Eliminator 011-1945-0 User manual

Model No. 011-1945-0
INSTRUCTION
MANUAL
SAVE THESE INSTRUCTIONS! - This manual contains
important safety and operating instructions. Read all
instructions and follow them with use of this product.
Questions? Call Customer Service Hotline: [phone]
MOBILE POWER OUTLET
120 W INVERTER

AC POWER
AC output voltage (nominal) 115 V, 60 Hz
Maximum continuous power 100 W
5 minutes AC output power 120 W
Peak power 200 W
AC output frequency 60 ± 1 Hz
AC output waveform Modified sine wave
DC POWER
USB output 5 V / 2.1 A
No load current draw (at 12 V) < 0.32 A
Efficiency (maximum) 85%
Low-voltage shutdown 10.0 – 11.0 V
High-voltage shutdown 15.0 – 16.3 V
PHYSICAL SPECIFICATIONS
Ambient operating temperature range 0 – 40 °C (32 – 104 °F)
Dimensions (L x W x H) 5 13/16 x 2 15/16 x 1 1/2" (148 x 74.1 x 38mm)
Weight 6 oz (169 g)
TECHNICAL SPECIFICATIONS .....................................................................................................2
SAFETY INFORMATION .............................................................................................................. 3
KEY PARTS DIAGRAM.................................................................................................................6
INTENDED USE...........................................................................................................................7
OPERATION ................................................................................................................................8
Determining the maximum load of connected devices .......................................................8
Wattage of commonly used devices....................................................................................9
Before you start .................................................................................................................11
Connecting the MotoMaster®Eliminator®Mobile Power Outlet ........................................12
Switching on / off ..............................................................................................................13
Using the USB port.............................................................................................................14
Automatic safety features..................................................................................................14
MAINTENANCE.........................................................................................................................15
Maintaining battery condition............................................................................................15
Fuse replacement..............................................................................................................16
TROUBLESHOOTING .................................................................................................................17
WARRANTY ..............................................................................................................................18
TABLE OF CONTENTS
1model no. 011-1945-0 | contact us : 1-877-466-8191
TECHNICAL SPECIFICATIONS
2
TECHNICAL SPECIFICATIONS

WARNING!
•HEATED SURFACE. The power outlet housing may become uncomfortably warm, and can
reach up to 60 °C (140 °F) under extended high power operation.
•Do not operate the outlet if it has been dropped or damaged in any way.
•Always disconnect the device by pulling on the plug itself, not the power cable.
•The device must be fastened so that it does not cause a safety hazard in case of collision
or hard braking.
•Route the power cable so that it does not interfere with the driver of the vehicle when
plugged into the cigarette lighter socket.
•Prevent the power supply cable from hanging over sharp edges.
•Using improper voltage may result in damage to the device and possible injury to the user.
The correct voltage is listed on the rating plate.
•Never leave the outlet unattended during operation.
CAUTION!
•Do not connect live AC power to the mobile power outlet's AC outlets. The outlet will be
damaged even if it is switched off.
•Avoid placing the mobile power outlet on or near heating vents, radiators or other sources
of heat. Do not place the outlet in direct sunlight (e.g. on the vehicle's dashboard) in order
to prevent an overheat shutdown caused by high temperatures. Do not use the outlet in
temperatures over 40 °C (104 °F).
•Do not insert foreign objects into the mobile power outlet outlets or ventilation openings.
This manual contains information that relates to PROTECTING PERSONAL SAFETY and
PREVENTING EQUIPMENT PROBLEMS. It is very important to read this manual carefully and
understand it thoroughly before using the product. The symbols listed below are used to
indicate this information.
DANGER!
Potential hazard that will result in serious injury or loss of life.
WARNING!
Potential hazard that could result in serious injury or loss of life.
CAUTION!
Potential hazard that may result in moderate injury or damage to equipment.
IMPORTANT!
Installation, operation, or maintenance information that is important but not hazard related.
SAFETY INFORMATION
3model no. 011-1945-0 | contact us : 1-877-466-8191
SAFETY INFORMATION
4

