Elba N58 205 Series Technical manual

GAS COOKERS
CUISINIERES A GAS
Instructions for the use - Installation advices
Mode d’emploi - Conseils pour l’installation
Made in Italy
HOME APPLIANCES
100%
ELBA QUALITY
MADE IN ITALY

2
The manufacturer cannot be held responsible for possible inaccuracies due to printing or transcription errors in the
present booklet.
The manufacturer re serves the right to make all modications to its products deemed necessary for manufacturer
commercial reasons at any moment and without prior notice, without jeopardising the es sential functional and safety
characteristics of the appliances.
Le fabricant n’est pas responsable des erreurs éventuelles, dues à des fautes de frappe ou d’impression, suscepti-
bles de se trouver dans cette notice.
Il se réserve le droit, sans porter préjudice aux caractéristiques essentielles, du point de vue fonctionnel et du point
de vue sécurité, d’apporter à ses produits, à tout moment et sans préavis, toutes les modications éventuellement
nécessaires pour faire face à des exigences de fabrication ou de commercialisation.
Français Mode d’emploi - Conseils Français pour l’installation Page 34
English Instructions for the use - Installation advices Page 3

3
Read the instructions carefully before installing and using the appliance.
CAUTION: this apparatus must only be installed in a permanently ventilated room in
compliance with the applicable regulations.
Dear Customer,
Thank you for having purchased and given your preference to
our product.
The safety precautions and recommendations reported below
are for your own safety and that of others. They will also provide
a means by which to make full use of the features offered by your
appliance.
Please preserve this booklet carefully. It may be useful in futu-
re, either to yourself or to others in the event that doubts should
arise relating to its operation.
This appliance must be used only for the task it has explicit-
ly been designed for, that is for cooking foodstuffs. Any other
form of usage is to be considered as inappropriate and there-
fore dangerous.
The manufacturer declines all responsibility in the event of
damage caused by improper, incorrect or illogical use of the
appliance.

4
FIRST USE OF THE OVEN
It is advised to follow these instructions:
• Furnish the interior of the oven by placing the wire racks as described at chapter
“Cle aning and maintenance”.
• Insert shelf and tray.
• Switch on the empty oven on max to eliminate grease from the heating elements.
• Let the oven cool down and clean the interior of the oven with a cloth soaked in
water and neutral detergent, then dry carefully.
Important:
This appliance is designed and manufactured solely for the cooking of domestic (house-
hold) food and is not suitable for any non domestic application and therefore should not
be used in a commercial environment.
This appliance guarantee will be void if the appliance is used within a non domestic
environment i.e. a semi commercial, commercial or communal environment.

5
IMPORTANT SAFEGUARDS AND
RECOMMENDATIONS
After unpacking the appliance, check to
ensure that it is not damaged and that the
oven door closes correctly. If in doubt, do
not use and consult your supplier or a pro-
fessionally qualied technician.
Packing materials (i.e. plastic bags, poly-
styrene foam, nails, packing straps, etc.)
should not be left around within easy re-
ach of children, as these may cause se-
rious injuries.
• Do not attempt to modify the techni-
cal characteristics of the appliance as
this may cause danger to users.
• Do not carry out any cleaning or main-
tenance operations on the appliance
without rst disconnecting it from the
electric power supply (only for models
with electrical components).
• If you should decide not to use this
appliance any longer (or decide to
substitute an older model), before di-
sposing of it, it is recommended that it
is made inoperative in an appropriate
manner in accordance to health and
environmental protection regulations,
ensuring in particular that all poten-
tially hazardous parts be made harm-
less, especially in relation to children
who could play with unused applian-
ces.
• After use, always ensure that the con-
trol knobs are in the “ “ off position.
• Do not allow young children or inrm
persons to use the appliance without
your supervision.
• During and after use of the cooker,
certain parts will become very hot. Do
not touch hot parts.
• Keep children away from the cooker
when it is in use.
• Some appliances are supplied with a
protective lm on steel and aluminium
parts. This lm must be removed be-
fore using the appliance.
• WARNING: When correctly installed, your
product meets all safety requirements laid
down for this type of product category. Ho-
wever special care should be taken around
the rear or the underneath of the appliance
as these areas are not designed or inten-
ded to be touched and may contain sharp
or rough edges, that may cause injury.
• Fire risk! Do not store ammable mate-
rial in the oven or in the storage com-
partment (some model only).
• Make sure that electrical cords connecting
other appliances in the proximity of the co-
oker cannot come into contact with the hob
or become entrapped in the oven door.
• Do not line the oven walls with alumi-
nium foil. Do not place baking trays or
the drip tray on the base of the oven
chamber.
• The manufacturer declines all liability for
injury to persons or damage to property
caused by incorrect or improper use of the
appliance.
• The various components of the appliance
are recyclable. Dispose of them in accor-
dance with the regulations in force in your
country. If the appliance is to be scrapped,
remove the power cord (
only for models
with electrical components ).
• Always use oven gloves when removing
the shelf and food tray from the oven whilst
hot.
• Do not hang towels, dishcloths or other
items on the cooker or its handle – as this
could be a re hazard.
• Clean the oven regularly and do not allow
fat or oils to build up in the oven base or
trays. Remove spillages as soon as they
occur.
• Do not stand on the cooker or on the open
oven door.
• Always stand back from the cooker when
opening the oven door to allow steam
and hot air to escape before removing the
food.
• This appliance is for domestic use only.

