Elektro-Automatik PSB 10060-1000 4U User manual

Elektro-Automatik
Doc ID: PSB1EN
Revision: 01
Date: 08/2019
Operating Guide
PSB 10000 4U
Bidirectional DC Power Supply
Note: everything marked in red in this document is either not
conrmed or may change due to hardware and software opti-
mizations, until the nal issue of this document is released.
PRELIMINARY

Page 3
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
TABLE OF CONTENTS
1GENERAL
1.1 About this document ......................................5
1.1.1 Retention and use ..........................................5
1.1.2 Copyright ........................................................5
1.1.3 Validity ............................................................5
1.1.4 Symbols and warnings ..................................5
1.2 Warranty .........................................................5
1.3 Limitation of liability ........................................5
1.4 Disposal of equipment ...................................6
1.5 Product key ....................................................6
1.6 Intended usage ..............................................6
1.7 Safety .............................................................7
1.7.1 Safety notices .................................................7
1.7.2 Responsibility of the user...............................8
1.7.3 Responsibility of the operator .......................8
1.7.4 User requirements .........................................8
1.7.5 Alarm signals ..................................................9
1.8 Technical Data ...............................................9
1.8.1 Approved operating conditions ......................9
1.8.2 General technical data ...................................9
1.8.3 Specic technical data .................................10
1.8.4 Views ............................................................16
1.8.5 Control elements ..........................................20
1.9 Construction and function ............................21
1.9.1 General description ......................................21
1.9.2 Block diagram ..............................................21
1.9.3 Scope of delivery .........................................22
1.9.4 Accessories ..................................................22
1.9.5 Options .........................................................22
1.9.6 The control panel (HMI) ...............................23
1.9.7 USB port (rear side) .....................................26
1.9.8 Interface module slot ...................................26
1.9.9 Analog interface ...........................................27
1.9.10 “Share BUS” connector ...............................27
1.9.11 “Sense” connector (remote sensing) ...........27
1.9.12 Master-Slave bus .........................................27
1.9.13 Ethernet port ................................................28
2INSTALLATION &
COMMISSIONING
2.1 Transport and storage .................................29
2.1.1 Transport ......................................................29
2.1.2 Packaging ....................................................29
2.1.3 Storage .........................................................29
2.2 Unpacking and visual check ........................29
2.3 Installation ....................................................29
2.3.1 Safety procedures before installation and
use ................................................................29
2.3.2 Preparation ...................................................30
2.3.3 Installing the device .....................................30
2.3.4 Connection to AC supply .............................31
2.3.5 Connection to DC loads or DC sources ......33
2.3.6 Connection of remote sense .......................34
2.3.7 Grounding of the DC terminal ......................35
2.3.8 Installation of an interface module ...............35
2.3.9 Connecting the analog interface .................35
2.3.10 Connecting the “Share” bus ........................36
2.3.11 Connecting the USB port (rear side) ...........36
2.3.12 Initial commission .........................................36
2.3.13 Initial network setup .....................................36
2.3.14 Commission after a rmware update or a
long period of non-use .................................37
3OPERATION AND APPLICATION
3.1 Terms ............................................................38
3.2 Important notes ............................................38
3.2.1 Personal safety ............................................38
3.2.2 Genera .........................................................38
3.3 Operating modes .........................................38
3.3.1 Voltage regulation / Constant voltage .........38
3.3.2 Current regulation / constant current / current
limiting ..........................................................39
3.3.3 Power regulation / constant power / power
limiting ..........................................................39
3.3.4 Internal resistance regulation (source
mode) ...........................................................40
3.3.5 Resistance regulation / constant resistance
(sink mode) ..................................................40
3.3.6 Sink-source mode switching ........................41
3.3.7 Dynamic characteristics and stability crite-
ria ..................................................................41
3.4 Alarm conditions ..........................................42
3.4.1 Power Fail ...................................................42
3.4.2 Overtemperature ..........................................42
3.4.3 Overvoltage protection.................................42
3.4.4 Overcurrent protection .................................42
3.4.5 Overpower protection ..................................42
3.4.6 Safety OVP ..................................................43
3.4.7 Share bus fail ...............................................43
3.5 Manual operation .........................................44
3.5.1 Switching on the device ...............................44
3.5.2 Switching o󰀨 the device ...............................44
3.5.3 Conguration via menu “Settings” ...............44
3.5.4 Adjustment limits ..........................................52
3.5.5 Changing the operating mode .....................52
3.5.6 Manual adjustment of set values .................53
3.5.7 Switching the DC terminal on or o󰀨 .............54
3.5.8 Recording to USB stick (logging) ................54
3.5.9 The quick menu ...........................................55
3.6 Remote control .............................................57
3.6.1 General .........................................................57
3.6.2 Control locations ..........................................57
3.6.3 Remote control via a digital interface ..........57
3.6.4 Remote control via the analog interface
PRELIMINARY

