EliteProAV Spectrum2 Series User manual

Rev. 11/27/18 eliteproav.com 1
Electric Motorized Projection Screen
AV Spectrum2 Series
User’s Guide
Important Safety & Warning Precautions
Make sure to read this user’s guide and follow the procedure below.
Caution: The screen’s Black Top Drop is already set to its maximum drop distance. There is NO extra
Black Top Drop in the roller. Please be aware of this as it will void your warranty with EliteProAV
Screens. Unapproved changes or modifications (except for cutting the power cord for hardwire
installations) to this unit are prohibited and will void your warranty. For more information, please
contact our Technical Support Department at [phone] Ext. 604.
•Please retain this user’s guide for future reference.
•To avoid damaging the unit, do not use with any unauthorized accessories not recommended by
the manufacturer.
•Handle the unit carefully during transportation to avoid any damages.
•To ensure safe and reliable operation, direct connection to a properly grounded power source is
advised.
•The power outlet supplying power to the unit should be close to the unit and easily accessible.
•Do not install the unit on uneven or inclined surfaces.
•Do not put heavy objects on the power cord and position it properly to avoid creating a trip
obstacle.
•Never overload the power cord to prevent an electric shock or fire due to a loose contact or a
short circuit.
•There are not user serviceable parts in this unit. Do not attempt to disassemble this unit by
yourself. No one except authorized technicians can open and make repairs to this unit.
•Make sure the power source this unit is connected to has a continuous power flow.
•If there is need to use an extension cord, make sure the cord has an equal rating as the appliance
to avoid overheat.
•Do not handle the power plug when your hands are wet or your feet are in contact with water.

Rev. 11/27/18 eliteproav.com 2
Do not use this unit under the following circumstances.
•Disconnect the power cord under the conditions of heavy rain, wind, thunder or lightning.
•Avoid direct Sunshine, rain shower and moisture.
•Keep away from fire sources and high temperature to prevent this device from overheating.
•Cut off the power supply first before transportation or maintenance.
•Fully disconnect from the power supply when the unit is not in use for a long period of time, as
should be done with any other electric household appliance.
•To avoid possible injury and/or an electric shock, do not attempt to use the screen if there is
obvious damage or if there are any evident broken parts.
Installation Warning:
Due to various installation environments, the instructions provided in this user’s guide are for reference
only. Please consult a professional installation company for further installation and safety advice. The
installer must insure that proper mounting hardware is used to provide adequate strength suitable for
the installation. EliteProAV Screens is not liable for any faulty installations.
Individual modifications to this product are prohibited and will void the warranty with the manufacturer.
Please contact EliteProAV Screens Customer Service for any questions.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that the interference will not occur on a particular installation. If this
equipment causes harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures.
Reorient or relocate the receiving antenna of the device which may be casing the interference.
Increase the separation between the screen and the device’s receiver.
Connect the equipment into a different power outlet other than the device.
Pre-Installation
1. Carefully unpack the screen.
2. Always handle the screen in a leveled position on a clean surface.
3. In order to protect the screen from exposure to stains, keep the screen out of contact with foreign
particles such as dust, sawdust, and/or liquids.
Regardless of the mounting method, the screen should be securely supported so that the vibration or
pulling on the viewing surface will not cause the casing to become loose or fall. The installer must insure
that the fasteners used are of adequate strength and suitable for the installation location.
NOTE

Rev. 11/27/18 eliteproav.com 3
Hardware Parts List for the Spectrum2 Series 00
Please make sure all parts listed below are included before proceeding with the installation.
a. b. c. d. e. f.
Installation Instructions
Please consult a professional Installer. EliteProAV Screens is not liable for faulty installations.
Flush Mount to the Wall
1. Mark the location of where the screen is to be installed, drill your holes, and insert the M10
Anchors (c).
2. Install the Mounting Brackets (a) to the wall and secure with the M4x50 Screws (b).
MouMounting Bracke Mounting Bracket
Fix Plate 1
Anchor M4x50 Screw
Mounting Bracket
Fix Plate 2
Wall Mounting
Bracket
Hardware Parts List
QTY
a. Mounting Bracket
2
b. M4x50 Screw
4
c. M10 Anchor
4
d. Suspended Ceiling Bracket Connector
2
e. M5x15 Screw & Bolt
4
f. Bubble Leveler
1

Rev. 11/27/18 eliteproav.com 4
3. Attach the screen to the Mounting Bracket by inserting the top of the case to the first fix plate,
and securing the back of the case to the second Fix Plate. Make sure the case slots are securely
attached to the Mounting Bracket.
Mounting Bracket Mounting Bracket
Fix Plate 1 Fix Plate 2
Mounting Bracket Case Slot 1
Case Slot 2
Flush Mount to the Ceiling
1. Mark the location of where the screen is to be installed, drill your holes, and insert the M10
Anchors (c).
2. Install the Mounting Brackets (a) to the ceiling and secure with the M4x50 Screws (b).
Screen Case

Rev. 11/27/18 eliteproav.com 5
Ceiling M10 Anchor
3. Attach the screen to the Mounting Bracket by inserting the top of the case to the first Fix Plate,
and securing the back of the case to the second Fix Plate. Make sure the case slots are securely
attached to the Hanging Bracket.
Suspended Ceiling using Chains (additional hardware required)
1. You can also hang the screen on a ceiling by using chains (not included).
2. Connect the Suspended Ceiling Bracket Connector (d) to the Mounting Bracket (a) and secure with
the M5x15 Screws & Bolts (e).
M5x15 Bolt
(e) Suspended Ceiling Bracket Connector
(d)
Mounting Bracket
(a) M5x15 Screw
(e)
Fix Plate
1
Fix Plate
2
M4x50 Screw
Mounting Bracket
Fix Plate 1
Mounting Bracket
Fix Plate 2

Rev. 11/27/18 eliteproav.com 6
3. Insert chains (not included) through the loop holes of the Suspended Ceiling Bracket Connector (d).
Suspended Ceiling Bracket Connector
Loop Holes
Built in 3 Way Control Switch
1. The PowerMax Series comes with a 3 Way Control Switch attached to the Power Cord, which is 3.5
meters in length.
2. Use the provided Bubble Leveler (f) to ensure the screen is level before plugging in the power
cord.
3 Way Control
Up/Stop/Down
Switch
Screen removal from Mounting Brackets
1. Pull down on the Mounting Bracket Release Tab and remove the bottom of the case first, away
from the wall/ceiling, followed by the top of the case.
Release Tab
Pull Bottom of case first away from wall/ceiling.