6
GAS BURNERS
1. Auxiliary burner (A) 1,00 kW
2. Rapid burner (R) 3,00 kW
3. Semi-rapid burner (SR) 1,75 kW
COOKING HOB
1
Fig. 1.1
2
3
1
3

7
CONTROL PANELS
2
Fig. 2.1
CONTROLS DESCRIPTION
1. Rear right burner control knob
2. Front right burner control knob
3. Front left burner control knob
4. Rear left burner control knob
5. Gas oven control knob (gas tap)
6. Gas oven/grill control knob (gas thermostat)
7. Gas burners electronic igniter control button (cooktop burners only)
8. Oven light rotisserie control button
9. 60 minutes alarm control knob
12345 7
12346 7
12345
12346 7
8 9
12346 78
Fig. 2.2
Fig. 2.3
Fig. 2.4
Fig. 2.5
Mod. N58 .. 205
Mod. N58 .. 220
Mod. N58 .. 222
Mod. N58 .. 214
Mod. N58 .. 204

8
USE OF COOKING HOB
3
Each burner is controlled by a gas tap (g.
3.1) assuring the opening and the closing
of the gas supply.
Make the knob symbols match with the in-
dicator on the control panel to obtain:
• symbol : off
• symbol : full on (nominal rate)
• symbol : reduced rate
The maximum aperture position permits ra-
pid boiling of liquids, whereas the minimum
aperture position allows slower warming of
food or maintaining boiling conditions of li-
quids.
Other intermediate operating adjustments
can be achieved by positioning the indica-
tor between the maximum and minimum
aperture positions, and never between the
maximum aperture and closed positions.
To reduce the gas ow to minimum, rotate
the knob further anti-clockwise to point the
indicator towards the small ame symbol.
Caution!
the cooking hob becomes very hot du-
ring operation.
Keep children well out of reach.
N.B. When the cooker is not being
used, set the gas knobs to their closed
positions and also close the cock val-
ve on the gas bottle or the main gas
supply line.
Fig. 3.1
Fig. 3.2

