Wittenborg FB 7100 User manual

Drink Vending Machine
FB 7100
Service Manual
75521400
January, 2005

© Copyright - All rights reserved
This manual is protected by a copyright. No part of this manual may be copied, reproduced, translated
or processed, copied or distributed by any form of electronic means without our prior written concent.
Wittenborg cannot take over any liability for errors and faults in manuals, brochures and other printed
matter, Wittenborg reserve the right to change their products without prior notice.
© Published by Wittenborg A/S, Odense, Denmark
January 2005

© 2005 Wittenborg A/S, Odense, Denmark
Preface and Safety Instructions 1
Installation / Putting into Operation 2
Faults 3
Programming 4
Functions 5
Water System A
Brewing System B
Dosing system C
Product Delivery D
Cooling System (Not available) F
Housing / Cabinet G
Power Supply Unit and Control K
External options (Not available) L
Payment Systems P
Preventive Maintenance 6
Service Procedures 7
Technical Information 8
Modification Instructions 9
Spare Parts List 10
5

© 2005 Wittenborg A/S, Odense, Denmark

Service Manual FB 7100 Preface and safety instructions
January, 2005 1 - 1
Table of contents
Preface and safety instructions 1
Preface / How to use this manual 1.1
General 1.1.1
Structure of the manual 1.1.2
Definition of options and accessories 1.1.3
Safety instructions 1.2
Various safety instructions 1.2.1

Service Manual FB 7100 Preface and safety instructions
1 - 2 January, 2005
,

Service Manual FB 7100 Preface and safety instructions
January, 2005 1 - 3
1 Preface and safety instructions
1.1 Preface / how to use this manual
1.1.1 General
Introduction This service manual is intended for trained service technicians, who have
gone through the product training courses of this machine.
Purpose The purpose of this service manual is to learn about the technical details of
the machine.
It can be considered and used as a reference manual.
1.1.2 Structurre of the manual
Chapters The service manual is divided into chapters, numbered from 1 to 10.
Sections Chapters may be divided into sections.
Example:
Chapter 5 Function contains nine subsections, each representing a specific
function in the machine.
Subsection Each section is divided into subsections.
Each subsection has the same build-up, see example on next page.

Service Manual FB 7100 Preface and safety instructions
1 - 4 January, 2005
Example The Brewing system serves as an example and it can be found under:
Service informa-
tion
As the vending machine is subject to changes, consecutively numbered
service messages (named ‘technical information’) will inform you on these
changes. The service messages are to be filed as chapter 8 in this service
manual.
General note The concept of this manual is designed in such a way that it is valid for dif-
ferent types of machines. If a machine is not equipped with a certain com-
ponent, the corresponding section is mentioned, but will be blank. The
complete numbering has not been changed. Some of the subsections, e.g.
the one on *External Options’, can be completed by the service technician
with respect to specific countries if required.
Chapter 5 Functions
Section B Brewing system
Subsection 1 Adjustments
-This subsection describes all possible adjustments
for this section, regarding timing, calibration, etc.
2 (Dis-)assemblies
-This subsection explains in detail how a certain
part, belonging to this section, has to be
assembled, disassembled or replaced.
3 Functional description
-This subsection explains in detail how a certain
system in the machine works and how the different
parts in the system interact.
4 Electrical diagrams
-Here you can find a description of electrical inputs
and outputs of the Brewing system.
5 Technical specifications
-The technical specifications for the Brewing
system, described in this section are given here.
6 Overview of options
-Available options, specially for the Brewing system.
7 Accessories
-Accessories to the Brewing system.

Service Manual FB 7100 Preface and safety instructions
January, 2005 1 - 5
1.1.3 Definitions of options and accessories
Definition Options and accessories are also described in this manual. They are de-
fined as follows:
Definition Description
Options Various options result in different versions, types or models.
Accessories Parts that a Service Technician can build into your machine to
enable new or different options for your machine.
External
options
Parts that can provide special functions or features for your
machine, without need to build them into the machine.