Page 4
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
(AI) ................................................................58
3.7 Alarms and monitoring .................................63
3.7.1 Denition of terms ........................................63
3.7.2 Device alarm and event handling ................63
3.8 Locking the control panel (HMI) ..................66
3.9 Locking the “Limits” and “Proles” ...............66
3.10 Loading and saving a user prole ...............67
3.11 The function generator.................................68
3.11.1 Introduction...................................................68
3.11.2 General .........................................................68
3.11.3 Method of operation .....................................69
3.11.4 Manual operation .........................................70
3.11.5 Sine wave function .......................................71
3.11.6 Triangular function .......................................71
3.11.7 Rectangular function ....................................72
3.11.8 Trapezoidal function .....................................73
3.11.9 DIN 40839 function ......................................73
3.11.10 Arbitrary function ..........................................74
3.11.11 Ramp function ..............................................78
3.11.12 IU table function (XY table) ..........................79
3.11.13 Simple PV (photovoltaics) function .............80
3.11.14 FC table function (fuel cell) ..........................82
3.11.15 Extended PV function according to EN
50530 ...........................................................83
3.11.16 Battery test function .....................................89
3.11.17 MPP tracking function ..................................93
3.11.18 Remote control of the function generator....95
3.12 Other applications ........................................96
3.12.1 Parallel operation in master-slave (MS) ......96
3.12.2 Series connection ........................................99
4 SERVICE AND MAINTENANCE
4.1 Maintenance / cleaning ..............................100
4.2 Fault nding / diagnosis / repair.................100
4.2.1 Firmware updates ......................................100
5 CONTACT AND SUPPORT
5.1 General .......................................................101
5.2 Contact options ..........................................101
PRELIMINARY

Page 5
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
1. General
1.1 About this document
1.1.1 Retention and use
This document is to be kept in the vicinity of the equipment for future reference and explanation of the operation of
the device. This document is to be delivered and kept with the equipment in case of change of location and/or user.
1.1.2 Copyright
Reprinting, copying, also partially, usage for other purposes as foreseen of this manual are forbidden and breach
may lead to legal process.
1.1.3 Validity
This manual is valid for the following equipment:
Model Article nr. Model Article nr. Model Article nr.
PSB 10060-1000 4U 30000800 PSB 10360-240 4U 30000803 PSB 11000-80 4U 30000806
PSB 10080-1000 4U 30000801 PSB 10500-180 4U 30000804 PSB 11500-60 4U 30000807
PSB 10200-420 4U 30000802 PSB 10750-120 4U 30000805 PSB 12000-40 4U 30000808
1.1.4 Symbols and warnings
Warning and safety notices as well as general notices in this document are shown in a box with a symbol as follows:
Symbol for a life threatening danger
Symbol for general safety notices (instructions and damage protection bans) or important infor-
mation for operation
Symbol for general notices
1.2 Warranty
EA Elektro-Automatik guarantees the functional competence of the applied technology and the stated performance
parameters. The warranty period begins with the delivery of free from defects equipment.
Terms of guarantee are included in the general terms and conditions (TOS) of EA Elektro-Automatik.
1.3 Limitation of liability
All statements and instructions in this manual are based on current norms and regulations, up-to-date technology
and our long term knowledge and experience. The manufacturer accepts no liability for losses due to:
• Usage for purposes other than designed
• Use by untrained personnel
• Rebuilding by the customer
• Technical changes
• Use of not authorized spare parts
The actual delivered device(s) may di󰀨er from the explanations and diagrams given here due to latest technical
changes or due to customized models with the inclusion of additionally ordered options.
PRELIMINARY

Page 6
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
1.4 Disposal of equipment
A piece of equipment which is intended for disposal must, according to European laws and regulations (ElektroG,
WEEE) be returned to the manufacturer for scrapping, unless the person operating the piece of equipment or an-
other, delegated person is conducting the disposal. Our equipment falls under these regulations and is accordingly
marked with the following symbol:
1.5 Product key
Decoding of the product description on the label, using an example:
PSB 10080 - 1000 4U xxx
Options and special versions:
WC = Water cooling
Construction (not always given):
4U = 19" frame with 4 height units
Maximum current of the device in Ampere
Maximum voltage of the device in Volt (“12000” = 2000 V)
Series: 10 = Series 10000
Type identication:
PSB = Power Supply Bidirectional
1.6 Intended usage
The equipment is intended to be used only as a variable voltage and current source or only as a variable current sink.
Typical application for a voltage source is DC power supply to any relevant user, including when used as battery
charger to test charge various battery types, and for current sinks the replacement of an ohmic resistor by an
adjustable electronic DC load in order to load relevant voltage and current sources of any type.
• Claims of any sort due to damage caused by non-intended usage will not be accepted
• All damage caused by non-intended usage is solely the responsibility of the operator
PRELIMINARY

