1. General
1.1 About this document
1.1.1 Retention and use
This document is to be kept in the vicinity of the equipment for future reference and explanation of the operation of the de-
vice. This document is to be delivered and kept with the equipment in case of change of location and/or user.
The most recent issue of this document can be found online, on our website.
1.1.2 Copyright
Modication and partial or complete usage of this PDF document for other purposes as intended are forbidden and breach
may lead to legal consequences.
1.1.3 Validity
This manual is valid for the following equipment and its variants:
Model Model Model
EA-PUB 10360-480 6U EA-PUB 10920-250 6U EA-PUB 12000-80 6U
EA-PUB 10500-360 6U EA-PUB 11000-160 6U
EA-PUB 10750-240 6U EA-PUB 11500-120 6U
1.1.4 Symbols and warnings in this document
Warning and safety notices as well as general notices in this document are shown in a box with a symbol as follows. The
symbols are also valid, where placed, also to mark specic spots on the device:
Symbol for a life threatening danger (electric shock hazard)
Symbol for risk (of damage to the equipment). If placed on the device it requests the user to read the
operating guide prior to start operation.
Symbol for general safety notices (instructions and damage protection bans) or important information
for operation
Symbol for general notices
1.2 Warranty
EA Elektro-Automatik guarantees the functional competence of the applied technology and the stated performance param-
eters. The warranty period begins with the delivery of free from defects equipment.
Terms of guarantee are included in the general terms and conditions (TOS) of EA Elektro-Automatik.
1.3 Limitation of liability
All statements and instructions in this manual are based on current norms and regulations, up-to-date technology and our
long term knowledge and experience. The manufacturer accepts no liability for losses due to:
• Usage for purposes other than designed
• Use by untrained personnel
• Rebuilding by the customer
• Technical changes
• Use of not authorized spare parts
The actual delivered device(s) may differ from the explanations and diagrams given here due to latest technical changes or
due to customized models with the inclusion of additionally ordered options.

© EA Elektro-Automatik in 2023, this information is subject to change without notice 601123011_manual_pub_10000_6u_60kw_en_01
1.4 Disposal of equipment
A piece of equipment which is intended for disposal must, according to European laws and regulations (ElektroG, WEEE) be
returned to the manufacturer for scrapping, unless the person operating the piece of equipment or another, delegated person
is conducting the disposal. Our equipment falls under these regulations and is accordingly marked with the following symbol:
The device contains a Lithium battery cell. Disposal of that battery follows the above stated rule or spe-
cic local regulations.
1.5 Product key
Decoding of the product description on the label, using an example:
EA-PUB 10360 -480 6U xxx
Options and special versions:
WC = Water cooling installed
Construction (only stated on type label):
6U = 19" frame with 6 height units
Maximum current of the device in Ampere
Maximum voltage of the device in Volt (“10360” = 360 V)
Series: 10 = Series 10000
Type identication:
PUB = Power Unit Bidirectional

