603355 (TRS22) TRS-22 Stainless Steel Food
Processor 115 V/1p/60Hz
603343 (TRS23) TRS-23 Stainless Steel Food
Processor 115 V/1p/60Hz
603356 (TRS24) TRS-24 Stainless Steel Food
Processor 115 V/1p/60Hz
603358 (TRSU) TRS-24 2 Speed Stainless Steel
Food Processor 208-240 V/3p/60Hz
Item No. ___________________________________
Unit to be Electrolux TRS Food Processor. Electrical
characteristics to be 115 V SINGLE-phase operation with
1 speed at 430 rpm. Electrical characteristics for Dual Speed
TRS-24 to be 208-240 V THREE-phase operation with 2 speed
at 430/870 rpm. Vegetable prep attachment especially
designed for quality, continuous feed slicing, shredding,
grating and julienne and dicing capabilities with 32 different
processing plates. All parts that come into contact with the
food are in Stainless steel or plastic, can be removed for easy
cleaning and are dishwasher safe. IPX5 (IP55) flat panel
touch-control, waterproof panel.
Short Form Specification
Electrolux Professional, Inc.
www.electroluxusa.com/professional
10200 David Taylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401
ITEM # _______________________________________________
MODEL # _____________________________________________
PROJECT NAME # ______________________________________
SIS # _________________________________________________
AIA # _________________________________________________
TRS Food Processor
Main features
• Continuous feed model.
• Power: 1/2 HP—Single phase (TRS-22 models), 2/3 HP—Single phase (TRS-23 models),
1 HP—Single phase (TRS-24 model). 1 HP—Three phase (TRSU model).
• 1 speed: 430 rpm plate speed. 2 speed: 430/870 rpm plate speeds.
•
370 watts ( TRS-22 models), 500 watts ( TRS-23 models), 750 watts ( TRS-24 and
TRSU
models),
• Red OFF, Green ON Buttons
• Compact Design
• Angled Front
• Planetary Drive
• Large Round and Large 3/4 Moon Hopper
• Hopper easily removed for cleaning.
• Magnetic safety system and motor brake. Prevents machine from running when
pusher plate swings away or is open.
• Automatic restart of the machine with the 3/4 Moon shaped pusher in position.
• Delivered with :
• All Stainless steel vegetable prep attachment with a 3/4 Moon Hopper
(L × W × H—6.5″x 3″x 6″) and a cylindrical hopper (diameter 2″).
• Complete selection of 32 blades and disks available.
• Processor has dicing and french fry capablities.
• Dimensions: (H × L × W): 19.75″× 19.7″× 9.9″
• Approx. shipping weight—56 lbs
• ETL electrical and sanitation listed/CETL (Canada).
• NEMA# 5-15P on Single Speed Models and NEMA# L15-20P on Two Speed Model.
• 2 year parts warranty, 1 year labor.