Page 7
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
1.7 Safety
1.7.1 Safety notices
Mortal danger - Hazardous voltage
• Electrical equipment operation means that some parts can be under dangerous voltage.
Therefore all parts under voltage must be covered! This basically applies to all models,
though 60 V models according to SELV can’t generate hazardous DC voltage.
• Never touch cables or connectors directly after unplugging from mains supply as the
danger of electric shock remains!
• Never touch the contacts on DC terminal directly after switching the device o󰀨, because
when running in source mode there still can be dangerous voltage present, sinking more
or less slowly depending on the load!
• There can be dangerous potential between DC minus to PE or DC plus to PE due to
charged X capacitors, even when the DC output/input is not switched on and the device is
still running. Never touch PE and any of the DC poles at the same time with bare hands!
• Always follow 5 safety rules when working with electric devices:
• Disconnect completely
• Secure against reconnection
• Verify that the system is dead
• Carry out earthing and short-circuiting
• Provide protection from adjacent live parts
• In situations where the device works in source mode, with a voltage > 0 adjusted and
the DC terminal being on, the output voltage can remain at the last setting after switch-
ing the DC output o󰀨 again, in case the set value of current for the internal load (sink
mode) is set to 0
• Even with the DC terminal being switched o󰀨, the device can generate a small, not load-
able voltage (< 2 V) on this terminal!
• The equipment must only be used as intended
• The equipment is only approved for use within the connection limits stated on the product label.
• Do not insert any object, particularly metallic, through the ventilator slots
• Avoid any use of liquids near the equipment. Protect the device from wet, damp and conden-
sation.
• When operating the device as power supply: do not connect loads, particularly low resistance,
to the device while the DC output is switched on; sparking may occur which can cause burns
as well as damage to the equipment and to the loads.
• When operating the device as electronic load: do not connect power sources to the device while
the DC input is switched on; sparking may occur which can cause burns as well as damage to
the equipment and to the source.
• ESD regulations must be applied when plugging interface cards or modules into the relative slot
• Interface cards or modules may only be attached or removed after the device is switched o󰀨.
It’s not necessary to open the device.
• Do not connect external power sources with reversed polarity to the DC terminal! The equipment
will be damaged, even when completely powered o󰀨.
• Never connect external power sources to the DC terminal that can generate a higher voltage
than the rated voltage of the device!
• Never insert a network cable which is connected to Ethernet or its components into the mas-
ter-slave sockets on the rear side of the device!
• Always congure the various protecting features against overcurrent, overpower etc. for sen-
sitive loads to what the target application requires!
• When operating the device as electronic load: always make sure that the energy recovery can
feed back the inverted energy and that it does not switch to isolated operation. For situations
of isolated operation a supervision device (AIU, grid and plat protection) has to be installed
• It’s not allowed to run the device on AC sources such as generators or UPS equipment. It must
only be connected to a power grid!
PRELIMINARY

Page 8
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
1.7.2 Responsibility of the user
The equipment is in industrial operation. Therefore the operators are governed by the legal safety regulations.
Alongside the warning and safety notices in this manual the relevant safety, accident prevention and environmental
regulations must also be applied. In particular the users of the equipment:
• must be informed of the relevant job safety requirements
• must work to the dened responsibilities for operation, maintenance and cleaning of the equipment
• before starting work must have read and understood the operating manual
• must use the designated and recommended safety equipment.
Furthermore, anyone working with the equipment is responsible for ensuring that the device is at all times tech-
nically t for use.
1.7.3 Responsibility of the operator
Operator is any natural or legal person who uses the equipment or delegates the usage to a third party, and is
responsible during its usage for the safety of the user, other personnel or third parties.
The equipment is in industrial operation. Therefore the operators are governed by the legal safety regulations.
Alongside the warning and safety notices in this manual the relevant safety, accident prevention and environmental
regulations must also be applied. In particular the operator has to
• be acquainted with the relevant job safety requirements
• identify other possible dangers arising from the specic usage conditions at the work station via a risk assessment
• introduce the necessary steps in the operating procedures for the local conditions
• regularly control that the operating procedures are current
• update the operating procedures where necessary to reect changes in regulation, standards or operating con-
ditions.
• dene clearly and unambiguously the responsibilities for operation, maintenance and cleaning of the equipment.
• ensure that all employees who use the equipment have read and understood the manual. Furthermore the users
are to be regularly schooled in working with the equipment and the possible dangers.
• provide all personnel who work with the equipment with the designated and recommended safety equipment
Furthermore, the operator is responsible for ensuring that the device is at all times technically t for use.
1.7.4 User requirements
Any activity with equipment of this type may only be performed by persons who are able to work correctly and
reliably and satisfy the requirements of the job.
• Persons whose reaction capability is negatively inuenced by e.g. drugs, alcohol or medication may not operate
the equipment.
• Age or job related regulations valid at the operating site must always be applied.
Danger for unqualied users
Improper operation can cause person or object damage. Only persons who have the nec-
essary training, knowledge and experience may use the equipment.
Delegated persons are those who have been properly and demonstrably instructed in their tasks and the atten-
dant dangers.
Qualied persons are those who are able through training, knowledge and experience as well as knowledge of
the specic details to carry out all the required tasks, identify dangers and avoid personal and other risks.
All work on electrical equipment may only be performed by qualied electricians.
PRELIMINARY

