Elektral Tru-VEND Midi Buffet STD Operating instructions

Midi Buffet STD®
USER & MAINTENANCE
MANUAL
Version: 18.04
“She sells, You earn!..®”
www.elektral.com.tr
Headquarters & FACTORIES:
Elektral ® Elektromekanik San. ve Tic. A.S.
Izmir Ataturk Industrial Zone
M.K. Ataturk Blv.23 Cigli
35620 İzmir-TR
Phone : [phone]
Fax : [phone]
E-mail : [email protected].tr

2
CONTENTS
PAGE
INTRODUCTION
OPERATION and SAFETY WARNINGS
1. GENERAL DESCRIPTION
2. MAIN UNITS
2.1 Product Trays
2.2 Control Panel
2.2.1 Capacitive Touch Keypad
2.2.2 Graphical LCD Screen
2.2.3 Payment Systems (Optional)
2.2.3.1 Coin Selector
2.2.3.2 Change Giver
2.2.3.3 Bill Validator
2.2.3.4 Prepaid Card System (Cashless Payment Device)
2.3 Coin Return Push Button
2.4. Coin Entry Slot
2.5 Coin Return Chute
2.6. Cash Box
2.7 Electronic Modules
3. VENDING MACHINE SAFETY
4. PROGRAMMING
4.1 Main Menus
4.2 Menus
4.2.1 Settings Main Menu
4.2.1.1. Payment System
4.2.1.1.1 Serial Protocol
4.2.1.1.2 MDB Settings
4.2.1.1.3 EXECUTIVE Settings
4.2.1.1.4 CCTALK Settings (Optional)
4.2.1.1.5 MDB Settings (Optional)
4.2.1.1.6 PARALLEL Settings (Optional)
4.2.1.2 IR Product Sensor
4.2.1.3 Cooling Unit (Optional)
4.2.1.4 Date-Time Settings
5
6
8
9
10
11
11
11
11
12
12
12
12
13
13
13
13
13
14
14
15
15
16
16
16
16
17
17
17
17
17
18
18

3
4.2.1.5 Language Setting
4.2.1.6 Change Password
4.2.1.7 Illumination Settings
4.2.1.7.1 Illumınation Power
4.2.1.7.2 LED Settings
4.2.1.8. Authorization
4.2.1.9 Factory Settings
4.2.2 Statistics Main Menu
4.2.2.1 Sale Counter
4.2.2.2 Cash Counter
4.2.2.3 Errors
4.2.2.4 Reset
4.2.2.5 Get Report (Optional
4.2.3 Prices Main Menu
4.2.3.1 Price Settings
4.2.3.2 Discount (Optional)
4.2.4 Machine Test Main Menu
4.2.4.1 Motor Control
4.2.4.2 IR Control
4.2.4.3 Motor Status
4.2.4.4 Payment System
4.2.4.5 Touch board
4.2.4.6. Relay Control
4.2.5 Accessories Main Menu
4.2.5.1. Alarm
4.2.5.2 GSM/GPRS (Optional
4.2.5.3 Impact Sensor
5. TECHNICAL SPECIFICATIONS and ENERGY EFFICIENCY
6. TRANSPORTATION and INSTALLATION
7. OPERATION OF MİDİ BUFFET STD
8. INSTALLATION and CLEANING
9. OPTIONAL UNITS
9.1 Cooling Unit
9.2 Additional Tray / Canned Drink Dispenser
9.3 GSM/GPRS Remote Access
18
18
18
18
19
19
19
19
19
19
20
21
21
21
21
21
21
21
21
21
21
21
22
22
22
22
22
22
22
24
24
24
24
25
25

4
9.4 Delivery Slot Lid
10. TROUBLESHOOTING
10.1 Warnings
10.2 Frequently Asked Questions
10.2.1 General Questions
10.2.2 Operational Questions
11. MENU TREE
12. SERVICE CENTRE and CERTIFICATE OF WARRANTY
25
26
26
26
26
26
27
29

