Elba EEC 866 WH Installation and operating instructions

Instructions for the use - Installation advices
DUAL FUEL COOKERS
Models:
Made in Italy
100%
ELBA QUALITY
MADE IN ITALY
EEC 866 WH

2
Dear Customer,
Thank you for having purchased and given your preference to
our product.
The safety precautions and recommendations reported below
are for your own safety and that of others. They will also provide
a means by which to make full use of the features offered by your
appliance.
Please preserve this booklet carefully. It may be useful in future,
either to yourself or to others in the event that doubts should
arise relating to its operation.
This appliance must be used only for the task it has
explicitly been designed for, that is for cooking foodstuffs.
Any other form of usage is to be considered as inappropriate
and therefore dangerous.
The manufacturer declines all responsibility in the event
of damage caused by improper, incorrect or illogical use of
the appliance.

3
IMPORTANT SAFETY PRECAUTIONSAND RECOMMENDATIONS
IMPORTANT: This appliance is designed and manufactured
solely for the cooking of domestic (household) food and is
not suitable for any non domestic application and therefore
should not be used in a commercial environment.
The appliance guarantee will be void if the appliance is used
within a non domestic environment i.e. a semi commercial,
commercial or communal environment.
Read the instructions carefully before installing and using
the appliance.
• After having unpacked the appliance, check to ensure that it is
not damaged and that the oven door closes correctly.
In case of doubt, do not use it and consult your supplier or a
professionally qualied technician.
• Packing elements (i.e. plastic bags, polystyrene foam, nails,
packing straps, etc.) should not be left around within easy reach
of children, as these may cause serious injuries.
• Some appliances are supplied with a protective lm on steel and
aluminium parts. Thislmmustberemovedbeforeusingthe
appliance.
• IMPORTANT: The use of suitable protective clothing/gloves is
recommended when handling or cleaning this appliance.
• Do not attempt to modify the technical characteristics of
the appliance as this may become dangerous to use. The
manufacturer declines all responsibility for any inconvenience
resulting from the inobservance of this condition.
• CAUTION: this appIiance must only be installed in a permanently
ventilated room in compliance with the applicable regulations.
• Do not operate your appliance by means of an external timer or
separate remote-control system.
• Do not carry out cleaning or maintenance operations on the
appliance without having previously disconnected it from the
electric power supply.

4
• WARNING: Ensure that the appliance is switched off before
replacing the oven lamp to avoid the possibility of electric shock.
• Do not use a steam cleaner because the moisture can get into the
appliance therefore making it unsafe.
• Do not touch the appliance with wet or damp hands (or feet).
• Do not use the appliance whilst in bare feet.
• If you should decide not to use this appliance any longer (or
decide to substitute another model), before disposing of it, it is
recommended that it be made inoperative in an appropriate manner
in accordance to health and environmental protection regulations,
ensuring in particular that all potentially hazardous parts be made
harmless, especially in relation to children who could play with
unused appliances.
• The various components of the appliance are recyclable. Dispose
of them in accordance with the regulations in force in your country.
If the appliance is to be scrapped, remove the power cord.
• After use, ensure that the knobs are in the off position.
• Children less than 8 years of age shall be kept away unless
continuously supervised.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision.
• Themanufacturerdeclinesallliabilityforinjurytopersonsordamage
to property caused by incorrect or improper use of the appliance.
• WARNING: During use the appliance and its accessible parts
become hot; they remain hot for some time after use.
– Care should be taken to avoid touching heating elements (on the
hob and inside the oven).
– The door is hot, use the handle.
– To avoid burns and scalds, young children should be kept away.

5
• Make sure that electrical cables connecting other appliances in
the proximity of the cooker cannot come into contact with the hob
or become entrapped in the oven door.
• WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in re. NEVER try to extinguish a re
with water, but switch off the appliance and then cover ame e.g.
with a lid or a re blanket.
• WARNING: Danger of re: do not store items on the cooking
surfaces.
• WARNING: When correctly installed, your product meets all
safety requirements laid down for this type of product category.
However special care should be taken around the rear or the
underneath of the appliance as these areas are not designed or
intended to be touched and may contain sharp or rough edges,
that may cause injury.
• FIRST USE OF THE OVEN - it is advised to follow these
instructions:
– Furnish the interior of the oven as described in the chapter
“CLEANING AND MAINTENANCE”.
– Switch on the empty oven on max to eliminate grease from the
heating elements.
– Disconnect the appliance from the electrical power supply, let
the oven cool down and clean the interior of the oven with a
cloth soaked in water and neutral detergent; then dry carefully.
• CAUTION: Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can scratch the
surface, which may result in shattering of the glass.
• Donotlinetheovenwallsorbasewithaluminiumfoil.Donotplace
baking trays or the drip tray on the base of the oven chamber.
• FIRE RISK! Do not store ammable material in the oven.
• Always use oven gloves when removing the shelves and food
trays from the oven whilst hot.
• Do not hang towels, dishcloths or other items on the appliance or
its handle – as this could be a re hazard.

