Elkay EFRC8C-A Installation manual

97162C (Rev. H - 10/02)PAGE 1
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
IMPORTANT
Installation/Care/Use Manual
Fully Recessed Refrigerated
Fountain with FLEXI-GUARD®
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
To assure you install this model easily and correctly, PLEASE READ THESE SIMPLE
INSTRUCTIONS BEFORE STARTING THE INSTALLATION. CHECK YOUR INSTALLATION
FOR COMPLIANCE WITH PLUMBING, ELECTRICAL AND OTHER APPLICABLE CODES.
After installation, leave these instructions inside the fountain for future reference.
IMPORTANT! INSTALLER PLEASE NOTE.
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCH AS TELEPHONE, COMPUTERS, ETC. TOWATER
LINES IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY
FROM THE BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTOA FOUNTAIN,
CREATING AN ELECTROLYSIS WHICH CAUSES A METALLIC TASTE OR AN INCREASE IN THE METAL
CONTENT OF THE WATER. THIS CONDITION ISAVOIDABLE BY USING THE PROPER MATERIALSAS
INDICATED.ANY DRAIN FITTINGS PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO
ELECTRICALLY ISOLATE THE FOUNTAIN FROM THE BUILDING PLUMBING SYSTEM.
SEE FIG. 7
SEE FIG. 8
SEE FIG. 9
SEE FIG. 9
SEE FIG. 11
25
20, 21
19, 22
23 24
EFRC8C, EFRC12C EFRC8CDC, EFRC12CDC
Installer

97162C (Rev. H - 10/02) PAGE 2
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
FIG. 1
FINISHED FLOOR LINE
EFRC8C/EFRC12C ROUGH-IN
LEGEND:
A = RECOMMENDED WATER SUPPLY LOCATION 3/8 O.D. UNPLATED COPPER TUBE CONNECT
STUB 1-1/2 (38mm) OUT FROM WALL, SHUT OFF BY OTHERS (BOTH SIDES).
B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4 O.D. DRAIN (BOTH SIDES).
C = ELECTRICAL SUPPLY LOCATION (BOTH SIDES).
NOTES:
1. THERE ARE HOLES AND KNOCKOUTS PROVIDED ON EACH SIDE OF THE MOUNTING BOX THAT
ARE INTENDED TO BE USED TO MOUNT THE BOX. USE SIX SCREWS OR BOLTS (NOT PROVIDED).

97162C (Rev. H - 10/02)PAGE 3
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
FIG. 2
FINISHED FLOOR LINE
EFRC8CDC/EFRC12CDC ROUGH-IN
LEGEND:
A = RECOMMENDED WATER SUPPLY LOCATION 3/8 O.D. UNPLATED COPPER TUBE CONNECT
STUB 1-1/2 (38mm) OUT FROM WALL, SHUT OFF BY OTHERS (LEFT SIDE ONLY).
B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4 O.D. DRAIN (LEFT SIDE ONLY).
C = ELECTRICAL SUPPLY LOCATION (BOTH SIDES).
*WATER AND DRAIN CONNECTIONS MUST BE MADE FROM LEFT SIDE ONLY.
NOTES:
1. THERE ARE HOLES AND KNOCKOUTS PROVIDED ON EACH SIDE OF THE MOUNTING BOX THAT
ARE INTENDED TO BE USED TO MOUNT THE BOX. USE SIX SCREWS OR BOLTS (NOT PROVIDED).

97162C (Rev. H - 10/02) PAGE 4
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
INSTALLATION INSTRUCTIONS
1. Remove shipping brace from mounting box and discard.
2. Fasten mounting box into wall cutout using screws or bolts (provided by others) through the holes or knock
outs provided on each side of the mounting box. (See Fig. 1 or 2)
3. Install fountain body to mounting box using #10 x .63 (16mm) PHSM screws and large clips provided.
4. Place refrigeration package into mounting box and connect water lines. (See Page 5 for details)
5. Water inlet is 3/8" O.D. and waste tube is 1-1/4" O.D. Contractor is to supply waste trap and service stop
valve in accordance with local codes.
6. Connecting lines to be unplated copper and thoroughly flushed to remove all foreign matter before connecting
to refrigeration package. The furnished strainer (Item 18) should be added to the supply line.
7. Connect the refrigeration package to the supply line service stop valve. Connect supplied fountain (internal
plumbing) tubes as shown in figures 3, 4, 5, or 6. Remove any burrs from water tubes before inserting into
fittings. (See Figs. 13 and 14) DO NOT SOLDER TUBES INSERTED INTO THE STRAINER AS DAMAGE
TO THE O-RINGS MAY RESULT.
8. Electrical: Insure power supply is identical in voltage, hertz, and phase to that specified on the refrigeration
package serial plate. Never wire compressor directly to the power supply.
9. Turn water supply on and check thoroughly for leaks.
10. Release air from tank by depressing push button; a steady stream of water assures all air is removed.
11. Re-check for leaks.
12. Stream height is factory set at 35 PSI. If supply pressure varies greatly from this, turn adjustment screw on
regulator (Item 14). Clockwise adjustment will raise the stream height and counter-clockwise adjustment
will lower stream height. For best adjustment, stream should hit basin approximately 6-1/2" from the bubbler.
13. Rotate fan blade on refrigeration package to insure proper clearance and free fan action.
14. Connect power supply.
15. Install grill using #8 x 1.00" (25mm) PH screws and small clips provided.
TROUBLE SHOOTING AND MAINTENANCE
1. Orifice Assy: Mineral deposits on orifice can cause water flow to spurt or not regulate. Mineral deposits
may be removed from orifice with a small round file not over 1/8 diameter or a small diameter wire.
CAUTION: Do not file or cut orifice materials.
2. Actuation of Quick Connect Water Fittings: Cooler is provided with lead-free connectors which utilize
an o-ring water seal. To remove tubing from the fitting, relieve water pressure, push in on the gray collar
while pulling on the tubing (See Fig. 13). To insert tubing, push tube straight into the fitting until it reaches
a positive stop, approximatley 3/4".