5
INTRODUCTION
Dear User,
Thank you for purchasing the Midi Buffet STD® vending machine, a product manufactured by
ELEKTRAL. As a company developing integrated production, our quality certified production has
continued since 1978 based on high technology. This integration can be broadly described as R&D,
Electronics, Electro-mechanics, Production Lines, Mechanics Workshop, Moulding Workshop, Plastic
Injection and Vacuum Forming Group. With T.R. State Planning Organization's various incentives,
the factory has reached an approximately 20,000 m2 production area with the capability of making
various electronic machines and components for professional use. Most of our machines have been
produced for the first time in our fatherland. Starting with Germany, our company is
technologically cooperating in terms of production, representation and OEM production with the
sector’s leading companies from UAE, Bulgaria, India, Great Britain, Iran, Israel etc. We have
direct or indirect exports to countries in Europe, Asia, America, Africa. Furthermore, to expand our
direct sale markets in foreign countries our intensive works and exhibition activities continue
uninterruptedly. As a result of our rapidly growing export potential, our company has been
awarded with a first place prize in 2004, during "Rising stars of e-commerce in Turkey"
competition. The same year we were awarded with the “25’th Anniversary Award of EBSO (Aegean
Area Chamber of Industry), “The Chamber of Industry, Innovation, Employment” with continuous
R&D projects being supported by TUBITAK (Turkish Scientific Research Council). In 2011 Istanbul
Chamber of Industry has chosen our company as "INNOVATION FINALISTS". In the year 2012,
with its innovative Vending Machine project, Elektral has been awarded as an “TET (Turkish
Electro Technology) R&D Project Market Finalist” by the Ministry of Economy, Turkish Export
Assembly and IMMIB (Istanbul Mining and Metal Exporters Union). Another award won by Elektral
is “The year 2013 First Rank in Innovation” organised by IAOSB (Izmir Ataturk Industrial Zone)-
Ege University. Believing that real growth target is to be achieved with a global industrial
understanding and a global move, Elektral is motivating all its employees with this understanding
and continues rapidly with an intensive R&D work to reach determined goals.
Tru-VEND® vending machines have been designed and produced to provide more spare time to
its owners. They ease your life in various situations with multipurpose and practical use. Our
products provide you profit and comfort for 24 hours continuously, loyal to the owner, with no
employee costs. Please note that as for all industrial machines, its necessary to periodically check
and maintain your machine. Please use the machine as recommended in this manual.
Elektral Products are produced in environmental friendly facilities,
causing no harm to the nature and living creatures.
Made in Turkey
Alteration rights reserved
No claims can be accepted by our firm
regarding the applications of this instrument
from second or third parties.
All rights Reserved

6
OPERATION AND SAFETY WARNING
Procedures & Safety Warnings before using the Midi Buffet STD ®
Technical specifications of the Midi Buffet STD®
Installation of the Midi Buffet STD®
Midi Buffet STD®Programming and further procedures
The arrow-end lightning symbol inside the
equilateral triangle informs that in the context of
the product, there is enough amount of ‘not
insulated’ dangerous voltage to cause an electric
shock.
The exclamation mark inside the equilateral triangle
informs the user that there are important instructions of
usage and information inside the booklets given with the
equipment.

7
Midi Buffet STD®BEFORE USE AND SAFETY WARNINGS
Midi Buffet STD® Tru-VEND Vending Machine is secured by three
electronic PIN codes and three mechanic locks which only allow the owner
to operate the machine. Please do not share your PIN CODE. If you forget or
lose the code, get in contact with our factory.
Midi Buffet STD® Do not wet the machine! Please unplug from the mains
power and use only a damp cloth to clean the vending machine.
Only use the vending machine on Earthed Electrical Supply.
Please carefully read the chapters where you see this Warning Sign in the
User’s Manual.
With Cooling: 220 VAC ±%10 50 Hz, ±
Without Cooling: 90-260 V AC 50-60 Hz, is designed to operate between
given electrical limitations.
WARNING: Please follow the instructions given in the User’s Manual.
Incorrect usage can cause damage to the Vending Machine and the
environment.