6
• Clean the oven regularly and do not allow fat or oils to build up in
the oven base or tray. Remove spillages as soon as they occur.
• Do not stand on the cooker or on the open oven door.
• Always stand back from the appliance when opening the oven
door to allow steam and hot air to escape before removing the
food.
• SAFE FOOD HANDLING: Leave food in the oven for as short
a time as possible before and after cooking. This is to avoid
contamination by organisms which may cause food poisoning.
Take particular care during warmer weather.
• WARNING: Take care NOT to lift the cooker by the door handle.
• CAUTION: The cooking process has to be supervised. A short
term cooking process has to be supervised continuously.
• The appliance must not be installed behind a decorative door in
order to avoid overheating.
• The oven accessories (e.g. oven wire rack) must be tted
correctly as indicated at page 19.
• If the power supply cable is damaged, it must be replaced only
by an authorized service agent in order to avoid a hazard.

7
2
3
1
GAS BURNERS
1. Semi-rapid burner (SR) 1,75 kW
2. Rapid burner (R) 3,00 kW
3. Triple-ring burner (TR) 3,50 kW
Fig. 1.1
COOKING HOB
1
Note: The appliance has a safety
valve system tted, the ow of gas
will be stopped if and when the ame
should accidentally go out.
Fig. 2.1
MADE IN ITALY
1 2 3 4 67 5
8
CONTROL PANEL
2
CONTROLS DESCRIPTION
1. Electric oven/grill control knob
2. Rear left burner control knob
3. Front left burner control knob
4. Central right burner control knob
5. 60 minutes alarm control knob
6. Gas burners electronic igniter pushbutton
7. Oven light / rotisserie control button
8. Electric oven/grill indicator light
CAUTION: If the burner is accidentally extinguished, turn the gas off at the control knob
and wait at least 1 minute before attempting to relight.
CAUTION:
Gas appliances produce heat and humidity in the environment in which they are installed.
Ensure that the cooking area is well ventilated by opening the natural ventilation grilles or
by installing an extractor hood connected to an outlet duct.
CAUTION:
Iftheapplianceisusedforaprolongedtimeitmaybenecessarytoprovidefurtherventilation
by opening a window or by increasing the suction power of the extractor hood (if tted).

8
Caution!
The cooking hob becomes very hot
during operation.
Keep children well out of reach.
N.B. When the cooker is not being
used, set the gas knobs to their closed
positions and also close the cock
valve on the gas bottle or the main gas
supply line.
Fig. 3.1
Fig. 3.2
Each burner is controlled by a gas tap (g.
3.1) assuring the opening and the closing
of the gas supply.
Make the knob symbols match with the
indicator on the control panel to obtain:
• symbol : off
• symbol : full on (nominal rate)
• symbol : reduced rate
√The maximum aperture position
permitsrapidboilingofliquids,whereas
the minimum aperture position allows
slower warming of food or maintaining
boiling conditions of liquids.
√To reduce the gas ow to minimum,
rotate the knob further anti-clockwise
to point the indicator towards the small
ame symbol.
√Other intermediate operating
adjustments can be achieved by
positioning the indicator between the
maximum and minimum aperture
positions, and never between the
maximum aperture and closed
positions.
Intheeventoftheburneramesbeing
accidentally extinguished, turn off the
burner control and do not attempt to
re-ignite the burner for at least 1 min.
USE OF THE HOB BURNERS
3
Caution!
Do not cover the hob with aluminium
foils.