Service Manual FB 7100 Preface and safety instructions
1 - 6 January, 2005
1.2 Safety instructions
Introduction This subsection is intended as an overview of the instructions and warnings
used in this manual, and which you must observe.
The following general safety precautions apply to the operation and main-
tenance of the machine and must always be observed. Non-observance of
these instructions or any other safety precautions mentioned in this manual
could impair the safety standards of the coffee machine.
Hazard intensity
level
There are three levels of hazard intensity identified by signal words -
Danger, Warning and Caution. The level of hazard is determined by the
following definitions:
General instruc-
tions
The instructions in this manual must always be followed. Non-observance
can lead to dangerous situations. The manufacturer cannot be held respon-
sible for damage, resulting from not following prescribed procedures.
The technicians must have read the service manual and the operator man-
ual thoroughly, and understood both, before they can install the machine
and put it into operation. The service technician must hand over and ex-
plain the operator manual to the customer.
Installation, start-up, programming and, if required, repair of the machine
must be performed by trained and authorised service technijcians only.
When the customer sells the vending machine to another party, he must
also hand over the complete documentation, delivered with the machine.
Danger -Immediate hazard will result in severe personal injury or
death.
Warning -Hazards of unsafe practices which could result in severe
personal injury or death.
Caution -Hazards of unsafe practices which could result in minor
personal injury or product or property damage.

Service Manual FB 7100 Preface and safety instructions
January, 2005 1 - 7
1.2.1 Various safety instructions
Introduction Below is listed the instructions divided into the hazard intensity levels
•Danger
•Warning
•Caution
Danger •Never insert the power supply plug of the machine in a wet or damp
socket. The plug itself must not be wet or damp either. Also never
insert or remove the plug from the socket with wet hands.
•Safety devices must not be bridged or put out of function.
•If the power supply cord of the machine is damaged, it must be
replaced by trained service technicians.
•Before cleaning the vending machine, ensure that it is switched off.
Warning •The vending machine must be connected to the mains in accordance
with all official regulations and local regulations laid down by the
electricity and water companies.
•Ensure that the supply voltage corresponds to the voltage indicated on
the rating plate which is located on the rear wall of the machine.
•The vending machine must be connected to an electric circuit which is
secured by an extra fuse. The connection to a supply with an integrated
fault current safety switch is recommended. If missing, we recommend
to install a fault current safety switch. The connection must be made
using an earthed safety plug socket complying with valid instructions.
•Check the drinking water quality prior to installation.
•The vending machine is suitable for indoor use only.
•Use only genuine spare parts when replacing components and / or
carrying out work on the vending machine, otherwise the manufacturer
will accept no liablility in the event of damage.
•Rinse the machine before putting it into operation.
•The beverages delivered by the machine are hot! In order to prevent
scalds, hands (and/or other parts of the body) must be kept out of the
drink delivery area during drink preparation and function tests.
•Keep children away from the machine!
•Carry out a functional test of the machine when the work is completed.
•Door switch:
When the door is opened, a special switch ensures that there is no
access to electrical or moving parts.
Any operation requiring the machine to be energized with the door
opened must be carried out exclusively by qualified technicians
informed about the specific risks of such situation.
The machine may be energized by qualified technicians by inserting

Service Manual FB 7100 Preface and safety instructions
1 - 8 January, 2005
the yellow service key into the door switch.
Before starting any maintenance or repair of energized or moving
parts, the machine must always be disconnected at the mains plug.
•When the yellow service key is inserted in the slot of the door key, the
machine is re-energized.
The door can be closed only after removing the key from the door
switch.
If power is turned on, be careful not to touch moving parts and
electrical components.
Caution •To ensure proper hygiene and operation of the machine, it must be
cleaned regularly. Watch out for possible sharp edges when cleaning
the machine. Danger of scratches or cuts.
•Do not switch off the machine between beverage dispensings in order
to keep the optimum water temperature in the boiler. Set ‘energy
saving’ in programming instead.
•Clean the inside and outside of the machine using a clean damp cloth
and do not splash/rinse it. To clean the machine, only use cleaning
agents approved by the food industry.
•Never use high-pressure sprays for cleaning.

Service Manual FB 7100 Installation
January, 2005 2 - 1
Table of contents
Installation 2
Transport / Handling 2.1
Dimensions and general transport instructions 2.1.1
Transport and storage conditions 2.1.2
Installation requirements 2.2
Prerequisites to water supply 2.2.1
Prerequisites to electricity supply 2.2.2
Physical dimensions of required space 2.2.3
Unpacking 2.3
How to unpack the vending machine 2.3.1
List of items, delivered with the vending machine 2.3.2
Disposal of packaging and vending machine
at the end of the lifetime 2.3.3
Installation notes 2.4
Installing the vending machine 2.5
Checklist of customer instructions 2.6
Technical specifications (total overview) 2.7

