Eldes EKB3 User manual

KEYBOARD
KLAVIATŪRA EKB3
INSTALLATION MANUAL

2
EKB3 is a keyboard intended to use with GSM alarm and management system ESIM264.
Main EKB3 keyboard functions are:
• armanddisarmsecuritysystem
• armanddisarmSTAYmode
• conguresystemparameters
• displayinformationwithLEDindicators
• informaboutsystemstatusviasoundsignaler
Thekeyboardusestwopasswordlevels-userandadministrator.Systemcongurationcanbeperformedbyenteringadministrator
passwordandusingprogramingcommands.ESIM264allowstoconnectupto4EKB3keyboards.Integratedsoundsignalerinforms
aboutsuccessful/unsuccessfulfunctionsperformance,informsaboutentryanddelaytimecountdowns.
CONTENT
1. Package content ................................................................................................................................................................ x
2. Device installation............................................................................................................................................................. x
3. Technical specications..................................................................................................................................................... x
 3.1Electricalandmechanicalcharacteristics ...................................................................................................................................................x
 3.2LEDindicatorfunctionality...............................................................................................................................................................................x
 3.3Connectorfunctionality ....................................................................................................................................................................................x
 3.4DIPswitches...........................................................................................................................................................................................................x
4. Operation description....................................................................................................................................................... x
 4.1Arming-Disarmingthesystem........................................................................................................................................................................x
4.2 System troubles....................................................................................................................................................................................................x
 4.3Bypassingzones...................................................................................................................................................................................................x
 4.3Congurationcommands.................................................................................................................................................................................x
  4.3.1Userscommands ....................................................................................................................................................................................x
  4.3.2Passwordcommands ............................................................................................................................................................................x
  4.3.3Zonescommands...................................................................................................................................................................................x
  4.3.4Monitoringstationcommands..........................................................................................................................................................x
  4.3.5Temperaturecommands......................................................................................................................................................................x
  4.3.6Othercommands....................................................................................................................................................................................x
5. Additional Information............................................................................................................................................................................................x

USER MANUAL EKB3 V1.0 3
BACK SIDE
DOWN SIDE
Fig. No. 1
1. Package content
1. EKB3 keyboard....................... qty. 1
2. User manual............................ qty. 1
3.5,6kΩresistor.......................... qty. 1
2. Device installation
1. DetachKeyboardholderfromEKB3keyboardandxittothewall.Keyboardholderdetachpointsaremarkedwithrows(seeFig.
No. 1).
2. DisconnectsecuritysystemESIM264powersupplyandbackupbatterybeforeconnectingthewires.
3. ConnectkeyboardconnectorstoESIM264.Accordingly,AUX+toAUX+,AUX-toAUX-,YtoY,GtoG.KeyboardZ1zoneconnectto
keyboardCOMwith5,6kΩresistor.ZoneZ2isnotactiveandthereisnoneedtoconnectit.CongureDIPswitches(seechapter
3.4).
4. Inxthekeyboardintotheholder.
NOTE:Payattentiontothetamperwhenxingthekeyboardtothekeyboardholder.Itmustbeproperlypressed.
5. TurnonESIM264powersupply.
4. EKB3 keyboard is ready to use.
3. Technical specications
3.1 Electrical and mechanical characteristics
Powersupply 12-14V 150mA max
Maximumkeyboardconnectioncablelength 100 m.
Dimensions 140x100x18mm
RangeofOperatingTemperatures 0...+55ºC

4
1 2 3
4 5 6
7
ARMED
READY
SYSTEM BYPS
A B
1
2
3
4
5
6
7
8
9
10
11
12
8 9
*0 #
STAY
BYPS
INST
CODE
FRONT SIDE
Z2 Z1
COM Y
G
AUX-
AUX+
ON
OFF
DIP SWITCH
TAMPER
BACK SIDE
Fig. No. 2 Fig. No. 3
Z2 Z1
COM Y
G
AUX-
AUX+
ON
OFF
DIP SWITCH
TAMPER
BACK SIDE
Fig. No. 4
3.2 LED indicator functionality
ARMED Armedsecuritystatusindicator
READY Indicateswhenallzonesareinactive
SYSTEM Administratormodeactivationindicator
BYPS Temporaryzonedisconnectionstatusindicator
1-12 Indicatesviolatedzones
3.3 Connector functionality
AUX+ Positivesupplypin12-14V connectedtothemainunitAUX+
AUX- Negativesupplypin12-14V connectedtothemainunitAUX-
GGpinconnectedtothemainunitG
YYpinconnectedtothemainunitY
COM Commoncontact
Z1 Securityzone
Z2 Inactivezone
3.4 DIP switches
DIPswitchesareusedtosetkeyboardaddress.ESIM264allowstoconnectupto4EKB3keyboards.
Everykeyboardmusthavedierentaddress(twokeyboardscannotbeconguredwiththesame
DIPswitchcombination).Possiblecongurationcombinationsaredisplayedinthetablebelow.
NOTE: Thirdswitchisnotactiveanditspositionisirrelevant.
1 2 Address
OFF OFF Keyboard 1
ON OFF Keyboard 2
OFF ON Keyboard 3
ON ON Keyboard 4