9
It is important that the diameter of the pot
be suitable to the potentiality of the burner
so as not to compromise the high output
of the burners and therefore energy waste.
Asmall pot on a large burner does not give
you a boiling point in a shorten amount of
time since the capacity of heat absorption
of a liquid mass depends on the volume
and the surface of the pot.
Fig. 3.4
CHOICE OF THE BURNER
On the control panel, near every knob,
there is a diagram that indicates which
burner is controlled by that knob.
The suitable burner must be chosen
according to the diameter and the capacity
used.
As an indication, the burners and the pots
must be used in the following way:
DIAMETERS OF PANS WHICH MAY
BE USED ON THE BURNERS
BURNERS MINIMUM MAXIMUM
Semi-rapid 12 cm 24 cm
Rapid 24 cm 26 cm
Triple-ring 26 cm 28 cm
Wok pan Max 36 cm
do not use pans with concave or
convex bases
Fig. 3.3
LIGHTING THE BURNERS
To ignite the burner, the following
instructions are to be followed:
1. Press in the corresponding knob and
t urn counter-clockwise (g. 3.2) to the
full ame position marked by the
symbol (g. 3.1) and hold the knob in
until the ame has been lit. Press the
ignition button marked by the symbol
(g. 3.3). The sparks produced
by the electrodes situated next to the
burner will light the selected burner.
In the case of a mains failure light the
burner with a match or lighted taper.
2. Wait for about ten seconds after the
gas burner has been lit before letting
go of the knob (valve activation delay).
3. Adjust the gas valve to the desired
position.
If the burner ame should go out for some
reason, the safety valve will automatically
stop the gas ow.
To re-light the burner, return the knob to
the closed position, wait for at least
1 minute and then repeat the lighting
procedure.
If your local gas supply makes it difcult
to light the burner with the knob set to
maximum, set the knob to minimum and
repeat the operation.

10
CORRECT USE OF THE TRIPLE-RING BURNER
The at-bottomed pans are to be placed directly onto the pan-support.
When using a WOK you need to place the supplied stand in the burner to avoid any faulty
operation of the triple-ring burner (gs. 3.5a - 3.5b).
IMPORTANT:
The special grille for wok pans (g. 3.5b) MUST BE PLACED ONLY over the pan-rest for
the triple-ring burner.
WRONG CORRECT
Fig. 3.5a Fig. 3.5b

11
NATURAL CONVECTION ELECTRIC OVEN
4
The glass of the oven door reaches high
temperatures during operation.
Keep children away.
WARNING:
The door is hot, use the handle.
Models with glass lid: The cooker lid
must be kept open when the oven or the
grill is in use.
During use the appliance becomes hot.
Care should be taken to avoid touching
heating elements inside the oven.
GENERAL FEATURES
The oven is furnished completely clean; it is
advisable, however, upon rst use, to turn
the oven on to the maximum temperature
for about 15 minutes to eliminate possible
traces of grease on the heating elements.
The convection oven is equipped with 3
electrical heating elements:
• 2 elements (upper and lower) for
normal oven cooking;
• 1 grill element, on the top of the oven,
for grilling which must be done with the
oven door slightly open and with the
protection shield for the control panel
mounted.
The input of the element is:
• upper element
• lower element
• grill element
0
1
2
3
4
5
6
7
8
9
10
Fig. 4.1
Table 4.2
ELECTRICAL THERMOSTAT
Turn on the oven or grill element by turning
the switch that is also provided with a
thermostat to control the oven temperature.
On the knob (g. 4.1), other than the “0”
position (off), are numbers 1to 10 which
indicate the oven temperature value with
the temperature increase according to the
number (see table 4.2).
The position serves only for grilling
with the oven door slightly open and with
the protection shield for the control panel
mounted.
The switch/thermostat symbols indicate:
• Position “0”= off
• Positionfrom“1”to“10”=simultaneous
operation of the 2 elements (upper
and lower). The numbers correspond
to the temperature shown in the table
4.2. The elements will turn on and
off automatically depending on the
temperature required commanded by
the thermostat.
• Position = grill element in
operation without temperature control
(see specic paragraph).
The automatic turning on and off of the
elements is signalled by a light above the
knob.

12
WARNING:
The door is hot, use the handle.
During use the appliance becomes
hot. Care should be taken to avoid
touching heating elements inside the
oven.
OVEN COOKING
Tocook,beforeintroducingthefood,preheat
the oven to the desired temperature.
When the oven has reached the desired
temperature, introduce the food, control
the cooking time and tum off the oven
5 minutes before the theoretical time to
recuperate the stored heat
For orientative purposes only, some oven
cooking indications are shown on the
following table:
THERMOSTAT
POSITION DISHES
1 - 4 Heating of foods
4 - 5 Meringue - Fruit pies
Cooked fruit
5 - 6 Cakes - Amaretti
Vegetables
6 Lasagna - Cakes
6 - 7 Roast veal - Pie crusts
8Wild game - Birds
Small sh - Roast pork
9Large sh - Roast beef
9 - 10 Pizza - Red meats
10 Toasted sandwiches
USE OF THE GRILL
Very important: The grill must always be
used with the oven door slightly open
andwithshield“A”mounted(g.4.3).
Mount shield “A” which permits to protect
the control panel from the heat.
Turn on the grill, as explained in the
preceding paragraphs and let the oven
preheat for about 5 minutes with the door
slightly open.
Introducethefoodto becooked, positioning
the rack as close to the grill as possible.
The dripping pan should be placed under
the rack to catch the cooking juices and
fats.
Note: It is recommended that you do not
grill for longer than 30 minutes at any
one time.
The oven door becomes very hot during
operation. Keep children away.
A
ATTENTION: Hot part.
Allow to cool before
removing.
Fig. 4.3

