Trinity TBFLWH-1402 User manual

OWNER’S MANUAL
TRINITY WOOD KITCHEN CART - WHITE
Model # TBFLWH-1402
TBFLWH-1403 (w/ tray)
Everything in its place.®
TBFLWH-1402 TBFLWH-1403

Your TRINITY Wood Kitchen Cart should include the following parts. Please inspect box
contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact
TRINITY Customer Service: 800.985.5506 or [e-mail]. Parts can also be
requested online via our “Contact Us” section at www.trinityii.com.
You may use a power screwdriver for easier assembly.
PARTS LIST
WOOD TOP FRAME (1)
A
SHELF (2)
B C
LEG SCREW (12)
Black
E
SCREWDRIVER (1)
F
IJ
CASTER LEG (2)
HANDLE (1)
G
CASTER (2)
WRENCH (1)
© 2016 TRINITY - 800.985.5506
1
D
HANDLE LEG (2)
HANDLE SCREW (2)
Silver
H
K
TRAY (1)
TBFLWH-1403 only

ASSEMBLY INSTRUCTIONS
Place HANDLE SCREW (H) through hole
in the HANDLE LEG (D) and tighten it
with SCREWDRIVER (I) to the nut in the
HANDLE (E).
Repeat for the other side.
Lay WOOD TOP FRAME (A) on a clean
surface to prevent scratching the top
surface. Take HANDLE LEG (D) and
orient it in the proper position by aligning
the hole for mounting the handle along
the long edge of the WOOD TOP FRAME
(A)
Place LEG SCREW (G) through hole in
WOOD TOP FRAME (A) and tighten it
with SCREWDRIVER (I) to the top nut in
HANDLE LEG (D).
Repeat for the other HANDLE LEG (D).
Please note that the HANDLE LEG (D) has a
FOOT PAD on the bottom.
© 2016 TRINITY - 800.985.5506 2
STEP 1
STEP 2
G (2) I (1)
A (1) D (2)
A
D
H (2) I (1)
E(1)
I
G
E
H
I

ASSEMBLY INSTRUCTIONS
Place LEG SCREW (G) through hole in
the WOOD TOP (A) or HANDLE LEG (D)
and tighten it with SCREWDRIVER (I) to
nut in CASTER LEG (C).
Repeat until all 6 LEG SCREWS (G) have
been installed.
STEP 3
STEP 4
G (4) I (1)
B(2)
G (6) I (1)
C(2)
© 2016 TRINITY - 800.985.5506
3
Lay kitchen cart on its side so it is leaning
on the side of WOOD TOP FRAME (A)
and (1) HANDLE LEG (D). Orient SHELF
(B) so the flat surface faces WOOD TOP
FRAME (A) and the raised edge of the 2
shelves are on the same side. Place LEG
SCREW (G) though the hole in the
SHELF (B) and tighten it with
SCREWDRIVER (I) to the nut in the
HANDLE LEG (D).
Repeat for the other side and for
2nd shelf.
C
G
I
B
G
I

ASSEMBLY INSTRUCTIONS
Carefully flip completed cart right side up.
TBFLWH-1403 only
Place TRAY (K) onto SHELF (B).
Flip cart over and lay WOOD TOP
FRAME (A) top surface on a clean
surface again. Screw CASTER (F) into
the nut at the bottom of CASTER LEG
(C). Tighten CASTER (F) with WRENCH
(J).
Use the provided caster wrench to
tighten completely. Failure to do as
instructed could result in the caster
stem breaking.
© 2016 TRINITY - 800.985.5506 4
STEP 5
STEP 6
F (2) J (1)
K (1)
TBFLWH-1403 only
TBFLWH-1402 TBFLWH-1403
FJ
K

SERVICE PARTS LIST
© 2016 TRINITY - 800.985.5506
5
Part Number Description Part Number Description
1) LNA-06-003-3018 Wood Top Frame 8) XXX-97-001-0002 Screwdriver
2) LWH-04-003-3400 Right Handle Leg 9) XXX-97-002-0001 Wrench
3) XBS-05-004-1600 Handle 10) ZSV-99-007-3010 Caster
4) ZSV-01-004-0643 Handle Screw 11) LWH-04-005-3025 Caster Leg
5) LWH-04-004-3400 Left Handle Leg 12) LWH-21-004-2415 Tray (TBFLWH-1403 only)
6) LWH-03-004-2816 Shelf 13) ZBK-01-004-0628 Leg Screw
7) XBK-98-002-2525 Foot Pad
TRINITY Customer Service provides the following replacement parts:
12
11
10
5
2
6
3
7
1
4
8
9
13

WARNINGS
1. Read and understand all instructions. Failure to follow all instructions may result
in injury and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot
cover all possible conditions or situations that may occur. The user must
always be aware of their environment and ensure that they use the product in a safe
and responsible manner.
3. Use the provided caster wrench to tighten completely. Failure to do as
instructed could result in the caster stem breaking thereby causing the kitchen cart
to collapse.
4. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product.
5. Check for damaged parts. Before using this product, carefully check that all parts
are in good condition, and that the product will operate properly and perform its
intended function. Check for damaged parts and any other conditions that may affect
the operation of this product. Replace damaged or worn parts, and never use this
product with a damaged part.
6. Do NOT overload the product.
CARE AND MAINTENANCE
• Avoid harsh, abrasive cleaners, and other corrosive chemicals.
• Do NOT use a scouring pad for cleaning.
• Keep dry and avoid damp environments.
• Wood top can be cleaned with damp cloth and wiped dry immediately with dry cloth.
If needed, solvent-based wood furniture cleaner can be used.
• Clean up any spills immediately to prevent stains from forming on the wood top.
• Do not let children climb or play on the cart.
Weight capacity per shelf 50 lb
Weight capacity on wood top 75 lb
Total weight capacity of kitchen cart 150 lb
Weight capacity of tray (TBFLWH-1403 only) 20 lb
© 2016 TRINITY - 800.985.5506 6

© 2016 TRINITY - 800.985.5506
7

Thank you for purchasing a TRINITY Wood Kitchen Cart. In order to register your product and
receive streamlined customer service, please fill out the following Product Registration Form
and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at
www.trinityii.com or (3) scan and email the form to customerserv[email protected]. Include a
copy of your original receipt with your submission.
