Elba EMC-F4316 User manual

OFF
Heating
Fire adjustment
Slow fire Mi dd le
fi re High f ire
OFF
Cooking
Power
Keep Warm High

1.
2.
3.
4.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
IMPORTANT SAFEGUARDS
220-240V~50Hz
CLEANING AND MAINTENANCE
PRODUCT SPECIFICATION
EMC-F4316(SS)
220-240V1600W5.0L
Model Rated Voltage Rated Power Capacity
CIRCUIT DIAGRAM
Be sure to use earthing switch socket, and the socket must be inserted tightly.
Never use a universal socket shared with others electrical appliances.
The inner pot, outer body and heating plate are very hot when in use or within
sometime after shutdown, never touch them with your hand.
Be sure to use the specific pot to the product, and do not put other pots on the
heating plate of this product for cooking.
If the power line of the appliance is broken, to avoid any dangers. Please send
the appliance to the nearest authorized dealer or after sales service center for
examination and repair.
Do not put the multi cooker in a location which is unstable or wet or near other fire
source or heat sources, or it may be damaged or fail to work.
Please do not put the inner pot on a gas stove or other heat source or it may be
deformed, affecting operating effect.
When the inner pot is not located in the cooker body, it is prohibited to pour water
or other substances into pot.
In case any defects are found, please do not disassemble the unit by yourself
and you should send it to an authorized after sales service center for repair.
Please do not cook direct on the heating plate so as to prevent from causing failure
and electrical shock dangers.
Do not use metallic or sharped appliance to scrap the inner pot, otherwise the
non-stick coating will be damaged.
This appliance is not intended for use by person (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
While operating the appliance, keep the appliance out of reach of children.
Save these instructions for future reference.
After each use, be sure to pull out the plug and start cleaning when the cooker
body completely cools down. During the cleaning, it is better to use soft cloth
dipped in neutral detergent, and you are not allowed to use metal brushes,
corrosive solvents and so on to avoid damages to the non-stick inner pot and
the cooker by body surface.
Never clean the multi cooker by putting it entirely into water, and never wash
the heating plate with water so as to prevent from electrical shock dangers and
functional failure. It is advisable to wipe off the attached sundries with slightly
wet cloth.
The cooker lid and enclosure surface can be cleaned with soft cloth dipped in
neutral detergent.
When the cooker not used for long, please clean and store it after it dries up.

1.
2.
3.
Be sure to clear water drop, outer of the pot and heating
surface, then place the inner pot into the cooker body and gently
rotate it several times to ensure that the inner pot is steadily placed
and has a good contact with the heating plate.Otherwise, it will
caused poor heat transfer and affecting the normal temperature rise.
Before plug the unit, please put the power regulator to “off” position,
make sure the power supply is 240V AC electricity,the outlet can
withstand rated current of no less than 10A, and safe earthing is
available. Otherwise the unit is not allowed to use.
Cooking Function : Stir fry, frying, steaming, slow cooking,warming
and steamboat.
a. After plugging in the unit, set the power regulator to the function
position required (at this moment the appliance lamp light up).
b. After cooking some time, set the power regulator to a position as
required.
c. Set the power regulator to keep warm function.
d. After finished using, set the power regulator to “off” position,and
be sure to pull out the plug.
OPERATING INSTRUCTION
Attention!
Where the unit is used for the first time or the socket is
frequently used, please regularly check whether the plug can
match the socket wall; methods for inspection: first insert the
plug into the socket, turn off the unit after it operates for half
an hour and then pull out the plug. Check whether the plug
pins burn the hand. If they are so hot to burn the hand
(approximately over 50°C), please make sure to replace the
socket by a well contacted socket so as to prevent from
burning out the plug or fire due to the overheat caused by
poor contact.
OFF
Heating
Fireadjustment
Slowf ire Mid dle fir e Highf ire
PRODUCT DESCRIPTION
PERFORMANCE CHARACTERISTICS
1. Cooker lid handle2. Cooker lid
4. Heating plate3. Non-stick inner pot
5. Body handle 6. Stainless steel body
7. Control panel 8. Power regulator
9. Power regulator
Having temperature control function to control cooking temperature.
Provided with temperature safety device, to prevent from unusual
overheat.
Removable non-stick inner pot, easy to clean.
High temperature transparent glass lid.
1.
2.
3.
4.