Page 9
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
1.7.5 Alarm signals
The equipment o󰀨ers various possibilities for signalling alarm conditions, however, not for danger situations. The
signals may be optical (on the display as text), acoustic (piezo buzzer) or electronic (pin/status output of an analog
interface). All alarms will cause the device to switch o󰀨 the DC terminal.
The meaning of the signals is as follows:
Signal OT
(OverTemperature)
• Overheating of the device
• DC terminal will be switched o󰀨
• Non-critical
Signal OVP
(OverVoltage)
• Overvoltage shutdown of the DC terminal due to high voltage entering the device or
generated by the device itself due to a defect
• Critical! The device and/or the load could be damaged
Signal OCP
(OverCurrent)
• Shutdown of the DC terminal due to excess of the preset limit
• Non-critical, protects the load or source from excessive current consumption
Signal OPP
(OverPower)
• Shutdown of the DC terminal due to excess of the preset limit
• Non-critical, protects the load or source from excessive power consumption
Signal PF
(Power Fail)
• DC terminal shutdown due to AC undervoltage or defect in the AC section
• Critical on overvoltage! AC section could be damaged
1.8 Technical Data
1.8.1 Approved operating conditions
• Use only inside dry buildings
• Ambient temperature 0-50°C (32-122 °F)
• Operational altitude: max. 2000 m (1.242 mi) above sea level
• Max 80% relative humidity, not condensing
1.8.2 General technical data
Display: Colour TFT touch screen with gorilla glass, 5”, 800pt x 480pt, capacitive
Controls: 2 rotary knobs with pushbutton function, 1 pushbutton
The nominal values for the device determine the maximum adjustable ranges.
PRELIMINARY

Page 10
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
1.8.3 Specic technical data
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: an 1000 A model has min. 0.2% current accuracy, that is 2 A. When adjusting the current to 300 A, the actual current on the DC terminal is allowed to
di󰀨er max. 2 A from the set value, which means it could be between 298 A and 302 A.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20MHz
(3 The display error adds to the error of the related actual value on the DC terminal
(4 Required minimum voltage on the DC terminal for the device to be able to sink the max. current in sink mode
30 kW Model
PSB 10060-1000 PSB 10080-1000 PSB 10200-420
AC supply
Voltage range (L-L). frequency 342...528 V AC. 45 - 66 Hz
Connection 3ph. PE
Leak current < 3.5 mA
Phase current max. 56 A
E󰀩ciency of energy recovery ≤ 95% ≤ 95% ≤ 95.5%
Power factor ≈ 0.99
DC terminal
Max. voltage UMax 60 V 80 V 200 V
Max. current IMax 1000 A 1000 A 420 A
Max. power PMax 30000 W 30000 W 30000 W
Overvoltage protection range 0...66 V 0...88 V 0...220 V
Overcurrent protection range 0...1100 A 0...1100 A 0...462 A
Overpower protection range 0…33000 W 0…33000 W 0…33000 W
Temperature coe󰀩cient for set
values Δ/K Voltage / current: 100 ppm
UMIN for IMAX
(4 2.1 V 2.8 V 7 V
Capacitance (approx.) 23970 μF 23970 μF 7560 μF
Voltage regulation (general)
Adjustment range 0...61.2 V 0...81.6 V 0...204 V
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.1% UNom < 0.1% UNom < 0.1% UNom
Line regulation at ±10% ΔUAC < 0.02% UNom < 0.02% UNom < 0.02% UNom
Display: Resolution See section 1.9.6.4. Resolution of the displayed values
Display: Accuracy (3 ≤ 0.2% UNom ≤ 0.2% UNom ≤ 0.2% UNom
Remote sensing compensation Max. 5% UNom Max. 5% UNom Max. 5% UNom
Voltage regulation (power supply)
Load regulation at 0...100% ΔIOUT < 0.05% UNom < 0.05% UNom < 0.05% UNom
Rise time 10...90% ΔUOUT Max. 30 ms Max. 30 ms Max. 30 ms
Transient time after ΔIOUT < 1.5 ms < 1.5 ms < 1.5 ms
Ripple (2 < 320 mVPP
< 25 mVRMS
< 320 mVPP
< 25 mVRMS
< 300 mVPP
< 40 mVRMS
Fall time at no load after switching
DC output o󰀨 -Down from 100% to <60 V: less than 10 s
Voltage regulation (el. load)
Load regulation at 0...100% ΔU < 0.05% UNom < 0.05% UNom < 0.05% UNom
Current regulation (general)
Adjustment range 0...1020 A 0...1020 A 0...428.4 A
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.2% INom < 0.2% INom < 0.2% INom
Line regulation at ±10% ΔUAC < 0.05% INom < 0.05% INom < 0.05% INom
Display: Resolution See section 1.9.6.4. Resolution of the displayed values
Display: Accuracy (3 ≤ 0.2% INom ≤ 0.2% INom ≤ 0.2% INom
Current regulation (power supply)
Load regulation at 0...100% ΔUOUT < 0.15% INom < 0.15% INom < 0.15% INom
Current regulation (el. load)
Load regulation at 0...100% ΔUIN < 0.15% INom < 0.15% INom < 0.15% INom
Ripple (2 < 240 mARMS < 240 mARMS < 66 mARMS
PRELIMINARY