9
CHOICE OF THE BURNER
On the control panel, near every knob, the-
re is a diagram that indicates which burner
is controlled by that knob.
The suitable burner must be chosen ac-
cording to the diameter and the capacity
used.
As an indication, the burners and the pots
must be used in the following way:
DIAMETERS OF PANS WHICH MAY
BE USED ON THE HOBS
BURNERS MINIMUM MAXIMUM
Auxiliary 12 cm 14 cm
Semi-rapid 16 cm 24 cm
Rapid 24 cm 26 cm
Do not use pans with concave or convexe
bases
It is important that the diameter of the pot
be suitable to the potentiality of the burner
so as not to compromise the high output
of the burners and therefore energy waste.
A small pot on a large burner does not give
you a boiling point in a shorten amount of
time since the capacity of heat absorption
of a liquid mass depends on the volume
and the surface of the pot.
Fig. 3.4Fig. 3.3
LIGHTING THE BURNERS
To ignite the burner, the following instruc-
tions are to be followed:
1. Press in the corresponding knob and
t
urn counter-clockwise (g. 3.2 ) to the
full ame position marked by the
symbol (g. 3.1).
2. Models without electric ignition: light
the burner with a match or lighted ta-
per.
 Models with electric ignition
: press the
ignition button marked by the symbol
(g. 3.3). The sparks produced
by the electrodes situated next to the
burner will light the selected burner.
In the case of a mains failure light the
burner with a match or lighted taper.
3. Adjust the gas to the desired position.
To turn it off, turn the knob towards the
right, up to the safety click.
If your local gas supply makes it difcult to
light the burner with the knob set to maxi-
mum, set the knob to minimum and repeat
the operation.
MODELS WITH BATTERY IGNITION
(N58 .. 204, N58 .. 214)
If the electronic ignition does not work
make sure that the battery, installed on the
back of the cooker, is not at and has been
installed correctly (see the chapter “Battery
installation”, page 30).

10
USE OF THE GAS OVEN
4
The glass on the oven door reaches
high temperatures during operation.
Keep children away.
The cooker lid must be kept open when
the gas oven or grill is in use.
Fig. 4.1
9
10
6
7
8
3
4
5
1
2
GENERAL FEATURES
The oven is furnished completely clean;
it is advisable, however, upon rst use, to
turn the oven on to the maximum tempera-
ture to eliminate possible traces of grease
from the oven burner.
The same operation should be followed for
grill burner (only for models with gas grill).
The gas oven is provided:
Models with gas tap
• One gas burner (wattage: 2,75 kW) lo-
cated at the bottom.
Models with gas thermostat
• One gas burner (wattage: 3,20 kW) lo-
cated at the bottom (providing safety
device - only for the models N58 ..
222, N58 .. 220).
• One gas grill (wattage: 2,00 kW), pla-
ced on the top (providing safety device
- only for the models N58 .. 222, N58
.. 220).
WARNING:
The door is hot, use the handle.
During use the appliance becomes hot.
Care should be taken to avoid touching
heating elements inside the oven.
OVEN BURNER
It carries out normal “oven cooking”.
The gas delivery to the oven burner may
be controlled, according to the models, by
a tap or by a thermostat.
Models with gas tap (g. 4.1)
The adjustments are the same as descri-
bed for the top burner (see page 9).
Models with gas thermostat (g. 4.2)
The gas ow to the burner is regulated by
a thermostat which allow to maintain the
oven temperature constant.
The control of the temperature is assured
by a thermostatic probe positioned inside
the oven.
The probe must be always kept in its hou-
sing, in a clean condition, as an incorrect
position or encrustment may cause an alte-
ration in the control of the temperature.
The numbers 1to 10 printed on the knob
indicate the increasing oven temperature
value (see table 4.5).
To regulate the temperature, make the
chosen number of the knob (g. 4.2) match
with the indicator on the control panel.
Only for the models N58 .. 222, N58 ..
220: the gas thermostat controlling the gas
supply to the burner is equipped with a sa-
fety device which automatically stops the
gas ow in case of ame extinction.
Fig. 4.2

11
Fig. 4.4
A
IGNITION OF THE OVEN BURNER
Models with gas tap
To ignite the burner:
1. Open the oven door to the full extent.
2. Approach a ame to the burner. You
must be careful to approach the ame
to the hole “A” (g. 4.3) before turning
the tap on (g. 4.4), never viceversa.
3. Press the knob thoroughly and turn it
anti-clockwise of 90° (g. 4.4).
4. Adjust the burner according to the po-
wer required.
To turn it off, turn the knob towards the
right, up to the safety click.
Models with gas thermostat
To ignite the oven burner:
1. Open the oven door to the full extent.
2. Approach a ame to hole “A” (g.
4.3).
3. Press thoroughly the knob and turn
it anti-clockwise; the indicator should
match with the number 10.
Only for the models N58 .. 222, N58
.. 220: Keep the knob pressed.
Never continue this operation for
more than 15 seconds. If the burner
has still not ignited, wait for about
1 minute prior to repeating the igni-
tion.
4. Only for the models N58 .. 222, N58
.. 220: After lighting the burner, wait a
few seconds before releasing the knob
(until the safety valve stays open).
5. Gently close the oven door and set the
oven control knob to the required tem-
perature.
Fig. 4.3
ATTENTION: Never turn the gas tap
before approaching a ame to the hole
“A” of the oor.
WARNING: Risk of explosion! The
oven door must be open during this
operation.
ATTENTION: Never turn the gas ther-
mostat before approaching a ame to
the hole “A” of the oor.
WARNING: Risk of explosion! The
oven door must be open during this
operation.