8
1. GENERAL DESCRIPTION
The Vending Machine that you have chosen has been produced by our factory using high
technology systems in parallel with other developing technologies and modern aesthetic design
providing versatile usage. Tru-VEND® Vending Machines can be used in all public areas such as
hotels, factories, hospitals, restaurants, clinics, cinemas, bus terminals, gas stations, doctors &
lawyer’s offices, shopping malls, etc. Backwards traceability is also possible on the performed
machine modifications by the serial number on each machine.
International norms, In conformity with CE Norms,
produced under ISO 9001:2008 QMS
Fully Microprocessor Controlled MDB Interface, high
storage capacity EEPROM
Full-View Multi-Selection Snacks Vending Machine
with Large Double Glazed LOW E Glass Front
Standard 4 Trays, 28 Selections (~220 - 300
Products Storage Capacity)
Easy to Load Snacks vending machine
Large advertisement panel and Ad Space on Both
Sides
User Friendly Interface with Graphical LCD Display
Easy Different Tray and/or Selection Pricing Feature
Decorative 3x4 User Friendly Capacitive Touch
Keypad
Integrated Coin Return Button
BITE (Built-in Test Equipment) automatically Fixing
problems and Warning Messages on Graphical LCD
Automatic Currency Recognition as per installed
Payment System
Easy firmware update with Bootloader
Time/Date Function Enabling Timetable Pricing
(Optional)
Double Electronic Thermostat controlled energy
efficient cooling feature provides long product life
Silent and Vibration Free Operation
Swinging and counterbalanced Self-Locking product dispensing slot
Ensures reliable operation with IR Product Sensor
Switch Controlled Menu Entry with Digital PIN Code Protection and two level Password (Owner-
Operator)
Two Stage ALARM against Vandalism. Audio Alarm against unauthorized door opening and impact
sensor
Highly corrosion-resistant production material
2 Years Manufacturer’s Warranty as per our “General Conditions of Sales, Delivery & Warranty”
MDB-Executive-Parallel protocols are available. Payment systems such as Banknote Reader,
Change Giver, Coin Selector and Cashless Payment Mechanism are supported.
All status, parameters and alarm input / output of the cooling system can be monitored via a
Data Transfer module (Optional).
Can be controlled via RS 232 interface.
Enhanced Motor Control System enabling detailed functional control
IR product sensors to control product delivery
Insulated products Storage Department with automatically opening and closing door during
product delivery
Ultra-Cool (4 °C) refrigeration unit

9
2. MAIN UNITS
Front View
Control Panel Door Open Control Panel Door Closed

10
Right Side View
2.1 Product Trays
Filling up the Vending Machine and Placing the Products to the Trays
7
7
7
7
7
7
7
7
7
7
7
7
7
7
4
4
4
4
4
4
4
4
4
4
4
4
4
4
The vending machine has 4 Trays (+1 optional). In this Snacks Vending Machine to avoid damage,
place any breakable and heavy products into the trays close to the dispense compartment
(chamber).

11
To place products in to the Trays:
Open the vending machine front door to be at 180° angle with the machine. Gently lift the tray
upwards and pull.
Adjust the spiral to drop the product easily by pulling the spiral forward, turn and let go for the
proper start position.
Start loading the products from the inner spiral slots for your convenience.
Place only one product in each slot.
The total weight capacity of a tray is ~35 kg (depending on the product loading/stacking
pattern in the tray)
The tray will stay on hold once it reaches the loading position with the help of its wheeled self-
locking shelf assembly.
There are two position trays for easy product loading.
However, in loading position you may load max. 7 kg heavy products and rest should be loaded
when the tray is pushed back into its place. For this reason, starting to load the inner slots first is
essential.
It is possible to change the spiral steps, sizes and loading capacity, depending on the available
spiral types (maximum number of trays can be 5).
WARNING: Placing the products incorrectly may
cause failure of dispensing products.
WARNING: When pulling the trays out, make sure
the front door is opened with a 180° angle.
Otherwise the Rubber Front Door Gasket can be
damaged.
2.2 Control Panel
All operational controls can be followed on the Graphical LCD Screen,
also Payment Systems and Touchpad Keypad are installed on this
panel.
2.2.1 Capacitive Touch Keypad
This is used for selecting products and vending machine settings,
explained in details under programming section. (IP 65 Weather proof
Anti-vandalism Metal Keypad is Optional.)
2.2.2 Graphical LCD Screen
All operations are being displayed on the Graphic Liquid Crystal
Display-GLCD for easy usage. Will be referred as GLCD thereafter.
2.2.3 Payment System (Optional)
Coin Selector accepts pre-defined coins for the payment processing. It
recognizes the domestic currency which had been programmed. The
mechanism will not accept the currency which has not been defined
and will be returned through the Coin Return Chute.