Page 11
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
30 kW Model
PSB 10060-1000 PSB 10080-1000 PSB 10200-420
Power regulation
Adjustment range 0…30600 W 0…30600 W 0…30600 W
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 1% PNom < 1% PNom < 1% PNom
Line regulation at ±10% ΔUAC < 0.05% PNom < 0.05% PNom < 0.05% PNom
Load reg. at 10-90% ΔUDC * ΔIDC < 0.75% PNom < 0.75% PNom < 0.75% PNom
Display: Resolution See section 1.9.6.4. Resolution of the displayed values
Display: Accuracy (2 ≤ 0.8% PNom ≤ 0.8% PNom ≤ 0.8% PNom
E󰀩ciency (5 ≈ 95.5% ≈ 95.5% ≈ 96%
Resistance regulation
Adjustment range 0.003...5 Ω 0.003...5 Ω 0.0165...25 Ω
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) ≤1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section 1.9.6.4. Resolution of the displayed values
Analog interface (3
Signals See 3.6.4.3. Analog interface specication
Galvanic isolation to the device Max. 800 V DC
Sample rate of inputs & outputs 500 Hz
Insulation Allowed potential shift (oating voltage) on the DC terminal:
Negative DC to PE Max. ±500 V DC ±500 V DC ±800 V DC
Positive DC to PE Max. +600 V DC +600 V DC +1000 V DC
AC input <-> PE 2.5 kV DC
AC input <-> DC terminal 2.5 kV DC
Miscellaneous
Cooling Temperature controlled fans, front inlet, rear exhaust
Ambient temperature 0...50 °C (32...133 °F)
Storage temperature -20...70 °C (-4...158 °F)
Humidity < 80%, not condensing
Standards EN 61010-1:2007-11, EN 50160:2011-02
EN 61000-6-2:2016-05, EN 61000-6-3:2011-09
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m (1.242 mi)
Digital interfaces
Featured 1x USB and 1x Ethernet for communication, 1x USB-A for data recording, Master-
slave
Slot Optional: CANopen, Probus, Pronet, RS232, CAN, EtherCAT
Galvanic isolation from device Max. 800 V DC
Terminals
Rear side Share Bus, DC terminal, AC supply, remote sensing, analog interface, USB, Ethernet
master-slave bus, interface module slot
Front side USB for sticks
Dimensions
Enclosure (W x H x D) 19“ x 4U x 670 mm (26.4”)
Total (W x H x D) 483 x 177 x 775 mm (19” x 7” x 30.5”)
Weight ≈44 kg (97 lb) ≈44 kg (97 lb) ≈44 kg (97 lb)
Article number (4 30000803 30000804 30000805
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value. With the resistance, the
accuracy rating already includes the error of the actual resistance display.
(2 The display error adds to the error of the related actual value on the DC terminal
(3 For technical specications of the analog interface see 3.6.4.3 Analog interface specication on page 59
(4 Article number of the standard version, devices with options will have a di󰀨erent number
(5 Typical value at 100% voltage and 100% power
PRELIMINARY