USER MANUAL EKB3 V1.0 5
4. Operation description
WhenthesystemisdisarmedandoperatingnormallyitwilldisplaygreenLEDcalledREADY.Whenanyzoneisviolated,thegreen
LEDcalledREADYturnsoandtheredLEDwiththenumberofviolatedzoneshowsup.Systemsoundsignalerusestwotypeof
signals-threeshortbeepsandonelongbeep.Threeshortbeepsstandsforsuccessfulcompletetasksandonelongbeepstandsfor
unsuccessfulcompletetasks.Star(*)buttonstandsforcancel.
4.1 Arming-Disarming the system
Toarmthesecuritysystemuserhavetoenteravalidkeyboardpassword.Thesystemstartstocountthetimededicatedtoleavethe
premises.Theuserisinformedaboutthetimecountdownbyasoundsignal.Whensystemissuccessfularmed,theredLEDcalled
ARMEDdisplays.
Todisarmthesecuritysystemuserhavetoenteravalidkeyboardpassword.Whenusersentersintosecuredpremises,thesystem
startstocountthetimededicatedtoenterkeyboardpassword.Ifuserswillnoenteravalidkeyboardpassword–thesystemwillcause
analarm.Whensystemissuccessfuldisarmed,theredLEDcalledARMEDturnso.
4.2 System troubles
YellowLED calledSYSTEMindicatessystemtroubles.Tocheckthe specictroubleuse command[CODE#],whereCODEmeansa
buttonnamedCODE.Thesystemfor15secondsshowstroubleswithzonesredLEDindicators.Thespecictroublesaredisplayedin
the table below.
Zone number Trouble
1Tamper
2Backupbattery
3Mainpower
4Time
5Highzones*
6GSMconnection
*Highzonesaretroubledzonesabove12.
IfyellowLEDcalledSYSTEMisblinkingmeansthatthereareviolatedzonesortampersabove12.Tocheckwhichzoneisviolateduse
command[CODE1],whereCODEmeansabuttonnamedCODE.Tocheckwhichtamperisviolatedusecommand[CODE2],where
CODEmeansabuttonnamedCODE.Thekeyboardwilldisplayacodeofviolatedzone.Toknowwhichzoneortamperabove12is
violated,useaformulaB+A,e.g.ifsystemdisplayszones5and10,meansthatviolatedzoneis30+5=35.
A B
Zonenumber1=1 Zonenumber7=12
Zonenumber2=2 Zonenumber8=18
Zonenumber3=3 Zonenumber9=24
Zonenumber4=4 Zonenumber10=30
Zonenumber5=5 Zonenumber11=36
Zonenumber6=6 Zonenumber12=42
4.3 Bypassing zones
Tobypassanyzoneusethecommand[BYPSxxyyyy#],whereBYPS-meansabuttonnamedBYPS,xx–zonenumberandyyyy–key-
boardpassword.Usethesamecommandtoenablebypassedzones.Thezonecanbebypassedonlyfortemporaryperiodandafter
arming-disarmingthesystemitwillbeactiveagain.
4.3 Conguration commands
Tousecongurationcommandsuserhavetoenteradministratorcode.Administratorcodecanbeenteredtothesystemwithcom-
mand[*XXXX#],whereXXXX–administratorcode.WhenadministratorcodeisenteredsuccessfullytheredLEDcalledARMEDstarts
blinking.

6
4.3.1 Users commands
Allow Only
Preset Users
SMS All
Inform about
Arming/Disarming
Whenthisfunctionisenabled,thesystemreactstotheSMSmessages-commandsthatare
sentonlyfromregisteredtelephonenumbers.Ifthisfunctionisdisabled,thedevicecanbe
controlledbyalluserswhoknowthenumberoftheSIMcardinsertedinthedevice,control
commandsandthemainpassword.Factorydefaultsetting–enabled.
Whenthisfunctionisenabled,inthecaseofanalarm,thesystemsimultaneouslysends
SMSmessagestoallenteredusers.Bydefaultthisfunctionisdisabled.Whenthisfunction
isdisabled,SMSmessagesaredeliveredinasequencestartingwiththerstuser(User1).
Themessagewillbesenttothenextuseronlyinthecasethedevicedoesnotreceivea
conrmationaboutasuccessfulSMSmessagedeliverytotherstrecipient.
Whenthisfunctionisenabled,thesystemsendsinformationmessagestothemainuser
(User1)aboutarmed/disarmedsecuritysystem.Bydefaultthisfunctionisdisabled.
Enter code 12 and function:
Enabled–[120#]
Disabled-[121#]
Enter code 21 and function:
Disabled–[210#]
Enabled-[211#]
Enter code 22 and function:
Disabled–[220#]
Enabled-[221#]
EKB3
EKB3
EKB3