D
E
A
B
C
D
E
A
C
B
LED DISPLAY
VENTILATION OPENNINGS
USB OUTPUT: 5 V/2.1 A
AC OUTPUT: 120 V
DC Input: 12 V
CAUTION!
•DO NOT USE the mobile power outlet with the following equipment:
Small battery-operated devices such as rechargeable flashlights,
some rechargeable shavers, and night lights that are plugged
directly into an AC receptacle to recharge. The device can be
damaged if connected to the power outlet. Always recharge
batteries using a separate battery charger.
Battery chargers used in power tools. These chargers display a
WARNING LABEL stating that there are dangerous voltages at the
charger’s battery terminals.
•Disconnect the power cable whenever the engine is switched off for extended periods of
time.In some vehicles, the power does not turn off after the engine has been switched off.
If the plug is left connected, the vehicle battery might become discharged or damaged.
•Using the mobile power outlet for extended periods of time can completely discharge the
vehicle battery.
•When using a mobile power outlet continuously inside a vehicle that is not running, the
engine should be started at least once an hour for 10 –15 minutes to keep the battery
from discharging. Do not start a vehicle in a closed garage, as the carbon monoxide in the
exhaust is fatal.
•Mobile power outlets work best with a battery that is good condition and fully charged. A
weak battery will be drained easily if demands are too high. This could leave you stranded
so be sure to check the battery’s condition before using a mobile power outlet in a
stationary vehicle.
SAFETY INFORMATION
5model no. 011-1945-0 | contact us : 1-877-466-8191
KEY PARTS DIAGRAM
6

Determining the maximum load of connected devices
WARNING!
DO NOT overload your mobile power outlet! Overloading the outlet, even for a short time,
could result in serious damage to the outlet and/or to the connected device.
A few simple steps are necessary to avoid overloading the mobile power outlet:
•Identify all devices that you would like to power.
•Add up the total wattage of devices that will be powered. The wattage can be found on the
individual device’s rating plate, as well as in the instruction manual.
IMPORTANT!
In some cases, the wattage might not be listed on the devices you want to connect to the
mobile power outlet. In that case, calculate the wattage using the following equation:
VOLTS x AMPERE = WATTS
Formula: 115 Volts x XAmperes = XXXX Watts
Example: 115 Volts x 0.5 Amperes = 60 Watts
CAUTION!
Understand the difference between rated (running) wattage and surge (starting) wattage.
The RATED (RUNNING) WATTAGE is the average amount of power that a device consumes
continuously.
OPERATION
The MotoMaster®Eliminator®mobile power outlet is an electronic device that converts the
low-voltage 12 V (direct current) from a battery, such as those found in cars, motor homes,
boats or other similar power sources, to the conventional 115 V (alternating current) like you
have in your home.
Do not connect this mobile power outlet to batteries below 6 V and above 16 V as it might get
damaged.
This conversion process allows you to run standard household devices such as portable
music/mp3 players, cell phones, digital cameras, handheld video games, portable work
lights, portable DVD players battery chargers, stereo systems, laptop computers.
This mobile power outlet uses a modified sine wave that delivers power consistent and
efficient enough to run most devices adequately.
Options for connecting devices to the mobile power outlet
According to the wattage of the devices and its features, you can choose to connect the
device to the:
AC OUTLET (D) USB PORT
INTENDED USE
7model no. 011-1945-0 | contact us : 1-877-466-8191
OPERATION
8

PRODUCTS WATTS
REQUIRED
Portable music 1–5 W
Cell phone 10 W
Digital camera 15 W
Handheld gaming device 20 W
Portable work light 25 W
The SURGE (STARTING) WATTAGE is the amount of power that a device consumes at start-
up for a limited period of time (2–3 seconds). Some devices (e.g. induction motors of drills
and fans) may have a start-up surge of 3 to 7 times the rated wattage.
IMPORTANT!
The mobile power outlet can supply momentary surge power that is higher (200 W) than
its maximum power rating (100 W). Some products with a rated wattage lower than the
maximum power rating for your mobile power outlet may still exceed the mobile power
outlet's surge capability and trigger an overload shutdown.
Products rated with the following power and surge ratings or less can be connected to the
mobile power outlet.
POWER RATING MAXIMUM WATTAGE
5 min max. power rating 120 W
Continuous power rating (RATED WATTAGE) 100 W
Surge rating max. (SURGE WATTAGE) 200 W
Wattage of commonly used devices
IMPORTANT!
The wattages given below are estimates. The actual wattage required for your devices may
differ from those listed. Be sure to check the specific wattage requirements on the rating
label and in the operating instructions of devices to be used.
OPERATION
PRODUCTS WATTS
REQUIRED
Portable DVD player 30 W
Battery Charger 35 W
Stereo system 50 W
Laptop computer 75 W
13" television 100 W
NOTE: Power requirements for product examples are estimates only. To calculate the wattage
of a product, use the following equation: amperage x 115.
IMPORTANT!
Add up the total wattage of devices to be powered.
TAKE INTO CONSIDERATION THE SURGE WATTAGE REQUIRED BY ELECTRICAL MOTORS
AS WELL AS THE RATED WATTAGE.
Example:
These devices can be operated simultaneously.
DEVICE SURGE (STARTING)
WATTAGE MAX. 200 W
RATED (RUNNING)
WATTAGE MAX. 100 W
Cell Phone 10 10
Laptop 50 50
Total wattage used 60 60
OPERATION
9model no. 011-1945-0 | contact us : 1-877-466-8191
OPERATION
10