12
For efcient oven preheating, we re-
commend that grill tray and rack are
removed from the oven and replaced
after about 15 minutes.
Only for the models N58 .. 222, N58 ..
220: If the ame extinguishes for any rea-
son, the safety valve will automatically shut
off the gas supply to the burner. To re-light
the burner, rst turn the oven control knob
to position , wait for at least 1 minute
and then repeat the lighting procedure.
THERMOSTAT
POSITION DISHES
1 Heating of foods
1Meringue - Fruit pies
Cooked fruit
1 - 2 Cakes - Amaretti
Vegetables
2 - 3 Lasagna - Cakes
3 - 4 Roast veal - Pie crusts
5 - 6 Wild game - Birds
Small sh - Roast pork
6 - 7 Large sh - Roast beef
7 - 8 Pizza - Red meats
8 - 9 Toasted sandwiches
10 Oven cleaning
OVEN COOKING
To cook, before introducing the food, pre-
heat the oven to the desired temperature.
When the oven has reached the desired
temperature, introduce the food, control
the cooking time and turn off the oven 5
minutes before the theoretical time to recu-
perate the stored heat.
COOKING EXAMPLES
Temperatures are approximate as they
vary depending on the quality and amount
of food.
Remember to use ovenproof dishes and
to adjust the oven temperature during co-
oking if necessary.
Table 4.5

13
Fig. 4.7
Fig. 4.6
IGNITION OF THE GRILL BURNER
(some models only)
To ignite the grill burner:
1. Open the oven door to the full extent.
2. Apply a ame to pipe of the grill burner
as shown in g. 4.6
3. Press in the oven control knob (g.
4.7) and turn clockwise to the position
marked by the symbol .
Only for the models N58 .. 222, N58
.. 220: Keep the knob pressed.
Never continue this operation for
more than 15 seconds. If the burner
has still not ignited, wait for about
1 minute prior to repeating the igni-
tion.
4. Only for the models N58 .. 222, N58
.. 220: After lighting the burner, wait a
few seconds before releasing the knob
(until the safety valve stays open).
The oven door must always be kept
half-open and with shield “A” mounted
when the grill is in operation (g. 4.9).
See specic instructions in the section
‘USE OF THE GRILL’.
ATTENTION: Never turn the gas ther-
mostat before approaching a ame to
the pipe of the burner.
WARNING: Risk of explosion! The
oven door must be open during this
operation.
Only for the models N58 .. 222, N58 ..
220: If the ame extinguishes for any rea-
son, the safety valve will automatically shut
off the gas supply to the burner. To re-light
the burner, rst turn the oven control knob
to position , wait for at least 1 minute
and then repeat the lighting procedure.
OVEN LIGHT (Only for the models
N58 .. 222, N58 .. 220)
The oven is equipped with a light that illu-
minates the oven to enable visually control-
ling the food that is cooking.
This light is controlled by a switch on the
control panel (g. 4.8)

