ELEVATE HCCA-2249 User manual

Page 1Rev. 060120 1-888-651-3431
Aluminum Cargo Carrier
Instructions for Part # HCCA-2249
General Guidelines
• It is the user’s responsibility to read and follow all instructions before operation. Failure to follow the
safety rules and precautions may result in serious personal injury.
• Keep these instructions with the product at all times and review before each use.
• It is the responsibility of this product’s owner to furnish the instructions to any person that borrows
or purchases the product.
• Inspect the product before use to ensure it is assembled properly and all parts are in safe working
order and free of defects.
• Never modify this product in any way.
• All circumstances cannot be addressed in these instructions. Please use common sense and prac-
tice general safety measures when using this product.
• Parts and/or instructions are subject to change without notice.
Technical Specications
• Weight Capacity: 500 lbs. (227 kg)
• Construction: Extruded aluminum carrier. Formed steel hitch and hitch bracket. Carbon steel hard-
ware. Thermoplastic end caps.
• Vehicle Hitch Receiver Size: 2” (5cm) Vehicle hitch requires a Class III or Class IV tow rating.
Safety
Work Area
• Keep work area clean, free of clutter, and well-lit. Clutter and dark work areas can cause accidents.
• Keep children and bystanders a safe distance away while operating the cargo carrier.
• Be aware of any power lines, electrical circuits, water pipes, or other mechanical hazards in the
work area that may be unintentionally contacted and cause personal harm or property damage.
• Always be aware of your surroundings. Using the cargo carrier in a conned area may put you
dangerously close to cutting tools and rotating parts.
Personal Safety
• Stay alert and use common sense. Do not use the cargo carrier while you are tired or under the
inuence of drugs, alcohol, or medication. Inattention may result in serious personal injury.
• Dress appropriately. Do not wear loose clothing, dangling objects, or jewelry that may be caught in
moving parts. Tie back long hair. Keep clothing, hair, and gloves away from moving parts.
• All persons in the work area should use appropriate safety apparel and equipment, including safety
goggles, dust masks, non-skid shoes, gloves, hearing protection, etc. when appropriate.

Page 2Rev. 060120 1-888-651-3431
Safety
Use and Care
• Inspect before use, including all bolts and nuts. Do not use if damaged. Do not modify in any way.
• Do not exceed the 500 lb. weight capacity.
• Distribute loads evenly on the carrier, keeping the load centered.
• Secure the carrier as close to your vehicle as possible.
• Beware of dynamic loading! Dropping or bouncing a load may briey create excess load, causing
personal injury and/or product failure.
• Not recommended for use on tow-behind trailers including 5th wheel and camping trailers, motor-
homes, or RVs.
• Never exceed the maximum tongue rating of your trailer hitch and be aware that your hauling
weight may be limited by your vehicle’s suspension. Some vehicles may require air shocks or
heavier springs to sti󰀨en up the suspension and prevent sagging.
• Not recommended for hitches less than 12” from the ground to the bottom of the hitch.
• Only use the carrier with a properly installed Class III or Class IV 2” hitch receiver capable of sup-
porting the carrier and its load.
• Use the cargo carrier on at and level surfaces capable of supporting the carrier and its load. Mov-
ing a load on a slanted or uneven surface can result in loss of control.
• Prior to transporting a load, make sure all cargo is properly secured to the carrier with appropriate
tie-downs (sold separately).
• Turn o󰀨 the vehicle engine and set the parking brake before loading or unloading the carrier.
• Never ride a motorized object (power scooters, lawn tractors, ATVs, etc.) onto or o󰀨 the carrier.
Only load any motorized object empty of cargo and people.
• Warning: Never impede or block vehicle exhaust. Always keep a clear exhaust path.
• Warning: Flammable cargo can ignite from exposure to heat. Be aware of the possible re risk and
property damage resulting from the vehicle’s exhaust system pointing at or running near the cargo
in the carrier. Do not use if this condition exists.
• Follow all D.O.T. (Department of Transportation) guidelines for installation and use.
• Keep the carrier clean and dry at all times.
• Keep out of reach of children at all times.
• When not in use, store the carrier in a secure place out of the reach of children.

Page 3Rev. 060120 1-888-651-3431
Diagram & Parts List
Part Description Quantity
1 Top Carrier Frame 1
2 Small Connect Plate 10
3Middle Connect Plate 2
4Reector Plate 2
5Nut M5 4
6 Spring Washer 5 4
7Reector 2
8 Carrier Frame 1
9Bolt M5x12 40
10 Lock Nut M5 40
Part Description Quantity
11 Bolt M10x45 2
12 Nut M10 2
13 Anti-Tilt Bracket 1
14 Hitch Pin 1
15 Hitch Connect Frame 1
16 Safety Pin 1
17 Bolt M6x45 6
18 Big Washer 6 12
19 Lock Nut M6 6
20 End Cap 1