Page 12
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
30 kW Model
PSB 10360-240 PSB 10500-180 PSB 10750-120
AC supply
Voltage range (L-L), frequency 342...528 V AC, 45 - 66 Hz
Connection 3ph, PE
Leak current < 3.5 mA
Phase current max. 56 A
E󰀩ciency of energy recovery ≈ 0.99
Power factor ≤ 96% ≤ 96% ≤ 96%
DC terminal
Max. voltage UMax 360 V 500 V 750 V
Max. current IMax 240 A 180 A 120 A
Max. power PMax 30000 W 30000 W 30000 W
Overvoltage protection range 0...396 V 0...550 V 0...825 V
Overcurrent protection range 0...264 A 0...198 A 0...132 A
Overpower protection range 0…33000 W 0…33000 W 0…33000 W
Temperature coe󰀩cient for set
values Δ/K Voltage / current: 100 ppm
UMIN for IMAX
(4 12.6 V 17.5 V 26.3 V
Capacitance (approx.) 1170 μF 540 μF 540 μF
Voltage regulation (general)
Adjustment range 0...1020 V 0...1530 V 0...2040 V
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.1% UNom < 0.1% UNom < 0.1% UNom
Line regulation at ±10% ΔUAC < 0.02% UNom < 0.02% UNom < 0.02% UNom
Display: Resolution See section 1.9.6.4. Resolution of the displayed values
Display: Accuracy (3 ≤ 0.2% UNom ≤ 0.2% UNom ≤ 0.2% UNom
Remote sensing compensation Max. 5% UNom Max. 5% UNom Max. 5% UNom
Voltage regulation (power supply)
Load regulation at 0...100% ΔIOUT < 0.05% UNom < 0.05% UNom < 0.05% UNom
Rise time 10...90% ΔUOUT Max. 30 ms Max. 30 ms Max. 30 ms
Transient time after ΔIOUT < 1.5 ms < 1.5 ms < 1.5 ms
Ripple (2 < 320 mVPP
< 55 mVRMS
< 350 mVPP
< 70 mVRMS
< 800 mVPP
< 200 mVRMS
Fall time at no load after switching
DC output o󰀨 Down from 100% to <60 V: less than 10 s
Voltage regulation (el. load)
Load regulation at 0...100% ΔU < 0.05% UNom < 0.05% UNom < 0.05% UNom
Current regulation (general)
Adjustment range 0...81.6 A 0...61.2 A 0...40.8 A
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.2% INom < 0.2% INom < 0.2% INom
Line regulation at ±10% ΔUAC < 0.05% INom < 0.05% INom < 0.05% INom
Display: Resolution See section 1.9.6.4. Resolution of the displayed values
Display: Accuracy (3 ≤ 0.2% INom ≤ 0.2% INom ≤ 0.2% INom
Current regulation (power supply)
Load regulation at 0...100% ΔUOUT < 0.15% INom < 0.15% INom < 0.15% INom
Current regulation (el. load)
Load regulation at 0...100% ΔUIN < 0.15% INom < 0.15% INom < 0.15% INom
Ripple (2 < 50 mARMS < 48 mARMS < 48 mARMS
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: an 1000 A model has min. 0.2% current accuracy, that is 2 A. When adjusting the current to 300 A, the actual current on the DC terminal is allowed to
di󰀨er max. 2 A from the set value, which means it could be between 298 A and 302 A.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20MHz
(3 The display error adds to the error of the related actual value on the DC terminal
(4 Required minimum voltage on the DC terminal for the device to be able to sink the max. current in sink mode
PRELIMINARY

Page 13
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
30 kW Model
PSB 10360-240 PSB 10500-180 PSB 10750-120
Power regulation
Adjustment range 0…30600 W 0…30600 W 0…30600 W
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 1% PNom < 1% PNom < 1% PNom
Line regulation at ±10% ΔUAC < 0.05% PNom < 0.05% PNom < 0.05% PNom
Load reg. at 10-90% ΔUDC * ΔIDC < 0.75% PNom < 0.75% PNom < 0.75% PNom
Display: Resolution See section 1.9.6.4. Resolution of the displayed values
Display: Accuracy (2 ≤ 0.8% PNom ≤ 0.8% PNom ≤ 0.8% PNom
E󰀩ciency (5 ≈ 96% ≈ 96% ≈ 96%
Resistance regulation
Adjustment range 0.05...90 Ω 0.08...170 Ω 0.2...370 Ω
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) ≤1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section 1.9.6.4. Resolution of the displayed values
Analog interface (3
Signals See 3.6.4.3. Analog interface specication
Galvanic isolation to the device Max. 1500 V DC
Sample rate of inputs & outputs 500 Hz
Insulation Allowed potential shift (oating voltage) on the DC terminal:
Negative DC to PE Max. ±1500 V DC ±1500 V DC ±1500 V DC
Positive DC to PE Max. +2000 V DC +2000 V DC +2000 V DC
AC input <-> PE 2.5 kV DC
AC input <-> DC terminal 2.5 kV DC
Miscellaneous
Cooling Temperature controlled fans, front inlet, rear exhaust
Ambient temperature 0...50 °C (32...133 °F)
Storage temperature -20...70 °C (-4...158 °F)
Humidity < 80%, not condensing
Standards EN 61010-1:2007-11, EN 50160:2011-02
EN 61000-6-2:2016-05, EN 61000-6-3:2011-09
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m (1.242 mi)
Digital interfaces
Featured 1x USB and 1x Ethernet for communication, 1x USB-A for data recording, Master-
slave
Slot Optional: CANopen, Probus, Pronet, RS232, CAN, EtherCAT
Galvanic isolation from device Max. 1500 V DC
Terminals
Rear side Share Bus, DC terminal, AC supply, remote sensing, analog interface, USB, Ethernet
master-slave bus, interface module slot
Front side USB for sticks
Dimensions
Enclosure (W x H x D) 19“ x 4U x 670 mm (26.4”)
Total (W x H x D) 483 x 177 x 775 mm (19” x 7” x 30.5”)
Weight ≈44 kg (97 lb) ≈44 kg (97 lb) ≈44 kg (97 lb)
Article number (4 30000803 30000804 30000805
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value. With the resistance, the
accuracy rating already includes the error of the actual resistance display.
(2 The display error adds to the error of the related actual value on the DC terminal
(3 For technical specications of the analog interface see 3.6.4.3 Analog interface specication on page 59
(4 Article number of the standard version, devices with options will have a di󰀨erent number
(5 Typical value at 100% voltage and 100% power
PRELIMINARY

