77.3 mm
• D-RGB (Addressable RGB) Cable Length: 500 mm
• D-RGB LED Count: 14
• D-RGB Connector: Standard 3-Pin (+5V, Data, Blocked, Ground)
EK-D5 PWM
PUMP
O-RING
52 x 3
O11D MINI -
SEAL SET
LED D-RGB STRIP
EK-RGB BADGE
EK-PLUG G1
M4 x 20 7984DIN SCREW
M4 x 25 7991DIN SCREW
LED COVER
(BLACK ELOX)
REFLECTION PC-O11D
MINI - BLOCK (PLEXI)
D5 MOUNT (ACETAL)
M4 x 16 7991DIN SCREW

- 7 -
PREPARING THE O11D Mini CHASSIS
Before installing the distribution plate, carefully read
the PC case manual.
STEP 1
Unscrew the factory provided screws and remove the top panel
from the case.
STEP 2
STEP 2
Remove side and the front panel from the case.
STEP 1
FACTORY
PROVIDED SCREWS

- 8 -
INSTALLING THE DISTRIBUTION PLATE IN THE O11D Mini
STEP 1
Carefully place the EK-Quantum Reflection PC-O11D Mini D5
PWM D-RGB - Plexi distribution plate into the PC case and align the
mounting holes.
STEP 1
STEP 2
Secure the distribution plate to the chassis with eight (8) M4 x 8
DIN7991 screws (as shown in the diagram).
STEP 2
M4 x 8 7991DIN SCREW

- 9 -
RECOMMENDED DISTRIBUTION PLATE CONFIGURATIONS
It is mandatory to use at least one of each type of port and all
remaining ports should be sealed using the supplied plugs. The
EK-Loop Multi Allen Key (6mm, 8mm, 9mm) may be used to install
all EK fittings, do not use excessive force.
If one of the prescribed components will not be installed (ie.
bottom radiator or GPU block) then one IN and one OUT port
must still be joined together in order for this distribution plate
to function!
Installing this distro plate in the front of the case allows two
radiator configurations based on your motherboard form factor.
7SLOT CONFIGURATION
ITX / mATX / ATX
CPU OUT/IN
RADIATOR 2 IN
RADIATOR 2 OUT
GPU IN/OUT (SLOT 1)
GPU IN/OUT (SLOT 2)
GPU IN/OUT (SLOT 3)
RADIATOR 1 OUT
DRAIN
RADIATOR 1 IN
GPU IN (SLOT2)
RADIATOR 1
Up to SE360 (bottom)
RADIATOR 2
Up to SE240 (side)

- 10 -
FILL (EXTERIOR)
DRAIN (EXTERIOR)
RADIATOR 1
Up to SE360 (bottom)
RADIATOR 2
Up to SE240 (side)

- 11 -
5SLOT CONFIGURATION
ITX / mATX
CPU OUT/IN
RADIATOR 2/3 IN
RADIATOR 2/3 OUT
GPU IN/OUT (SLOT 1)
RADIATOR 1 OUT
DRAIN
RADIATOR 1 IN
RADIATOR 1
Up to SE360 (bottom)
RADIATOR 3 (Optional)
Up to SE360 (top)
RADIATOR 2 (Optional)
Up to SE240 (side)

- 12 -
FILL (EXTERIOR)
DRAIN (EXTERIOR)
RADIATOR 1
Up to SE360 (bottom)
RADIATOR 3 (Optional)
Up to SE360 (top)
RADIATOR 2 (Optional)
Up to SE240 (side)

- 13 -
CONNECTING THE D-RGB LED STRIP
Plug the 3-pin connector of the distribution plate D-RGB LED light
to the D-RGB HEADER on the motherboard. The LED will work if the
pin layout on the header is as follows: +5V, Digital, Empty, Ground.
D-RGB Header
RGB Header
CONNECTING THE PUMP
The EK-D5 PWM pump has two connectors.
1. 4-pin Molex: It must be connected directly to your PSU at all
times as it is used to power the pump.
2. 4-pin PWM fan: It can be connected to your motherboard’s CPU
Fan or designated water pump header. It can also be connected to
a controller. This cable is used to control and report the rotational
speed of the pump. If it’s not connected, the pump will run at
maximum speed (100% PWM).
4-pin molex
connector
4-pin PWM fan
connector

- 14 -
To make sure the installation of EK components was successful, we
recommend you perform a leak test for 24 hours.
When your loop is complete and filled with coolant, connect the
pump to a PSU outside of your system. Do not connect power to
any of the other components. Turn on the PSU and let the pump
run continuously. It is normal for the coolant level to drop during this
process as air collects in the distribution plate.
Inspect all parts of the loop, and in the eventuality that coolant leaks,
fix the issue and repeat the testing process. Ensure that all hardware is
dry before the system is powered on in order to prevent any damage.
TESTING THE LOOP