Accessories
• Slicing Blade 9/16″(14 mm) (PNC 653185)
• Slicing Blade 5/16″(8 mm) (PNC 653108)
• Slicing Blade 3/8″(10 mm) (PNC 653110)
• Slicing Blade 1/8″(3 mm) (PNC 653103)
• Slicing Blade 1/4″(6 mm) (PNC 653106)
• Slicing Blade 1/32″(1 mm) (PNC 653101)
• Slicing Blade 1/16″(2 mm) (PNC 653102)
• Julienne Blade 5/32″(4 × 4 mm) (PNC 653154)
• Julienne Blade 1/8″(3 × 3 mm) (PNC 653153)
• Julienne Blade 1/16″(2 × 2 mm) (PNC 653214)
• Dicing Grid (5 × 5 × 5 mm) (PNC 653566)
• Dicing Grid 5/16″(8 × 8 × 8 mm) (PNC 653567)
• Dicing Grid 3/8″(10 × 10 × 10 mm) (PNC 653568)
• Dicing Grid 1/2″(12 × 12 × 12 mm) (PNC 653569)
• Dicing Grid 3/4″(20 × 20 × 20 mm) (PNC 653570)
• Grid for French Fries or Vegetable Sticks 1/4″(6 × 6 × 6 mm) (PNC 653571)
• Grid for French Fries or Vegetable Sticks 5/16″(8 × 8 × 8 mm) (PNC 653572)
• Grid for French Fries or Vegetable Sticks 3/8″(10 × 10 × 10 mm) (PNC 653573)
• Grating Blade for Parmesan and Bread (PNC 653170)
• Grating Blade for Nuts, Chocolate, Bread Crumbs (PNC 653008)
• Grating Blade (XX Course) 23/64″(9 mm) (PNC 653498)
• Grating Blade (Medium) 1/8″(3 mm) (PNC 653163)
• Grating Blade (Fine) 1/16″(2 mm) (PNC 653162)
• Grating Blade (Extra Course) 9/32″(7 mm) (PNC 653167)
• Grating Blade (Course) 5/32″(4 mm) (PNC 653164)
• Curved Serrated Slicing Blade 3/8″(10 mm) (PNC 653511)
• Curved Serrated Slicing Blade 3/16″(5 mm) (PNC 653115)
• Curved Serrated Slicing Blade 1/8″(3 mm) (PNC 653113)
• Curved Serrated Slicing Blade 1/32″(1 mm) (PNC 653111)
• Curved Serrated Slicing Blade 1/16″(2 mm) (PNC 653112)
• Wavy Cut Slicing Blade 1/8″(3 mm) (PNC 653123)
• Wavy Cut Slicing Blade 1/4″(6 mm) (PNC 653126)
• Wavy Cut Slicing Blade 1/16″(2 mm) (PNC 653122)
• Stainless steel Worktable Folding Shelves+Blade Rack (PNC 653283)
• Table with Hotel Pan Polycarbonate Tray (PNC 653180)
TRS Food Processor
TRS Food Processor
5-15P
15-20P with
TRSU model
only

30.71s
12.60s
320 mm
780 mm
7.95s
202 mm
19.76s
502 mm
9.92s
252 mm
19.69s
500 mm
EC
EC = Electrical connection
TRS Series
TRS Food Processor
Supply voltage:
603355 (TRS22) 115 V/1p/60Hz – 6.3A - 1/2HP
603343 (TRS23) 115 V/1p/60Hz – 7.1A - 2/3HP
603356 (TRS24) 115 V/1p/60Hz – 10A - 1HP
603358 (TRSU) 208-240 V/3p/60Hz – 3.2A - 1HP
Electric
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
12-16-10
Key Information
TRS Series
TRS Food Processor
NEW FEATURES
• Wide range of functions: slicing, mincing, grating,
shredding and cutting into chips or cubes of all sizes.
• Plate speed at 430 RPM for precise cutting, slicing and
dicing.
• Large round hopper (85°) allows food of greater dimension
to be processed.
• Feeding arm with integrated long-vegetable hopper (tube
pusher), 60 mm in diameter. Ideal for carrots, zucchini and
cucumbers.
• Base inclined at 20° provides easy loading and discharging.
• High discharge zone permits the use of deep GN containers
(up to 8 inches in height).
• Feeding arm and hopper are made entirely in Stainless steel.
Aluminium motor housing.
• Plates and ejector may be removed in seconds by opening
the cover.
• All parts that come into contact with the food are in Stainless
steel or plastic, can be removed for easy cleaning and are
dishwasher safe.
• IPX5 (IP55) flat panel touch-control, waterproof panel.
• Green button indicates ON, Red button indicates OFF.
• Pulse control for precise slicing.
• Asynchronous industrial motor with no brushes for high
reliability and quiet functioning. Stainless steel motor shaft.
• Two separate safety switches stop the machine in order to
protect the operator from potentially dangerous conditions.
• IP24 throughout entire machine.
Front View
Top View
Side View