© EA Elektro-Automatik in 2023, this information is subject to change without notice 701123011_manual_pub_10000_6u_60kw_en_01
1.6 Intended usage
The equipment is intended to be used only as a variable voltage and current source or only as a variable current sink. Fur-
thermore it’s only intended to be used installed and operated in suitable equipment (19” rack or similar), together with a rigid,
non-retractable AC supply connection.
Typical application for a voltage source is DC power supply to any relevant user, including when used as battery charger to
test charge various battery types, and for current sinks the replacement of an ohmic resistor by an adjustable electronic DC
load in order to load relevant voltage and current sources of any type.
Additionally to the functionality of the equipment as source or sink of electrical energy on the DC side, all models in this series
are also so-called recuperating devices and thus not just drain energy on the AC side, but also source energy when being
sinks on the DC side. This is where the term “bidirectional” comes from. In sink mode the devices become energy recoverers,
but are not dened or considered as energy generation equipment.
• Claims of any sort due to damage caused by non-intended usage will not be accepted
• All damage caused by non-intended usage is solely the responsibility of the operator
1.6.1 Symbols and warnings on the device
Decal Explanation
DANGER
RISK OF ELECTRIC
SHOCK
Disconnect all sources of
supply prior to servicing.
!This warning is primarily related to the reconguration of the device on the DC termi-
nal which, for safety reasons, requires to also cut the device from AC (external main
switch). The same applies to disconnection and reconnection of the AC terminal.
Capacitors on DC, stor-
ing voltage! Discharge
for 10 sec then ground
before working.
DANGER
!Even after disconnection of the DC terminal from an external source there can still be
dangerous voltage potential present between the DC terminal poles and/or between
DC and the enclosure. For safety reasons the DC terminal must be short-circuited
after the capacitors have been discharged and it must also be grounded, i. e. con-
nected to PE.
WARNING
ELECTRICAL
HAZARDS
Authorized personnel
only.
!There can always be a voltage potential on metallic, openly touchable parts on
electrical devices, though the voltage level may not be hazardous. Caution is still
advisable, as these potential can still cause mild electrical shocks or sparking.
WARNING
Read and understand the operat-
ing guide before using this device.
Non-adherence of the instructions
in the operating guide can result
in serious injury or death.
!This is valid for any use of the device.

© EA Elektro-Automatik in 2023, this information is subject to change without notice 801123011_manual_pub_10000_6u_60kw_en_01
1.7 Safety
1.7.1 Safety notices
Mortal danger - Hazardous voltage
• Electrical equipment operation means that some parts accessible on the outside of the device can be
under high voltage. Therefore all parts under voltage must be covered during operation! This basically
applies to all models.
• The DC terminal is isolated from the AC input and not connected to ground internally. Hence there can
be dangerous potential between the DC poles and PE, for instance caused by a connected external
source application. Due to charged capacitors this could even be true if the DC output or the device
are already switched off.
• Do not insert any object, particularly metallic, through the ventilator slots!
• For every reconguration on the AC or DC connectors, specically those which can have a dangerous
voltage potential, the device must be cut completely from the AC supply (main switch on the distant
end of the AC cable); it doesn’t suce to only use the power switch on the front
• Always follow 5 safety rules when working with electric devices:
• Disconnect completely
• Secure against reconnection
• Verify that the system is dead
• Carry out earthing and short-circuiting
• Provide protection from adjacent live parts
• Avoid any use of liquids near the equipment. Protect the device from wet, damp and condensation.
• Do not connect external power sources with reversed polarity to the DC terminal! The equipment will be
damaged, even when completely powered off.
• Never connect external power sources to the DC terminal that can generate a higher voltage than the
rated voltage of the device!
• Never insert a network cable which is connected to Ethernet or its components into the master-slave
sockets on the rear side of the device!
• The equipment must only be used as intended
• The equipment is only approved for use within the connection limits stated on the product label.
• ESD regulations must be applied when plugging interface cards or modules into the relative slot
• Interface cards or modules may only be attached or removed after the device is switched off. It’s not
necessary to open the device.
• Always congure the various protecting features against overcurrent, overvoltage etc. for sensitive loads
to what the target application requires!
• When operating the device as electronic load: always make sure that the energy recovery can feed back
the inverted energy and that it does not switch to isolated operation. For situations of isolated operation
a supervision device (grid protection) has to be installed
• It’s not allowed to run the device on AC sources such as generators or UPS equipment. It must only be
connected to a power grid!