Page 14
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
30 kW Model
PSB 11000-80 PSB 11500-60 PSB 12000-40
AC supply
Voltage range (L-L), frequency 342...528 V AC. 45 - 66 Hz
Connection 3ph, PE
Leak current < 3.5 mA
Phase current max. 56 A
E󰀩ciency of energy recovery ≈ 0.99
Power factor ≤ 96% ≤ 96% ≤ 96%
DC terminal
Max. voltage UMax 1000 V 1500 V 2000 V
Max. current IMax 80 A 60 A 40 A
Max. power PMax 30000 W 30000 W 30000 W
Overvoltage protection range 0...1100 V 0...1650 V 0...2200 V
Overcurrent protection range 0...88 A 0...66 A 0...44 A
Overpower protection range 0…33000 W 0…33000 W 0…33000 W
Temperature coe󰀩cient for set
values Δ/K Voltage / current: 100 ppm
UMIN for IMAX
(4 35 V 52.5 V 70 V
Capacitance (approx.) 130 μF 60 μF 60 μF
Voltage regulation (general)
Adjustment range 0...1020 V 0...1530 V 0...2040 V
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.1% UNom < 0.1% UNom < 0.1% UNom
Line regulation at ±10% ΔUAC < 0.02% UNom < 0.02% UNom < 0.02% UNom
Display: Resolution See section 1.9.6.4. Resolution of the displayed values
Display: Accuracy (3 ≤ 0.2% UNom ≤ 0.2% UNom ≤ 0.2% UNom
Remote sensing compensation Max. 5% UNom Max. 5% UNom Max. 5% UNom
Voltage regulation (power supply)
Load regulation at 0...100% ΔIOUT < 0.05% UNom < 0.05% UNom < 0.05% UNom
Rise time 10...90% ΔUOUT Max. 30 ms Max. 30 ms Max. 30 ms
Transient time after ΔIOUT < 1.5 ms < 1.5 ms < 1.5 ms
Ripple (2 < 1600 mVPP
< 300 mVRMS
< 2400 mVPP
< 400 mVRMS
< 2400 mVPP
< 400 mVRMS
Fall time at no load after switching
DC output o󰀨 Down from 100% to <60 V: less than 10 s
Voltage regulation (el. load)
Load regulation at 0...100% ΔU < 0.05% UNom < 0.05% UNom < 0.05% UNom
Current regulation (general)
Adjustment range 0...81.6 A 0...61.2 A 0...40.8 A
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 0.2% INom < 0.2% INom < 0.2% INom
Line regulation at ±10% ΔUAC < 0.05% INom < 0.05% INom < 0.05% INom
Display: Resolution See section 1.9.6.4. Resolution of the displayed values
Display: Accuracy (3 ≤ 0.2% INom ≤ 0.2% INom ≤ 0.2% INom
Current regulation (power supply)
Load regulation at 0...100% ΔUOUT < 0.15% INom < 0.15% INom < 0.15% INom
Current regulation (el. load)
Load regulation at 0...100% ΔUIN < 0.15% INom < 0.15% INom < 0.15% INom
Ripple (2 < 16 mARMS < 26 mARMS < 26 mARMS
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value.
Example: an 1000 A model has min. 0.2% current accuracy, that is 2 A. When adjusting the current to 300 A, the actual current on the DC terminal is allowed to
di󰀨er max. 2 A from the set value, which means it could be between 298 A and 302 A.
(2 RMS value: LF 0...300 kHz, PP value: HF 0...20MHz
(3 The display error adds to the error of the related actual value on the DC terminal
(4 Required minimum voltage on the DC terminal for the device to be able to sink the max. current in sink mode
PRELIMINARY

