Eldat RCU01 Series User manual

GB
Universal Receiver (2-Channel) RCU01
Models
RCU01-4102M-01: 433.92 MHz
RCU01-5002M-01: 868.3 MHz
Package Content
Universal Receiver
Rod antenna (only 433.92 MHz)
Mounting accessories
Operating instructions
Technical Data
Frequency: 433.92 or 868.30 MHz
Power supply: 230 V AC / 12-24 V DC
Output: 2 potential-free relay
contacts
Max. load: 230 V AC / 1.800 VA
30 V DC / 3 A / 120 W
Response time: approx. 1 second
Degree of protection: IP 65
Operating temperature: -20°C to +60°C
Dimensions: 162 x 70 x 38 mm
(without rod antenna)
Weight: approx. 250 g
Intended Use
The unit may only be used as a radio con-
trol system together with low voltage or
mains voltage devices!
The manufacturer does not assume any
liability for damage caused as a result of
improper or non-intended use!
Safety Advice
Warning! During program-
ming, the Universal Receiver
is live!
Do not touch the terminals! Only use
suitable tools!
Carefully read through these instructions
before connecting and operating the
radio control!
Caution! Electrical installation may only
be carried out by a qualified electrician!
Observe the applicable laws, standards
and regulations, particularly EN 60669!
Have faulty units checked by the manufac-
turer!
Do not make any unauthorized alterations
or modifications to the unit!
Non-observance of the installation instruc-
tions may cause fire or other hazards.
Function
The unit is a universally applicable two
channel receiver, which can be operated
both with low voltage and mains voltage.
The receiver can memorize 4 transmission
codes for each channel. For each channel
different operating modes can be pro-
grammed: Impulse, ON/OFF (1- and 2-
button operation), timer (30 seconds and 3
minutes), continuous and awning operation.
General Information
Do not mount the receiver near the floor or
near large metal objects!
The maximum length of all connecting
cables may not exceed 3 m.
The reception quality can be affected by a
number of factors:
•location
•equipment and systems without interfer-
ence suppression
•other transmitters within the frequency
range
•atmospheric conditions and other fac-
tors.
In case of malfunctions, contact your dealer
or the manufacturer.
Connection Diagram
HF
module
ST2
ST1
LNNN 1
2
+
-
DR1
H1
S1
TA1
TA2
K1
V1
K2
V2
N
230 VAC
L
S1 Dip switch for memory location
select
DR1
Rotary switch for operating mode
select
H1 LED
TA1 Programming button for channel 1
TA2 Programming button for channel 2
K1 Relay 1 for device 1
K2 Relay 2 for device 2
V1 Connecting terminal for relay 1
V2 Connecting terminal for relay 2
ST1 Connecting terminal for mains
voltage 230 V AC
ST2 Connecting terminal for low voltage
12-24 V DC
Start-Up
Start-up the Receiver in three steps:
1. Installing the radio control
2. Programming the operating mode
3. Memorizing the transmitter codes
Installing the Receiver
1. Unscrew the housing cover.
2. (only 433.92 MHz) Mounting the rod
antenna:
Feed the rod antenna 1from the back
through the back plate 2into the
receiver (fig. A).
Connect the aerial wire 3of the HF
module to the rod antenna (fig. B).
2
1
3
3. Using the screws and dowels supplied,
mount the receiver on the wall.
4. Connect the low voltage or mains
voltage devices to be switched to the
connecting terminals V1 or V2 according
to the connection diagram. The
connecting terminals are plug-type
terminals.
Max. contact rating:
230 V AC / 1.800 VA
30 V DC / 3 A / 120 W
5. Connect the power supply cables to the
connecting terminal ST1 (mains voltage
230 V AC) or ST2 (low voltage 12-24 V
DC) according to the connection
diagram. The connecting terminal ST1 is
a plug-type terminal.
Note: All cables are to be fed into the
radio control via the openings on the
bottom using the watertight PG screw
fittings.
6. Switch on the supply voltage. The LED
H1 lights up for approx. 1 sec.
7. Carry out a function check:
Press any button of the radio transmitter.
The LED H1 of the receiver should flash
rapidly.
433 MHz model
with Rod Antenna

70471 1005 GB
Programming the Operating Mode
Warning! During program-
ming, the Universal Receiver
is live!
Do not touch the terminals! Only use
suitable tools!