14
USE OF THE GRILL
Very important: the grill must always be
used with the oven door slightly open
and with shield “A” mounted (Fig. 4.9)
The oven door becomes very hot during
operation.
Keep children away.
Mount shield “A” which permits to protect
the control panel from the heat.
Turn on the grill, as explained in the prece-
ding paragraphs and let the oven preheat
for about 5 minutes with the door slightly
open.
Introduce the food to be cooked, positioning
the rack as close to the grill as possible.
The dripping pan should be placed under
the rack to catch the cooking juices and
fats.
Note: It is recommended that you do not
grill for longer than 30 minutes at any
one time.
ROTISSERIE (Only for the models
N58 .. 222, N58 .. 220)
The oven is equipped with a rotisserie for
cooking on the spit using the grill.
This device is made up of:
• an electrical motor mounted on the
rear part of the oven;
• a stainless steel rod, equipped with a
detachable athermic grip and 2 recor-
dable forks;
• a rod support to be inserted into the
central rack holders of the oven.
The rotisserie motor is operated by the
switch indicated by the symbol on
the control panel (g. 4.8).
USE OF THE ROTISSERIE
Very important: the rotisserie must al-
ways be used with the oven door slight-
ly open and with shield “A” mounted
(Fig. 4.9).
• Insert the dripping pan into the lowest
rack holders of the oven and insert the
rod support into the intermediate rack
holders.
• Put the meat to be cooked onto the
rod, being careful to secure it in the
center with the special forks.
• Insert the rod into the motor opening
and rest it onto the support of the spit
collar; then remove the grip by turning
it to the left.
The rotation direction of the rotisserie can
be either clockwise or counter-clockwise.
A
ATTENTION: Hot part.
Allow to cool before
removing.
Fig. 4.9
Fig. 4.8
Fig. 4.10

15
10
20
30
40
50
0
60’ ALARM - only for model N58 .. 220
5
60’ ALARM (Fig. 5.1)
The minute counter is a timed acoustic
warning device which can be set for a ma-
ximum of 60 minutes.
The knob must be rotated clockwise as far
as the 60 minute position and then set to
the required time by rotating it anticlockwi-
se.
Fig. 5.1

16
ADVICE FOR THE CONSUMER
6
GENERAL ADVICE
• Important: before any operation of
cleaning and maintenance discon-
nect the appliance from the electri-
cal network (only for models with
electrical components).
• When the appliance is not being used,
it is advisable to keep the gas tap clo-
sed.
• Every now and then check to make
sure that the exible tube that con-
nects the gas line or the gas cylinder
to the appliance is in perfect condition
and eventually substitute it if it shows
signs of wearing or damage.
• The periodical lubrication of the gas
taps must be done only by specialized
personnel.
• If a tap becomes stiff, do not force;
contact your local Service Centre.
• Do not use cleaning products with a
chlorine or acidic base.
WARNING
When correctly installed, your product
meets all safety requirements laid down
for this type of product category. Ho-
wever special care should be taken
around the rear or the underneath of the
appliance as these areas are not desig-
ned or intended to be touched and may
contain sharp or rough edges, that may
cause injury.
Attention
The appliance gets very hot, mainly around the cooking areas. It is very important
that children are not left alone in the kitchen when you are cooking.
Do not use a steam cleaner because the moisture can get into the appliance thus
make it unsafe.
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door
glass or the glass lid (models with glass lid only) since they can scratch the surfa-
ce, which may result in shattering of the glass.
ENAMELLED PARTS
All the enamelled parts must be cleaned
with a sponge and soapy water or other
non-abrasive products.
Dry preferably with a microbre or soft
cloth.
Acidic substances like lemon juice, tomato
sauce, vinegar etc. can damage the ena-
mel if left too long.
STAINLESS STEEL, ALUMINIUM
PARTS AND SILK-SCREEN PRIN-
TED SURFACES
Clean using an appropriate product.
Always dry thoroughly.
IMPORTANT: these parts must be cleaned
very carefully to avoid scratching and abra-
sion. You are advised to use a soft cloth
and neutral soap.
CAUTION: Do not use abrasive substan-
ces or non-neutral detergents as these
will irreparably damage the surface.