12
The system has Automatic Currency Recognition feature as per the assembled Payment System.
The Vending Machine which is eligible for MDB protocol can be equipped with Change Giver, Coin
Selector, Bill Validator and/or a combination of Bill Validator and Change Giver, Cashless Payment
Systems as per customers’ choice.
Please note that the Payment System is Optional and not all Midi Buffet STD Vending Machines are
equipped with a Payment System.
2.2.3.1 Coin Selector
Accepts coins only. This equipment can accept different types of coins. There is no Change
Function.
2.2.3.2 Change Giver
There are 5 - 6 tubes (may change as per the ordered model) where the coins are being collected
for change giving. The coins of the main currency defined to the device are being collected in
these tubes to be used later for change giving. Once the tubes are full, coins are sent to the Cash
Box under the Change Giver Unit automatically. The coins are collected in the Cash Box.
Please check Chapter 4.2.1.1 for the settings of the Change Giver Unit.
2.2.3.3 Bill Validator
The bill validator accepts only the pre-defined banknotes and proceeds with the payment process.
It recognizes the currency bills which had been programmed and returns the unidentified or
counterfeit banknotes. It can be used at the same time with either MDB Supporting Change Giver
or Coin Selector.
2.2.3.4 Prepaid Card System (Cashless Payment Device)
This application enables the customers to shop without using Money. A Prepaid Card is used
instead. This cashless system enables the customers to load credit to their cards and use their
credits for shopping using the Vending Machine. When placed into its slot on the Vending Machine,
the available credit of the User is displayed on the GLCD. Customers may easily load credits into
their cards by inserting Money and the shopping value is being deducted from their credits.

13
2.3 Coin Return Push Button
This button is used for getting the change after shopping. After pressing this
button change can be collected from the Coin Return Chute.
2.4 Coin Entry Slot
This entry slot is used for inserting coins into Vending Machine. Coins are being
placed into the slot then simply being pushed upwards.
Inserted coin value can be seen on the screen. If the inserted coin is not defined
or is an imitation then the coin drops down to the Coin Return Chute and is not
accepted.
2.5 Coin Return Chute
This chute is for the change and/or coins which cannot be validated.
Coins can be collected after falling into the return chute.
2.6 Cash Box
Cash Box is where accepted coins are collected (excess money over tubes). For
increased security the cash box has a padlock.
The cash box has to be checked and emptied periodically or the cash box can be
filled up with coins and coins may drop around which may cause problems.
2.7 Electronic Modules
Midi Buffet STD is fully microprocessor controlled and the electronic modules in
use are as follows:
a) Power distribution board electronic module: This module is used for distributing
energy to the Vending Machine. With its two fuse control this unit helps preventing possible
electrical problems which may be caused by other electronic modules or the optional cooling unit
and it provides increased safety.
b) Power Supply Module: This module is to provide DC Voltage.
c) Main Electronic Module: All functions of the Midi Buffet STD Vending Machine are being
controlled by this Module.
d) Capacitive Touchpad Keypad
e) Graphical LCD Screen
f) IR Product Sensor: This module is used for checking the Proper Physical Vending Process. If
there is no real vend then the credit will remain so that another product can be selected or the
credit can be taken. (Chapter 4.2.1.2)
g) Illumination electronic module.
Please contact our Technical Service for any failures on electronic modules.

14
www.elektral.com.tr
READY TO OPERATE
INSERT COIN/BILL
4° C DATE
ŞİFRE DEĞİŞTİRME
MAIN MENU
SETTINGS
STATISTICS
PRICES
MACHINE TEST
ACCESSORIES
DEVICE INFO
MAIN MENU
SETTINGS
STATISTICS
PRICES
MACHINE TEST
ACCESSORIES
DEVICE INFO
PASSWORD
[****]
3. VENDING MACHINE SAFETY
There are many security precautions against theft and other vandalism possibilities with the Midi
Buffet STD®.
The Cabinet and the Low-E Glass Front have been designed with maximum safety using robust
production materials. There are Security Locks on the Vending Machine and the Cash box.
There are three security passwords as electronic security precautions.
a) Alarm Password: This password has to be entered prior to opening the door of the Midi
Buffet STD. When opened without entering password, the Midi Buffet STD will give a 120db
audio alarm. After 10 seconds the front door is closed, the alarm is activated automatically.
Default alarm password is “1234 ”.
b) Administrator Password: This admin level password enables Access to all settings of the
Midi Buffet STD. Default administrative password is “8888 ”.
c) User Password: This level menu entry enables Access to menus which are authorized by
the administrator. (Chapter 4.2.1.8) . Default User Password is
“ 0000 ”.
Note: The Administrator Password and the User Password cannot be the same.
4. PROGRAMMING
All programming settings of the Midi Buffet STD®can be done using the Touchpad
Keypad on the Control Panel. Keypad buttons are as follows;
XEXIT/NO
√ SAVE/YES/SELECT
8 Up Arrow to Scroll Up
0 Down Arrow to Scroll Down
7To copy the selected value in some menus i.e., Price
Settings
9To Paste the copied Value
Press the Red Button on the Mother Board to enter into
the Menu (Shown in the Right side view of the VM)
Number Keys 1 to 9 are used for entering values.
To silence the alarm enter 1234 default alarm password.
To enter programming menu press ‘8888’ in sequence.
Open the front door of the Midi Buffet STD and open the
protective door to access the main electronic board. Press
the button on the Main Board (BUT1) to enter the menu.
Enter the ‘Administrator Password’ or the ‘User Password’
using the keypad.
SCROLL IN THE MENU Using (8) UP and (0) DOWN keys
and Select the desired Menu by (√) SELECT.