© EA Elektro-Automatik in 2023, this information is subject to change without notice 901123011_manual_pub_10000_6u_60kw_en_01
1.7.2 Responsibility of the operator
Operator is any natural or legal person who uses the equipment or delegates the usage to a third party, and is responsible
during its usage for the safety of the user, other personnel or third parties.
The equipment is in industrial operation. Therefore the operators are governed by the legal safety regulations. Alongside the
warning and safety notices in this manual the relevant safety, accident prevention and environmental regulations must also
be applied. In particular the operator has to
• be acquainted with the relevant job safety requirements
• identify other possible dangers arising from the specic usage conditions at the work station via a risk assessment
• introduce the necessary steps in the operating procedures for the local conditions
• regularly control that the operating procedures are current
• update the operating procedures where necessary to reect changes in regulation, standards or operating conditions.
• dene clearly and unambiguously the responsibilities for operation, maintenance and cleaning of the equipment.
• ensure that all employees who use the equipment have read and understood the manual. Furthermore the users are to be
regularly schooled in working with the equipment and the possible dangers.
• provide all personnel who work with the equipment with the designated and recommended safety equipment
Furthermore, the operator is responsible for ensuring that the device is at all times technically t for use.
1.7.3 Requirements to the user
Any activity with equipment of this type may only be performed by persons who are able to work correctly and reliably and
satisfy the requirements of the job.
• Persons whose reaction capability is negatively inuenced by e.g. drugs, alcohol or medication may not operate the equipment.
• Age or job related regulations valid at the operating site must always be applied.
Danger for unqualied users
Improper operation can cause person or object damage. Only persons who have the necessary train-
ing, knowledge and experience may use the equipment.
The group of people allowed to operate the equipment is additionally limited to:
Delegated persons: these are persons who have been properly and demonstrably instructed in their tasks and the attendant
dangers.
Qualied persons: these are persons who are able through training, knowledge and experience as well as knowledge of the
specic details to carry out all the required tasks, identify dangers and avoid personal and other risks.
1.7.4 Responsibility of the user
The equipment is in industrial operation. Therefore the operators are governed by the legal safety regulations. Alongside the
warning and safety notices in this manual the relevant safety, accident prevention and environmental regulations must also
be applied. In particular the users of the equipment:
• must be informed of the relevant job safety requirements
• must work to the dened responsibilities for operation, maintenance and cleaning of the equipment
• before starting work must have read and understood the operating manual

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1001123011_manual_pub_10000_6u_60kw_en_01
1.7.5 Alarm signals
The equipment offers various possibilities for signaling alarm conditions, however, not for danger situations. The signals
are optical (via an LED on the control panel) or electronic (status output of the analog interface and digitally readable status
bits). All alarms will cause the device to switch off the DC terminal. For details about the different alarms refer to section «3.4
Alarm conditions» .
The meaning of the signals is as follows:
Signal OT
(OverTemperature)
• Overheating of the device
• DC terminal will be switched off
• Non-critical
Signal OVP
(OverVoltage)
• Overvoltage shutdown of the DC terminal due to high voltage entering the device or generated by
the device itself due to a defect
• Critical! The device and/or the load could be damaged
Signal OCP
(OverCurrent)
• Shutdown of the DC terminal due to excess of the preset limit
• Non-critical, protects the load or source from excessive current consumption
Signal OPP
(OverPower)
• Shutdown of the DC terminal due to excess of the preset limit
• Non-critical, protects the load or source from excessive power consumption
Signal PF
(Power Fail)
• DC terminal shutdown due to AC undervoltage or defect in the AC section
• Critical on overvoltage! AC section could be damaged
Signal MSP
(Master-Slave Pro-
tection)
• DC terminal shutdown due to communication problems on the master-slave bus
• Non-critical
Signal SF
(Share Bus Fail)
• DC terminal shutdown due to signal distortion on the Share bus
• Non-critical
1.7.6 Functionality test
The operator of the device must decide when to check the device for correct functionality, by whom and how often. The
“when” could either be before every use or after it has been relocated or recongured or perhaps in a dened interval.
Should the set values not be adjustable as instructed below it could simply be due to adjustment limits
interfering. When reaching a limit adjusting value can’t be signaled by the device. In remote control an
invalid value would be rejected, together with an error message.
The test procedure would always be like this:
1. Disconnect all cables (DC, Sense, Share bus, analog interface, USB), except for AC.
2. Connect a suitable voltage meter to the DC terminal.
3. Switch the device on. Adjust a voltage of 10% UNom using remote control via the front or rear USB port while the current
and power set values for source mode should be at maximum and those for sink mode at 0. Then switch the DC output
on and verify with the multimeter that the adjusted voltage is available on the DC terminal. Also compare it to the actual
voltage value read via remote command query.
4. Repeat the same thing at 100% UNom.
5. Switch the DC output off and bridge the DC terminal with a cable or copper rails of suitable current capability of at least
INom. If available, put a current measuring device (transducer, current probe).
6. Adjust the current for source mode to 10% INom, switch the DC output on and measure the current with the external
measuring device, if available, and compare to the actual current measured by the device which can be read via remote
query command or at least compare the read actual current with the set value.
7. Repeat the same thing at 100% INom.
Only if the current and voltage are supplied by the device as adjustable in the range of 0-100% FS, the device can be consid-
ered as fully operational.