97162C (Rev. H - 10/02)PAGE 5
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
FIG. 3 FIG. 4
FIG. 5 FIG. 6
17
18
16
18
17
18
17 16
18
EFRC8C EFRC8C W/GLASS FILLER
EFRC12C EFRC12C W/GLASS FILLER
44
44
44 44
17
17

97162C (Rev. H - 10/02) PAGE 6
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
10 11
12
13
15
5
1
6
9
14
4
3
8
7
2
28
30
28
34
32
33
FIG. 8FIG. 7
FIG. 9
NOTE: WHEN INSTALLING REPLACEMENT BUBBLER
AND PEDESTAL, TIGHEN NUT (ITEM 15) ONLY TO
HOLD PARTS SNUG IN POSITION. DO NOT OVER
TIGHTEN.
BASIN
BASIN

97162C (Rev. H - 10/02)PAGE 7
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
16
31
43
15
DISPENSER/
DISPOSAL
26 29
17
39
40
41
36
38
35
42
15 26 27
FIG. 12
FIG. 11
FIG. 10
37

97162C (Rev. H - 10/02) PAGE 8
EFRC8C-A EFRC8CDC-A EFRC12C-A EFRC12CDC-A LJNE8C-A LJNE12C
ELKAY MANUFACTURING COMPANY  2222 CAMDEN COURT  OAK BROOK, IL 60523
PRINTED IN U.S.A.
PARTS LIST
ITEM NO. PARTNO. DESCRIPTION
15005C
20397C
40301C
40480C
40561C
40038C
40048C
40089C
40169C
40619C
50074C
50986C
56073C
40322C
56011C
55997C
61313C
75580C
70682C
70683C
55996C
110669443890
74070030
74070032
70567C
55001084
EFRCDF
55000881
EG23
31525028
40493C
40299C
40562C
50258C
50967C
61099C
70151C
70234C
22940C
51294C
51299C
70792C
70818C
70822C
70823C
62084C
62088C
56092C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
Retaining Nut
Tailpipe - EFRC8, EFRC8F
Tailpipe - EFRC8CD
Precooler - EFRC12, EFRC12F
Precooler - EFRC12CD
Strainer
Button
Nut - Cover
Hex Nut
Ferrule
Gasket
Regulator Holder
Bubbler Assy
Orifice Assy
Housing Assy
Pedestal
Regulator
Locknut - 3/8-18
Tee - 1/4
Union - 1/4
Strainer
Screw - #10 x .63 PHSM
Screw - #8 x 1.00 PH
Speed Nut - #8
Clip - Speed
Fountain
Fountain - GF
Dispenser/Disposal
Grill
O-ring
Glass Filler
Drain - 1/2
Glass Filler
Washer
Flow Regulator Assy
Connector Assy
Washer
Hose Clamp
Bracket - Filter Mounting
Filter Head Assy
Filter Assy
Screw - #8-18 x .75 PH
Elbow - 3/8 (10mm)
Fitting - Superseal 1/4 ((8mm)
Fitting - Superseal 3/8 (10mm)
Tube Assy - GF
Tube Assy - GF
Poly Tubing 48(Cut to Length)
FIG. 13
FIG. 14
NOTE: REMOVE ANY BURRS FROM WATER TUBES
BEFORE INSERTING INTO FITTINGS.
NOTE: WATER FLOW
DIRECTION
BUILDING WATER
INLET
SERVICE STOP
(NOT FURNISHED)
1/4" O.D. TUBE
WATER INLET
TO COOLER
3/8" O.D. UNPLATED
COPPER TUBE CONNECT
COLD WATER SUPPLY