Service Manual FB 7100 Installation
2 - 2 January, 2005
,

Service Manual FB 7100
January, 2005 2 - 3
2 Installation
2.1 Transport / Handling
2.1.1 Dimensions and general transport instructions
Dimensions The following table states the dimensions of the machine
Weight Approx. 50 kg (without ingredients).
General transport
instructions
Observe the following instructions / cautions:
•Transport the machine carefully in its original packaging.
•Only transport the machine in upright position.
•Do not turn the vending machine upside down.
•Do not lift the vending machine from the side.
•Do not lift the vending machine with whatever sling or rope.
•Do not place one packed machine on top of another..
General storing
instructions
•When storing machine, ensure that it is only stored indoors and take
precautions against parasites and frost.
•Keep the machine away from unusual odours.
2.1.2 Transport and storage conditions
General Note To prevent damage to the machine, (un)load and handle the machine with
special care.
It is possible to lift the machine, both with a motor or hand operated fork
lift, placing the forks in the front or rear side of the pallet.
Precautions
before transporta-
tion and storage
Before storing or transporting a used vending machine to a new location
the following steps must be taken
Topic Measurement
Height 870 mm
Width 450 mm
Depth 378 mm (cabinet), 475 mm (cabinet+door)
Step Action
1. Switch off the main switch and disconnect the power supply plug.
2. Disconnect the machine from the water supply.
3. Empty the ingredient canisters.

Service Manual FB 7100
2 - 4 January, 2005
Ambient tempera-
ture
Min. 5°C - max. 36°C (min. 41°F - max. 97°F) at 80% RH.
Storage require-
ments
The machine must be stored in dry and frost proof ambient conditions and
must not be exposed to sunlight.
• Before storing the machine for a longer period, it must have been
cleaned correctly.
• When used machines are stored intermediately for a long time, the inlet
valve of the water supply hose towards the boiler must be disconnected
in order to ensure that the hose is empty. In this way future spoiling of
the tast is avoided.
4. Drain the boiler completely.
Danger of being scalded by hot water.
5. Ensure that the water system is drained completely when machine is to
be stored for a longer period of time or in a room with temperatures below
0°C.
It is recommended to disassemble individual parts of water system to
empty system completely.
6. Loosen and remove possible wall securing brackets. (Special parts).
7. Pack the vending machine in such a manner that a safe transport is
guaranteed. Use the original packaging, if possible.
Step Action

Service Manual FB 7100
January, 2005 2 - 5
2.2 Installation requirements
2.2.1 Prerequisites to water supply
Customer’s site •Water supply line with stop valve and non return valve.
•Connection to cold water line only with suitable supply lines.
•Supply system requirements:
Machine The connector of the supply hose has to be ordered separately according to
the local connections at the installation site.
Special condi-
tions to be
observed
•Observe safety precautions and local regulations.
•When selecting the supply hoses, only use material that is neutral in
taste and compliant with local regulations.
•Check the drinking water quality. A drinking water filter is
recommended.
•If machine is provided with a water purifying filter, always observe the
data stated by supplier in question.
2.2.2 Prerequisites to electricity supply
Customer’s site Recommended:
•Fault current safety switch and an isolating switch.
Requirements:
•The mains connection must match the machine output (socket), refer to
the rating plate of the machine. The machine must be protected
individually by means of fuses, value 10A.
•The power supply voltage must be 230 V.
•The connection must be earthed.
The machine housing will be carrying voltage if no earthed con-
ductor is connected! (mains filter).
Machine •National plug on power supply cable.
•Length of the power supply cable approx. 3500 mm.
Diagram The diagram illustrates the dimensions of the electrical inlet and water inlet
to machine in relation to rear side of macine:
Description Data
Water flow: 25 ml/sec.
Min. back pressure (dynamic): 0.8 bar
Max. pressure (static): 10 bar

Service Manual FB 7100
2 - 6 January, 2005
520 mm
100 mm
55 mm
210 mm

Service Manual FB 7100
January, 2005 2 - 7
2.2.3 Physical dimensions of required space
Diagram
475 mm
380 mm470 mm
120 mm
280 mm
870 mm
450 mm

Service Manual FB 7100
2 - 8 January, 2005
2.3 Unpacking
2.3.1 How to unpack the machine
Note Do not use any sharp utensils in order to avoid scratches on the machine.
Unpacking Follow these steps to unpack the machine:
Positioning parts
delivered with
macine
Follow these steps to locate the parts delivered with the machine:
Step Action
1. Ensure that the machine has not been damaged during transportation.
2. Remove pallet from machine and position the machine on proper site.
3. Level the machine by adjusting the
feet.
It is essential that the machine is
completely level.
4. Remove the transport protections located inside the machine.
5. Check the list of all items delivered with the machine. see this section,
page 2-9.
6. Position all parts delivered with machine, see Positioning below.
Step Action
1. Place the drip tray in door.
2. Place the quick reference card and
the operator manual in manual
holder between ingredient canister
and cabinet wall.