15
SETTINGS
VALIDATORS
IR SENSOR
COOLING UNIT
DATE-TIME
LANGUAGE SETTING
CHANGE PASSWORD
MACHINE TEST
MOTOR CONTROL
IR CONTROL
MOTOR STATUS
VALIDATORS
TOUCHBOARD
RELAY CONTROL
ACCESSORIES
ALARM
BILL
GSM/GPRS
TILT SENSOR
STATISTICS
SALE COUNTER
CASH COUNTER
ERRORS
RESET
GET REPORT
PRICES
PRICE SETTINGS
EXCHANGE OF RATE
DISCOUNT
4.1 Main Menus
Settings: Selection of Payment System, Date-Time
Settings, Cooling Unit Settings, Password Settings etc.
Settings can be done in this menu.
Statistics: All statistical information available can be seen
inside this menu.
Price Settings: This menu is for setting Prices, Currency
Settings and Discount Rates.
Machine Test: This menu is for testing the hardware
equipped on the Vending Machine (motors, IR Product
Sensor etc.).
Accessories: This menu is for the settings of Alarm,
Impact Sensor and GSM/GPRS etc. accessories available.
4.2 Menus
To enter sub menus, you need to enter Main Menus and scroll using SCROLL Keys. Find the Menu
you wish to proceed and press (√) SELECT.To proceed with entering new values press (√)
SELECT button to save the changes press (√) SELECT again or Exit with (X)button.

16
VALIDATORS
SERIAL PROTOCOL
MDB SETTINGS
EXECUTIVE SETTINGS
CCTALK SETTINGS
Imp MDB SETTINGS
PARALLEL SETTINGS
SERIAL PROTOCOL
MDB
EXECUTIVE
CCTALK
impMDB
PARALLEL
MDB SETTINGS
MAX. WAIT 60
MAX CHANGE 20.00
MAX. ACCEPT 20
ERASE CREDIT
FREE VEND
CHANGE BACK
4.2.1 Settings Main Menu
4.2.1.1 Payment System
WARNING: The standard Coin Mechanisms installed on the Midi Buffet
STD®are compatible with MDB protocol. If there will be another Coin
Mechanism in use with the following protocols; EXECUTIVE, PARALEL and
CCTALK the compatible Coin Mechanisms should be installed and the
Protocol has to be selected from the Menu. If by mistake a different protocol
(other than MDB) is selected from the Menu, the Midi Buffet STD®will not
accept any money and will return all.
This menu is used to change the standard settings of the
payment system.
4.2.1.1.1 Serial Protocol
This menu is used for selecting the Payment System in
use.
Use UP (8) and DOWN (0) Scroll Keys and (√) SELECT.
4.2.1.1.2 MDB Settings
This menu is for MDB Payment System Settings.
Maximum Waiting: Waiting Period after money
insertion. After threshold period the value on the LCD
resets to Zero the money gets collected inside the
Vending Machine.
Maximum Change: This menu is to set the Maximum
Change Value.
Erase Credit: This parameter is used to define whether to reset or not to reset the Credit Value
after a Certain Waiting Period upon money insertion. Full bracket (X) means this feature is active.
Free Vend: This feature enables free distribution of products with prices set to ‘0’. Full bracket (X)
means this feature is active.
Change Back: This parameter is used for activating or deactivating the Change Function. Full
bracket (X) means this feature is active.
Manual Dispense: This parameter is used to activate or deactivate Manual Dispensing of the
Coins in the tubes using the buttons on the Change Giver unit. Full bracket (X) means this feature
is active.