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1101123011_manual_pub_10000_6u_60kw_en_01
1.8 Technical Data
1.8.1 Approved operating conditions
1. 8 .1.1 Ambiance
The allowed ambient temperature range for operation is 0 °C (32 °F) to 50 °C (122 °F). During storage or transport, the al-
lowed range extends to -20 °C (-4 °F) to 70 °C (158 °F). In case water condensation occurred due to transport, the device
must be acclimatized prior to operation for at least 2 hours, ideally in a place with good air circulation.
The device is intended to be operation in dry rooms. It must not be exposed or operated to extreme dust, high air humidity,
danger of explosion and aggressive chemicals polluting the air. The operating position isn’t arbitrary (see «2.3.3 Installing
the device» ),but in any case it requires a sucient air circulation. The device is allowed to be operated in altitude up to 2000
m (approx. 6,560 ft) above sea level. Technical specications (here: ratings), when given with tolerance, are valid for a unit
warmed up for at least 30 minutes and for an ambient temperature of 23 °C (73 °F). Specications without tolerance are
typical values from an average device.
1.8.1.2 Cooling
Power dissipated inside the device heats up air circulating through the device. With the air-cooled versions a fan at the end
of an air ow channel,in which a cooling block is placed, pulls the air through the device. Entry is on the front, exhaust at the
back. Depending on the internal temperature, the fan speed is automatically regulated up or down, whereas a certain mini-
mum speed is maintained because some internal components even heat up when the device is idle.
Dust in the air can obstruct the air ow with time, thus it’s important to keep the air ow unimpeded at least outside of the
device be leaving sucient room behind it. Since it’s usually installed inside cabinets, the cabinet doors are required to be
meshed.
At the same time, the ambient temperature should be kept at low levels, perhaps by external means such as an air condition.
Should the device heat up internally and the cooling block temperature exceed 80 °C (160 °F), the device will protect itself
from overheating by automatically switching off the power stage. It could then only continue to operate and switch the power
stage on again after cooling down for some time.
For the water-cooled versions, water is the main cooling agent, owing through the internal cooling blocks. The air inside the
almost hermetically body circulates, engaged by fans, to cool the remaining components not sitting on the cooling blocks,
but heat up over time.
1.8.2 General technical data
Display: 6 LED with different colors
Controls: 1 pushbutton