Positioning of the mobile power outlet:
Position the mobile power outlet on a flat and stable surface in a location that is:
DRY Do not expose to water, rain, moisture, snow or spray.
COOL
Operate the outlet in ambient temperatures between 0 °C and
40 °C (32 °F and 104 °F). Keep it away from heating vents and
direct sunlight. We recommend using the outlet in environments
not exceeding 25 °C (77 °F).
WELL-VENTILATED For proper cooling, allow at least 2" (5 cm) of clearance around
the outlet.
CLEAN Choose a location that is free of any debris that could get into the
outlet.
SAFE
Do not install the mobile power outlet in a compartment with
batteries or flammable liquids, such as gasoline, or explosive
vapours.
Connecting the MotoMaster®Eliminator®mobile power outlet
•Insert the lighter plug directly into the cigarette lighter socket of your vehicle. Make sure
the plug is fully inserted.
•Plug an AC product into the three-prong AC receptacle and turn it on. Ensure your product
draws 120 W or less of continuous AC power. To avoid discharging the battery, always
remove the mobile power outlet from the lighter socket when not in use.
•The mobile power outlet is now ready for use.
These devices usually CAN be connected to the MotoMaster®Eliminator®mobile power
outlet:
These devices usually CANNOT be connected to the MotoMaster®Eliminator®mobile power
outlet, as they might have a start-up surge or continuous rating that is too high.
IMPORTANT!
The device is not suitable for professional or industrial use.
Before you start
•Unpack the mobile power outlet. Inspect the unit for damage. If the unit has been damaged,
contact the retailer immediately.
The carton should contain:
•Mobile power outlet
•Owner’s manual
•Check the mobile power outlet's identification label to ensure that you have purchased the
intended model and that it has the required specifications for its intended use.
> 120 W
OPERATION
11 model no. 011-1945-0 | contact us : 1-877-466-8191
OPERATION
12

Using the USB port
Plug the USB-powered device into the inverter’s USB port (C) and operate
normally.
IMPORTANT!
This unit’s USB charging port does not support data communication. It only provides
5 V/2.1 A DC power to an external USB-powered device. Not all mobile phones are provided
with a charging cable. Data cables are not supported by this device. Please check with your
mobile phone dealer for the correct charging cable.
Automatic safety features
The MotoMaster®Eliminator®mobile power outlet includes the following automatic safety
features to ensure safe and trouble-free operation:
•Vehicle battery low-voltage automatic shutdown: activated when the battery voltage drops
to 10–11 V, to protect the battery from being damaged.
•Vehicle battery high-voltage automatic shutdown: activated when the battery voltage rises
to a dangerously high level due to a defective battery.
•Overload protection with automatic shutdown: activated when a device rated more than
120 W is plugged into the mobile power outlet.
•Overheat protection with automatic shutdown: activated in case the mobile power outlet
overheats due to improper ventilation or a high ambient temperature.
•Output short-circuit protection: activated in case of a short circuit in the connected device.
•Replaceable 8 A fuse: used for continued protection against a risk of fire or electric shock
and should be replaced manually, if necessary.
The GREEN indicator (A) will flash in cases of short-circuit or overload shutdown.
The GREEN indicator (A) will turn off in case of low-/high-voltage shutdown.
CAUTION!
Always disconnect the mobile power outlet from the cigarette lighter socket when you are
not using the device.
IMPORTANT!
The normal voltage drop that occurs when the vehicle's engine is started may trigger the
mobile power outlet's low-voltage shutdown feature. We recommend having the mobile
power outlet disconnected from the cigarette lighter plug while starting the engine.
Switching on/off
•Be sure to have your mobile power outlet properly placed and connected before attempting
to switch it on.
• Plug in the device that you want to operate by using either the AC outlet (D) or the USB
port (C).
•To switch the mobile power outlet off, disconnect it directly form the cigarette lighter
socket of your vehicle.
CAUTION!
Switch the mobile power outlet off and disconnect it from the cigarette lighter socket when it
is not in use.
IMPORTANT!
When the mobile power outlet is switched off, it draws no current from the battery. When
the outlet is switched on without any load connected to it, it draws approx. 0.32 A from the
battery. This low current draw will eventually discharge the battery.
OPERATION
13 model no. 011-1945-0 | contact us : 1-877-466-8191
OPERATION
14