17
SETTINGS
VALIDATORS
IR SENSOR
COOLING UNIT
DATE-TIME
LANGUAGE SETTING
CHANGE PASSWORD
IR SENSOR STATUS
OFF
Free Change: This parameter is used to activate or deactivate the Change Function without
purchasing any product from the Vending Machine. Full bracket (X) means this feature is active.
Automatic Change: This feature enables automatic Change without the need to press Coin
Return Push Button. Full bracket (X) means this feature is active.
Big Value Mode: This mode is for some currencies which have very little purchase value and the
Note Values are very high i.e. 1000 etc. to display a Product Price of 12000 in Big Value Mode 12k
is used in short.
Coin XX: This parameter is to set the acceptance status of the nr. XX Coin. Full bracket ( X)
means this feature is active.
Bill XX: This parameter is to set the acceptance status of the nr. XX Bill. Full bracket (X) means
this feature is active.
4.2.1.1.3 EXECUTIVE Settings
This menu is for EXECUTIVE Payment System Settings.
Price Holding: This parameter displays the Status of Price Holding function. Full bracket (X)
means this feature is active.
Free Vend: This feature enables free distribution of products with prices set to ‘0’. Full bracket (X)
means this feature is active.
Product (XX): When in Price Holding operation mode these values become active. This is to
mention that Nr. XX product belongs to Nr. XX Value in sequence.
4.2.1.1.4 CCTALK Settings (Optional)
This menu is for CCTALK payment system settings.
4.2.1.1.5 Imp MDB Settings (Optional)
This menu is for MDB payment system settings.
4.2.1.1.6 PARALLEL Settings (Optional)
This menu is for PARALLEL payment system settings.
4.2.1.2 IR Product Sensor
This menu is to activate or deactivate the IR Product Sensor.
IR Product Sensor checks if the product is delivered to the
customer or not.
WARNING: If the IR Sensor is deactivated, the vending machine will not
be able to check product delivery conditions and the presence or lack of
products in the machine trays.
If the IR product sensor determines that a product is not delivered, the
related selection (Spiral) is deactivated and customer credit remains
active on Graphic LCD for another vend.
ON

18
DATE - TIME
13:44
2012.06.08
FRIDAY
COOLING UNIT
UNIT : ON
SET : 8 ºC
ECO-MOD : ON
SET : 10 ºC
ECO-TIME : 22:00 –07:00
LANGUAGE SETTING
TURKISH
ENGLISH
GERMAN
SPANISH
CHANGE PASSWORD
ADMIN PASSWORD
USER PASSWORD
ALARM PASSWORD
ILLUMINATION
If there has not been a product dispense upon 5 vends in a row, the IR
product sensor turns itself off. The Vending Machine operates without IR
product sensor. It can be re-activated from the menu again.
4.2.1.3 Cooling Unit
This menu is for Cooling Unit Settings. Using the menu
you may activate and/or deactivate the Cooling System,
proceed to temperature settings and the Economy-Mode
Operation Settings for certain periods.
4.2.1.4 Date-Time Settings
This menu is to set Time and Date. Press (√) SELECT
button to enter value settings. The values can be entered
in sequence. Wrong entries are not accepted. Weekday is
automatic as per Date Settings.
4.2.1.5 Language Setting
This menu is for Language Selection. Desired Language
can be highlighted and selected with button (√) SELECT.
Languages other than Turkish and English are Optional.
4.2.1.6 Change Password
Move onto the Password you want to change using UP
and DOWN arrow Keys and press (√) SELECT. First, you
need to enter the old password. If the old password is
correct then you may proceed next and enter the New
Password. For approval you need to re-enter the New
Password.
Admin Password: This password enables Access to all
settings of the Midi Buffet STD. Default administrative password is “8888”.
User Password: This level password entry enables Access to menus which are authorized by the
administrator. Default User Password is “0000” and cannot be the same with the Admin
Password. Please check Chapter 4.2.1.8 Authorization.
Alarm Password: This password has to be entered prior to opening the door of the Midi Buffet
STD. When opened without entering password, the Midi Buffet STD gives a 120db audio alarm.
The alarm is being activated automatically after 10 seconds the front door is closed. Default alarm
password is “1234”.
4.2.1.7 Illumination
4.2.1.7.1 Illumınation Power
This menu is for adjusting the Power of LED Illumination
of the Low-E Glass Front.
Adjustment can be made using UP (8) and DOWN (0)
Buttons.

