eliving FURNITURE Raku Series User manual

( )
760x760x320mm
Please read through instruction carefully
Before assembly and keep for future reference.
For our full catalogue of assembly instructions,
Visit: eliving.com.au/assembly.
Raku Series
Raku Sofa Ottoman-IVORY

1.
Keep children and animals
away from working area as
smaller parts may cause chok-
ing if swallowed.
2.
Never place liquids or anything
damp upon furniture as it
will mark. Ensure a coaster or
running is beneath.
Never use ammonia based
3.
cleaning products as it will
damage the finish.
4.
To avoid fading, keep furniture
out of direct sunlight.
5.
Use a soft or damp cloth(dry
cloth)when wiping or cleaning
surfaces.
6.
Two person are required.
7.
Lay a soft matt down to protect
the furniture piece before and
during assembly.
RKU-OTM

RKU-OTM-IVORY
15
10
6
RKU-OTM

Ø8*80mm
Nut
Please check you have all the fittings
part or tools are listed in below.
Quantity:6Pcs
Cam Bolt Cam Nut
Quantity:6Pc Quantity:2Pcs
Quantity:2Pcs
Half-moon part
Quantity:2Pcs
Wrench Allen Key
Quantity:1Pc Quantity:1Pc
RKU-OTM
F G
Screw

Please check you have all the panels
are listed below.
1
4
2
3
2
Seat panel
Leg
Connect panel
Seat cushion
1
2
1
1
RKU-OTM
4

STEP 1
STEP 2
C
G
F
D
C
C
2
2
2
2
3
RKU-OTM
Nut
Quantity:2Pcs
Half-moon part
Quantity:2Pcs
F G
Wrench
Quantity:1Pc
Ø8*80mm
Quantity:2Pcs
Screw

STEP 3
STEP 4
1
A
A
A
B
BB
BB
B
A
A
A
Quantity:6Pcs
Cam Bolt
Cam Nut
Quantity:6Pcs
1
RKU-OTM

STEP 5
STEP 6
RKU-OTM
4
Put the seat cushion on the ottoman body.