Page 15
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
30 kW Model
PSB 11000-80 PSB 11500-60 PSB 12000-40
Power regulation
Adjustment range 0…30600 W 0…30600 W 0…30600 W
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) < 1% PNom < 1% PNom < 1% PNom
Line regulation at ±10% ΔUAC < 0.05% PNom < 0.05% PNom < 0.05% PNom
Load reg. at 10-90% ΔUDC * ΔIDC < 0.75% PNom < 0.75% PNom < 0.75% PNom
Display: Resolution See section 1.9.6.4. Resolution of the displayed values
Display: Accuracy (2 ≤ 0.8% PNom ≤ 0.8% PNom ≤ 0.8% PNom
E󰀩ciency (5 ≈ 96% ≈ 96% ≈ 96%
Resistance regulation
Adjustment range 0.4...650 Ω 0.8...1500 Ω 1.7...2700 Ω
Accuracy (1 (at 23 ± 5 °C / 73±9 °F) ≤1% of max. resistance ± 0.3% of maximum current
Display: Resolution See section 1.9.6.4. Resolution of the displayed values
Analog interface (3
Signals See 3.6.4.3. Analog interface specication
Galvanic isolation to the device Max. 1500 V DC
Sample rate of inputs & outputs 500 Hz
Insulation Allowed potential shift (oating voltage) on the DC terminal:
Negative DC to PE Max. ±1500 V DC ±1500 V DC ±1500 V DC
Positive DC to PE Max. +2000 V DC +2000 V DC +2000 V DC
AC input <-> PE 2.5 kV DC
AC input <-> DC terminal 2.5 kV DC
Miscellaneous
Cooling Temperature controlled fans. front inlet. rear exhaust
Ambient temperature 0...50 °C (32...133 °F)
Storage temperature -20...70 °C (-4...158 °F)
Humidity < 80%. not condensing
Standards EN 61010-1:2007-11. EN 50160:2011-02
EN 61000-6-2:2016-05. EN 61000-6-3:2011-09
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m (1.242 mi)
Digital interfaces
Featured 1x USB and 1x Ethernet for communication, 1x USB-A for data recording, Master-
slave
Slot Optional: CANopen, Probus, Pronet, RS232, CAN, EtherCAT
Galvanic isolation from device Max. 1500 V DC
Terminals
Rear side Share Bus, DC terminal, AC supply, remote sensing, analog interface, USB, Ethernet
master-slave bus, interface module slot
Front side USB for sticks
Dimensions
Enclosure (W x H x D) 19“ x 4U x 670 mm (26.4”)
Total (W x H x D) 483 x 177 x 775 mm (19” x 7” x 30.5”)
Weight ≈44 kg (97 lb) ≈44 kg (97 lb) ≈44 kg (97 lb)
Article number (4 30000806 30000807 30000808
(1 Related to the nominal values, the accuracy denes the maximum deviation between an adjusted values and the true (actual) value. With the resistance, the
accuracy rating already includes the error of the actual resistance display.
(2 The display error adds to the error of the related actual value on the DC terminal
(3 For technical specications of the analog interface see 3.6.4.3 Analog interface specication on page 59
(4 Article number of the standard version, devices with options will have a di󰀨erent number
(5 Typical value at 100% voltage and 100% power
PRELIMINARY

Page 16
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
A - Power switch B - Control panel
Figure 1 - Front view
1.8.4 Views
PRELIMINARY

Page 17
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
C - Control interfaces (digital, analog) F - Share Bus connectors J - AC plug D - Master-slave bus ports G - DC terminal (type 1 shown) E - Remote sensing connection H - AC input lter
Figure 2 - Rear view (standard version)
PRELIMINARY

Page 18
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
Figure 3 - Side view
PRELIMINARY

Page 19
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
Figure 4 - Top view
PRELIMINARY

Page 20
EA Elektro-Automatik GmbH
Helmholtzstr. 31-37 • 41747 Viersen
Germany
Fon: +49 2162 / 3785-0
Fax: +49 2162 / 16230
www.elektroautomatik.de
[email protected]
PSB 10000 4U Series
1.8.5 Control elements
Figure 5- Control Panel
Overview of the elements on the control panel
For a detailed description see section 1.9.6. The control panel (HMI).
(1)
Touchscreen display
Used for selection of set values, menus and settings, as well as display of actual values and status.
The touchscreen can be operated with the ngers or with a stylus.
(2)
Rotary knob with push button function
Left knob (turn): voltage set value adjustment
Left knob (push): shift the decimal position (cursor) of the voltage value for adjustment
Right knob (turn): current, power or resistance set value adjustment
Right knob (push): shift the decimal position (cursor) of the currently selected value for adjustment
(3)
On/O󰀨 Button for DC terminal
Used to toggle the DC terminal between on and o󰀨, also used to start a function run. The LEDs “On” and
“O󰀨” indicate the state of the DC terminal, no matter if the device is manually controlled or remotely.
(4) Port for USB sticks
For the connection of standard USB sticks. See section 1.9.6.5. USB port (front side) for more details.
PRELIMINARY