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1201123011_manual_pub_10000_6u_60kw_en_01
1.8.3 Specic technical data
General speci cations
AC input
Voltage, Phases 380 V - 480 V ±10%, 3ph AC
Frequency 45 - 65 Hz
Power factor ca. 0.99
Leakage current <10 mA
Phase current ≤110 A @ 400 V AC
Overvoltage category 2
DC output static
Load regulation CV ≤0.05% FS (0 - 100% load, constant AC input voltage and constant temperature)
Line regulation CV
≤0.01% FS
(380 V - 480 V +10% AC input voltage, constant load and constant temperature)
Stability CV ≤0.02% FS (during 8 h of operation, after 30 minutes warm-up, at constant AC input voltage, load and temperature)
Temperature coeffi cient CV ≤30ppm/°C (after 30 minutes of warm-up)
Compensation (remote sense) ≤5% UNominal
Load regulation CC ≤0.1% FS (0 - 100% load, constant AC input voltage and constant temperature)
Line regulation CC ≤0.01% FS (380 V - 480 V +10% AC input voltage, constant load and constant temperature)
Stability CC ≤0.02% FS (during 8 h of operation, after 30 minutes warm-up, at constant AC input voltage, load and temperature)
Temperature coeffi cient CC ≤50ppm/°C (after 30 minutes of warm-up)
Load regulation CP ≤0.3% FS (0 - 100% load, constant AC input voltage and constant temperature)
Load regulation CR ≤0.3% FS + 0.1% FS current (0 - 100% load, constant AC input voltage and constant temperature)
Protective functions
OVP Overvoltage protection, adjustable 0 - 110% UNominal
OCP Overcurrent protection, adjustable 0 - 110% INominal
OPP Overpower protection, adjustable 0 - 110% PNominal
OT Overtemperature protection (DC output shuts down in case of insuffi cient cooling)
DC output dynamic
Rise time 10 - 90% CV ≤10 ms
Fall time 90 - 10% CV ≤10 ms
Rise time 10 - 90% CC ≤2 ms
Fall time 90 - 10% CC ≤2 ms
Insulation
AC input to DC output 3750 Vrms (1 minute, creepage distance >8 mm)
AC input to case (PE) 2500 Vrms
DC output to case (PE) Depending on the model, see model tables
DC output to interfaces 1000 V DC (models up to 360 V output), 1500 V DC (models from 500 V output)
Interfaces digital
Built-in, galvanically isolated USB, Ethernet (100 MBit), USB front panel, all for communication
Optional, galvanically isolated CAN, CANopen, RS232, ModBus TCP, Profi net, Profi bus, EtherCAT, Ethernet
Interfaces analog
Built-in, galvanically isolated 15 pole D-Sub
Signal range 0 - 10 V or 0 - 5 V (switchable)
Inputs U, I, P, R, remote control on/off, DC output on/off, resistance mode on/off
Outputs Monitor U and I, alarms, reference voltage, DC output status, CV/CC regulation mode
Accuracy U / I / P / R 0 - 10 V: ≤0.2%, 0 - 5 V: ≤0.4%
Device con guration
Parallel operation Up to 64 units of any power class in series 10000 starting from 5 kW, with Master-Slave bus and Share-Bus

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1301123011_manual_pub_10000_6u_60kw_en_01
General speci cations
Safety and EMC
Safety
EN 61010-1
IEC 61010-1
UL 61010-1
CSA C22.2 No 61010-1
BS EN 61010-1
EMC
EN 55011, class A
CISPR 11, class A
FCC 47 CFR part 15B, unintentional radiator, class A
EN 61326-1 include tests according to:
- EN 61000-4-2
- EN 61000-4-3
- EN 61000-4-4
- EN 61000-4-5
- EN 61000-4-6
Safety protection class 1
Ingress Protection IP20
Environmental conditions
Operating temperature 0 - 50 °C (32 - 122 °F)
Storage temperature -20 - 70 °C (-4 - 158 °F)
Humidity ≤80% relative humidity, non-condensing
Altitude ≤2000 m (≤6,600 ft)
Pollution degree 2
Mechanical construction
Cooling Forced air fl ow from front to rear (temperature controlled fans), optional: water cooling
Dimensions (W x H x D) Enclosure: 19“ x 6U x 668 mm (26.3 in)
Weight 76 kg (168 lb)
Weight with water cooling 82 kg (180 lb)