13
OVEN LIGHT
The oven is equipped with a light that
illuminates the oven to enable visually
controlling the food that is cooking.
Thelightis operated by the switch indicated
in g. 4.5.
Fig. 4.5
ROTISSERIE
The oven is equipped with a rotisserie for
cooking on the spit using the grill.
This device is made up of:
• an electrical motor mounted on the
rear part of the oven;
• a stainless steel rod, equipped with
a detachable athermic grip and 2
recordable forks;
• a rod support to be inserted into the
central rack holders of the oven.
The rotisserie motor is operated by the
switch indicated in g. 4.5.
USE OF THE ROTISSERIE
Very important: The rotisserie must
always be used with the oven door
slightly open and with shield “A”
mounted(g.4.3).
• Insert the dripping pan into the lowest
rack holders of the oven and insert the
rod support into the intermediate rack
holders.
• Put the meat to be cooked onto the
rod, being careful to secure it in the
center with the special forks.
• Insert the rod into the motor opening
and rest it onto the support of the spit
collar; then remove the grip by turning
it to the left.
The rotation direction of the rotisserie can
be either clockwise or counter-clockwise.
Fig. 4.4

14
10
20
30
40
50
0
60 MINUTES ALARM (g. 5.1)
The minute counter is a timed acoustic
warning device which can be set for a
maximum of 60 minutes.
The knob must be rotated clockwise as far
asthe60 minuteposition andthensettothe
required time by rotating it anticlockwise.
IMPORTANT WARNING:
This is only a mechanical timer.
Remember to turn off the oven/grill
manually.
Fig. 5.1
60’ALARM
5

15
GLASS LID
For cleaning purposes, the lid can be easily
removed upwards once taken to the upright
position.
Should the hinges slip off, replace them in
their housing being careful that:
• The right housing must receive the
hingemarked “D” while the lefthousing
must receive the hinge marked “S” (g.
6.1).
REGULATING OF THE BALANCE
Lowerthelidandcheckthecorrectbalance.
While opened at 45° it should hang up.
The springs of the hinges can be adjusted
if necessary by turning the screws “R”
clockwise (g. 6.1).
Do not shut lid when
burner alight.
ATTENTION
Do not lower the glass lid when the
gas burner or electrical plates are
still hot or when the oven is
working or still hot.
Do not lay on the glass lid hot pans
and heavy kitchen utensils.
Dry off any liquid whitch may have
spilt on the cover before opening it.
Models with glass lid
CLEANING AND MAINTENANCE
6
S
D
R
Fig. 6.1

16
Attention
The appliance gets very hot, mainly around the cooking areas. It is very important
that children are not left alone in the kitchen when you are cooking.
Do not use a steam cleaner because the moisture can get into the appliance thus
make it unsafe.
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven
door glass or the glass lid (models with glass lid only) since they can scratch the
surface, which may result in shattering of the glass.
GENERAL ADVICE
• Important! Before you begin
cleaning, you must ensure that
the appliance is switched off and
disconnected from the electrical
power supply.
• When the appliance is not being used,
it is advisable to keep the gas tap
closed.
• The periodical lubrication of the gas
taps must be done only by specialized
personnel.
• If a tap becomes stiff, do not force;
contact your local After Sales Service
Centre.
• It is advisable to clean when the
appliance is cold and especially when
cleaning the enamelled parts.
• Avoid leaving alkaline or acidic
substances (lemon juice, vinegar, etc.)
on the surfaces.
• Avoid using cleaning products with a
chlorine or acidic base.
• Important: The use of suitable
protective clothing/gloves is
recommended when handling or
cleaning of this appliance.
WARNING! When correctly installed,
your product meets all safety
requirements laid down for this type of
product category. However special care
should be taken around the rear or the
underneath of the appliance as these
areas are not designed or intended to
be touched and may contain sharp or
rough edges, that may cause injury.
ENAMELLED PARTS
All the enamelled parts must be cleaned
with a sponge and soapy water or other
non-abrasive products.
Dry preferably with a microbre or soft
cloth.
Acidic substances like lemon juice, tomato
sauce,vinegaretc.can damagethe enamel
if left too long.
STAINLESS STEEL, ALUMINIUM
PARTS,PAINTEDANDSILK-SCREEN
PRINTED SURFACES
Clean using an appropriate product.
Always dry thoroughly.
IMPORTANT: these parts must be cleaned
very carefully to avoid scratching and
abrasion. You are advised to use a soft
cloth and neutral soap.
CAUTION: Do not use abrasive
substances or non-neutral detergents
as these will irreparably damage the
surface.
GAS TAPS
Periodic lubrication of the gas taps must be
carried out by specialist personnel only.
In the event of operating faults in the gas
taps, call the Service Department.