Page 4Rev. 060120 1-888-651-3431
Assembly
Set up the carrier
Your cargo carrier will require some light assembly prior to use. It is important that you read the entire
manual to become familiar with the product BEFORE you assemble and use the cargo carrier. Before
assembling and operating the cargo carrier, be sure that you have all parts described in the parts list
and assembly diagram.
1. Align the top carrier frame (1) with the carrier frame (8). Connect them with the two reector plates
(4) on the outside rear corners of the cargo carrier using bolts (9) and nuts (10). See assembly
diagram. The reective side must be facing the rear of the cargo carrier.
2. Use the small connect plate (2) to connect the top carrier frame (1) to the carrier frame (8). Attach
each end of the small connect plate (2) to the top carrier frame (1) and the carrier frame (8) using
bolts (9) and nuts (10). See assembly diagram. Repeat for each small connect plate (2).
3. Attach the middle connect plate (3) so that the top and bottom of the middle connect plate (3) is
attached to the top carrier frame (1) with three bolts (9) and three nuts (10) on each end. A middle
connect plate (3) is attached to both the front and back of the cargo carrier. See assembly diagram.
4. Place the hitch connect frame (15) underneath the carrier frame (8) and align the holes.
5. To secure the connect frame (15), insert a bolt (17) through both holes in the carrier frame (8) and
the hitch connect frame (15). Slide on washers (18), and thread on nut (19). See assembly dia-
gram.
Mounting carrier to hitch receiver
1. Remove the hitch pin (14) and the safety pin (16) from the front of the hitch connect frame (15).
2. Slide the anti-tilt bracket (13) over the end of the hitch tube. Make sure the large open end of the
anti-tilt bracket faces the hitch receiver on the vehicle and the bolts are downward.
3. With assistance, lift the empty carrier and slide the open end of the hitch tube into the hitch receiv-
er. Secure with the hitch pin (14) and safety pin (16).
4. Slide the anti-tilt bracket (13) up against the hitch receiver. Tighten the two bolts against the under-
side of the hitch receiver collar, then secure the two nuts.

Page 5Rev. 060120 1-888-651-3431
Operation
Load your cargo on the carrier. Then secure the load in place using appropriate tie-downs (sold sepa-
rately). Do not exceed the 500 lb. weight capacity. Weight inside the carrier should be evenly distribut-
ed.
WARNING: The load weight must be centered or evenly distributed across the carrier frame (8).
Always use appropriate tie-down restraints to securely attach any cargo loaded on to the cargo car-
rier before moving your vehicle any distance. Do not leave loose items on the carrier frame (8) while
operating the vehicle.
Note: Any load over 320 lbs. requires a Class III vehicle hitch receiver.
(Class II Hitch = 350 lb. maximum tongue weight, add carrier weight of about 30 lbs.)
(Class III Hitch = 500 lb. maximum tongue weight.)
Always use reectors (7). Make certain to use the appropriate red ags (not included) when moving a
load. Check with your local tra󰀩c enforcement agency to make certain that you are correctly following
all local laws.
Maintenance
Keep your cargo carrier in good repair by adopting a program of conscientious repair and mainte-
nance. If any abnormal vibrations or noise occurs, have the problem corrected before further use.
Have necessary repairs made by qualied service personnel.
• Before each use, inspect the general condition of the carrier. Check misalignment, loose or dam-
aged parts, and any other condition that may a󰀨ect its safe operation.
• Before each use, make sure any dirt, debris, oil, grease, etc. is cleaned o󰀨 the carrier. Clean the
carrier with a clean, moist cloth. Do not use solvents.
• Periodically check all hardware for tightness.

Page 6Rev. 060120 1-888-651-3431
Product Warranty and Liability
GENERAL PRODUCT WARRANTY: Products purchased from the Authorized Dealer (original place
of purchase) or Merchant (“Dealer”) will be free of defects in material and workmanship at the time of
receipt, and will meet the specications stated at the place of purchase transaction or online at the
Dealer’s website, under normal use and service when correctly installed, operated and maintained.
This product warranty is e󰀨ective for the period of time stated below, unless otherwise stated in the
product instructions or depicted in the product advertisement. All Authorized Dealer warranties are
NON-TRANSFERABLE and cover only the original end purchaser. This limited warranty does not
cover products purchased through non-authorized dealers. Non-authorized dealer receipts are not
accepted for warranty verication.
***Warranty claims must be made directly to the original place of purchase.***
WARRANTY PERIOD: This warranty remains in force for one year from the date of the product’s
accepted delivery. The Authorized Dealer o󰀨ers a one year manufacturer’s warranty for most products
unless otherwise specied on the product advertisement.
WARRANTY SERVICE: The Authorized Dealer will replace any defective or malfunctioning part at
no charge, including payment of the shipping costs of parts or replacement product to and from the
manufacturer. The purchaser is responsible for labor charges. If the product does not meet specica-
tions as depicted in the advertisement, the Authorized Dealer will refund the full purchase price of the
product.
Questions regarding the warranty on a specic product and warranty claims should be directed to the
Authorized Dealer with whom the purchase transaction was made.
WARRANTY LIMITATIONS: The above warranty does not apply to products that are repaired, modi-
ed or altered by any party other than the Authorized Dealer; are subjected to unusual physical stress
or conditions (such as overloaded ramps or corrosion), natural disaster, governmental actions, wars,
strikes, labor disputes, riots, theft, vandalism, terrorism or any reason beyond reasonable control; are
damaged due to improper installation, misuse, abuse, accident or negligence in use, storage, trans-
portation or handling, or tampering; or to products that are considered consumable items or items
requiring repair or replacement due to normal wear and tear.
Product should be inspected prior to signing for delivery. Product damage incurred during shipping,
unless noted on the Bill of Lading at the time of delivery, renders this warranty void.
LIMITED LIABILITY: In no event shall THE AUTHORIZED DEALER be liable to the purchaser or any
third party for any indirect, incidental, consequential, special, exemplary or punitive damages arising
out of the use of the product, including, without limitation, property damage, loss of value of the prod-
uct or any third party products that are used in or with the product, or loss of use of the product or any
third party products that are used in or with the product.