Fuse replacement
WARNING!
For continued protection against risk of fire or electric shock, replace only with a fuse of the
same type and rating (12 V, 8 A).
Screw off the upper cover of the cigarette lighter plug.
Remove the faulty fuse.
Insert a new fuse and screw the cover of the plug back on.
FAULTY FUSE
NEW FUSE
WARNING!
Before cleaning, make sure the mobile power outlet is switched off and
disconnected from the power source.
•The exterior of the device should be cleaned periodically with a damp cloth or sponge and
a mild soap solution.
•Be sure vents and fans are free of dust or debris.
•Never immerse the device in water or any other liquid.
•For cleaning, never use corrosive detergents, wire brushes, abrasive scourers, or metal or
sharp objects.
•Store the device in a cool, dry, location that is protected from moisture and out of the reach
of children.
Maintaining battery condition
•Vehicle batteries are designed to provide brief periods of very high current needed for
engine starting. They are not intended for constant deep discharge.
•The battery operating time depends on:
•the charge level of the battery,
•the battery capacity,
•the amount of power drawn by the devices that are connected to the mobile power outlet.
•With an average load of about 100 W connected to the mobile power outlet, consider that
the engine should be started at least once an hour for 10–15 minutes to keep the battery
from discharging.
•If you need to start the engine to recharge the battery, first disconnect the mobile power
outlet from the battery or the cigarette lighter socket.
•Once the engine is running, the mobile power outlet can be connected to the cigarette
lighter socket again.
MAINTENANCE
MAINTENANCE
15 model no. 011-1945-0 | contact us : 1-877-466-8191
MAINTENANCE
16

PROBLEM POSSIBLE CAUSE SOLUTION
The connected
device does
not switch on.
The battery is defective. Check the battery and replace it if required.
The mobile power outlet is
damaged and needs to be
repaired.
Have the mobile power outlet repaired by an
authorized service centre.
Connection to the mobile power
outlet or cigarette lighter plug is
not tight.
Check all connections. Make sure the
connection is correct and tight.
Measured
mobile power
outlet output
is too low.
The battery voltage is too low. Recharge the battery.
No power to
inverter. Blown fuse. Replace fuse.
Buzz in the
audio system.
Inadequate internal power supply
filtering of stereo system. Use an audio system with a high-quality filter.
Television
interference. TV signals are weak.
•Adjust the orientation of the mobile power
outlet, television, antenna and cables.
•Maximize TV signal strength by using a
better antenna and use shielded antenna
cable where possible.
•Try a different TV model.
This MotoMaster®Eliminator®product carries a one (1) year warranty against defects
in workmanship and materials. At its discretion, MotoMaster Canada agrees to have any
defective part(s) repaired or replaced free of charge, within the stated warranty period, when
returned by the original purchaser with proof of purchase. This product is not guaranteed
against wear or breakage due to misuse and/or abuse.
The mobile power outlet is equipped with protective shut-down features.
The details are listed in the following table:
PROTECTION POSSIBLE CAUSE SOLUTION
Low battery
low-voltage
shutdown
Voltage drops to:
10.0–10.5 V = shutdown.
This protects the battery from
being over-discharged.
Recharge the battery.
High-
Voltage
shutdown
A defective battery charging
system can cause the battery
voltage to rise to high levels
(15.0–16.3 V).
Although the mobile power outlet
has a protection against high
voltage, it might still be damaged
if the input voltage were to
exceed 16 V.
Disconnect the connected devices. Verify that
the charging system is properly regulated
and the battery is 12V nominal.
Overload
shutdown
If you connect a device that is
rated too high or a load that draws
excessive surge power, the mobile
power outlet shuts down.
Use a product with a power rating within
the mobile power outlet's continuous power
rating range (see Operation).
Overheat
shutdown
The power inverter shuts down
automatically if it exceeds its safe
operating temperature.
•Switch the mobile power outlet off and
disconnect it from the cigarette lighter
socket.
•Disconnect all connected devices and allow
the mobile power outlet to cool for at least
15 minutes.
•Use a brush to clear any blocked ventilation
holes.
•Move the mobile power outlet to a cooler
place. Reduce the load if continuous
operation is required.
TROUBLESHOOTING
17 model no. 011-1945-0 | contact us : 1-877-466-8191
TROUBLESHOOTING
18
WARRANTY

TROUBLESHOOTING
19 model no. 011-1945-0 | contact us : 1-877-466-8191