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1401123011_manual_pub_10000_6u_60kw_en_01
Technical speci cations PUB 10360-480 PUB 10500-360 PUB 10750-240 PUB 10920-250
DC output
Voltage range 0 - 360 V 0 - 500 V 0 - 750 V 0 - 920 V
Ripple in CV (rms) ≤55 mV (BWL 300 kHz) ≤70 mV (BWL 300 kHz) ≤200 mV (BWL 300 kHz) ≤250 mV (BWL 300 kHz)
Ripple in CV (pp) ≤320 mV (BWL 20 MHz) ≤350 mV (BWL 20 MHz) ≤800 mV (BWL 20 MHz) ≤1200 mV (BWL 20 MHz)
UMin for IMax (sink) 2.5 V 1.1 V 1.2 V 2 V
Current range 0 - 480 A 0 - 360 A 0 - 240 A 0 - 250 A
Power range 0 - 60000 W 0 - 60000 W 0 - 60000 W 0 - 60000 W
Resistance range 0.025 Ω - 45 Ω 0.04 Ω - 85 Ω 0.1 Ω - 185 Ω 0.125 Ω - 275 Ω
Output capacitance 3480 μF 1560μF 765 μF 465 μF
Effi ciency sink/source (up to) 95.8% *1 96.5% *1 96.5% *1 96.5% *1
Insulation
Negative DC pole <-> PE ±1000 V DC ±1500 V DC ±1500 V DC ±1500 V DC
Positive DC pole <-> PE +1000 V DC +2000 V DC +2000 V DC +2000 V DC
Article numbers
Standard 01123011 01123012 01123013 01123014
Standard + Water Cooling 01563001 01563002 01563003 01563004
Technical speci cations PUB 11000-160 PUB 11500-120 PUB 12000-80
DC output
Voltage range 0 - 1000 V 0 - 1500 V 0 - 2000 V
Ripple in CV (rms) ≤300 mV (BWL 300 kHz) ≤400 mV (BWL 300 kHz) ≤500 mV (BWL 300 kHz)
Ripple in CV (pp) ≤1600 mV (BWL 20 MHz) ≤2400 mV (BWL 20 MHz) ≤3000 mV (BWL 20 MHz)
UMin for IMax (sink) 3.4 V 3.2 V 3.7 V
Current range 0 - 160 A 0 - 120 A 0 - 80 A
Power range 0 - 60000 W 0 - 60000 W 0 - 60000 W
Resistance range 0.2 Ω - 325 Ω 0.4 Ω - 750 Ω 0.85 Ω - 1350 Ω
Output capacitance 387 μF 173 μF 85 μF
Effi ciency sink/source (up to) 95.8% *1 96.5% *1 96.5% *1
Insulation
Negative DC pole <-> PE ±1500 V DC ±1500 V DC ±1500 V DC
Positive DC pole <-> PE +2000 V DC +2000 V DC +2000 V DC
Article numbers
Standard 01123015 01123016 01123017
Standard + Water Cooling 01563005 01563006 01563007
*1 At 100% power and 100% output voltage
BWL = band width limit
*1 At 100% power and 100% output voltage
BWL = band width limit

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1501123011_manual_pub_10000_6u_60kw_en_01
1.8.4 Views
1.8.4.1 Technical drawings PUB 10000 6U
Side view of the air-cooled version shown

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1601123011_manual_pub_10000_6u_60kw_en_01
1.8.4.2 Front panel description PUB 10000 6U
1.8.4.3 Rear panel description PUB 10000 6U
1. DC on/off pushbutton
2. LED status display
3. USB interface
1. Master-Slave bus connectors to set up a system for parallel connection
2. Slot for optional interfaces
3. Ethernet interface
4. USB interface n
5. Connector (DB15 female) for isolated analog programming, monitoring and other functions
6. DC output terminal (copper blades)
7. Share bus connectors to set up a system for parallel connection
8. AC input connector
9. Remote sense connectors

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1701123011_manual_pub_10000_6u_60kw_en_01
1.8.4.4 Front panel description PUB 10000 6U WC (water cooling option)
1.8.4.5 Rear panel description PUB 10000 6U WC (water cooling option)
1. DC on/off pushbutton
2. LED status display
3. USB interface
1. Master-Slave bus connectors to set up a system for parallel connection
2. Slot for optional interfaces
3. Ethernet interface
4. USB interface n
5. Connector (DB15 female) for isolated analog programming, monitoring and other functions
6. DC output terminal (copper blades)
7. Share bus connectors to set up a system for parallel connection
8. AC input connector
9. Remote sense connectors
10. Water inlet and outlet

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1801123011_manual_pub_10000_6u_60kw_en_01
1.8.5 Control elements
Figure 1- Control Panel
Overview of the elements on the control panel
For a detailed description see section «1.9.6 The control panel (HMI)».
(1)
On/Off button
Can be used to switch the DC output on or off during manual operation, while LED “Remote” is off
Pin REM-SB on the analog interface, when set to a logical level which would request to turn DC off,
can block switching DC on by this pushbutton.
(2)
USB port
For quick and easy access to the most important DC output related values when the device isn’t in master-slave
mode. This port has reduced functionality compared to the rear port.
(3) Status indicators (LED)
These six color LEDs show the device status.