17
BURNERS
They can be removed and washed with soapy water only.
They will remain always perfect if cleaned with products used for silverware.
After cleaning or wash, check that burner-caps and burner-heads are dry before placing
them in the respective housings.
Check that the electrode “S” (gs. 6.2, 6.4) next to each burner is always clean to ensure
trouble-free sparking.
Check that the probe “T” (gs. 6.2, 6.4) next to each burner is always clean to ensure
correct operation of the safety valves.
Both the probe and electrode must be very carefully cleaned.
Note: To avoid damage to the electric ignition do not use it when the burners are not
in place.
CORRECT REPLACEMENT OF THE AUXILIARY, SEMI-RAPID AND RAPID
BURNERS
It is very important to check that the burner ame distributor “F” and the cap “C” has been
correctly positioned (see gs. 6.2 - 6.3) - failure to do so can cause serious problems.
CORRECT REPLACEMENT OF THE TRIPLE RING BURNER
The triple ring burner must be correctly positioned (see g. 6.6); the burner rib must be
enter in their logement as shown by the arrow (see g. 6.4).
The burner correctly positioned must not rotate (g. 6.5).
Then position the cap “A” and the ring “B” (gs. 6.5 - 6.6).

18
S
F
C
T
Fig. 6.2 Fig. 6.3
A
B
S
T
Fig. 6.4
Fig. 6.5 Fig. 6.6

19
FITTING THE OVEN SHELF
• The oven shelf is provided with a
security block to prevent accidental
extraction. It must be inserted
operating as per gure 6.7.
• To pull it out operate in the inverse
order.
OVEN DOOR
The internal glass of the oven door can be
easily removed for cleaning by unscrewing
the two lateral xing screws (g. 6.8).
INSIDE OF OVEN
The oven should always be cleaned after
use when it has cooled down.
The cavity should be cleaned using a
mild detergent solution and warm water.
Suitable proprietary chemical cleaners
may be used after rst consulting with
the manufacturers recommendations and
testing a small sample of the oven cavity.
Abrasive cleaning agents or scouring pads/
cloths should not be used on the cavity
surface.
NOTE:The manufacturersofthis appliance
will accept no responsibility for damage
caused by chemical or abrasive cleaning.
Let the oven cool down and pay special
attention no to touch the hot heating
elements inside the oven cavity.
WARNING !!
Do not store ammable
material in the oven.
Fig. 6.7
Security block
Fig. 6.8

20
REPLACING THE OVEN LAMP
(MODELS WITH INCANDESCENT
LAMP)
WARNING: Ensure the appliance is
switched off and disconnected from the
electrical power supply before replacing
the lamp to avoid the possibility of
electric shock.
• Let the oven cavity and the heating
elements to cool down.
• Switch off the electrical supply.
• Remove the protective cover “A” (g.
6.9).
• Unscrew and replace the bulb “B”
with a new one suitable for high
temperatures (300°C) having the
following specications: 220-240V,
50/60Hz, E14 and same power (check
watt power as stamped in the bulb
itself) of the replaced bulb.
• Ret the protective cover.
Note: Oven bulb replacement is not
covered by your guarantee.
REPLACING THE OVEN LAMP
(MODELS WITH HALOGEN LAMP)
WARNING: Ensure the appliance is
switched off and disconnected from the
electrical power supply before replacing
the lamp to avoid the possibility of
electric shock.
• Let the oven cavity and the heating
elements to cool down.
• Switch off the electrical supply.
• Remove the protective cover “A” (g.
6.10).
• Replace the halogen lamp “C”
with a new one suitable for high
temperatures (300°C) having the
following specications: 220-240V,
50/60Hz and same power (check watt
power as stamped in the lamp itself) of
the replaced lamp.
IMPORTANT WARNING: Never
replace the bulb with bare hands;
contamination from your ngers can
cause premature failure. Always use a
clean cloth or gloves.
• Ret the protective cover.
Note: Oven lamp replacement is not
covered by your guarantee.
A
B
A
C
Fig. 6.9
A
B
A
C
Fig. 6.10
WRONG
CORRECT
