Elkay ERC8-1B/2B User manual

96602C (Rev. D)
ERC8-1B/2B, TRC8-1B/2B
NOTE: It is important to insure proper ventilation. Allow a
minimum clearance of 6 inches (152 mm) in front and 3 inches
(76mm) in the rear of the unit. If unit is to be installed in an
enclosure, allow the following clearances around unit - 1 inch
(25mm) each side, 3 inches (76mm) in the rear, 3 inches
(76mm) inches above wall.
This chiller has been designed for use with potable water and
includes an o-ring seal on the drain plug. This fitting should be
replaced if the unit is to be used with more aggressive fluids.
ERC8-1B/2B, TRC8-1B/2B
Refrigeration Packages
Installation Instructions
TEMPERATURE
ADJUSTMENT
1/4" (6 mm) O.D.
TUBE OUTLET 1/4" (6 mm) O.D.
TUBE INLET
ELECTRICAL
3/8" (9 mm) O.D.
TANK DRAIN
ELKAY MANUFACTURING COMPANY - 2222 CAMDEN COURT - OAK BROOK, IL 60523 - 630.574.8484
FOR PARTS, CONTACTYOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620

96602C (Rev. D)
ERC8-1B/2B, TRC8-1B/2B
ITEM
NO. PART NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14*
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
NS
NS
23027C
31513C
31513C
191550951550
31475C
20282C
70018C
70091C
70009C
66305C
50189C
66202C
66267C
35807C
35801C
35795C
30180C
30181C
30182C
50076C
100806740570
19037000
101516143550
66455C
23025C
70772C
23033C
23034C
23036C
23037C
23031C
23026C
23028C
ITEMIZED PARTS LIST
DESCRIPTION
*INCLUDES RELAY & OVERLOAD. IF UNDER
WARRANTY, REPLACE WITH SAME COMPRESSOR
USED IN ORIGINAL ASSEMBLY.
NOTE: All correspondence pertaining to any of the
above water cooler or orders for repair parts MUST
include model number and serial number of cooler, name
and part number of replacement part.
Cover - Electrical
Control - Cold
Control - freeze prot.
Fan Motor
Fan Blade
Fan Bracket
Fan Nut
Washer - Fan Blade
Screw - Motor Mounting
Condenser
Shroud
Drier
Heat Exchanger
Compressor serv Pak (115v)
Relay
Overload
Overload Spring
Terminal Cover
Bale Strap
Sound Dampner
Grommet
Clip - Compressor Mtg.
Stud - Compressor Mtg.
Evaporator Assy
Panel - Front
Drain Plug
Panel - Side Right Hand
Panel - Side left Hand
Air Deflector
Electrical Compartment
Bracket - Evap. Locating
Panel - Rear
Cover - Top
ITEM
NO. PART NO.
ERC8-2B, TRC8-2B - 220/240V, 50 HZ
DESCRIPTION
4
13
14*
15
16
191555551550
66476C
35809C
35802C
35796C
Fan Motor
Heat Exchanger
Compressor Serv Pak
Relay
Overload
WIRING DIAGRAM
ELKAY MANUFACTURING COMPANY - 2222 CAMDEN COURT - OAK BROOK, IL 60523 - 630.574.8484
FOR PARTS, CONTACTYOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
FREEZE PROTECT
THERMOSTAT
COLD CONTROL
THERMOSTAT
21 TO 23
20
27
15 TO 19
14
13
26
25
28
29
12
10,11
4 TO 9
24
31
30
1
2
3
INSTALLATION
1. It is important to insure proper ventilation. For remote installation
a minimum clearance of 6 inches (152 mm) to the front must be
maintained, 1 inch (25 mm) each side, 3 inches (76 mm) to the rear
above the unit. Wall grille EG-1 or EG-2 to be ysed when unit is
inserted into an enclosure. Install unit as close as possible to wall
grille a 6 inch (152 mm) clearance beyond the front of the wall
grille is required for adequate air circulation.
2. Water inlet is 1/4" (6 mm) O.D. tube. Contractor to supply
connections as required.
3. Connecting lines to be of copper, thoroughly flushed to remove all
foreign matter before being connected to cooler. If flushing does
not remove all particles, a water strainer should be installed in
supply line
4. Connect cooler to building supply line with a shut-off valve and
install a union connection between the valve and cooler
5. Electrical: Make sure power supply is identical in voltage, cycle,
and phase to that specified on cooler serial plate. Never wire
compressor directly to the power supply.
START-UP
1. Open supply line valve.
2. Purge air from all water lines by operating bubbler valve of
fountain to which cooler is connected. Steady stream assures all air
removed.
3. Rotate fan to insure proper clearance and free fan action.
4. Connect to electrical power.
TROUBLE SHOOTING & MAINTENANCE
Temperature Control: Factory set at 50°F (+/- 5°) under normal
conditions. For colder water, adjust screw on item no. 3 CW.
Ventilation: Cabinet louvers and condenser fins should be
periodically cleaned with brush, air hose or vacuum cleaner.
Excess dirt or poor ventilation can cause no cold water and
compressor cycling on the compressor overload prctector.
Lubrication: Motors are lifetime lubricated.