USER MANUAL EKB3 V1.0 7
Disable Call
during Alarm
Disable SMS
during Alarm
User Partition
Afunction disablingcalls to the specied users in the case of analarm.By default, this
functionisdisabled.
AfunctiondisablingSMSmessagedeliverytothespeciedusersinthecaseofalarm.By
default,thisfunctionisdisabled.
Indicatespartitioninwhichuserisassigned.
Enter code 30 and function:
Disabled–[300#]
Enabled-[301#]
Enter code 31 and function:
Disabled–[310#]
Enabled-[311#]
Enter code 59, user number and partition:
User1–[5901x#]
User2–[5902x#]
User3–[5903x#]
User4–[5904x#]
User5–[5905x#]
where x – 0: partition 0, 1: partition 1.
EKB3
EKB3
EKB3

8
iButton Partition
SMS Password
Keyboard Password
IndicatespartitioninwhichiButtonkeyisassigned.
Themain4digitSMSpasswordwhichisusedforsystemcongurationsandcontrolviaSMS
messages.Bydefault,passwordis0000,whichisNECESSARYtochange.
The4digitskeyboardpasswordwhichisusedtoarm/disarmthesystemsecuritywitha
keyboard.Bydefault,thispasswordis1111,whichisrecommendedtochange.Userscan
enterupto10dierentkeyboardpassword.
Enter code 60, iButton number and partition:
iButton1–[6001x#]
iButton2–[6002x#]
iButton3–[6003x#]
iButton4–[6004x#]
iButton5–[6005x#]
where x – 0: partition 0, 1: partition 1.
EKB3
Enter code 14 and new SMS password:
[14xxxx#]
where xxxx – 4 digit SMS password.
Enter code 15, keyboard code number and new keyboard code:
[15xxyyyy#]
where xx – keyboard code number, yyyy – 4 digits new keyboard code.
EKB3
EKB3
4.3.2 Password commands

USER MANUAL EKB3 V1.0 9
Change Keyboard
Password
Add Keyboard
Password
Delete Keyboard
Password
Thisfunctionchangesenteredkeyboardpasswordwithnewone.
Thisfunctionaddsnewkeyboardpassword.
Thisfunctiondeleteskeyboardpassword.
Enter code 63, old keyboard password and
new keyboard password:
[63xxxxyyyy#]
where xxxx – old keyboard password, yyyy - new keyboard password.
Enter code 64 and new keyboard password:
[64xxxx#]
where xxxx – new keyboard password.
Enter code 65 and keyboard password:
[65xxxx#]
where xxxx – keyboard password.
EKB3
EKB3
EKB3
Admin Password The4digitsadministratorpasswordwhichisusedtoconguresystemsettingswithakey-
board.Bydefault,thispasswordis1470,whichisrecommendedtochange.
Enter code 16 and new administrator password:
[16xxxx#]
where xxxx – 4 digits new administrator password.
EKB3

10
4.3.3 Zones commands
ATZ Mode WhenATZmode(zoneduplication)isenabled,thezonenumberisincreasedto12.Byde-
fault,ATZmodeisdisabled.
Enter code 28 and function:
Disabled–[280#]
Enabled-[281#]
EKB3
Arm-Disarm
By Zone
Zone Mode No ATZ
ChoosethezonewhichwillworkinArm-Disarmmode.Withthiszonesecuritysystemcanbe
activated/deactivatedwitha“low”levelimpulsewhichisnotshorterthan3seconds.Thismode
canbesetonlyforonezone.Noresistanceisconnectedwhenusing6zoneconnectiontype
andtheinputmustbeNO(normallyopen).IfATZmodeisenabledtheimpulseistransmitted
throughresistance.IfZ2-Z6zonesareused,theimpulseshouldbetransmittedthrough5.6k
resistance,ifZ7-Z12zones-theimpulseshouldbetransmittedthrough3.3kresistance.
In the environment of ESIM264 Conguration Tool the user must specify the mode
of connected Zones:
• Type1–Normallyopencontactwith5,6KΩendoflineresistor.
• Type2–Normallyclosedcontactwith5,6KΩendoflineresistor.
• Type3–Tamper and5,6KΩendofline resistorand3,3KΩ endoflineresistorwith
normallyclosedcontact.
Enter code 34 and zone number:
Zone1–[3401#]
Zone2–[3402#]
Zone3–[3403#]
…
Zone12-[3412#]
Disabled–[3400#]
EKB3
Enter code 38 and Zone mode:
Type1–[381#]
Type2–[382#]
Type3–[383#]
EKB3