© EA Elektro-Automatik in 2023, this information is subject to change without notice 1901123011_manual_pub_10000_6u_60kw_en_01
1.9 Construction and function
1. 9 .1 General description
The devices in series PUB 10000 6U represent matching models to series PSB 10000 4U and PSBE 10000 4U. They serve as
extension modules, so called power units, which are intended to build master-slave systems with higher total power. Devices
from series PSB 10000 4U or PSBE 10000 4U, which both have a color touch display, can serve as master unit, but all PUB
10000 6U can also serve as master for other 10000 series power supplies should the control be solely remote.
For remote control the devices are provided as standard with USB and Ethernet ports on the rear side, as well as a galvani-
cally isolated analog interface. Via optional plug-in interface modules, another digital interface such as for RS232, Probus,
ProNet, ModBus TCP, CAN, CANopen or EtherCAT can be added. These enable the devices to be connected to standard
industrial buses simply by changing or adding a small module.
Alternatively to the air-cooled versions there are also water-cooled version available which are usually congured and offered
in cabinet systems with a complete water cooling distribution inside. For DIY water-cooled systems single units can also be
obtained upon request.
1.9.2 Block diagram
The block diagram illustrates the main components inside the device and their relationships.
There are digital, microprocessor controlled components (KE, DR, HMI), which can be target of rmware updates.
Controller
(DR)
Commu-
nication
(KE)
MSUSB Ana
log
Share &
Sense
Block diagram
=
≈
=
≈
AC
DC
Commu-
nication
(KE)
Power blocks
Any
bus
ETH
PUB 10000
HMI
USB

© EA Elektro-Automatik in 2023, this information is subject to change without notice 2001123011_manual_pub_10000_6u_60kw_en_01
1.9.3 Scope of delivery
1 x Bidirectional power supply device
2 x Remote sensing plugs
1 x 1.8 m (5.9 ft) USB cable
1 x DC terminal cover
1 x Sense terminal cover
1 x USB stick with documentation and software
1 x AC terminal cover
1 x Set for AC cable strain relief (bracket & cable ties)
1.9.4 Accessories
For all models in this series, with or without water cooling option installed, the following accessories are available:
IF-AB
Interface modules
Pluggable and retrottable, digital interface modules for RS232, CANopen, Probus, ProNet,
ModBus TCP, EtherCAT or CAN are available. Details about the interface modules and the pro-
gramming of the device using those interfaces can be found in separate documentation. It’s
usually available on the USB stick, which is included with the device, or as PDF download on the
manufacturers website.
EABS
Battery simulation
EABS is short for EA Battery Simulator and is an optionally available, USB dongle licensed
Windows software. In combination with the bidirectional power supplies of series PSB 9000,
PSBE 9000, PSB 10000, PSBE 10000 or PUB 10000 it simulates either a single lithium-ion cell
or lead-acid battery or multiple in series and/or parallel connection. The simulation works with
battery typical values such as capacity, temperature, state of charge, internal resistance and cell
voltage, plus adjustable test conditions.
1.9.5 Options
These options are usually ordered along with the device, as they are permanently built in or precongured during the manu-
facturing process.
POWER RACKS
19“ rack
Racks in various congurations up to 42U as parallel systems are available, or mixed with elec-
tronic load devices to create test systems. Further information can be found on our website or
obtained upon request
WC
Water cooling
Replaces the standard cooling blocks of the internal power blocks by three interconnected, wa-
ter cooled blocks with two taps led out for supply. This option helps to avoid heating up the
environment due to exhausted heat caused by a certain power dissipation when the device or a
cabinet full of units runs as source.
As a side effect, this type of cooling also reduces audible noise.