17
INSIDE OF OVEN
The oven should always be cleaned after
use when it has cooled down.
The cavity should be cleaned using a mild
detergent solution and warm water. Suita-
ble proprietary chemical cleaners may be
used after rst consulting with the manu-
facturers recommendations and testing a
small sample of the oven cavity. Abrasive
cleaning agents or scouring pads/cloths
should not be used on the cavity surface.
NOTE: The manufacturers of this applian-
ce will accept no responsibility for damage
caused by chemical or abrasive cleaning.
Fire risk! Do not store ammable material
in the oven.
Let the oven cool down and pay special
attention no to touch the hot heating
elements inside the oven cavity.
BURNERS
They can be removed and washed with so-
apy water only.
They will remain always perfect if cleaned
with products used for silverware.
After cleaning or wash, check that burner-
caps and burner-heads are dry before pla-
cing them in the respective housings.
Only for models with electric ignition:
Check that the electrode “S” (gs. 6.1) is
always clean to ensure trouble-free spar-
king.
Note: The electrode S must be very ca-
refully cleaned. To avoid damage to the
electric ignition do not use it when the
burners are not in place.
CORRECT REPLACEMENT OF THE
BURNERS
It is very important to check that the bur-
ner ame distributor Fand the cap Chas
been correctly positioned (see gs. 6.1
- 6.2) - failure to do so can cause serious
problems.
S
F
C
Fig. 6.1 Fig. 6.2
(*) Only for models with
electric ignition
(*)

18
GLASS LID (models with glass lid)
For cleaning purposes, the lid can be ea-
sily removed upwards once taken to the
upright position.
Should the hinges slip off, replace them in
their housing being careful that:
• The right housing must receive the
hinge marked “D” while the left hou-
sing must receive the hinge marked
“S” (Fig. 6.3)
REGULATING OF THE BALANCE
Lower the lid and check the correct balan-
ce.
While opened at 45° it should hang up.
If necessary, register the calibration of the
hinge springs using the screws “R” (g.
6.3).
SUBSTITUTION OF THE OVEN
LIGHT (models with oven light)
WARNING: Ensure the appliance is
switched off before replacing the lamp to
avoid the possibility of electric shock.
• Let the oven cavity and the heating
elements to cool down.
• Switch off the electrical supply.
• Remove the protective cover.
• Unscrew and replace the bulb with a
new one suitable for high temperatu-
res (300°C) having the following speci-
cations: 230V, E14 and same power
(check watt power as stamped in the
bulb itself) of the replaced bulb
• Ret the protective cover.
Note: Oven bulb replacement is not cove-
red by your guarantee.
OVEN DOOR
(only for model N58 .. 220)
The internal glass of the oven door can be
easily removed for cleaning by unscrewing
the two lateral xing screws (g. 6.4).
Do not shut lid when
burner alight.
ATTENTION
Do not lower the glass lid when the
gas burners are still hot or when
the oven is working or still hot.
Do not lay on the glass lid hot pans
and heavy kitchen utensils.
Dry off any liquid whitch may have
spilt on the cover before opening it.
Models with glass lid
Fig. 6.4
only for model
N58 .. 220
S
D
R
Fig. 6.3

19
Advice for the
installer
IMPORTANT
• Cooker installation must only be carried out by QUALIFIED TECHNICIANS and in
compliance with local safety standards.
• The appliance must be installed in compliance with regulations in force in your country
and in observation of the manufacturer’s instructions.
• Always disconnect the appliance from the electrical supply before carrying out any
maintenance operations or repairs (only for models with electrical components).
• The surfaces of adjacent furniture and walls must be capable of withstanding tempe-
ratures in excess of 75°C. If the cooker is installed adjacent to furniture which is higher
than the gas hob cooktop, a gap of at least 30 cm must be left between the side of the
cooker and the furniture.
• Some appliances are supplied with a protective lm on steel and aluminium parts.
This lm must be removed before using the cooker.

20
INSTALLATION
7
INSTALLATION
Gas oven models afford class ‘1’
protection against overheating of
surrounding surfaces.
A space of at least 2 cm must be left
between the cooker and any adja-
cent furniture, which must not exce-
ed the height of the cooktop
(g. 7.1).
The walls of the units must not
be higher than work top and must
be capable of resisting tempera-
tures of 75 °C above room tem-
perature.
Do not instal the appliance near
inammable materials (eg. cur-
tains)
Fig. 7.1
Fig. 7.2
50 cm
50 cm
450 mm
300 mm
20 mm
20 mm
650 mm
500 mm