19
SALE COUNTER
PROD. (11): 0 pcs.
PROD. (12): 1 pcs.
PROD. (13): 9 pcs.
PROD. (14): 3 pcs.
PROD. (15): 4 pcs.
PROD. (16): 5 pcs.
CASH COUNTER
TOTAL VM REVENUE 158,25 EUR
NET REVENUE
GROSS REVENUE
DISCOUNT SALES
TOTAL DISCOUNTS
SETTİNGS
DATE
LANGUAGAE
CHAN
LIGG
DEFAULT SETTINGS
LED SETTINGS
ILL –MOD: ON
ECO - MOD: ON
ECO - MOD: 20:00 –07:00
4.2.1.7.2 LED Settings
Using the LED settings, economy mode can be activated
to save energy. During the economy mode lighting is
turned off for the adjusted time limit.
4.2.1.8 Authorization
This menu is to set the Access limitations of the User
Password by the administrator.
Full bracket (X) means this feature is active.
4.2.1.9 Factory Settings
4.2.2 Statistics Main Menu
4.2.2.1 Sale Counter
This menu displays the total number of products sold
after the last reset.
Each and every Product Selection can be chosen and
Reset to Zero.
4.2.2.2 Cash Counter
This menu displays the total amount of cash in defined
currency.
Total VM Revenue: Displays the Total Cash collected by
the VM. This Value cannot be reset.
Net Revenue: This is the Net Amount collected by the
VM. This value can be reset.
Gross Revenue: This value is for the total amount of sales excluding discount amount of
Discount Sales. This value can be reset.
Discount Sales: This value displays the total revenue generated whilst discount period. This
value can be reset.
Total Discounts: This value displays the total discounts applied. This value can be reset.
Overpaid: This value is to display remaining (overpaid) credit reset in the machine. This value can
be reset.
Normal Sales: This value displays the sales amount without any discounts applied. This value can
be reset.
Cashless Total: This value displays the sales amount without paid by Cashless Payment System.
This value can be reset.
Cash Box Total: This value displays the total amount of money collected in the cash box. VM
equipped with Change Giver first collects the coins into its tubes then fills up the Cash Box. This
value can be reset.
RETUN TO DEFAULT
SETTINGS?
YES NO

20
ERRORS
ERROR (01): 052-11
06.09.10 12:10 (3)
ERROR (02): 068-02
ERROR (03): 000-00
ERROR (04): 000-00
ERROR (05): 000-00
Stacker Total : This value displays the amount of Banknotes Collected in the Bill Validator
Stacker.
Tubes Total: This value displays the amount of Coins in Change Giver Tubes.
4.2.2.3 Errors
Pre-defined Error Codes are as mentioned hereunder;
Parameters shown on GLCD are to display current settings
of the Midi Buffet STD®as follows;
1 Door Open
2 IR Product Sensor Off
3 Alarm Off
4 Impact Sensor Off
5 No Change
6 IR Sensor Problem Occurred
7 Motor Error Occurred
8 Machined Reported an Error
#
Change Giver Error Codes
#
Other Error Codes
01-003
No Credit1
50
51
Motor Error 3
Extreme Current on Motor
01-004
Defective Tube Sensor1
52
Motor Error 1
01-005
Double Arrival1
53
Motor Error 2
01-006
Acceptor Unplugged2
54
Heat Sensor Error
01-007
Tube Jam1
56
EEPROM Error
01-008
ROM checksum error1
58
Flash Error
01-009
Coin Routing Error1
60
Keypad Error
01-012
Coin Jam1
62
RTC Error
01-013
Possible Credited Coin Removal1
64
IR Error 1
65
IR Error 2
#
Bill Validator Errors
66
IR Error 3
02-021
Defective Motor3
67
IR Error 4
02-22
Sensor Problem3
68
MDB Communication Error
02-24
ROM Checksum Error3
70
WDT Reset Error
02-25
Validator Jammed3
71
Brownout Reset Error
02-27
Bill Removed1
74
Address Error
02-28
Cash Box out of position3
02-30
Invalid Escrow request1
02-32
Possible Credited Bill Removal1
76 Trap Conflict
78 Change Giving Error 1
79 Change Giving Error `2
83 Motor Short Circuit
84 Tray Short Circuit
86 High Side Problem
9X Change Giver Advanced
Malfunctions