Note:
For each chennel a different operating
mode can be programmed.
1. Select the operating mode via rotary
switch DR1 according to the following
table.
2. Press and hold the programming button
for the desired channel (TA1 or TA2),
until the LED H1 lights up for approx.
1 second.
DR1 Operating Mode
0 Impulse
Relay operates for approx. 1 sec.
1 On/Off (1-Button Operation)
1
st
transmission: Switching on
2
nd
transmission: Switching off
2 Timer 30 Seconds
After transmission, the device is
switched on for 30 seconds. If a
new signal is transmitted within this
30 s period, the 30 s timer is re-
started.
3 Timer 3 Minutes
as for setting 2, but with a period of
3 minutes
4 Memorizing transmission codes
5 Deleting transmission codes
6 Continuous Operation
Relay operates as long as the
transmitter button is pressed.
7 Awning Operation
1
st
transmission: Channel 1
switched on for max. 2 minutes
2
nd
transmission: Channel 1
switched off
3
rd
transmission: Channel 2
switched on for max. 2 minutes
4
th
transmission: Channel 2
switched off
9 On/Off (2-Button Operation)
Transmitter button 1: Switching on
Transmitter button 2: Switching off
Note:
On the operating mode 7 („Awning Opera-
tion“) the two channels interact simultane-
ously. Only one of the programming buttons
(TA1 or TA2) has to be pressed in order to
program the operating mode.
Memorizing the Transmission Codes
4 different transmission codes can be
memorized for each channel.
The memory locations for the
transmission codes can be
selected via dip switch S1.
1
2
O
N
ON
OFF
1. Select a memory location via dip switch
S1.
a) Operating Modes 0 to 3, 6, 7
1 2
Transmitter 1: OFF OFF
Transmitter 2: ON OFF
Transmitter 3: OFF ON
Transmitter 4: ON ON
b) Operating Mode 9
Transmitter
Button Function 1 2
Button 1: Off OFF OFF
Button 2: On ON OFF
Button 3 or
Transmitter 2/
Button 1:
Off OFF ON
Button 4 or
Transmitter 2/
Button 2:
On ON ON
2. Turn rotary switch DR1 to position 4
(„Memorizing Transmission Codes“).
3. Press and hold the programming button
for the desired channel (TA 1 or TA2)
until the LED H1 of the receiver flashes.
4. Within the next 10 s, press the transmit-
ter button which is supposed to control
this channel. After memorizing the
transmission code, the LED H1 of the
receiver lights up constantly for approx.
2 s and then turns off. Release the
transmitter button.
5. Repeat steps 1 to 4 for the other trans-
mitters or transmitter buttons.
6. Screw the housing cover back on.
Note:
If a new transmission code is memorized on
a memory location, the old code memorized
on that location is deleted.
Deleting the Transmission Codes
1. Select the memory location to be de-
leted via dip switch S1.
2. Turn rotary switch DR1 to position 5
(„Deleting Transmission Codes“).
3. Press and hold the programming button
for the desired channel (TA 1 or TA2)
until the LED H1 of the receiver lights
up. The transmission code on the se-
lected memory location is deleted.
Cleaning the Receiver
Wipe the housing carefully with a damp lint
free cloth.
Caution:
Do not use cleansing agents containing
organic solvents. These are dangerous to
your health and may damage the surface of
the housing.
Disposal
Waste electrical products may not be
disposed of with household waste!
Dispose of the waste product via a
collection point for electronic scrap
or via your specialist dealer.
Put the packaging material into the
recycling bins for cardboard, paper
and plastics.
Warranty
Within the statutory warranty period we
undertake to rectify free of charge by repair
or replacement any product defects arising
from material or production faults.
Any unauthorized tampering with, or modifi-
cations to, the product shall render this
warranty null and void.
Conformity
This product complies with the
essential requirements of the
R&TTE Directive 1999/5/EC.
The Declaration of Conformity can be found
on the Internet at: www.eldat.de.
Customer Service
If, despite correct handling, faults or mal-
functions occur or if the product was dam-
aged, please contact the company at the
address below:
ELDAT GmbH
Im Gewerbepark 14
15711 Zeesen/Germany
Phone: + 49 (0) 33 75 / 90 37-310
Telefax: + 49 (0) 33 75 / 90 37-90
Internet: www.eldat.de
E-mail: [email protected]
