Elba ESMB-E3030(WH) User manual

STAND MIXER
MODEL: ESMB-E3030(WH)
Owner’s Manual
Please read this manual carefully
before operating your set.
Retain it for future reference.
Record model number and serial
number of the set.
See the label attached on the set and
quote this information to your dealer
when you require service.
For The Warranty Terms & Conditions, Please Refer To Warranty Certificate.

1
IMPORTANT SAFEGUARDS
Before using the appliance, basic precautions should always be followed including the
following:
1. Read all instructions before using.
2. Do not operate the appliance with damaged power cord or plug, after the
appliance malfunction, or if it is dropped or damaged in any manner. Return the
appliance to the nearest authorized dealer or after-sales service center for
examination, repair, electrical or mechanical adjustment.
3. Do not leave the mixer unattended while operating.
4. Do not let the power cord hang over the edge of the table or counter or hot surface.
5. When removing the plug from wall outlet, grasp the plug to pull and not the cable.
6. To protect against risk of electrical shock, do not immerse mixer in water or
any other liquids. This may cause personal injury or damage to the product!
7. Avoid contacting with moving parts. Keep hands, clothing, as well as spatulas and
other utensils away from beaters and dough hooks during operation to reduce the
risk of injury to persons, and/or damage to the appliance.
8. Close supervision is necessary when your appliance is being used near children or
infirm persons.
9. Never use any accessories or parts from other manufacturers or that ELBA does
not specifically recommended.
10.Always make sure that the beaters or dough hooks are fully inserted into position
before connecting the plug to the wall outlet.
11.Do not place the appliance on or near hot gas or on a heated oven.
12.Never eject beaters or dough hooks while in use.
13.Bowl must be in proper position before operating the mixer.
14.Unplug the plug from wall outlet when not in use, before putting on or taking off
parts, and before cleaning.
15.Let the appliance to cool off before cleaning or storing.
16.This appliance is for domestic use only.
17.Do not operate the appliance for other than its intended use.
18.Do not use this mixer outdoors.
19.This appliance is not intended for used by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use
of the appliances by a person responsible for their safety.
20.Children should be supervised to ensure that they do not play with the appliance.
21.Save these instructions for future reference.
Important note:
The maximum operation time shall not exceed 9 minutes. Let the appliance
rest for approximate 30 minutes until the mixer has cooled down.
Always power off the appliance before changing or removing the accessories.

2
PRODUCT DESCRIPTION
1. Eject button
2. Speed selector
3. Turbo button
4. Mixer handle
5. Hand mixer
6. Lock/release button
7. Base switch
8. Mixer bowl
9. Mixer base
10.Dough hooks
11.Beaters
Accessories:
Beaters: For mixing egg or any other liquids.
Dough hooks: For kneading the dough.
MIXING GUIDE
Caution: When mixing flour, start with speed 1 for 30-60 seconds, then change to
speed 5 for continuous mixing.
Speed selector
Descriptions
0
<OFF>
No power at this stage.
1
<FOLD>
This is a good starting speed for bulk and dry foods such as flour,
butter and potatoes.
2
<BLEND>
Best speed to start liquid ingredients for mixing salad dressings.
3
<MIX>
For mixing cakes, cookies and quick breads.
4
<CREAM>
For creaming butter and sugar.
5
<WHIP>
For beating eggs, cooked icings, whipping potatoes, whipping
cream, etc.
TURBO
Maximum speed

3
USING THE APPLIANCE FOR THE FIRST TIME
Please read all instructions carefully before using this appliance.
Remove all packing material and check carefully. Make sure that the appliance is
in good condition. It must have no cracks on the unit and no damage to the
power cord or plug. Do not discard any packaging until all accessories are
confirmed available in the packaging.
Please make sure that the voltage indicated on the appliance corresponds with
the household voltage.
Remove any adhesive labels or stickers before using.
OPERATING THE APPLIANCE
Install the beaters or dough hooks
Figure 1
Note: Prior to initial use, wash all parts
that come into contact with food. Switch
off and unplug the appliance before
changing accessories. Select the desired
accessories, depending on the mixing
task to be performed: beaters for
whisking, mixing and beating, or dough
hooks for kneading.
Hold the handle of the hand mixer
with one hand and place the beaters
or dough hooks with the other. Install
the beaters or dough hooks to the
hole at the bottom of the hand mixer
The one with gear can only be
inserted into the right side of the hole
and the one without gear to the left
side.
Note: The two beaters and two dough
hooks cannot be inserted in reverse
directions.
Right
Left

4
Install the hand mixer to the upper
base
Figure 2
Align the hole at the bottom of the
hand mixer with the clips on top of
the upper base, and then press the
lock button to assemble the hand
mixer to the upper base until it
“clicks”.
Make sure the mixer is placed on a
flat and stable surface.
Detach the hand mixer from the
upper base
Figure 3
To detach the hand mixer from the
upper base, press the lock button and
lift the hand mixer’s handle as per
figure 3.
Place the mixer bowl onto the mixer
base
Figure 4
Figure 5
Press the base switch and lift up the
upper base. Place the food into the
mixer bowl and return the bowl back to
the base (Figure 4)
After that, press the base switch again
to level down the mixer until it locks
into position. (Figure 5)
Connect the plug to the wall outlet and
power on.
Switch on the appliance beginning
from the lowest speed “1” to prevent
ingredients from splashing out of the
bowl.
Then dial the speed selector
according to your desired setting and
the mixer will start working. There
are 5 speed settings and the speed
will achieve the highest if the turbo
button is pressed at any time.
The bowl will rotate by itself when
operating if the gear is fitted properly.
Warning: The max operation time shall
not exceed 9 minutes. Let the appliance
rest for approximate 30 minutes until the
mixer has cooled down.

5
4. Never eject beaters or dough hooks when the appliance is in operation.
5. After using, reset the speed selector to position “0” and unplug the appliance.
6. To dismantle the beaters or dough hooks from the mixer, press the eject button
and remove.
WARNING: Remove the beaters/dough hooks only at “0”setting.
7. Always unplug from the power supply when you have done mixing and before
cleaning.
8. The hand mixer can be used separately without the mixer base in position.
CLEANING AND MAINTENANCE
1. Unplug the appliance from the power supply and wait until it completely cools
down before cleaning.
2. Clean the exterior of the appliance using a damp cloth and then wipe it with a soft
dry cloth.
3. Do not immerse the mixer on any other liquids.
4. Clean the beaters or dough hooks in warm soapy water. Rinse and wipe dry.
Please note that beaters and hooks are suitable for dishwasher.
5. We recommend cleaning the accessories immediately to remove any food
residues from the accessories after using. This will make cleaning easier and
prevents bacterial growth.
6. Never use abrasive cleaners to clean the appliance, beaters or dough hooks.
7. If the supply cord is damaged, it must be replaced by the authorized service
center or qualified technician in order to avoid hazard.
COOKING TIPS
1. Ingredients such as butter and eggs should always store in refrigerator before
mixing begins.
2. To eliminate the possibility of shells or deteriorated eggs in your mixture, break
eggs into separate container first, then adding it to the mixture.
3. Always start the process of mixing at lowest speed. Gradually increase to the
recommended speed as stated in the recipe.
ENVIRONMENT-FRIENDLY DISPOSAL
You can help to protect the environment!
Please remember to respect the local regulations: hand in the non-working
electrical equipments to an appropriate waste disposal centre.

6
